Sayfa 0-40 - Isuzu EPC

0-40 — FUEL INJECTION SYSTEM (#47612) — 244 parça

31 32 34 58 140 44 43 146 46 33 35

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B	C
31	03.332 NOZZLE ASM; INJ	8-97148-960-1	04	1	0102-0501	●
31	03.332 NOZZLE ASM; INJ	8-97148-960-1	04	1	0502-		●
31	03.332 NOZZLE ASM; INJ	8-97119-812-0	04	1	0201-			●
32	03.332 HOLDER ASM; NOZZLE	8-94311-966-2	04	1	0102-0112	●
32	03.332 HOLDER ASM; NOZZLE	8-94311-966-2	04	1	0201-0501	●		●
32	03.332 HOLDER ASM; NOZZLE	8-94311-966-2	04	1	0502-		●	●
33	03.332 NOZZLE; INJ	8-97148-961-1	04	1	0102-0501	●
33	03.332 NOZZLE; INJ	8-97148-961-1	04	1	0502-		●
33	03.332 NOZZLE; INJ	8-97119-810-0	04	1	0201-			●
34	03.330 BOLT; EYE,NOZZLE HOLDER	1-15339-009-0	04	1	0102-0112	●
34	03.330 BOLT; EYE,NOZZLE HOLDER	1-15339-009-0	04	1	0201-0501	●		●
34	03.330 BOLT; EYE,NOZZLE HOLDER	1-15339-009-0	04	1	0502-		●	●
35	03.330 NUT; NOZZLE RET,NOZZLE HOLDER	8-94174-184-0	04	1	0102-0112	●
35	03.330 NUT; NOZZLE RET,NOZZLE HOLDER	8-94174-184-0	04	1	0201-0501	●		●
35	03.330 NUT; NOZZLE RET,NOZZLE HOLDER	8-94174-184-0	04	1	0502-		●	●
43	03.332 SEAT; NOZZLE SPRING,NOZZLE HOLDE	8-94329-555-0	04	1	0102-0112	●
43	03.332 SEAT; NOZZLE SPRING,NOZZLE HOLDE	8-94329-555-0	04	1	0201-0501	●		●
43	03.332 SEAT; NOZZLE SPRING,NOZZLE HOLDE	8-94329-555-0	04	1	0502-		●	●
44	03.330 SPRING; NOZZLE,NOZZLE HOLDER	8-94174-141-0	04	1	0102-0112	●
44	03.330 SPRING; NOZZLE,NOZZLE HOLDER	8-94174-141-0	04	1	0201-0501	●		●
44	03.330 SPRING; NOZZLE,NOZZLE HOLDER	8-94174-141-0	04	1	0502-		●	●
46	03.330 PIN; NOZZLE SET,NOZZLE HOLDER	8-94174-139-0	08	1	0102-0112	●
46	03.330 PIN; NOZZLE SET,NOZZLE HOLDER	8-94174-139-0	08	1	0201-0501	●		●
46	03.330 PIN; NOZZLE SET,NOZZLE HOLDER	8-94174-139-0	08	1	0502-		●	●
58	03.332 FLANGE; INJ,NOZZLE HOLDER	8-97065-713-0	04	1	0102-0112	●
58	03.332 FLANGE; INJ,NOZZLE HOLDER	8-97065-713-0	04	1	0201-0501	●		●
58	03.332 FLANGE; INJ,NOZZLE HOLDER	8-97065-713-0	04	1	0502-		●	●
140	03.330 SHIM; NOZZLE SPRING,NOZZLE HOLDE 03.332 T=0.10	8-97027-432-0	AR	1	0102-0112	●
140	03.330 SHIM; NOZZLE SPRING,NOZZLE HOLDE 03.332 T=0.10	8-97027-432-0	AR	1	0201-0501	●		●
140	03.330 SHIM; NOZZLE SPRING,NOZZLE HOLDE 03.332 T=0.10	8-97027-432-0	AR	1	0502-		●	●
140	03.330 SHIM; NOZZLE SPRING,NOZZLE HOLDE 03.332 T=0.20	8-97027-433-0	AR	1	0102-0112	●
140	03.330 SHIM; NOZZLE SPRING,NOZZLE HOLDE 03.332 T=0.20	8-97027-433-0	AR	1	0201-0501	●		●
140	03.330 SHIM; NOZZLE SPRING,NOZZLE HOLDE 03.332 T=0.20	8-97027-433-0	AR	1	0502-		●	●
140	03.330 SHIM; NOZZLE SPRING,NOZZLE HOLDE 03.332 T=0.30	8-97027-434-0	AR	1	0102-0112	●
