5 |
BOLT; BRKT TO FRAME
WHEEL BASE 2400MM(24W)
M10X25 FLANGE
|
0-28051-025-0 |
04 |
1 |
1012-1406 |
● |
|
| |
5 |
BOLT; BRKT TO FRAME
WHEEL BASE 2400MM(24W)
SPARE WHEEL CARRIER<P10>
M10X25 FLANGE
|
0-28051-025-0 |
04 |
1 |
1407-1407 |
● |
|
| |
5 |
BOLT; BRKT TO FRAME
WHEEL BASE 2400MM(24W)
M10X25 FLANGE
|
0-28051-025-0 |
04 |
1 |
1408- |
● |
|
| |
9 |
NUT; BRKT TO FRAME
WHEEL BASE 2400MM(24W)
M10 FLANGE
|
0-91180-110-0 |
04 |
1 |
1012-1406 |
● |
|
| |
9 |
NUT; BRKT TO FRAME
WHEEL BASE 2400MM(24W)
SPARE WHEEL CARRIER<P10>
M10 FLANGE
|
0-91180-110-0 |
04 |
1 |
1407-1407 |
● |
|
| |
9 |
NUT; BRKT TO FRAME
WHEEL BASE 2400MM(24W)
M10 FLANGE
|
0-91180-110-0 |
04 |
1 |
1408- |
● |
|
| |
10 |
BOLT; TIRE HANGER
M8X20 FLANGE
|
0-28650-820-0 |
03 |
1 |
1012-1406 |
|
● |
| |
10 |
BOLT; TIRE HANGER
WHEEL BASE 2400MM(24W)
M8X20 FLANGE
|
0-28650-820-0 |
03 |
1 |
1012-1406 |
● |
|
| |
10 |
BOLT; TIRE HANGER
M8X20 FLANGE
|
0-28650-820-0 |
03 |
1 |
1407-1407 |
|
● |
| |
10 |
BOLT; TIRE HANGER
WHEEL BASE 2400MM(24W)
SPARE WHEEL CARRIER<P10>
M8X20 FLANGE
|
0-28650-820-0 |
03 |
1 |
1407-1407 |
● |
|
| |
10 |
BOLT; TIRE HANGER
M8X20 FLANGE
|
0-28650-820-0 |
03 |
1 |
1408- |
|
● |
| |
10 |
BOLT; TIRE HANGER
WHEEL BASE 2400MM(24W)
M8X20 FLANGE
|
0-28650-820-0 |
03 |
1 |
1408- |
● |
|
| |
10 |
BOLT; TIRE HANGER
WHEEL BASE 3300MM(33W)
M8X25 FLANGE
|
0-28650-825-0 |
04 |
1 |
1012-1406 |
● |
|
| |
10 |
BOLT; TIRE HANGER
WHEEL BASE 3300MM(33W)
SPARE WHEEL CARRIER<P10>
M8X25 FLANGE
|
0-28650-825-0 |
04 |
1 |
1407-1407 |
● |
|
| |
10 |
BOLT; TIRE HANGER
WHEEL BASE 3300MM(33W)
M8X25 FLANGE
|
0-28650-825-0 |
04 |
1 |
1408- |
● |
|
| |
18 |
NUT; MEMBER
WHEEL BASE 3300MM(33W)
M10 FLANGE
|
0-91180-110-0 |
04 |
1 |
1012- |
● |
|
| |
19 |
BOLT; C/MBR
WHEEL BASE 3300MM(33W)
M10X30 FLANGE
|
0-28651-030-0 |
04 |
1 |
1012- |
● |
|
| |
21 |
BRACKET; SPARE TIRE HANGER
WHEEL BASE 2400MM(24W)
REAR WIDE TREAD(V4T)
|
8-98036-085-2 |
01 |
1 |
1012-1406 |
● |
|
| |
21 |
BRACKET; SPARE TIRE HANGER
WHEEL BASE 2400MM(24W)
SPARE WHEEL CARRIER<P10>
REAR WIDE TREAD(V4T)
EXC. FRAME-KICK UP<7EW>
|
8-98036-085-2 |
01 |
1 |
1407-1407 |
● |
|
| |
21 |
BRACKET; SPARE TIRE HANGER
WHEEL BASE 2400MM(24W)
REAR WIDE TREAD(V4T)
|
8-98036-085-2 |
01 |
1 |
1408- |
● |
|
| |
27 |
CUSHION; FRAME TO SPARE TIRE
SPARE TIRE CARRIER INSIDE MOUNTED<P15>
125X50X10
|
8-94341-284-0 |
03 |
1 |
1407-1407 |
● |
|
| |
34 |
BOLT; SPARE TIRE
SPARE TIRE CARRIER INSIDE MOUNTED<P15>
M12X330
|
8-98226-501-0 |
01 |
1 |
1407-1407 |
● |
|
| |
35 |
WASHER; PL,SPARE TIRE
SPARE TIRE CARRIER INSIDE MOUNTED<P15>
ID=12.5 OD=54
|
8-94466-483-0 |
01 |
1 |
1407-1407 |
● |
|
| |
36 |
NUT; SPARE TIRE
SPARE TIRE CARRIER INSIDE MOUNTED<P15>
M12
|
0-91110-512-0 |
01 |
1 |
1407-1407 |
● |
|
| |
38 |
BOLT; STOPPER
EXC. FRT INDEPENDENT SUSPENSION(FF0)
M8X20 FLANGE
|
0-28650-820-0 |
04 |
1 |
1012-1307 |
|
● |
| |
120 |
PLATE; SPARE TIRE
SPARE TIRE CARRIER INSIDE MOUNTED<P15>
FRAME-KICK UP<7EW>
|
1-51377-166-0 |
01 |
1 |
1407-1407 |
● |
|
| |
131 |
CROSSMEMBER; SPARE TIRE
WHEEL BASE 3300MM(33W)
|
8-98035-825-3 |
02 |
1 |
1012- |
● |
|
| |
139 |
STOPPER; SPARE TIRE
EXC. FRT INDEPENDENT SUSPENSION(FF0)
|
8-98107-563-2 |
01 |
1 |
1012-1307 |
|
● |
| |
167 |
HANGER; TIRE
(C)
|
8-94380-175-1 |
01 |
1 |
1012- |
|
● |
| |
167 |
HANGER; TIRE
WHEEL BASE 2400MM(24W)
(A)
|
8-94382-875-1 |
01 |
1 |
1012-1406 |
● |
|
| |
167 |
HANGER; TIRE
WHEEL BASE 2400MM(24W)
SPARE WHEEL CARRIER<P10>
(A)
|
8-94382-875-1 |
01 |
1 |
1407-1407 |
● |
|
| |
167 |
HANGER; TIRE
WHEEL BASE 2400MM(24W)
(A)
|
8-94382-875-1 |
01 |
1 |
1408- |
● |
|
| |
167 |
HANGER; TIRE
WHEEL BASE 3300MM(33W)
(B)
|
8-98036-384-0 |
01 |
1 |
1012-1406 |
● |
|
| |
167 |
HANGER; TIRE
WHEEL BASE 3300MM(33W)
SPARE WHEEL CARRIER<P10>
(B)
|
8-98036-384-0 |
01 |
1 |
1407-1407 |
● |
|
| |
167 |
HANGER; TIRE
WHEEL BASE 3300MM(33W)
(B)
|
8-98036-384-0 |
01 |
1 |
1408- |
● |
|
