1 |
TANK ASM; OIL,P/S
|
1-21210-205-0 |
01 |
1 |
0110-0508 |
| |
1 |
TANK ASM; OIL,P/S
|
1-21210-238-1 |
01 |
1 |
0509-1006 |
| |
1 |
TANK ASM; OIL,P/S
|
8-98166-928-0 |
01 |
1 |
1007- |
| |
2 |
CAP; OIL TANK,P/S
|
1-21241-004-4 |
01 |
1 |
0110-1006 |
| |
2 |
CAP; OIL TANK,P/S
|
8-98166-876-0 |
01 |
1 |
1007- |
| |
3 |
GASKET; OIL TANK,P/S
|
1-21249-003-1 |
01 |
1 |
0110- |
| |
5 |
STRAINER; OIL TANK,P/S
|
1-21235-007-1 |
01 |
1 |
0110- |
| |
12 |
FILTER; MICROBON,OIL TANK,P/S
|
1-21235-011-0 |
01 |
1 |
0110- |
| |
15 |
PLATE; FILTER,OIL TANK
|
1-21249-007-1 |
02 |
1 |
0110-0508 |
| |
15 |
PLATE; FILTER,OIL TANK
|
1-21249-016-0 |
02 |
1 |
0509- |
| |
19 |
SEAT; OIL TANK
|
1-21249-004-0 |
02 |
1 |
0110- |
| |
25 |
BOLT; OIL TANK BRKT
M8X25 FLANGE
MAL
|
0-28680-825-0 |
02 |
1 |
0110-0512 |
| |
25 |
BOLT; OIL TANK BRKT
M8X25 FLANGE
MAL
|
0-28650-825-0 |
02 |
1 |
0601- |
| |
26 |
NUT; OIL TANK TO BRKT
M8 FLANGE
|
0-91150-108-0 |
02 |
1 |
0110-0602 |
| |
26 |
NUT; OIL TANK TO BRKT
M8 FLANGE
MAL
|
0-91180-108-0 |
02 |
1 |
0603- |
| |
31 |
HOSE; P/S OIL TANK,INL
|
1-21113-591-1 |
01 |
1 |
0110- |
| |
37 |
CLIP; HOSE,P/S
ID=26
|
1-09704-082-0 |
02 |
1 |
0110- |
| |
39 |
CLIP; FLEX HOSE
ID=40
|
8-94226-553-0 |
01 |
1 |
0110- |
| |
41 |
CLIP; HOSE,P/S
ID=32
|
1-09704-085-0 |
02 |
1 |
0110- |
| |
44 |
PIPE; OIL,P/S UNIT TO NIPPLE
L=1035
|
1-21116-108-0 |
01 |
1 |
0110- |
| |
46 |
PIPE; OIL,P/S UNIT TO OIL TANK
L=743
|
1-21115-891-0 |
01 |
1 |
0110-0210 |
| |
46 |
PIPE; OIL,P/S UNIT TO OIL TANK
L=748
|
1-21117-080-0 |
01 |
1 |
0211- |
| |
58 |
BOLT; CLIP
(A)
M8X20 FLANGE
MAL
|
0-28680-820-0 |
01 |
1 |
0110-0512 |
| |
58 |
BOLT; CLIP
(A)
M8X20 FLANGE
MAL
|
0-28650-820-0 |
01 |
1 |
0601- |
| |
58 |
BOLT; CLIP
(B)
M8X25 FLANGE
MAL
|
0-28680-825-0 |
01 |
1 |
0110-0512 |
| |
58 |
BOLT; CLIP
(B)
M8X25 FLANGE
MAL
|
0-28650-825-0 |
01 |
1 |
0601- |
| |
59 |
BRACKET; CLIP,OIL PIPE
L=60
|
1-47475-455-0 |
01 |
1 |
0110- |
| |
61 |
CLIP; OIL PIPE
(A)
