3-25 — BRAKE LOCK CONTROL (#5372) — 46 parça

32 32 32 32 32 1 26 30

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
1	BOX; CONT,BRK LOCK 10PE1S(60L) POWER BRAKE LOCK SYSTEM(J50)	1-82550-307-0	01	1	9603-9704	●
1	BOX; CONT,BRK LOCK 10PE1S(60L) POWER BRAKE LOCK SYSTEM(J50)	1-82550-311-0	01	1	9705-9901	●
1	BOX; CONT,BRK LOCK 10PE1S(60L) POWER BRAKE LOCK SYSTEM(J50)	1-82550-311-0	01	1	9905-0001	●
1	BOX; CONT,BRK LOCK POWER BRAKE LOCK SYSTEM(J50)	1-82550-311-0	01	1	0002-	●	●
26	UNION; CONT VLV BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06) EXC. AIR DRYER<PS7> ELBOW M22	1-09650-277-0	01	1	9603-9609	●	●
26	UNION; CONT VLV BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06) EXC. AIR DRYER<PS7>,SAKHALIN EQUIPMENT(TLE) M22	1-09650-277-0	01	1	9907-	●	●
30	NUT POWER BRAKE LOCK SYSTEM(J50) M6 FLANGE	0-91150-106-0	02	1	9603-9901	●
30	NUT 10PE1S(60L) POWER BRAKE LOCK SYSTEM(J50) M6 FLANGE	0-91150-106-0	02	1	9905-0001	●
30	NUT POWER BRAKE LOCK SYSTEM(J50) M6 FLANGE	0-91150-106-0	02	1	0002-	●	●
32	UNION; DOUBLE CHECK VLV BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06) CHINA-SOUTHERN ECONOMIC ZONE EQUIPMENT(TAB), CHINAEQUIPMENT(YT2) (A) ELBOW R3/8(DIN-12)	1-09660-653-1	04	1	9603-9705	●	●
32	UNION; DOUBLE CHECK VLV BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06) CHINA-SOUTHERN ECONOMIC ZONE EQUIPMENT(TAB), CHINAEQUIPMENT(YT2)	1-09660-653-1	04	1	9706-9901	●	●
32	UNION; DOUBLE CHECK VLV BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06) FRIGID ZONE KIT<YL3> (A) ELBOW R3/8(DIN-12)	1-09660-653-1	04	1	9706-9901	●
32	UNION; DOUBLE CHECK VLV BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06) CHINA-SOUTHERN ECONOMIC ZONE EQUIPMENT(TAB), CHINAEQUIPMENT(YT2) (B) DIN12 & R1/2 ELBOW	1-09660-654-1	01	1	9603-9705	●	●
32	UNION; DOUBLE CHECK VLV BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06) CHINA-SOUTHERN ECONOMIC ZONE EQUIPMENT(TAB), CHINAEQUIPMENT(YT2) (A) DIN12 & R1/2 ELBOW	1-09660-654-1	01	1	9706-9901	●	●
32	UNION; DOUBLE CHECK VLV BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06) FRIGID ZONE KIT<YL3> (A) DIN12 & R1/2 ELBOW	1-09660-654-1	01	1	9706-9901	●
32	UNION; DOUBLE CHECK VLV BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06) CHINA-SOUTHERN ECONOMIC ZONE EQUIPMENT(TAB), CHINAEQUIPMENT(YT2) (A) DIN12 & R3/8 ELBOW	1-09660-959-0	04	1	9905-	●	●
32	UNION; DOUBLE CHECK VLV BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06) FRIGID ZONE KIT<YL3> (A) DIN12 & R3/8 ELBOW	1-09660-959-0	04	1	9905-	●
32	UNION; DOUBLE CHECK VLV BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06) CHINA-SOUTHERN ECONOMIC ZONE EQUIPMENT(TAB), CHINAEQUIPMENT(YT2) (B) DIN12 & R1/2 ELBOW	1-09660-960-0	01	1	9905-0001	●	●
32	UNION; DOUBLE CHECK VLV BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06) FRIGID ZONE KIT<YL3> (B) DIN12 & R1/2 ELBOW	1-09660-960-0	01	1	9905-0001	●
32	UNION; DOUBLE CHECK VLV BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06) CHINA-SOUTHERN ECONOMIC ZONE EQUIPMENT(TAB), CHINAEQUIPMENT(YT2) (B) DIN12 & R1/2 ELBOW	1-09660-960-0	01	1	0002-	●	●
32	UNION; DOUBLE CHECK VLV 10PE1N(61L) BRAKE SYSTEM AIR OVER HYDRAULIC DUAL CIRCUIT(Z05) (B) DIN12 & R1/2 ELBOW	1-09660-960-0	01	1	0002-	●	●
32	UNION; DOUBLE CHECK VLV BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06) FRIGID ZONE KIT<YL3> (B) DIN12 & R1/2 ELBOW	1-09660-960-0	01	1	0002-	●
32	UNION; DOUBLE CHECK VLV 10PE1N(61L) BRAKE SYSTEM AIR OVER HYDRAULIC DUAL CIRCUIT(Z05) (A) DIN12 & R3/8 ELBOW	1-09660-959-0	01	1	0002-	●	●

