2-03 — CLUTCH PEDAL AND CONTROL (#48255) — 64 parça

242 177 325 6 61 6 27 7 14 10 6 11 265 13 25 30 6 13 10 32 4 1 49 11 32 84 85 85 9

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B	C
1	PEDAL; CLU 4HG1 ENG<RJH> FLOOR REMOTE SHIFT<M11> POWER ASSIST CLUTCH<S2T>	8-97853-220-2	01	1	0009-	●
1	PEDAL; CLU POWER ASSIST CLUTCH<S2T>	8-97853-220-2	01	1	0009-		●
1	PEDAL; CLU 4HE1 ENG<RLY> FLOOR REMOTE SHIFT<M11> EXC. POWER ASSIST CLUTCH<S2T> THA	8-97920-904-0	01	1	0009-	●
1	PEDAL; CLU EXC. POWER ASSIST CLUTCH<S2T> THA	8-97920-904-0	01	1	0009-			●
1	PEDAL; CLU 4HG1 ENG<RJH> FLOOR REMOTE SHIFT<M11> EXC. POWER ASSIST CLUTCH<S2T> THA	8-97916-303-0	01	1	0009-	●
1	PEDAL; CLU EXC. POWER ASSIST CLUTCH<S2T> THA	8-97916-303-0	01	1	0009-		●
4	STOPPER; CLU PEDAL 4HE1 ENG<RLY> FLOOR REMOTE SHIFT<M11> EXC. POWER ASSIST CLUTCH<S2T> THA	8-97853-534-1	02	1	0009-	●
4	STOPPER; CLU PEDAL 4HG1 ENG<RJH> FLOOR REMOTE SHIFT<M11> THA	8-97853-534-1	02	1	0009-	●
4	STOPPER; CLU PEDAL THA	8-97853-534-1	02	1	0009-		●
4	STOPPER; CLU PEDAL EXC. POWER ASSIST CLUTCH<S2T> THA	8-97853-534-1	02	1	0009-			●
6	BUSHING; CLU PEDAL FLOOR REMOTE SHIFT<M11> EXC. POWER ASSIST CLUTCH<S2T> (A) THA	8-97853-619-0	02	1	0009-	●
6	BUSHING; CLU PEDAL EXC. POWER ASSIST CLUTCH<S2T> (A) THA	8-97853-619-0	02	1	0009-		●	●
6	BUSHING; CLU PEDAL FLOOR REMOTE SHIFT<M11> EXC. POWER ASSIST CLUTCH<S2T> (B) THA	8-97853-620-0	01	1	0009-	●
6	BUSHING; CLU PEDAL EXC. POWER ASSIST CLUTCH<S2T> (B) THA	8-97853-620-0	01	1	0009-		●	●
6	BUSHING; CLU PEDAL 4HE1 ENG<RLY> FLOOR REMOTE SHIFT<M11> EXC. POWER ASSIST CLUTCH<S2T> (C)	8-94238-596-0	02	1	0009-	●
6	BUSHING; CLU PEDAL 4HG1 ENG<RJH> FLOOR REMOTE SHIFT<M11> (C)	8-94238-596-0	02	1	0009-	●
6	BUSHING; CLU PEDAL (C)	8-94238-596-0	02	1	0009-		●
6	BUSHING; CLU PEDAL EXC. POWER ASSIST CLUTCH<S2T> (C)	8-94238-596-0	02	1	0009-			●
7	BRACKET; CLU PEDAL 4HE1 ENG<RLY> FLOOR REMOTE SHIFT<M11> EXC. POWER ASSIST CLUTCH<S2T>	8-97853-522-4	01	1	0009-	●
7	BRACKET; CLU PEDAL 4HG1 ENG<RJH> FLOOR REMOTE SHIFT<M11>	8-97853-522-4	01	1	0009-	●
7	BRACKET; CLU PEDAL	8-97853-522-4	01	1	0009-		●
7	BRACKET; CLU PEDAL EXC. POWER ASSIST CLUTCH<S2T>	8-97853-522-4	01	1	0009-			●
9	PIN; CLU PEDAL 4HE1 ENG<RLY> FLOOR REMOTE SHIFT<M11> EXC. POWER ASSIST CLUTCH<S2T>	8-97866-667-0	01	1	0009-	●
9	PIN; CLU PEDAL 4HG1 ENG<RJH> FLOOR REMOTE SHIFT<M11>	8-97866-667-0	01	1	0009-	●
9	PIN; CLU PEDAL	8-97866-667-0	01	1	0009-		●
9	PIN; CLU PEDAL EXC. POWER ASSIST CLUTCH<S2T>	8-97866-667-0	01	1	0009-			●
10	PIN; CLU PEDAL FLOOR REMOTE SHIFT<M11>	8-94410-276-0	01	1	0009-	●
10	PIN; CLU PEDAL	8-94410-276-0	01	1	0009-		●	●
11	PIN; SNAP,PUSH ROD TO PEDAL FLOOR REMOTE SHIFT<M11>	8-94279-912-0	01	1	0009-	●
11	PIN; SNAP,PUSH ROD TO PEDAL	8-94279-912-0	01	1	0009-		●	●
13	SPRING; ASSIST,CLU PEDAL FLOOR REMOTE SHIFT<M11> EXC. POWER ASSIST CLUTCH<S2T> (B)	8-97853-221-1	01	1	0009-	●
