1 |
DRUM; BRK,RR
|
1-42315-220-4 |
04 |
1 |
8910- |
| |
1 |
DRUM; BRK,RR
INTERNATIONAL STANDARD ISO 10STUD<B3V>
|
1-42315-220-2 |
04 |
1 |
8712-8909 |
| |
1 |
DRUM; BRK,RR
EXC. INTERNATIONAL STANDARD ISO 10STUD<B3V>
|
1-42315-220-2 |
02 |
1 |
8712-8909 |
| |
1 |
DRUM; BRK,RR
EXC. INTERNATIONAL STANDARD ISO 10STUD<B3V>
|
1-42315-221-2 |
02 |
1 |
8712-8909 |
| |
8 |
HUB; RR AXLE
INTERNATIONAL STANDARD ISO 10STUD<B3V>
|
1-42311-038-6 |
04 |
1 |
8712- |
| |
8 |
HUB; RR AXLE
EXC. INTERNATIONAL STANDARD ISO 10STUD<B3V>
|
1-42311-033-4 |
04 |
1 |
8712- |
| |
9 |
PIN; WHEEL,RR AXLE
INTERNATIONAL STANDARD ISO 10STUD<B3V>
|
1-42337-012-0 |
40 |
1 |
8712-9306 |
| |
9 |
PIN; WHEEL,RR AXLE
INTERNATIONAL STANDARD ISO 10STUD<B3V>
|
1-42337-035-0 |
40 |
1 |
9307-9311 |
| |
9 |
PIN; WHEEL,RR AXLE
INTERNATIONAL STANDARD ISO 10STUD<B3V>
|
1-42337-012-0 |
40 |
1 |
9312- |
| |
9 |
PIN; WHEEL,RR AXLE
EXC. INTERNATIONAL STANDARD ISO 10STUD<B3V>
|
1-42331-041-0 |
40 |
1 |
8712-9111 |
| |
9 |
PIN; WHEEL,RR AXLE
EXC. INTERNATIONAL STANDARD ISO 10STUD<B3V>
|
1-42331-136-0 |
40 |
1 |
9112- |
| |
10 |
NUT; WHEEL PIN,RR AXLE
M22
|
1-09400-071-0 |
40 |
1 |
9112- |
| |
10 |
NUT; WHEEL PIN,RR AXLE
INTERNATIONAL STANDARD ISO 10STUD<B3V>
M22
|
1-09400-071-0 |
40 |
1 |
8712-9111 |
| |
10 |
NUT; WHEEL PIN,RR AXLE
EXC. INTERNATIONAL STANDARD ISO 10STUD<B3V>
M22
|
1-09400-037-0 |
40 |
1 |
8712-9111 |
| |
15 |
BEARING; HUB OUTER,RR AXLE
NSK
|
1-09812-079-0 |
04 |
1 |
8712- |
| |
15 |
BEARING; HUB OUTER,RR AXLE
NACHI
|
1-09812-166-0 |
04 |
1 |
8712- |
| |
16 |
SEAL; OIL,RR HUB,OUTER
NOK
|
1-09625-226-1 |
04 |
1 |
8712- |
| |
16 |
SEAL; OIL,RR HUB,OUTER
TKK
|
1-09625-444-0 |
04 |
1 |
8712- |
| |
20 |
NUT; BRG,RR HUB
M88
|
9-09843-062-2 |
04 |
1 |
8712- |
| |
21 |
WASHER; LK,BRG NUT
ID=88
|
9-09854-112-0 |
04 |
1 |
8712- |
| |
24 |
BOLT; LK WASHER
M6X16 W/LK WASHER
|
9-01910-616-0 |
12 |
1 |
8712-9005 |
| |
24 |
BOLT; LK WASHER
M6X16 W/LK WASHER
|
0-50040-616-0 |
12 |
1 |
9006- |
| |
25 |
SHAFT; AXLE,RR
FORWARD RH REARWARD LH
|
1-42171-170-2 |
02 |
1 |
8712-8908 |
| |
25 |
SHAFT; AXLE,RR
FORWARD LH REARWARD RH
|
1-42171-171-2 |
02 |
1 |
8712-8908 |
| |
25 |
SHAFT; AXLE,RR
FORWARD RH REARWARD LH
|
1-42171-339-0 |
02 |
1 |
8909-9307 |
| |
25 |
SHAFT; AXLE,RR
FORWARD RH REARWARD LH
|
1-42171-356-0 |
02 |
1 |
9308- |
| |
25 |
SHAFT; AXLE,RR
FORWARD LH REARWARD RH
|
1-42171-340-0 |
02 |
1 |
8909-9307 |
| |
25 |
SHAFT; AXLE,RR
FORWARD LH REARWARD RH
|
1-42171-357-0 |
02 |
1 |
9308- |
| |
30 |
BOLT; HUB TO AXLE SHAFT
M14X58
|
1-09020-095-1 |
40 |
1 |
8712- |
| |
33 |
WASHER; AXLE SHAFT
ID=14.2
|
9-09150-614-0 |
40 |
1 |
8712-9408 |
| |
33 |
WASHER; AXLE SHAFT
ID=14.2
|
9-09150-814-0 |
40 |
1 |
9409- |
| |
37 |
BEARING; HUB INNER,RR AXLE
NSK
|
1-09812-077-0 |
04 |
1 |
8712- |
| |
37 |
BEARING; HUB INNER,RR AXLE
NACHI
|
1-09812-165-0 |
04 |
1 |
8712- |
| |
38 |
SEAL; OIL,RR HUB,INNER
NOK
|
1-09625-265-0 |
04 |
1 |
8712- |
| |
38 |
SEAL; OIL,RR HUB,INNER
TKK
|
1-09625-350-0 |
04 |
1 |
8712- |
| |
43 |
