◀ 🏠 ▶ Isuzu WW ▶ TRUCKS ▶ GVR ▶ 11195 - GVR CNG(THAILAND) ▶ 7 - Interior Trim, Emblems / Labels, Seats, Mirrors ▶ 7-10 - CAUTION PLATE AND LABEL ▶
7-10 — CAUTION PLATE AND LABEL (#56572) — 11 parça
çizim 163088
119 49 291 35 306 160
BalonParca AdiParca NoAdetTipApplied Date
35 PLATE; CAUTION,CAB
THA 		8-97924-297-0 01 1 1006-
49 PLATE; CAUTION,FUSE BOX
THA 		8-97924-899-1 01 1 1006-
119 PLATE; CAUTION,HAND BRK LEVER
THA 		8-97924-257-1 01 1 1006-
160 PLATE; CAUTION,TOWING
THA 		8-97918-791-1 01 1 1006-
291 PLATE; CAUTION,TIRE AIR PRESS
THA 		8-97924-660-1 01 1 1006-
306 LABEL; BEAM & PASS 8-98070-239-0 01 1 1006-
çizim 163183
51 6 2 2
BalonParca AdiParca NoAdetTipApplied Date
2 LABEL; FUEL CAUTION
(A) THA 		8-97924-883-1 01 1 1006-
2 LABEL; FUEL CAUTION
(B) THA 		8-97924-884-1 05 1 1006-
6 PLATE; CAUTION,SPARE TIRE
THA 		8-97918-788-0 01 1 1006-
6 PLATE; CAUTION,SPARE TIRE
SPARE TIRE CARRIER LIFTING TYPE VAR1<SY8> THA 		8-97918-788-0 01 1 1006-
51 PLATE; CAUTION,WARNING
THA 		8-97924-894-1 01 1 1006-
