41 |
CLIP; FUEL PIPE,FUEL TANK
BIO DIESEL FUEL B10<8NV>
(C)
ID=16
|
8-94238-568-0 |
04 |
1 |
1004- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
(B)
ID=11 & 9 L=17.5 & 17.5
|
1-09700-747-0 |
03 |
1 |
0906- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
(C)
ID=14
|
1-09704-102-0 |
04 |
1 |
0906-1003 |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
EXC. BIO DIESEL FUEL B10<8NV>
(C)
ID=14
|
1-09704-102-0 |
04 |
1 |
1004- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
(E)
L=250
|
5-09707-030-1 |
03 |
1 |
0906- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
(D)
ID=16
|
8-94238-568-0 |
02 |
1 |
0906- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
6HK1-TCC ENG(81L)
(A)
ID=13
|
8-94238-571-0 |
06 |
1 |
0906- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
6HK1-TCS ENG(80L)
(F)
ID=9 & 9 L=17 & 17
|
1-09700-651-0 |
02 |
1 |
0906- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
6HK1-TCS ENG(80L)
(A)
ID=13
|
8-94238-571-0 |
08 |
1 |
0906- |
| |
47 |
PIPE; FUEL,RETURN
(A)
L=688
|
8-98129-921-0 |
01 |
1 |
0906- |
| |
47 |
PIPE; FUEL,RETURN
6HK1-TCS ENG(80L)
(B)
|
8-98127-647-0 |
01 |
1 |
0906- |
| |
55 |
COVER; PIPE,FUEL TANK
L=150
SERVICED BY L=1300
|
1-09360-677-1 |
03 |
1 |
0906- |
| |
65 |
HOSE; FUEL,DELIVERY PIPE
BIO DIESEL FUEL B10<8NV>
L=900
SERVICED BY L=3000
|
0-01859-300-0 |
01 |
1 |
1004- |
| |
65 |
HOSE; FUEL,DELIVERY PIPE
L=900
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0906-1003 |
| |
65 |
HOSE; FUEL,DELIVERY PIPE
EXC. BIO DIESEL FUEL B10<8NV>
L=900
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
1004- |
| |
66 |
HOSE; FUEL,RETURN PIPE
6HK1-TCS ENG(80L)
L=180
SERVICED BY L=3000
|
0-01558-300-0 |
01 |
1 |
0906- |
| |
80 |
BOLT; CLIP,FUEL TANK
M8X20 FLANGE
|
0-28650-820-0 |
02 |
1 |
0906- |
| |
80 |
BOLT; CLIP,FUEL TANK
6HK1-TCS ENG(80L)
M8X20 FLANGE
|
0-28650-820-0 |
02 |
1 |
0906- |
| |
83 |
NUT; CLIP,FUEL TANK
M8 FLANGE
|
0-91180-108-0 |
03 |
1 |
0906- |
| |
83 |
NUT; CLIP,FUEL TANK
6HK1-TCS ENG(80L)
M8 FLANGE
|
0-91180-108-0 |
02 |
1 |
0906- |
| |
95 |
BUSHING; PIPE,FUEL TANK
6HK1-TCS ENG(80L)
ID=28 OD=35 T=25
|
1-09332-011-1 |
02 |
1 |
0906- |
| |
97 |
BRACKET; CLIP
(A)
L=50
|
1-47475-299-2 |
01 |
1 |
0906- |
| |
97 |
BRACKET; CLIP
(B)
|
8-98053-654-0 |
01 |
1 |
0906- |
| |
97 |
BRACKET; CLIP
(C)
|
8-98129-922-0 |
01 |
1 |
0906- |
| |
98 |
BOLT; BRKT,FUEL PIPE
6HK1-TCS ENG(80L)
M8X30 FLANGE
|
0-28650-830-0 |
02 |
1 |
0906- |
| |
103 |
NUT; BRKT
6HK1-TCS ENG(80L)
M8 FLANGE
|
0-91180-108-0 |
02 |
1 |
0906- |
| |
174 |
PIPE; FUEL,FEED,FRT
L=685
|
8-98129-920-0 |
01 |
1 |
0906- |
| |
303 |
BOLT; BRKT
M8X35 FLANGE
|
0-28650-835-0 |
02 |
1 |
0906- |
| |
304 |
NUT; BRKT
M8 FLANGE
|
0-91180-108-0 |
03 |
1 |
0906- |
| |
308 |
BRACKET; FUEL PIPE
6HK1-TCS ENG(80L)
L=75
|
1-47478-323-0 |
02 |
1 |
0906- |
| |
634 |
HOSE; RUBBER RETURN
6HK1-TCC ENG(81L)
L=900
SERVICED BY L=3000
|
0-01558-300-0 |
01 |
1 |
0906- |
| |
634 |
HOSE; RUBBER RETURN
6HK1-TCS ENG(80L)
L=730
SERVICED BY L=3000
|
0-01558-300-0 |
01 |
1 |
0906- |