ID=15 H=24 L=20
|
1-09700-606-0 |
01 |
1 |
0110- |
| |
61 |
CLIP; OIL PIPE
(B)
ID=16 & 13 L=18 & 17
|
1-09700-658-0 |
01 |
1 |
0110- |
| |
65 |
NUT; BRKT
M8 FLANGE
|
0-91150-108-0 |
02 |
1 |
0110-0602 |
| |
65 |
NUT; BRKT
M8 FLANGE
MAL
|
0-91180-108-0 |
02 |
1 |
0603- |
| |
66 |
BOLT; BRKT,OIL PIPE
M8X20 FLANGE
MAL
|
0-28680-820-0 |
01 |
1 |
0110-0512 |
| |
66 |
BOLT; BRKT,OIL PIPE
M8X20 FLANGE
MAL
|
0-28650-820-0 |
01 |
1 |
0601- |
| |
68 |
NUT; CLIP,OIL PIPE
M8 FLANGE
|
0-91150-108-0 |
01 |
1 |
0110-0602 |
| |
68 |
NUT; CLIP,OIL PIPE
M8 FLANGE
MAL
|
0-91180-108-0 |
01 |
1 |
0603- |
| |
79 |
BOLT; BRKT
M8X12 FLANGE
|
0-28080-812-0 |
02 |
1 |
0110-0512 |
| |
79 |
BOLT; BRKT
M8X12 FLANGE
|
0-28050-812-0 |
02 |
1 |
0601- |
| |
125 |
CONNECTOR; P/S PUMP
|
8-94390-584-1 |
01 |
1 |
0110- |
| |
130 |
ADAPTER; P/S PUMP
|
8-94390-583-0 |
01 |
1 |
0110- |
| |
131 |
HOSE; RUBBER,P/S
|
8-94396-331-1 |
01 |
1 |
0110- |
| |
155 |
BOLT; CONNECTOR
M8X16 FLANGE
|
0-28080-816-0 |
02 |
1 |
0110-0512 |
| |
155 |
BOLT; CONNECTOR
M8X16 FLANGE
MAL
|
0-28050-816-0 |
02 |
1 |
0601- |
| |
157 |
GASKET; P/S PUMP
ALSO INCLUDED IN GASKET SET(ENGINE).
ID=96.4
|
1-09623-178-0 |
01 |
1 |
0110- |
| |
161 |
NUT; P/S PIPE
M10 FLANGE
MAL
|
0-91150-110-0 |
01 |
1 |
0110-0602 |
| |
161 |
NUT; P/S PIPE
M10 FLANGE
MAL
|
0-91180-110-0 |
01 |
1 |
0603- |
| |
192 |
BRACKET; P/S OIL TANK
|
1-21119-129-0 |
01 |
1 |
0110- |
| |
195 |
BOLT; BRKT
M10X30 FLANGE
|
0-28681-030-0 |
02 |
1 |
0110-0512 |
| |
195 |
BOLT; BRKT
M10X30 FLANGE
|
0-28651-030-0 |
02 |
1 |
0601- |
| |
232 |
NUT; BRKT
M8 FLANGE
|
0-91150-108-0 |
02 |
1 |
0110-0602 |
| |
232 |
NUT; BRKT
M8 FLANGE
MAL
|
0-91180-108-0 |
02 |
1 |
0603- |
| |
263 |
BRACKET; P/S PIPE
|
8-97600-117-0 |
01 |
1 |
0110- |
| |
277 |
BOLT; HOSE CLIP
M8X16 FLANGE
|
0-28080-816-0 |
01 |
1 |
0110-0512 |
| |
277 |
BOLT; HOSE CLIP
M8X16 FLANGE
MAL
|
0-28050-816-0 |
01 |
1 |
0601- |
| |
280 |
HOSE; P/S OIL PUMP,INL
|
1-21116-695-0 |
01 |
1 |
0110- |