13	SPRING; ASSIST,CLU PEDAL EXC. POWER ASSIST CLUTCH<S2T> (B)	8-97853-221-1	01	1	0009-		●	●
13	SPRING; ASSIST,CLU PEDAL 4HG1 ENG<RJH> FLOOR REMOTE SHIFT<M11> POWER ASSIST CLUTCH<S2T> (A)	8-97853-535-1	01	1	0009-	●
13	SPRING; ASSIST,CLU PEDAL POWER ASSIST CLUTCH<S2T> (A)	8-97853-535-1	01	1	0009-		●
14	BRACKET ASM; CLU PEDAL MTG FLOOR REMOTE SHIFT<M11> EXC. POWER ASSIST CLUTCH<S2T>	8-97892-848-2	01	1	0009-	●
14	BRACKET ASM; CLU PEDAL MTG EXC. POWER ASSIST CLUTCH<S2T>	8-97892-848-2	01	1	0009-		●	●
14	BRACKET ASM; CLU PEDAL MTG 4HG1 ENG<RJH> FLOOR REMOTE SHIFT<M11> POWER ASSIST CLUTCH<S2T>	8-97892-849-2	01	1	0009-	●
14	BRACKET ASM; CLU PEDAL MTG POWER ASSIST CLUTCH<S2T>	8-97892-849-2	01	1	0009-		●
25	BOLT; PEDAL M10X22 W/WASHER	8-94279-099-0	01	1	0009-0110	●	●	●
25	BOLT; PEDAL M10X22 W/PL WASHER	8-97313-188-0	01	1	0111-	●	●	●
27	NUT; FULCRUM PIN 4HE1 ENG<RLY> FLOOR REMOTE SHIFT<M11> EXC. POWER ASSIST CLUTCH<S2T> M10 FLANGE	1-09440-022-0	01	1	0009-	●
27	NUT; FULCRUM PIN 4HG1 ENG<RJH> FLOOR REMOTE SHIFT<M11> M10 FLANGE	1-09440-022-0	01	1	0009-	●
27	NUT; FULCRUM PIN M10 FLANGE	1-09440-022-0	01	1	0009-		●
27	NUT; FULCRUM PIN EXC. POWER ASSIST CLUTCH<S2T> M10 FLANGE	1-09440-022-0	01	1	0009-			●
30	BOLT; CLU MTG BRKT M10X25 FLANGE	0-28691-025-0	01	1	0009-	●	●	●
32	NUT; BRKT TO CLU M/CYL POWER ASSIST CLUTCH<S2T> M8 W/LK WASHER	8-94279-050-0	02	1	0009-	●
32	NUT; BRKT TO CLU M/CYL FLOOR REMOTE SHIFT<M11> EXC. POWER ASSIST CLUTCH<S2T> M8 W/LK WASHER	8-94279-050-0	02	1	0009-	●
32	NUT; BRKT TO CLU M/CYL M8 W/LK WASHER	8-94279-050-0	02	1	0009-		●	●
49	RUBBER; PAD,CLU PEDAL 4HE1 ENG<RLY> FLOOR REMOTE SHIFT<M11> EXC. POWER ASSIST CLUTCH<S2T>	8-97853-413-2	01	1	0009-	●
49	RUBBER; PAD,CLU PEDAL 4HG1 ENG<RJH> FLOOR REMOTE SHIFT<M11>	8-97853-413-2	01	1	0009-	●
49	RUBBER; PAD,CLU PEDAL	8-97853-413-2	01	1	0009-		●
49	RUBBER; PAD,CLU PEDAL EXC. POWER ASSIST CLUTCH<S2T>	8-97853-413-2	01	1	0009-			●
61	NUT; BOOSTER TO BRKT POWER ASSIST CLUTCH<S2T> M8 W/LK WASHER	8-94279-050-0	04	1	0009-	●	●	●
84	HOSE; RUBBER,CLU LINE FLOOR REMOTE SHIFT<M11>	8-97135-025-0	01	1	0009-	●
84	HOSE; RUBBER,CLU LINE	8-97135-025-0	01	1	0009-		●	●
85	CLIP; HOSE TO M/CYL FLOOR REMOTE SHIFT<M11>	8-97130-480-0	02	1	0009-	●
85	CLIP; HOSE TO M/CYL	8-97130-480-0	02	1	0009-		●	●
177	NUT; BRKT M8 W/LK WASHER	8-94279-050-0	02	1	0009-	●	●	●
242	BOLT; BRKT,CLUTCH 4HE1 ENG<RLY> FLOOR REMOTE SHIFT<M11> EXC. POWER ASSIST CLUTCH<S2T> M8X16 FLANGE	0-28480-816-0	02	1	0009-	●
242	BOLT; BRKT,CLUTCH 4HG1 ENG<RJH> FLOOR REMOTE SHIFT<M11> M8X16 FLANGE	0-28480-816-0	02	1	0009-	●
242	BOLT; BRKT,CLUTCH M8X16 FLANGE	0-28480-816-0	02	1	0009-		●
242	BOLT; BRKT,CLUTCH EXC. POWER ASSIST CLUTCH<S2T> M8X16 FLANGE	0-28480-816-0	02	1	0009-			●
265	NUT; BRKT,COLUMN SUPT TO C.PDL M8 FLANGE	8-97046-127-0	01	1	0009-	●	●	●
325	BOLT; BRKT,STRG SUPPORT M8X20 FLANGE	0-28680-820-0	01	1	0009-	●	●	●
