Isuzu WW
▶
TRUCKS
▶
ELF
▶
51047 - ELF400/450(MEXICO)
▶
0 - Engine, Emission, Engine Electrical
▶
0-10 - CYLINDER HEAD COVER
▶
0-10 — CYLINDER HEAD COVER
(#53508) — 12 parça
4
5
79
79
43
43
1
79
43
69
82
82
128
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
1
COVER; CYL HD
8-97331-361-2
01
1
0507-
4
CAP; OIL FILLER
8-94133-207-5
01
1
0507-
5
GASKET; OIL FILLER
ALSO INCLUDED IN GASKET SET(ENGINE). ID=32 OD=40
8-94123-623-1
01
1
0507-
43
RUBBER; MTG,HD COVER,OUTER
OD=22
8-94395-684-0
11
1
0507-
69
GASKET; HD TO COVER
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
8-97331-359-1
01
1
0507-
79
BOLT; COVER
M8X35 FLANGE
0-28680-835-0
02
1
0507-0512
79
BOLT; COVER
M8X35 FLANGE
0-28650-835-0
02
1
0601-
79
BOLT; COVER
M8X65 FLANGE
1-09044-072-1
07
1
0507-
82
PLUG; CYL HD COVER
8-94399-605-0
02
1
0507-1005
82
PLUG; CYL HD COVER
8-98163-813-0
02
1
1006-
128
NUT; COVER,CYL HEAD COVER
M8 FLANGE
0-91150-108-0
02
1
0507-0602
128
NUT; COVER,CYL HEAD COVER
M8 FLANGE
0-91180-108-0
02
1
0603-