140	03.330 SHIM; NOZZLE SPRING,NOZZLE HOLDE 03.332 T=0.30	8-97027-434-0	AR	1	0201-0501	●		●
140	03.330 SHIM; NOZZLE SPRING,NOZZLE HOLDE 03.332 T=0.30	8-97027-434-0	AR	1	0502-		●	●
140	03.330 SHIM; NOZZLE SPRING,NOZZLE HOLDE 03.332 T=0.40	8-97027-435-0	AR	1	0102-0112	●
140	03.330 SHIM; NOZZLE SPRING,NOZZLE HOLDE 03.332 T=0.40	8-97027-435-0	AR	1	0201-0501	●		●
140	03.330 SHIM; NOZZLE SPRING,NOZZLE HOLDE 03.332 T=0.40	8-97027-435-0	AR	1	0502-		●	●
140	03.330 SHIM; NOZZLE SPRING,NOZZLE HOLDE 03.332 T=0.50	8-97027-436-0	AR	1	0102-0112	●
140	03.330 SHIM; NOZZLE SPRING,NOZZLE HOLDE 03.332 T=0.50	8-97027-436-0	AR	1	0201-0501	●		●
140	03.330 SHIM; NOZZLE SPRING,NOZZLE HOLDE 03.332 T=0.50	8-97027-436-0	AR	1	0502-		●	●
140	03.330 SHIM; NOZZLE SPRING,NOZZLE HOLDE 03.332 T=0.52	8-97027-437-0	AR	1	0102-0112	●
140	03.330 SHIM; NOZZLE SPRING,NOZZLE HOLDE 03.332 T=0.52	8-97027-437-0	AR	1	0201-0501	●		●
140	03.330 SHIM; NOZZLE SPRING,NOZZLE HOLDE 03.332 T=0.52	8-97027-437-0	AR	1	0502-		●	●
140	03.330 SHIM; NOZZLE SPRING,NOZZLE HOLDE 03.332 T=0.54	8-97027-438-0	AR	1	0102-0112	●
140	03.330 SHIM; NOZZLE SPRING,NOZZLE HOLDE 03.332 T=0.54	8-97027-438-0	AR	1	0201-0501	●		●
140	03.330 SHIM; NOZZLE SPRING,NOZZLE HOLDE 03.332 T=0.54	8-97027-438-0	AR	1	0502-		●	●
140	03.330 SHIM; NOZZLE SPRING,NOZZLE HOLDE 03.332 T=0.56	8-97027-439-0	AR	1	0102-0112	●
140	03.330 SHIM; NOZZLE SPRING,NOZZLE HOLDE 03.332 T=0.56	8-97027-439-0	AR	1	0201-0501	●		●
140	03.330 SHIM; NOZZLE SPRING,NOZZLE HOLDE 03.332 T=0.56	8-97027-439-0	AR	1	0502-		●	●
140	03.330 SHIM; NOZZLE SPRING,NOZZLE HOLDE 03.332 T=0.58	8-97027-440-0	AR	1	0102-0112	●
140	03.330 SHIM; NOZZLE SPRING,NOZZLE HOLDE 03.332 T=0.58	8-97027-440-0	AR	1	0201-0501	●		●
140	03.330 SHIM; NOZZLE SPRING,NOZZLE HOLDE 03.332 T=0.58	8-97027-440-0	AR	1	0502-		●	●
146	03.332 SPACER; NOZZLE	8-94344-439-0	04	1	0102-0112	●
146	03.332 SPACER; NOZZLE	8-94344-439-0	04	1	0201-0501	●		●
146	03.332 SPACER; NOZZLE	8-94344-439-0	04	1	0502-		●	●

18 19 17 113 16 36 63 2 1 2 2 161 62 31 1 219 219 2 80 158 2 2 84 66 78 66 226

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B	C
1	03.306 PUMP ASM; INJ SEE FIG-NO 0-80 - 0-85 FOR COMPONENT.	8-97212-186-1	01	1	0102-0501	●
1	03.306 PUMP ASM; INJ SEE FIG-NO 0-80 - 0-85 FOR COMPONENT.	8-97212-935-1	01	1	0502-		●
1	03.306 PUMP ASM; INJ SEE FIG-NO 0-80 - 0-85 FOR COMPONENT. HIGH ALTITUDE COMPENSATOR(EE2)	8-97203-383-0	01	1	0201-			●
1	03.306 PUMP ASM; INJ SEE FIG-NO 0-80 - 0-85 FOR COMPONENT. EXC. HIGH ALTITUDE COMPENSATOR(EE2)	8-97203-380-0	01	1	0201-0506			●
