Isuzu WW
▶
TRUCKS
▶
NPR
▶
51244 - NPR(LHD) EURO5
▶
6 - Exterior Body, Glass Mounting, Door Trim, Molding
▶
6-78 - FLOOR HOLE PLUG
▶
6-78 — FLOOR HOLE PLUG
(#50532) — 8 parça
Tümü
A - NPR6SN
B - NPR6SE
110
113
112
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
110
16.802 FASTENER; FLOOR MAT
INSPECTION ENGINE COVER<8GA> BLACK
8-94279-089-0
11
1
0911-1108
●
110
16.802 FASTENER; FLOOR MAT
INSPECTION ENGINE COVER<8GA> BLACK
8-94279-089-0
11
1
1109-
●
●
110
16.802 FASTENER; FLOOR MAT
EXC. INSPECTION ENGINE COVER<8GA> BLACK
8-94279-089-0
12
1
0911-1108
●
110
16.802 FASTENER; FLOOR MAT
EXC. INSPECTION ENGINE COVER<8GA> BLACK
8-94279-089-0
12
1
1109-
●
●
112
16.800 GROMMET; SCREW,TRIM COVER
04.931 H=15
8-94463-268-1
08
1
0911-1108
●
112
16.800 GROMMET; SCREW,TRIM COVER
04.931 H=15
8-94463-268-1
08
1
1109-
●
●
113
16.800 SCREW; TRIM COVER
04.681 T25 M5X12 TAPPING HEXALOBULAR
0-72180-512-0
08
1
0911-1108
●
113
16.800 SCREW; TRIM COVER
04.681 T25 M5X12 TAPPING HEXALOBULAR
0-72180-512-0
08
1
1109-
●
●
Seçili parçaları sepete ekle
İpucu: çizimdeki balona veya tablodaki
Balon
sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
