Isuzu WW
▶
TRUCKS
▶
EXR
▶
10724 - EXR RHD
▶
2 - Clutch, Transmission, Trans Axle
▶
2-85C - POWER TAKE OFF CONTROL
▶
2-85C — POWER TAKE OFF CONTROL
(#4846) — 13 parça
Tümü
A - TRANSMISSION-FULLER RTLO149 13 OD
B - TRANSMISSION-FULLER RTL0147 13 OD
1
132
246
217
21
121
21
73
73
21
55
3
1
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
1
LEVER ASM; PTO & DUMP CONT
DUMP CONTROL LEVER<RC4>
1-79996-244-0
01
1
9905-
●
1
LEVER ASM; PTO & DUMP CONT
DUMP CONTROL LEVER<RC4>
1-79996-244-0
01
1
9611-9904
●
3
BOLT; BRKT,DUMP CONT LEVER
DUMP CONTROL LEVER<RC4> M8X20.5 W/LK&PL WASHER
8-94279-207-0
03
1
9905-
●
3
BOLT; BRKT,DUMP CONT LEVER
DUMP CONTROL LEVER<RC4> M8X16 W/LK & PL WASHER
8-94279-207-0
03
1
9611-9904
●
21
WASHER; PL,CONT LEVER
DUMP CONTROL LEVER<RC4> ID=6.4 OD=14
9-09160-606-0
03
1
9905-
●
55
GROMMET; CABLE
EXC. DUMP CONTROL LEVER<RC4>
1-09983-068-0
01
1
9905-
●
55
GROMMET; CABLE
EXC. DUMP CONTROL LEVER<RC4>
1-09983-068-0
01
1
9601-9904
●
73
NUT; LEVER
DUMP CONTROL LEVER<RC4> ID=5.9 PUSH NUT
8-97015-036-0
02
1
9905-
●
121
RING; SNAP
DUMP CONTROL LEVER<RC4> ID=5
9-09185-405-0
01
1
9905-
●
132
COVER; PTO CONT
DUMP CONTROL LEVER<RC4>
1-79997-376-0
01
1
9601-9904
●
132
COVER; PTO CONT
DUMP CONTROL LEVER<RC4>
1-79997-376-0
01
1
9905-
●
217
WASHER; PL
DUMP CONTROL LEVER<RC4> ID=4.3
9-09160-504-0
02
1
9905-
●
246
SCREW; CABLE CLIP
DUMP CONTROL LEVER<RC4> M4X8 TAPPING
0-71180-408-0
02
1
9905-
●
