Isuzu WW
▶
TRUCKS
▶
ELF
▶
51047 - ELF400/450(MEXICO)
▶
8 - Chassis Electrical, Heating / Air Conditioning, Wipers, Radio
▶
8-03 - LAMP; REAR AND REAR SIDE
▶
8-03 — LAMP; REAR AND REAR SIDE
(#51893) — 50 parça
Tümü
A - NPC7SC
B - NPC7SF
C - NPC7SK
D - NPC7SS
55
38
37
58
59
49
1
1
3
8
24
51
5
49
5
22
50
54
28
14
5
13
15
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
C
D
1
LAMP ASM; RR COMB
8-97065-810-0
01
1
0507-0604
●
●
●
1
LAMP ASM; RR COMB
8-97065-810-0
01
1
0605-
●
●
●
●
1
LAMP ASM; RR COMB
8-97065-809-0
01
1
0507-0604
●
●
●
1
LAMP ASM; RR COMB
8-97065-809-0
01
1
0605-
●
●
●
●
3
GASKET; RR COMB LAMP
8-97066-836-0
02
1
0507-0604
●
●
●
3
GASKET; RR COMB LAMP
8-97066-836-0
02
1
0605-
●
●
●
●
5
BULB; RR COMB LAMP
(A) 12V 27W
1-82194-040-0
04
1
0507-0604
●
●
●
5
BULB; RR COMB LAMP
(A) 12V 27W
1-82194-040-0
04
1
0605-
●
●
●
●
5
BULB; RR COMB LAMP
(B) 12V 27/8W
8-94404-036-0
02
1
0507-0604
●
●
●
5
BULB; RR COMB LAMP
(B) 12V 27/8W
8-94404-036-0
02
1
0605-
●
●
●
●
8
HARNESS; RR COMB LAMP
8-97066-998-0
02
1
0507-0604
●
●
●
8
HARNESS; RR COMB LAMP
8-97066-998-0
02
1
0605-
●
●
●
●
13
LENS; TURN SIGNAL
8-97066-839-0
02
1
0507-0604
●
●
●
13
LENS; TURN SIGNAL
8-97066-839-0
02
1
0605-
●
●
●
●
14
LENS; TAIL & STOP,RR COMB LAMP
8-97066-981-0
01
1
0507-0604
●
●
●
14
LENS; TAIL & STOP,RR COMB LAMP
8-97066-981-0
01
1
0605-
●
●
●
●
14
LENS; TAIL & STOP,RR COMB LAMP
8-97066-838-0
01
1
0507-0604
●
●
●
14
LENS; TAIL & STOP,RR COMB LAMP
8-97066-838-0
01
1
0605-
●
●
●
●
15
SCREW; RR COMB LAMP
M4X20 TAPPING STAINLESS
0-71190-420-0
20
1
0507-0604
●
●
●
15
SCREW; RR COMB LAMP
M4X20 TAPPING STAINLESS
0-71190-420-0
20
1
0605-
●
●
●
●
15
SCREW; RR COMB LAMP
M4X14 TAPPING
9-07076-414-0
01
1
0507-0604
●
●
●
15
SCREW; RR COMB LAMP
M4X14 TAPPING
9-07076-414-0
01
1
0605-
●
●
●
●
15
SCREW; RR COMB LAMP
M4X12 TAPPING
9-07076-412-0
01
1
0507-0604
●
●
●
15
SCREW; RR COMB LAMP
M4X12 TAPPING
9-07076-412-0
01
1
0605-
●
●
●
●
22
LENS; BACKUP,RR COMB LAMP
8-94257-512-0
02
1
0507-0604
●
●
●
22
LENS; BACKUP,RR COMB LAMP
8-94257-512-0
02
1
0605-
●
●
●
●
24
GASKET; BACK,LAMP
8-94257-506-0
02
1
0507-0604
●
●
●
24
GASKET; BACK,LAMP
8-94257-506-0
02
1
0605-
●
●
●
●
28
GASKET; TURN,LAMP
8-97066-837-0
02
1
0507-0604
●
●
●
28
GASKET; TURN,LAMP
8-97066-837-0
02
1
0605-
●
●
●
●
37
COVER; RR COMB LAMP
8-97066-251-0
01
1
0507-0604
●
●
●
37
COVER; RR COMB LAMP
8-97066-251-0
01
1
0605-
●
●
●
●
37
COVER; RR COMB LAMP
8-97066-250-0
01
1
0507-0604
●
●
●
37
COVER; RR COMB LAMP
8-97066-250-0
01
1
0605-
●
●
●
●
38
BOLT; LAMP,RR COMB
M6X20
8-94402-623-0
06
1
0507-0604
●
●
●
38
BOLT; LAMP,RR COMB
M6X20
8-94402-623-0
06
1
0605-
●
●
●
●
49
LAMP; LICENSE PLATE
8-94178-897-0
01
1
0507-0604
●
●
●
49
LAMP; LICENSE PLATE
8-94178-897-0
01
1
0605-
●
●
●
●
50
LENS; LICENSE PLATE LAMP
5-82125-004-0
01
1
0507-0604
●
●
●
50
LENS; LICENSE PLATE LAMP
5-82125-004-0
01
1
0605-
●
●
●
●
51
BULB; LICENSE PLATE LAMP
12V 7.5W
9-82692-128-0
01
1
0507-0604
●
●
●
51
BULB; LICENSE PLATE LAMP
12V 7.5W
9-82692-128-0
01
1
0605-
●
●
●
●
54
SCREW; LICENSE PLATE LAMP
M4X8
8-94419-312-0
01
1
0507-0604
●
●
●
54
SCREW; LICENSE PLATE LAMP
M4X8
8-94419-312-0
01
1
0605-
●
●
●
●
55
NUT; LICENSE PLATE LAMP
M5 FLANGE
8-94153-039-0
02
1
0507-0604
●
●
●
55
NUT; LICENSE PLATE LAMP
M5 FLANGE
8-94153-039-0
02
1
0605-
●
●
●
●
58
COVER; LICENSE PLATE LAMP
8-97076-590-1
01
1
0507-0604
●
●
●
58
COVER; LICENSE PLATE LAMP
8-97076-590-1
01
1
0605-
●
●
●
●
59
SCREW; TAP,LICENSE LAMP BODY
M5X20
9-93490-520-0
02
1
0507-0604
●
●
●
59
SCREW; TAP,LICENSE LAMP BODY
M5X20
9-93490-520-0
02
1
0605-
●
●
●
●
