Isuzu WW
▶
TRUCKS
▶
EXR
▶
10724 - EXR RHD
▶
2 - Clutch, Transmission, Trans Axle
▶
2-25C - SPEEDOMETER DRIVEN GEAR
▶
2-25C — SPEEDOMETER DRIVEN GEAR
(#4822) — 14 parça
Tümü
A - TRANSMISSION-FULLER RTL0147 13 OD
B - TRANSMISSION-FULLER RTLO149 13 OD
32
33
57
32
33
57
32
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
32
BOLT; CLU HSG TO FLYWHEEL HSG
(A) M12X35 FLANGE
0-28781-235-0
08
1
9712-9904
●
32
BOLT; CLU HSG TO FLYWHEEL HSG
(A) M12X35 FLANGE
0-28781-235-0
08
1
9905-
●
32
BOLT; CLU HSG TO FLYWHEEL HSG
(B) M12X40 FLANGE
0-28181-240-0
03
1
9611-9904
●
32
BOLT; CLU HSG TO FLYWHEEL HSG
(B) M12X40 FLANGE
0-28181-240-0
03
1
9905-
●
32
BOLT; CLU HSG TO FLYWHEEL HSG
(B) M12X35 FLANGE
0-28781-235-0
06
1
9611-9711
●
32
BOLT; CLU HSG TO FLYWHEEL HSG
(A) M10X16,M12X35 L=59
1-09029-031-1
03
1
9611-9711
●
32
BOLT; CLU HSG TO FLYWHEEL HSG
(A) M10X16,M12X35 L=59
1-09029-031-1
01
1
9712-9904
●
32
BOLT; CLU HSG TO FLYWHEEL HSG
(A) M10X16,M12X35 L=59
1-09029-031-1
01
1
9905-
●
33
WASHER; LK,CLU HSG
ID=12.2
9-09150-612-0
03
1
9611-9711
●
33
WASHER; LK,CLU HSG
ID=12.2
9-09150-612-0
01
1
9712-9904
●
33
WASHER; LK,CLU HSG
ID=12.2
9-09150-612-0
01
1
9905-
●
57
WASHER; PL,CLU HSG
ID=12.5
9-09164-512-0
03
1
9611-9711
●
57
WASHER; PL,CLU HSG
ID=12.5
9-09164-512-0
01
1
9712-9904
●
57
WASHER; PL,CLU HSG
ID=12.5
9-09164-512-0
01
1
9905-
●
Seçili parçaları sepete ekle
İpucu: çizimdeki balona veya tablodaki
Balon
sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