1	03.306 PUMP ASM; INJ SEE FIG-NO 0-80 - 0-85 FOR COMPONENT. EXC. AIR CONDITIONER MANUAL CONT(C60), HIGH ALTITUDE COMPENSATOR(EE2)	8-97203-380-0	01	1	0507-0507			●
1	03.306 PUMP ASM; INJ SEE FIG-NO 0-80 - 0-85 FOR COMPONENT. EXC. HIGH ALTITUDE COMPENSATOR(EE2)	8-97203-380-0	01	1	0508-			●
2	03.330 BOLT; INJ PUMP 03.890 (A) M10X70 FLANGE	0-28181-070-0	01	1	0102-0112	●
2	03.330 BOLT; INJ PUMP 03.890 (A) M10X70 FLANGE	0-28181-070-0	01	1	0201-0501	●		●
2	03.330 BOLT; INJ PUMP 03.890 (A) M10X70 FLANGE	0-28181-070-0	01	1	0502-0512		●	●
2	03.330 BOLT; INJ PUMP 02.277 (A) M10X70 FLANGE	0-28151-070-0	01	1	0601-		●	●
2	03.330 BOLT; INJ PUMP (B) M12X70 FLANGE	0-28181-270-0	01	1	0102-0112	●
2	03.330 BOLT; INJ PUMP (B) M12X70 FLANGE	0-28181-270-0	01	1	0201-0501	●		●
2	03.330 BOLT; INJ PUMP (B) M12X70 FLANGE	0-28181-270-0	01	1	0502-0512		●	●
2	03.330 BOLT; INJ PUMP 00.206 (B) M12X70 FLANGE	0-28151-270-0	01	1	0601-		●	●
2	03.330 BOLT; INJ PUMP (C) M12X110	0-28186-211-0	01	1	0102-0501	●
2	03.330 BOLT; INJ PUMP (C) M12X110	0-28186-211-0	01	1	0502-0512		●
2	03.330 BOLT; INJ PUMP (C) M12X110 FLANGE	0-28156-211-0	01	1	0601-		●
2	03.330 BOLT; INJ PUMP 03.162 (D) M14X27 FLANGE	1-09675-086-0	01	1	0102-0501	●
2	03.330 BOLT; INJ PUMP 03.162 (D) M14X27 FLANGE	1-09675-086-0	01	1	0502-		●
2	03.330 BOLT; INJ PUMP (C) M12X90 FLANGE	0-28181-290-0	01	1	0201-0512			●
2	03.330 BOLT; INJ PUMP (C) M12X90 FLANGE	0-28151-290-0	01	1	0601-			●
2	03.330 BOLT; INJ PUMP 03.162 (D) M14X27 FLANGE	1-09675-086-0	02	1	0201-			●
2	03.330 BOLT; INJ PUMP 03.162 (E) M14X30	8-97203-957-0	01	1	0201-			●
16	03.330 PIPE; INJ NO.1	8-97148-963-4	01	1	0102-0501	●
16	03.330 PIPE; INJ NO.1	8-97148-963-4	01	1	0502-		●
16	03.330 PIPE; INJ NO.1	8-97123-374-0	01	1	0201-			●
17	03.330 PIPE; INJ NO.2	8-97148-964-3	01	1	0102-0501	●
17	03.330 PIPE; INJ NO.2	8-97148-964-3	01	1	0502-		●
17	03.330 PIPE; INJ NO.2	8-97123-375-0	01	1	0201-			●
18	03.330 PIPE; INJ NO.3	8-97148-965-4	01	1	0102-0501	●
18	03.330 PIPE; INJ NO.3	8-97148-965-4	01	1	0502-		●
18	03.330 PIPE; INJ NO.3	8-97123-376-0	01	1	0201-			●
19	03.330 PIPE; INJ NO.4	8-97148-966-3	01	1	0102-0501	●
19	03.330 PIPE; INJ NO.4	8-97148-966-3	01	1	0502-		●
19	03.330 PIPE; INJ NO.4	8-97123-377-1	01	1	0201-			●
31	03.332 NOZZLE ASM; INJ	8-97148-960-1	04	1	0102-0501	●
31	03.332 NOZZLE ASM; INJ	8-97148-960-1	04	1	0502-		●
31	03.332 NOZZLE ASM; INJ	8-97119-812-0	04	1	0201-			●
36	03.332 GASKET; RETURN PIPE,NOZZLE HOLDE ALSO INCLUDED IN GASKET SET(ENG. & HEAD) ID=8.6	8-94395-214-0	04	1	0102-0112	●
36	03.332 GASKET; RETURN PIPE,NOZZLE HOLDE ALSO INCLUDED IN GASKET SET(ENG. & HEAD) ID=8.6	8-94395-214-0	04	1	0201-0501	●		●
