1 |
PUMP ASM; WATER,W/GASKET
EXC. HEATER & DEFROSTER(C41),AIR CON MANUAL
CONTROL(C60)
|
1-13650-058-2 |
01 |
1 |
9905- |
● |
|
|
|
| |
1 |
PUMP ASM; WATER,W/GASKET
HEATER & DEFROSTER(C41),AIR CON MANUAL
CONTROL(C60)
|
1-13650-006-0 |
01 |
1 |
9603-9711 |
|
● |
|
|
| |
1 |
PUMP ASM; WATER,W/GASKET
HEATER & DEFROSTER(C41),AIR CON MANUAL
CONTROL(C60)
|
1-13650-057-0 |
01 |
1 |
9712-9810 |
|
● |
|
|
| |
1 |
PUMP ASM; WATER,W/GASKET
HEATER & DEFROSTER(C41),AIR CON MANUAL
CONTROL(C60)
|
1-13650-057-0 |
01 |
1 |
9811-9904 |
● |
● |
|
|
| |
1 |
PUMP ASM; WATER,W/GASKET
EXC. HEATER & DEFROSTER(C41),AIR CON MANUAL
CONTROL(C60)
|
1-13650-007-0 |
01 |
1 |
9603-9711 |
|
● |
|
|
| |
1 |
PUMP ASM; WATER,W/GASKET
EXC. HEATER & DEFROSTER(C41),AIR CON MANUAL
CONTROL(C60)
|
1-13650-058-0 |
01 |
1 |
9712-9902 |
|
● |
|
|
| |
1 |
PUMP ASM; WATER,W/GASKET
EXC. HEATER & DEFROSTER(C41),AIR CON MANUAL
CONTROL(C60)
|
1-13650-058-0 |
01 |
1 |
9903-9904 |
● |
● |
|
|
| |
1 |
PUMP ASM; WATER,W/GASKET
HEATER & DEFROSTER(C41),AIR CON MANUAL
CONTROL(C60)
|
1-13650-057-2 |
01 |
1 |
9905- |
● |
|
● |
● |
| |
3 |
GASKET; PUMP TO C/BL
ALSO INCLUDED IN GASKET SET(ENGINE).
|
1-09623-586-1 |
01 |
1 |
9603-9810 |
|
● |
|
|
| |
3 |
GASKET; PUMP TO C/BL
ALSO INCLUDED IN GASKET SET(ENGINE).
|
1-09623-586-1 |
01 |
1 |
9811-9904 |
● |
● |
|
|
| |
3 |
GASKET; PUMP TO C/BL
ALSO INCLUDED IN GASKET SET(ENGINE).
|
1-09623-586-1 |
01 |
1 |
9905- |
● |
|
● |
● |
| |
4 |
REPAIR KIT; WATER PUMP
|
1-87811-065-1 |
01 |
1 |
9603-9711 |
|
● |
|
|
| |
4 |
REPAIR KIT; WATER PUMP
|
1-87811-843-0 |
01 |
1 |
9712-9810 |
|
● |
|
|
| |
4 |
REPAIR KIT; WATER PUMP
|
1-87811-843-0 |
01 |
1 |
9811-9904 |
● |
● |
|
|
| |
4 |
REPAIR KIT; WATER PUMP
|
1-87811-843-0 |
01 |
1 |
9905- |
● |
|
● |
● |
| |
10 |
BEARING; WATER PUMP
(A)
|
1-09800-252-0 |
01 |
1 |
9603-9810 |
|
● |
|
|
| |
10 |
BEARING; WATER PUMP
(A)
|
1-09800-252-0 |
01 |
1 |
9811-9904 |
● |
● |
|
|
| |
10 |
BEARING; WATER PUMP
(B)
|
1-09800-253-0 |
01 |
1 |
9603-9810 |
|
● |
|
|
| |
10 |
BEARING; WATER PUMP
(B)
|
1-09800-253-0 |
01 |
1 |
9811-9904 |
● |
● |
|
|
| |
10 |
