1 |
04.128 HOSE; ATF
4JJ1-TCS ENG(LFB)
TRANSMISSION CONTROL-SMOOTHER(8GF)
(A)
|
8-98086-371-1 |
01 |
1 |
0710-1011 |
| |
1 |
04.128 HOSE; ATF
4JJ1-TCS ENG(LFB)
TRANSMISSION CONTROL-SMOOTHER(8GF)
(A)
|
8-98172-352-0 |
01 |
1 |
1012- |
| |
1 |
04.128 HOSE; ATF
4JJ1-TCS ENG(LFB)
TRANSMISSION CONTROL-SMOOTHER(8GF)
(C)
|
8-98086-373-0 |
01 |
1 |
0710-0801 |
| |
1 |
04.128 HOSE; ATF
4JJ1-TCS ENG(LFB)
TRANSMISSION CONTROL-SMOOTHER(8GF)
(C)
|
8-98084-161-0 |
01 |
1 |
0802- |
| |
1 |
04.128 HOSE; ATF
4JJ1-TCS ENG(LFB)
TRANSMISSION CONTROL-SMOOTHER(8GF)
(B)
|
8-98086-380-0 |
02 |
1 |
0710- |
| |
3 |
04.128 PIPE; OIL,A/T TO OIL COOLER
4JJ1-TCS ENG(LFB)
TRANSMISSION CONTROL-SMOOTHER(8GF)
|
8-98006-093-1 |
01 |
1 |
0710- |
| |
11 |
04.128 CLIP; PIPE
4JJ1-TCS ENG(LFB)
TRANSMISSION CONTROL-SMOOTHER(8GF)
06.672
(A)
ID=10X2 H=22
|
8-94252-455-2 |
01 |
1 |
0710- |
| |
11 |
04.128 CLIP; PIPE
4JJ1-TCS ENG(LFB)
TRANSMISSION CONTROL-SMOOTHER(8GF)
01.097
(B)
ID=16
|
8-97329-628-0 |
12 |
1 |
0710- |
| |
13 |
04.128 BOLT; BRKT
4JJ1-TCS ENG(LFB)
TRANSMISSION CONTROL-SMOOTHER(8GF)
M6X25 W/LK WASHER
|
0-50540-625-0 |
02 |
1 |
0710- |
| |
14 |
04.128 CLIP; PIPE TO ENG SIDE
TRANSMISSION CONTROL-SMOOTHER(8GF)
00.854
(B)
ID=11 & 11 L=17.5 & 17.5
|
1-09700-739-0 |
02 |
1 |
0710- |
| |
14 |
04.128 CLIP; PIPE TO ENG SIDE
4JJ1-TCS ENG(LFB)
TRANSMISSION CONTROL-SMOOTHER(8GF)
04.930
(A)
ID=10X2 H=37.5
|
8-97018-546-0 |
01 |
1 |
0710-0801 |
| |
14 |
04.128 CLIP; PIPE TO ENG SIDE
4JJ1-TCS ENG(LFB)
TRANSMISSION CONTROL-SMOOTHER(8GF)
(A)
ID=10 OR 12X2 & 4.76
|
8-98058-323-0 |
01 |
1 |
0802- |
| |
15 |
04.128 BRACKET; ATF PIPE
4JJ1-TCS ENG(LFB)
TRANSMISSION CONTROL-SMOOTHER(8GF)
(A)
|
8-98035-763-0 |
01 |
1 |
0710- |
| |
15 |
04.128 BRACKET; ATF PIPE
4JJ1-TCS ENG(LFB)
TRANSMISSION CONTROL-SMOOTHER(8GF)
(B)
|
8-98035-764-0 |
02 |
1 |
0710- |
| |
16 |
04.128 BOLT; CLIP,ENG SIDE
TRANSMISSION CONTROL-SMOOTHER(8GF)
01.531
M8X20 FLANGE
|
0-28650-820-0 |
02 |
1 |
0710- |
| |
60 |
04.128 BOLT; EYE,ATF PIPE
TRANSMISSION CONTROL-SMOOTHER(8GF)
01.855
(B)
M14X30 EYE-BOLT
|
1-09675-146-0 |
01 |
1 |
0710-0805 |
| |
60 |
04.128 BOLT; EYE,ATF PIPE
TRANSMISSION CONTROL-SMOOTHER(8GF)
(B)
M14X30 EYE-BOLT
|
8-98037-827-0 |
01 |
1 |
0806- |
| |
60 |
04.128 BOLT; EYE,ATF PIPE
