1 |
00.269 HEAD ASM; CYL
EURO5 SPECIFICATION(NT5)
|
8-98074-596-4 |
01 |
1 |
1009-1301 |
| |
1 |
00.269 HEAD ASM; CYL
EURO5 SPECIFICATION(NT5)
|
8-98223-080-2 |
01 |
1 |
1302- |
| |
1 |
00.269 HEAD ASM; CYL
|
8-97355-970-9 |
01 |
1 |
0908-1008 |
| |
1 |
00.269 HEAD ASM; CYL
EURO4 SPECIFICATION(NT4)
|
8-97355-970-9 |
01 |
1 |
1009-1012 |
| |
1 |
00.269 HEAD ASM; CYL
EURO4 SPECIFICATION(NT4)
|
8-98175-606-1 |
01 |
1 |
1101-1301 |
| |
1 |
00.269 HEAD ASM; CYL
EURO4 SPECIFICATION(NT4)
|
8-98223-019-2 |
01 |
1 |
1302- |
| |
2 |
00.289 GASKET; CYL HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
GRADE A
T=1.05 1-NOTCH
|
8-98135-953-0 |
01 |
1 |
0908-1108 |
| |
2 |
00.289 GASKET; CYL HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
GRADE A
T=1.05 1-NOTCH
|
8-97328-866-2 |
01 |
1 |
1109-1304 |
| |
2 |
00.289 GASKET; CYL HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
GRADE A
T=1.05 1-NOTCH
|
8-98241-037-0 |
01 |
1 |
1305-1411 |
| |
2 |
00.289 GASKET; CYL HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
GRADE A
T=1.14 1-NOTCH
|
8-98291-683-0 |
01 |
1 |
1412- |
| |
2 |
00.289 GASKET; CYL HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
GRADE B
T=1.10 2-NOTCH
|
8-98135-954-0 |
01 |
1 |
0908-1108 |
| |
2 |
00.289 GASKET; CYL HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
GRADE B
T=1.10 2-NOTCH
|
8-97328-867-2 |
01 |
1 |
1109-1304 |
| |
2 |
00.289 GASKET; CYL HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
GRADE B
T=1.10 2-NOTCH
|
8-98241-038-0 |
01 |
1 |
1305-1411 |
| |
2 |
00.289 GASKET; CYL HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
GRADE B
T=1.19 2-NOTCH
|
8-98291-684-0 |
01 |
1 |
1412- |
| |
2 |
00.289 GASKET; CYL HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
GRADE C
T=1.15 3-NOTCH
|
8-98135-955-0 |
01 |
1 |
0908-1108 |
| |
2 |
00.289 GASKET; CYL HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
GRADE C
T=1.15 3-NOTCH
|
8-97328-868-2 |
01 |
1 |
1109-1304 |
| |
2 |
00.289 GASKET; CYL HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
GRADE C
T=1.15 3-NOTCH
|
8-98241-039-0 |
01 |
1 |
1305-1411 |
| |
2 |
00.289 GASKET; CYL HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
GRADE C
T=1.24 3-NOTCH
|
8-98291-685-0 |
01 |
1 |
1412- |
| |
3 |
00.293 BOLT; CYL HD TO BLOCK
M11X114
|
8-97144-583-2 |
18 |
1 |
0908-1108 |
| |
3 |
00.293 BOLT; CYL HD TO BLOCK
M11X114 W/WASHER
|
8-98201-019-0 |
18 |
1 |
1109- |
| |
4 |
00.283 GUIDE; VLV
L=42
|
8-94239-423-0 |
16 |
1 |
0908- |
| |
5 |
00.253 SEAT; VLV INSERT
(A) INLET
ID=29 OD=35
|
8-97311-378-0 |
08 |
1 |
0908- |
| |
5 |
00.253 SEAT; VLV INSERT
(B) EXHAUST
ID=26 OD=32
|
8-97311-379-0 |
08 |
1 |
0908- |
| |
7 |
00.253 CUP; SEALING,CYL HEAD
00.034
(A)
OD=32
|
1-09600-012-2 |
02 |
1 |
0908- |
| |
7 |
00.253 CUP; SEALING,CYL HEAD
(B)
OD=18
|
5-11219-008-0 |
13 |
1 |
0908- |
| |
7 |
00.253 CUP; SEALING,CYL HEAD
00.034
(C)
OD=14
|
5-11219-011-0 |
07 |
1 |
0908- |
| |
10 |
02.270 PLUG; GLOW
NGK
|
8-94390-777-6 |
04 |
1 |
0908- |
| |
11 |
02.251 CONNECTOR; GLOW PLUG
|
8-98014-335-0 |
01 |
1 |
0908- |
| |
39 |
00.413 DOWEL; CAP,CM/SHF
|
8-97329-129-1 |
20 |
1 |
0908- |
| |
91 |
08.846 PIPE; HTR
01.251
|
8-94343-211-1 |
01 |
1 |
0908- |
| |
123 |
00.206 BOLT; COVER
M8X20 FLANGE
|
8-97366-632-0 |
04 |
1 |
0908- |
| |
143 |
02.251 BOLT; FIX
00.685
M8X40 FLANGE
|
0-28650-840-0 |
20 |
1 |
0908- |
| |
155 |
00.349 BOLT; BAFFLE PLATE
M6X10 HEX SOCKET
|
0-58330-610-0 |
04 |
1 |
0908- |
| |
172 |
00.207 PLATE; BAFFLE,CYL HD
|
8-98016-865-0 |
01 |
1 |
0908- |
| |
192 |
00.349 NUT; GLOW PLUG
02.559
M4 FLANGE
|
8-97368-853-0 |
04 |
1 |
0908- |
| |
224 |
00.349 NUT; COVER
01.540
M8 FLANGE
|
0-91180-208-0 |
04 |
1 |
0908- |
| |
225 |
00.349 STUD; COVER
M8X15.5 L=33.5
|
8-98017-062-0 |
02 |
1 |
0908- |
| |
230 |
03.300 GASKET; SLEEVE,INJECTOR
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
03.306
OD=30
|
1-09639-034-0 |
04 |
1 |
0908- |
| |
232 |
00.413 STUD; CAM,CARRIER
(A)
M8X15 M8X17 L=40
|
8-97366-633-0 |
01 |
1 |
0908-1006 |
| |
232 |
00.413 STUD; CAM,CARRIER
(A)
M8X15 M8X17 L=40
|
8-98166-373-0 |
01 |
1 |
1007- |
| |
232 |
00.413 STUD; CAM,CARRIER
(B)
M6X12 M8X17 L=37
|
8-97375-460-0 |
01 |
1 |
0908- |
| |
262 |
00.206 COVER; CYL HEAD
|
8-97355-516-4 |
01 |
1 |
0908- |
| |
263 |
00.293 BOLT; CYL HD
04.686
(A)
M8X60 FLANGE
|
0-28050-860-0 |
01 |
1 |
0908- |
| |
263 |
00.293 BOLT; CYL HD
01.060
(B)
M8X35 FLANGE
|
0-28650-835-0 |
03 |
1 |
0908- |