BEARING; WATER PUMP
(A)
|
1-09800-252-0 |
01 |
1 |
9905- |
● |
|
● |
● |
| |
10 |
BEARING; WATER PUMP
(B)
|
1-09800-253-0 |
01 |
1 |
9905- |
● |
|
● |
● |
| |
13 |
HOSE; FLEX
L=520
SERVICED BY L=10000
|
9-09914-909-0 |
01 |
1 |
9603-9810 |
|
● |
|
|
| |
13 |
HOSE; FLEX
L=520
SERVICED BY L=10000
|
9-09914-909-0 |
01 |
1 |
9811-9904 |
● |
● |
|
|
| |
13 |
HOSE; FLEX
L=520
SERVICED BY L=10000
|
9-09914-909-0 |
01 |
1 |
9905-0003 |
● |
|
● |
● |
| |
16 |
SEAL; OIL,WATER PUMP
|
1-09625-551-0 |
01 |
1 |
9603-9810 |
|
● |
|
|
| |
16 |
SEAL; OIL,WATER PUMP
|
1-09625-551-0 |
01 |
1 |
9811-9904 |
● |
● |
|
|
| |
16 |
SEAL; OIL,WATER PUMP
|
1-09625-551-0 |
01 |
1 |
9905- |
● |
|
● |
● |
| |
17 |
SEAL UNIT; WATER PUMP
|
8-94395-036-0 |
01 |
1 |
9603-9711 |
|
● |
|
|
| |
17 |
SEAL UNIT; WATER PUMP
|
8-94392-090-0 |
01 |
1 |
9712-9810 |
|
● |
|
|
| |
17 |
SEAL UNIT; WATER PUMP
|
8-94392-090-0 |
01 |
1 |
9811-9812 |
● |
● |
|
|
| |
17 |
SEAL UNIT; WATER PUMP
|
8-94392-090-0 |
01 |
1 |
9901-9904 |
● |
● |
|
|
| |
17 |
SEAL UNIT; WATER PUMP
|
8-94392-090-0 |
01 |
1 |
9905- |
● |
|
● |
● |
| |
18 |
IMPELLER; WATER PUMP
|
1-13621-049-0 |
01 |
1 |
9603-9810 |
|
● |
|
|
| |
18 |
IMPELLER; WATER PUMP
|
1-13621-049-0 |
01 |
1 |
9811-9904 |
● |
● |
|
|
| |
18 |
IMPELLER; WATER PUMP
|
1-13621-049-0 |
01 |
1 |
9905- |
● |
|
● |
● |
| |
19 |
GASKET; COVER TO BODY
|
1-09623-587-0 |
01 |
1 |
9603-9810 |
|
● |
|
|
| |
19 |
GASKET; COVER TO BODY
|
1-09623-587-0 |
01 |
1 |
9811-9904 |
● |
● |
|
|
| |
19 |
GASKET; COVER TO BODY
|
1-09623-587-0 |
01 |
1 |
9905- |
● |
|
● |
● |
| |
20 |
COVER; WATER PUMP
|
1-13612-041-0 |
01 |
1 |
9603-9810 |
|
● |
|
|
| |
20 |
COVER; WATER PUMP
|
1-13612-041-0 |
01 |
1 |
9811-9904 |
● |
● |
|
|
| |
20 |
COVER; WATER PUMP
|
1-13612-041-1 |
01 |
1 |
9905- |
● |
|
● |
● |
| |
21 |
CLIP; FLEX HOSE,W/PUMP
L=140
|
5-09707-031-0 |
01 |
1 |
9603-9810 |
|
● |
|
|
| |
21 |
CLIP; FLEX HOSE,W/PUMP
L=140
|
5-09707-031-1 |
01 |
1 |
9811-9904 |
● |
● |
|
|
| |
21 |
CLIP; FLEX HOSE,W/PUMP
L=140
|
5-09707-031-1 |
01 |
1 |
9905-0003 |
● |
|
● |
● |
| |
24 |
BOLT; WATER PUMP
(A)