RING; SNAP,HUB SEAL,RR AXLE
OD=179
|
1-09587-057-0 |
04 |
1 |
8712- |
| |
49 |
CASE; RR AXLE
FORWARD
|
1-42130-409-9 |
01 |
1 |
8712-8902 |
| |
49 |
CASE; RR AXLE
FORWARD
|
1-42150-321-0 |
01 |
1 |
8903-9001 |
| |
49 |
CASE; RR AXLE
REARWARD
|
1-42130-571-9 |
01 |
1 |
8712-8902 |
| |
49 |
CASE; RR AXLE
REARWARD
|
1-42150-322-0 |
01 |
1 |
8903-9001 |
| |
49 |
CASE; RR AXLE
FORWARD
|
1-42150-360-5 |
01 |
1 |
9002-9306 |
| |
49 |
CASE; RR AXLE
REARWARD
|
1-42150-379-4 |
01 |
1 |
9002-9306 |
| |
49 |
CASE; RR AXLE
REARWARD
|
1-42150-698-1 |
01 |
1 |
9307- |
| |
49 |
CASE; RR AXLE
FINAL GEAR 43/11 17.5"(W4S)
FORWARD
|
1-42150-695-2 |
01 |
1 |
9307- |
| |
49 |
CASE; RR AXLE
FINAL GEAR 45/7 17.5"(W3X),FINAL GEAR 39/8
17.5"(W4B)
FORWARD
|
1-42150-696-1 |
01 |
1 |
9307- |
| |
58 |
PLUG; DRAIN,AXLE CASE
M24X17 FLANGE
|
1-09604-023-0 |
02 |
1 |
8712- |
| |
59 |
GASKET; DRAIN PLUG
ID=26.8
|
9-09920-605-0 |
02 |
1 |
8712- |
| |
60 |
BREATHER; RR AXLE CASE
|
1-09893-003-0 |
02 |
1 |
8712-9306 |
| |
60 |
BREATHER; RR AXLE CASE
|
1-09893-011-1 |
02 |
1 |
9307- |
| |
63 |
PLUG; OIL FILLER,AXLE CASE
M24X17 FLANGE
|
1-09604-021-0 |
02 |
1 |
8712-9307 |
| |
63 |
PLUG; OIL FILLER,AXLE CASE
M24X17 FLANGE
|
1-09604-022-0 |
02 |
1 |
9308- |
| |
64 |
GASKET; OIL FILLER,AXLE CASE
ID=24.5 OD=32.5
|
9-09920-392-0 |
02 |
1 |
8712-9307 |
| |
64 |
GASKET; OIL FILLER,AXLE CASE
ID=26.8
|
9-09920-605-0 |
02 |
1 |
9308- |
| |
65 |
NUT
M14
|
9-99110-514-0 |
16 |
1 |
8712- |
| |
66 |
WASHER; LK
ID=14.2
|
9-09150-514-0 |
16 |
1 |
8712-9401 |
| |
66 |
WASHER; LK
ID=14.2
|
9-09150-814-0 |
16 |
1 |
9402- |
| |
67 |
BOLT; FINAL DRIVE SETTING
M16X70
|
9-91056-670-0 |
08 |
1 |
8712-9003 |
| |
67 |
BOLT; FINAL DRIVE SETTING
M16X70
|
9-91066-670-0 |
08 |
1 |
9004- |
| |
67 |
BOLT; FINAL DRIVE SETTING
M16X40
|
9-92051-640-0 |
08 |
1 |
8712-9003 |
| |
67 |
BOLT; FINAL DRIVE SETTING
M16X40
|
9-92061-640-0 |
08 |
1 |
9004- |
| |
67 |
BOLT; FINAL DRIVE SETTING
M16X40
|
9-92051-640-0 |
06 |
1 |
8712-9003 |
| |
67 |
BOLT; FINAL DRIVE SETTING
M16X40
|
9-92061-640-0 |
06 |
1 |
9004-9306 |
| |
67 |
BOLT; FINAL DRIVE SETTING
M16X40
|
9-92061-640-0 |
07 |
1 |
9307- |
| |
71 |
WASHER; LK,FINAL DRIVE SETTING
ID=16.2
|
9-09150-516-0 |
24 |
1 |
8712-9003 |
| |
71 |
WASHER; LK,FINAL DRIVE SETTING
ID=16.2
|
9-09150-816-0 |
24 |
1 |
9004- |
| |
72 |
BOLT; PAD FIX
M14X45
|
9-91066-445-0 |
16 |
1 |
8712-8912 |
| |
72 |
BOLT; PAD FIX
M14X45
|
9-92061-445-0 |
16 |
1 |
9001- |
| |
73 |
PAD; RR SPR CONTACT
|
1-42124-064-0 |
04 |
1 |
8712-8809 |
| |
73 |
PAD; RR SPR CONTACT
|
1-42124-101-0 |
04 |
1 |
8810- |
| |
74 |
BOLT; RR BRK ASM SETTING
M14X50
|
1-09040-066-0 |
32 |
1 |
8712- |
| |
75 |
WASHER; LK,RR BRK ASM SETTING
ID=14.2
|
9-09150-614-0 |
32 |
1 |
8712-9401 |
| |
75 |
WASHER; LK,RR BRK ASM SETTING
ID=14.2
|
9-09150-814-0 |
32 |
1 |
9402- |
| |
76 |
NUT; RR BRK ASM SETTING
M14
|
9-99110-514-0 |
32 |
1 |
8712- |
| |
161 |
RING; SPRING,REAR WHEEL
EXC. INTERNATIONAL STANDARD ISO 10STUD<B3V>
|
1-42339-025-1 |
40 |
1 |
8712- |