22 21 23 12 22 23

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
12	BOLT; CONT VALVE,BRK LOCK 10PE1S(60L) POWER BRAKE LOCK SYSTEM(J50) M8X25 FLANGE	0-28080-825-0	02	1	9603-9608	●
12	BOLT; CONT VALVE,BRK LOCK 10PE1S(60L) POWER BRAKE LOCK SYSTEM(J50) M8X20 FLANGE	0-28680-820-0	02	1	9609-9901	●
12	BOLT; CONT VALVE,BRK LOCK 10PE1S(60L) POWER BRAKE LOCK SYSTEM(J50) M8X20 FLANGE	0-28680-820-0	02	1	9905-0001	●
12	BOLT; CONT VALVE,BRK LOCK POWER BRAKE LOCK SYSTEM(J50) M8X20 FLANGE	0-28680-820-0	02	1	0002-	●	●
21	BRACKET; CONT VLV,BRK LOCK 10PE1S(60L) POWER BRAKE LOCK SYSTEM(J50)	1-82569-226-0	01	1	9603-9901	●
21	BRACKET; CONT VLV,BRK LOCK 10PE1S(60L) POWER BRAKE LOCK SYSTEM(J50)	1-82569-283-1	01	1	9905-0001	●
21	BRACKET; CONT VLV,BRK LOCK POWER BRAKE LOCK SYSTEM(J50)	1-82569-283-1	01	1	0002-	●	●
22	BOLT; BRKT FIX,BRK LOCK CONT VLV 10PE1S(60L) POWER BRAKE LOCK SYSTEM(J50) (A) M8X25 FLANGE	0-28080-825-0	02	1	9603-9606	●
22	BOLT; BRKT FIX,BRK LOCK CONT VLV 10PE1S(60L) POWER BRAKE LOCK SYSTEM(J50) (A) M8X30 FLANGE	0-28680-830-0	02	1	9607-9901	●
22	BOLT; BRKT FIX,BRK LOCK CONT VLV 10PE1S(60L) POWER BRAKE LOCK SYSTEM(J50) (B) M10X25 FLANGE	0-28081-025-0	02	1	9603-9606	●
22	BOLT; BRKT FIX,BRK LOCK CONT VLV 10PE1S(60L) POWER BRAKE LOCK SYSTEM(J50) (B) M10X30 FLANGE	0-28681-030-0	02	1	9607-9901	●
22	BOLT; BRKT FIX,BRK LOCK CONT VLV 10PE1S(60L) POWER BRAKE LOCK SYSTEM(J50) (A) M8X30 FLANGE	0-28680-830-0	02	1	9905-0001	●
22	BOLT; BRKT FIX,BRK LOCK CONT VLV POWER BRAKE LOCK SYSTEM(J50) (A) M8X30 FLANGE	0-28680-830-0	02	1	0002-	●	●
22	BOLT; BRKT FIX,BRK LOCK CONT VLV 10PE1S(60L) POWER BRAKE LOCK SYSTEM(J50) (B) M10X30 FLANGE	0-28681-030-0	02	1	9905-0001	●
22	BOLT; BRKT FIX,BRK LOCK CONT VLV POWER BRAKE LOCK SYSTEM(J50) (B) M10X30 FLANGE	0-28681-030-0	02	1	0002-	●	●
23	NUT; BRKT FIX,BRK LOCK CONT VLV 10PE1S(60L) POWER BRAKE LOCK SYSTEM(J50) (A) M8	9-09110-408-0	02	1	9603-9606	●
23	NUT; BRKT FIX,BRK LOCK CONT VLV 10PE1S(60L) POWER BRAKE LOCK SYSTEM(J50) (A) M8 FLANGE	0-91150-108-0	02	1	9607-9901	●
23	NUT; BRKT FIX,BRK LOCK CONT VLV 10PE1S(60L) POWER BRAKE LOCK SYSTEM(J50) (B) M10	9-09110-510-0	02	1	9603-9606	●
23	NUT; BRKT FIX,BRK LOCK CONT VLV 10PE1S(60L) POWER BRAKE LOCK SYSTEM(J50) (B) M10 FLANGE	0-91150-210-0	02	1	9607-9901	●
23	NUT; BRKT FIX,BRK LOCK CONT VLV 10PE1S(60L) POWER BRAKE LOCK SYSTEM(J50) (A) M8 FLANGE	0-91150-108-0	02	1	9905-0001	●
23	NUT; BRKT FIX,BRK LOCK CONT VLV POWER BRAKE LOCK SYSTEM(J50) (A) M8 FLANGE	0-91150-108-0	02	1	0002-	●	●
23	NUT; BRKT FIX,BRK LOCK CONT VLV 10PE1S(60L) POWER BRAKE LOCK SYSTEM(J50) (B) M10 FLANGE	0-91150-210-0	02	1	9905-0001	●
23	NUT; BRKT FIX,BRK LOCK CONT VLV POWER BRAKE LOCK SYSTEM(J50) (B) M10 FLANGE	0-91150-210-0	02	1	0002-	●	●

İpucu: çizimdeki balona veya tablodaki Balon sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