M10X25 FLANGE
|
0-28181-025-0 |
02 |
1 |
9603-9810 |
|
● |
|
|
| |
24 |
BOLT; WATER PUMP
(A)
M10X25 FLANGE
|
0-28181-025-0 |
02 |
1 |
9811-9904 |
● |
● |
|
|
| |
24 |
BOLT; WATER PUMP
(A)
M10X25 FLANGE
|
0-28181-025-0 |
02 |
1 |
9905- |
● |
|
● |
● |
| |
24 |
BOLT; WATER PUMP
(B)
M10X90 FLANGE
|
0-28181-090-0 |
02 |
1 |
9603-9810 |
|
● |
|
|
| |
24 |
BOLT; WATER PUMP
(B)
M10X90 FLANGE
|
0-28181-090-0 |
02 |
1 |
9811-9904 |
● |
● |
|
|
| |
24 |
BOLT; WATER PUMP
(C)
M10X95 FLANGE
|
8-94397-027-1 |
02 |
1 |
9603-9810 |
|
● |
|
|
| |
24 |
BOLT; WATER PUMP
(C)
M10X95 FLANGE
|
8-94397-027-1 |
02 |
1 |
9811-9904 |
● |
● |
|
|
| |
24 |
BOLT; WATER PUMP
(B)
M10X90 FLANGE
|
0-28181-090-0 |
02 |
1 |
9905- |
● |
|
● |
● |
| |
24 |
BOLT; WATER PUMP
(C)
M10X95 FLANGE
|
8-94397-027-1 |
02 |
1 |
9905- |
● |
|
● |
● |
| |
29 |
SHAFT; WATER PUMP
|
1-13631-078-1 |
01 |
1 |
9603-9810 |
|
● |
|
|
| |
29 |
SHAFT; WATER PUMP
|
1-13631-078-1 |
01 |
1 |
9811-9904 |
● |
● |
|
|
| |
29 |
SHAFT; WATER PUMP
|
1-13631-078-1 |
01 |
1 |
9905- |
● |
|
● |
● |
| |
45 |
JOINT; HTR HOSE,WATER PUMP
HEATER & DEFROSTER(C41),AIR CON MANUAL
CONTROL(C60)
PT3/8 & OD=18.3 L=47
|
9-09903-631-0 |
01 |
1 |
9603-9810 |
|
● |
|
|
| |
45 |
JOINT; HTR HOSE,WATER PUMP
HEATER & DEFROSTER(C41),AIR CON MANUAL
CONTROL(C60)
PT3/8 & OD=18.3 L=47
|
9-09903-631-0 |
01 |
1 |
9811-9904 |
● |
● |
|
|
| |
45 |
JOINT; HTR HOSE,WATER PUMP
HEATER & DEFROSTER(C41),AIR CON MANUAL
CONTROL(C60)
PT3/8 & OD=18.3 L=47
|
9-09903-631-0 |
01 |
1 |
9905- |
● |
|
● |
● |
| |
58 |
PLUG; HTR
EXC. HEATER & DEFROSTER(C41),AIR CON MANUAL
CONTROL(C60)
PT3/8
|
9-99205-517-0 |
01 |
1 |
9905-0003 |
● |
|
|
|
| |
58 |
PLUG; HTR
EXC. HEATER & DEFROSTER(C41),AIR CON MANUAL
CONTROL(C60)
PT3/8
|
5-09605-005-0 |
01 |
1 |
0004- |
● |
|
|
|
| |
58 |
PLUG; HTR
EXC. HEATER & DEFROSTER(C41),AIR CON MANUAL
CONTROL(C60)
PT3/8
|
9-99205-517-0 |
01 |
1 |
9603-9902 |
|
● |
|
|
| |
58 |
PLUG; HTR
EXC. HEATER & DEFROSTER(C41),AIR CON MANUAL
CONTROL(C60)
PT3/8
|
9-99205-517-0 |
01 |
1 |
9811-9904 |
● |
● |
|
|
| |
104 |
GASKET; WATER PUMP
ALSO INCLUDED IN GASKET SET(ENGINE).
