Isuzu WW
▶
TRUCKS
▶
GVR
▶
11195 - GVR CNG(THAILAND)
▶
2 - Clutch, Transmission, Trans Axle
▶
2-25 - SPEEDOMETER DRIVEN GEAR
▶
2-25 — SPEEDOMETER DRIVEN GEAR
(#56098) — 17 parça
78
32
19
32
18
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
18
BOLT; CLU HSG TO TRANS
M18X85 THA
1-31119-057-0
10
1
1302-
18
BOLT; CLU HSG TO TRANS
EXC. PTO ZF TRANS RR<BDM>,PTO CONTROL<SV6>
1-31119-048-0
10
1
1011-1011
18
BOLT; CLU HSG TO TRANS
1-31119-048-0
10
1
1006-1010
18
BOLT; CLU HSG TO TRANS
PTO ZF TRANS RR<BDM> PTO CONTROL<SV6>
1-31119-048-0
10
1
1011-1011
18
BOLT; CLU HSG TO TRANS
1-31119-048-0
10
1
1011-1305
19
WASHER; PL,CLU HSG TO TRANS
EXC. PTO ZF TRANS RR<BDM>,PTO CONTROL<SV6> THA
1-31119-012-0
10
1
1011-1011
19
WASHER; PL,CLU HSG TO TRANS
THA
1-31119-012-0
10
1
1006-1010
19
WASHER; PL,CLU HSG TO TRANS
PTO ZF TRANS RR<BDM> PTO CONTROL<SV6> THA
1-31119-012-0
10
1
1011-1011
19
WASHER; PL,CLU HSG TO TRANS
THA
1-31119-012-0
10
1
1011-
32
BOLT; CLU HSG TO FLYWHEEL HSG
M10X90 FLANGE
0-28151-090-0
02
1
1006-
32
BOLT; CLU HSG TO FLYWHEEL HSG
M10X75 FLANGE
8-94399-669-1
07
1
1006-
32
BOLT; CLU HSG TO FLYWHEEL HSG
M10X92 FLANGE
8-98131-010-0
02
1
1006-1211
32
BOLT; CLU HSG TO FLYWHEEL HSG
M10X92 FLANGE
8-98234-153-0
02
1
1212-
78
SENSOR; SPD
EXC. PTO ZF TRANS RR<BDM>,PTO CONTROL<SV6> THA
1-83227-018-0
01
1
1011-1011
78
SENSOR; SPD
THA
1-83227-018-0
01
1
1006-1010
78
SENSOR; SPD
PTO ZF TRANS RR<BDM> PTO CONTROL<SV6> THA
1-83227-018-0
01
1
1011-1011
78
SENSOR; SPD
THA
1-83227-018-0
01
1
1011-