TRANSMISSION CONTROL-SMOOTHER(8GF)
(A)
M14X35.5 EYE-BOLT
|
8-98060-382-0 |
01 |
1 |
0710- |
| |
88 |
04.128 GASKET; EYE BOLT
TRANSMISSION CONTROL-SMOOTHER(8GF)
08.955
ID=14.2 OD=20.0
|
9-09571-414-0 |
04 |
1 |
0710- |
| |
92 |
04.128 NUT; CLIP
4JJ1-TCS ENG(LFB)
TRANSMISSION CONTROL-SMOOTHER(8GF)
03.162
M10 FLANGE
|
0-91180-110-0 |
01 |
1 |
0710- |
| |
95 |
04.128 BRACKET; CLIP
TRANSMISSION CONTROL-SMOOTHER(8GF)
(C)
|
8-97349-876-0 |
01 |
1 |
0710- |
| |
95 |
04.128 BRACKET; CLIP
4JJ1-TCS ENG(LFB)
TRANSMISSION CONTROL-SMOOTHER(8GF)
(A)
|
8-97389-858-2 |
01 |
1 |
0710- |
| |
95 |
04.128 BRACKET; CLIP
4JJ1-TCS ENG(LFB)
TRANSMISSION CONTROL-SMOOTHER(8GF)
(B)
|
8-98035-762-0 |
01 |
1 |
0710- |
| |
106 |
04.128 PIPE ASM; OIL,COOLER TO UNION
TRANSMISSION CONTROL-SMOOTHER(8GF)
(A)
|
8-98017-110-0 |
01 |
1 |
0710- |
| |
106 |
04.128 PIPE ASM; OIL,COOLER TO UNION
TRANSMISSION CONTROL-SMOOTHER(8GF)
(B)
|
8-98035-638-0 |
01 |
1 |
0710- |
| |
106 |
04.128 PIPE ASM; OIL,COOLER TO UNION
4JJ1-TCS ENG(LFB)
TRANSMISSION CONTROL-SMOOTHER(8GF)
(C)
|
8-97389-649-2 |
01 |
1 |
0710-0801 |
| |
106 |
04.128 PIPE ASM; OIL,COOLER TO UNION
4JJ1-TCS ENG(LFB)
TRANSMISSION CONTROL-SMOOTHER(8GF)
(C)
|
8-98084-140-0 |
01 |
1 |
0802- |
| |
106 |
04.128 PIPE ASM; OIL,COOLER TO UNION
4JJ1-TCS ENG(LFB)
TRANSMISSION CONTROL-SMOOTHER(8GF)
(D)
|
8-97389-650-2 |
01 |
1 |
0710-0801 |
| |
106 |
04.128 PIPE ASM; OIL,COOLER TO UNION
4JJ1-TCS ENG(LFB)
TRANSMISSION CONTROL-SMOOTHER(8GF)
(D)
|
8-98084-141-0 |
01 |
1 |
0802- |
| |
236 |
04.128 PIPE; OIL,OIL COOLER TO A/T
4JJ1-TCS ENG(LFB)
TRANSMISSION CONTROL-SMOOTHER(8GF)
|
8-98006-094-1 |
01 |
1 |
0710-0803 |
| |
236 |
04.128 PIPE; OIL,OIL COOLER TO A/T
4JJ1-TCS ENG(LFB)
FRT INDEPENDENT SUSPENSION(FF0)
TRANSMISSION CONTROL-SMOOTHER(8GF)
|
8-98006-094-1 |
01 |
1 |
0804- |
| |
236 |
04.128 PIPE; OIL,OIL COOLER TO A/T
4JJ1-TCS ENG(LFB)
TRANSMISSION CONTROL-SMOOTHER(8GF)
EXC. FRT INDEPENDENT SUSPENSION(FF0)
|
8-98041-745-0 |
01 |
1 |
0804- |
| |
248 |
04.128 BOLT; RETAINER
TRANSMISSION CONTROL-SMOOTHER(8GF)
01.531
(B)
M8X20 FLANGE
|
0-28650-820-0 |
01 |
1 |
0710- |
| |
248 |
04.128 BOLT; RETAINER
4JJ1-TCS ENG(LFB)
TRANSMISSION CONTROL-SMOOTHER(8GF)
06.216
(A)
M8X25 FLANGE
|
0-28650-825-0 |
02 |
1 |
0710- |