|
1-09623-494-0 |
01 |
1 |
9603-9810 |
|
● |
|
|
| |
104 |
GASKET; WATER PUMP
ALSO INCLUDED IN GASKET SET(ENGINE).
|
1-09623-494-0 |
01 |
1 |
9811-9904 |
● |
● |
|
|
| |
104 |
GASKET; WATER PUMP
ALSO INCLUDED IN GASKET SET(ENGINE).
|
1-09623-494-0 |
01 |
1 |
9905- |
● |
|
● |
● |
| |
119 |
BOLT; PUMP COVER
(A)
M8X40 FLANGE
|
0-28080-840-0 |
04 |
1 |
9603-9810 |
|
● |
|
|
| |
119 |
BOLT; PUMP COVER
(A)
M8X40 FLANGE
|
0-28080-840-0 |
04 |
1 |
9811-9904 |
● |
● |
|
|
| |
119 |
BOLT; PUMP COVER
(A)
M8X40 FLANGE
|
0-28080-840-0 |
04 |
1 |
9905- |
● |
|
● |
● |
| |
119 |
BOLT; PUMP COVER
(B)
M10X25 W/LK&PL WASHER
|
0-50151-025-0 |
01 |
1 |
9603-9810 |
|
● |
|
|
| |
119 |
BOLT; PUMP COVER
(B)
M10X25 W/LK&PL WASHER
|
0-50151-025-0 |
01 |
1 |
9811-9904 |
● |
● |
|
|
| |
119 |
BOLT; PUMP COVER
(B)
M10X25 W/LK&PL WASHER
|
0-50151-025-0 |
01 |
1 |
9905-0003 |
● |
|
● |
● |
| |
119 |
BOLT; PUMP COVER
(B)
M10X20
|
0-23801-020-0 |
01 |
1 |
0004- |
● |
|
● |
● |
| |
133 |
HOSE; RUBBER,WATER PIPE
L=270
|
0-03230-270-0 |
01 |
1 |
9603-9810 |
|
● |
|
|
| |
133 |
HOSE; RUBBER,WATER PIPE
L=270
|
0-03230-270-0 |
01 |
1 |
9811-9904 |
● |
● |
|
|
| |
133 |
HOSE; RUBBER,WATER PIPE
L=270
|
0-03230-270-0 |
01 |
1 |
9905-0103 |
● |
|
● |
● |
| |
133 |
HOSE; RUBBER,WATER PIPE
L=270
SERVICED BY L=3000
|
0-03580-300-0 |
01 |
1 |
0104- |
● |
|
● |
● |
| |
138 |
CLIP; RUBBER HOSE
ID=44
|
1-09704-077-0 |
02 |
1 |
9603-9810 |
|
● |
|
|
| |
138 |
CLIP; RUBBER HOSE
ID=44
|
1-09704-077-0 |
02 |
1 |
9811-9904 |
● |
● |
|
|
| |
138 |
CLIP; RUBBER HOSE
ID=44
|
1-09704-077-0 |
02 |
1 |
9905- |
● |
|
● |
● |
| |
139 |
GEAR; WATER PUMP,DRIVE
|
1-13641-168-0 |
01 |
1 |
9603-9810 |
|
● |
|
|
| |
139 |
GEAR; WATER PUMP,DRIVE
|
1-13641-168-0 |
01 |
1 |
9811-9904 |
● |
● |
|
|
| |
139 |
GEAR; WATER PUMP,DRIVE
|
1-13641-168-0 |
01 |
1 |
9905- |
● |
|
● |
● |
