◀ 🏠 ▶ Isuzu WW ▶ TRUCKS ▶ NPR ▶ 51296 - NPR/NQR-RHD ▶ 0 - Engine, Emission, Engine Electrical ▶ 0-01 - PARTIAL ENGINE ▶
0-01 — PARTIAL ENGINE (#54477) — 24 parça
çizim 175812
1
BalonParca AdiParca NoAdetTipApplied Date A B C D
1 00.033 ENGINE ASM; PARTIAL 5-87311-087-3 01 1 1012-1112 ●
1 00.033 ENGINE ASM; PARTIAL 5-87311-155-2 01 1 1201- ●
1 00.033 ENGINE ASM; PARTIAL 5-87311-086-3 01 1 1012-1112 ●
1 00.033 ENGINE ASM; PARTIAL 5-87311-157-2 01 1 1201- ●
1 00.033 ENGINE ASM; PARTIAL 5-87311-093-6 01 1 1012-1312 ●
1 00.033 ENGINE ASM; PARTIAL 5-87311-235-2 01 1 1401- ●
1 00.033 ENGINE ASM; PARTIAL 5-87311-111-5 01 1 1012-1409 ●
1 00.033 ENGINE ASM; PARTIAL 5-87311-260-0 01 1 1410- ●
çizim 175815
1
BalonParca AdiParca NoAdetTipApplied Date A B C D
1 00.033 ENGINE ASM; PARTIAL 5-87311-087-3 01 1 1012-1112 ●
1 00.033 ENGINE ASM; PARTIAL 5-87311-155-2 01 1 1201- ●
1 00.033 ENGINE ASM; PARTIAL 5-87311-086-3 01 1 1012-1112 ●
1 00.033 ENGINE ASM; PARTIAL 5-87311-157-2 01 1 1201- ●
1 00.033 ENGINE ASM; PARTIAL 5-87311-093-6 01 1 1012-1312 ●
1 00.033 ENGINE ASM; PARTIAL 5-87311-235-2 01 1 1401- ●
1 00.033 ENGINE ASM; PARTIAL 5-87311-111-5 01 1 1012-1409 ●
1 00.033 ENGINE ASM; PARTIAL 5-87311-260-0 01 1 1410- ●
çizim 175817
1
BalonParca AdiParca NoAdetTipApplied Date A B C D
1 00.033 ENGINE ASM; PARTIAL 5-87311-087-3 01 1 1012-1112 ●
1 00.033 ENGINE ASM; PARTIAL 5-87311-155-2 01 1 1201- ●
1 00.033 ENGINE ASM; PARTIAL 5-87311-086-3 01 1 1012-1112 ●
1 00.033 ENGINE ASM; PARTIAL 5-87311-157-2 01 1 1201- ●
1 00.033 ENGINE ASM; PARTIAL 5-87311-093-6 01 1 1012-1312 ●
1 00.033 ENGINE ASM; PARTIAL 5-87311-235-2 01 1 1401- ●
1 00.033 ENGINE ASM; PARTIAL 5-87311-111-5 01 1 1012-1409 ●
1 00.033 ENGINE ASM; PARTIAL 5-87311-260-0 01 1 1410- ●
İpucu: çizimdeki balona veya tablodaki Balon sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
