24 |
CLIP; FUEL HOSE
(B)
ID=15 H=24 L=20
|
1-09700-606-0 |
01 |
1 |
1012- |
| |
24 |
CLIP; FUEL HOSE
(C)
ID=14X29 H=15 L=20
|
1-09700-744-0 |
01 |
1 |
1012- |
| |
24 |
CLIP; FUEL HOSE
(A)
ID=14.5 & 14.5
|
1-09701-246-1 |
07 |
1 |
1012- |
| |
24 |
CLIP; FUEL HOSE
(D)
ID=16.5 & 10.5-14
|
8-98147-093-0 |
01 |
1 |
1012- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
(C)
ID=14
|
1-09704-102-0 |
02 |
1 |
1012- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
(B)
ID=11 & 9 L=17.5 & 17.5
|
1-09700-747-0 |
03 |
1 |
1012- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
(C)
ID=14
|
1-09704-102-0 |
06 |
1 |
1012- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
(E)
L=250
|
5-09707-030-1 |
01 |
1 |
1012- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
(E)
L=250
|
5-09707-030-1 |
02 |
1 |
1012- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
(D)
ID=16
|
8-94238-568-0 |
02 |
1 |
1012- |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
(A)
ID=13
|
8-94238-571-0 |
08 |
1 |
1012- |
| |
47 |
PIPE; FUEL,RETURN
L=1496
SERVICED BY L=1550
|
1-47428-851-0 |
01 |
1 |
1012- |
| |
55 |
COVER; PIPE,FUEL TANK
L=800
|
1-09361-018-0 |
01 |
1 |
1012- |
| |
62 |
BOLT; CLIP FIX
M8X20 FLANGE
|
0-28650-820-0 |
01 |
1 |
1012- |
| |
64 |
NUT; CLIP
M8 FLANGE
|
0-91180-108-0 |
01 |
1 |
1012- |
| |
65 |
HOSE; FUEL,DELIVERY PIPE
L=60
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
1012- |
| |
65 |
HOSE; FUEL,DELIVERY PIPE
L=2850
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
1012- |
| |
66 |
HOSE; FUEL,RETURN PIPE
L=60
SERVICED BY L=3000
|
0-01558-300-0 |
01 |
1 |
1012- |
| |
80 |
BOLT; CLIP,FUEL TANK
M8X50 FLANGE
|
0-28050-850-0 |
01 |
1 |
1012- |
| |
80 |
BOLT; CLIP,FUEL TANK
M8X20 FLANGE
|
0-28650-820-0 |
01 |
1 |
1012- |
| |
83 |
NUT; CLIP,FUEL TANK
M8 FLANGE
|
0-91180-108-0 |
04 |
1 |
1012- |
| |
95 |
BUSHING; PIPE,FUEL TANK
ID=28 OD=35 T=17
|
9-09956-256-2 |
01 |
1 |
1012- |
| |
97 |
BRACKET; CLIP
(B)
L=50
|
1-47475-299-2 |
01 |
1 |
1012- |
| |
97 |
BRACKET; CLIP
(C)
|
8-98078-201-0 |
01 |
1 |
1012- |
| |
97 |
BRACKET; CLIP
(A)
|
8-98083-349-0 |
01 |
1 |
1012- |
| |
97 |
BRACKET; CLIP
(D)
|
8-98083-537-0 |
01 |
1 |
1012- |
| |
97 |
BRACKET; CLIP
(F)
|
8-98100-216-1 |
01 |
1 |
1012- |
| |
97 |
BRACKET; CLIP
(E)
|
8-98109-768-0 |
01 |
1 |
1012- |
| |
98 |
BOLT; BRKT,FUEL PIPE
M10X30 FLANGE
|
0-28651-030-0 |
01 |
1 |
1012- |
| |
174 |
PIPE; FUEL,FEED,FRT
L=1322
|
8-98100-140-0 |
01 |
1 |
1012- |
| |
213 |
BOLT; FUEL PIPE FIX
M8X20 FLANGE
|
0-28650-820-0 |
01 |
1 |
1012- |
| |
217 |
COLLAR; FUEL PIPE FIX
ID=8
|
1-47459-011-0 |
01 |
1 |
1012- |
| |
303 |
BOLT; BRKT
M8X30 FLANGE
|
0-28650-830-0 |
01 |
1 |
1012- |
| |
303 |
BOLT; BRKT
M8X30 FLANGE
|
0-28650-830-0 |
01 |
1 |
1012- |
| |
303 |
BOLT; BRKT
M10X30 FLANGE
|
0-28651-030-0 |
01 |
1 |
1012- |
| |
303 |
BOLT; BRKT
M10X30 FLANGE
|
0-28651-030-0 |
01 |
1 |
1012- |
| |
303 |
BOLT; BRKT
M10X35 FLANGE
|
0-28651-035-0 |
02 |
1 |
1012- |
| |
304 |
NUT; BRKT
M8 FLANGE
|
0-91180-108-0 |
01 |
1 |
1012- |
| |
304 |
NUT; BRKT
M8 FLANGE
|
0-91180-108-0 |
01 |
1 |
1012- |
| |
304 |
NUT; BRKT
M10 FLANGE
|
0-91180-210-0 |
01 |
1 |
1012- |
| |
304 |
NUT; BRKT
M10 FLANGE
|
0-91180-210-0 |
01 |
1 |
1012- |
| |
304 |
NUT; BRKT
M10 FLANGE
|
0-91180-210-0 |
02 |
1 |
1012- |
| |
304 |
NUT; BRKT
M10 FLANGE
|
0-91180-210-0 |
02 |
1 |
1012- |
| |
308 |
BRACKET; FUEL PIPE
|
8-98117-691-0 |
01 |
1 |
1012- |
| |
309 |
CLIP; PIPE
(A)
ID=10 & 10
|
1-09709-241-0 |
01 |
1 |
1012- |
| |
309 |
CLIP; PIPE
(B)
ID=10 & 10
|
1-09709-243-0 |
01 |
1 |
1012- |
| |
350 |
PIPE; FUEL,DEL & RET
|
8-98084-131-0 |
01 |
1 |
1012- |
| |
634 |
HOSE; RUBBER RETURN
L=2400
SERVICED BY L=3000
|
0-01558-300-0 |
01 |
1 |
1012- |