36	03.332 GASKET; RETURN PIPE,NOZZLE HOLDE ALSO INCLUDED IN GASKET SET(ENG. & HEAD) ID=8.6	8-94395-214-0	04	1	0502-1312		●	●
36	03.332 GASKET; RETURN PIPE,NOZZLE HOLDE ALSO INCLUDED IN GASKET SET(ENG. & HEAD) ID=8.6	8-98246-930-0	04	1	1401-		●	●
62	03.332 NUT; NOZZLE HOLDER 07.633 M8 FLANGE	0-91150-108-0	08	1	0102-0112	●
62	03.332 NUT; NOZZLE HOLDER 07.633 M8 FLANGE	0-91150-108-0	08	1	0201-0501	●		●
62	03.332 NUT; NOZZLE HOLDER 07.633 M8 FLANGE	0-91150-108-0	08	1	0502-0602		●	●
62	03.332 NUT; NOZZLE HOLDER 01.062 M8 FLANGE	0-91180-108-0	08	1	0603-		●	●
63	03.163 PIPE; FUEL,NOZZLE LEAK OFF	8-97148-969-2	01	1	0102-0501	●
63	03.163 PIPE; FUEL,NOZZLE LEAK OFF	8-97148-969-2	01	1	0502-		●
63	03.163 PIPE; FUEL,NOZZLE LEAK OFF	8-97118-895-0	01	1	0201-			●
66	03.332 GASKET; INJ NOZZLE ALSO INCLUDED IN GASKET SET(ENG. & HEAD) (B)	8-94326-439-0	04	1	0102-0112	●
66	03.332 GASKET; INJ NOZZLE ALSO INCLUDED IN GASKET SET(ENG. & HEAD) (B)	8-94326-439-0	04	1	0201-0501	●		●
66	03.332 GASKET; INJ NOZZLE ALSO INCLUDED IN GASKET SET(ENG. & HEAD) (B)	8-94326-439-0	04	1	0502-		●	●
66	03.332 GASKET; INJ NOZZLE ALSO INCLUDED IN GASKET SET(ENG. & HEAD) (A)	8-97171-922-0	04	1	0102-0501	●
66	03.332 GASKET; INJ NOZZLE ALSO INCLUDED IN GASKET SET(ENG. & HEAD) (A)	8-97171-922-0	04	1	0502-		●
66	03.332 GASKET; INJ NOZZLE ALSO INCLUDED IN GASKET SET(ENG. & HEAD) (A) ID=7.2 OD=15.0 T=6.6	8-97171-331-0	04	1	0201-			●
78	03.330 BOLT; BRKT TO C/BL 04.785 M10X20 FLANGE	0-28781-020-0	01	1	0102-0501	●
78	03.330 BOLT; BRKT TO C/BL 04.785 M10X20 FLANGE	0-28781-020-0	01	1	0502-0512		●
78	03.330 BOLT; BRKT TO C/BL 02.343 M10X20 FLANGE	0-28751-020-0	01	1	0601-		●
78	03.330 BOLT; BRKT TO C/BL 04.785 M10X20 FLANGE	0-28781-020-0	02	1	0201-0512			●
78	03.330 BOLT; BRKT TO C/BL 02.343 M10X20 FLANGE	0-28751-020-0	02	1	0601-			●
80	03.306 BRACKET; PUMP (A)	8-97148-958-1	01	1	0102-0501	●
80	03.306 BRACKET; PUMP (A)	8-97148-958-1	01	1	0502-		●
80	03.306 BRACKET; PUMP (B)	8-97136-677-0	01	1	0201-			●
84	03.330 NUT; BRKT TO BRKT 07.243 M12 FLANGE	0-91150-212-0	01	1	0102-0501	●
84	03.330 NUT; BRKT TO BRKT 07.243 M12 FLANGE	0-91150-212-0	01	1	0502-0602		●
84	03.330 NUT; BRKT TO BRKT 05.816 M12 FLANGE	0-91180-212-0	01	1	0603-		●
84	03.330 NUT; BRKT TO BRKT 08.917 M10 FLANGE	0-91150-210-0	01	1	0201-0602			●
84	03.330 NUT; BRKT TO BRKT 04.085 M10 FLANGE	0-91180-210-0	01	1	0603-			●
113	03.162 CLIP; INJ PIPE	8-97213-050-0	05	1	0102-0501	●
113	03.162 CLIP; INJ PIPE	8-97213-050-0	05	1	0502-		●
113	03.162 CLIP; INJ PIPE	8-97213-050-0	04	1	0201-			●
158	03.330 NUT; INJ PUMP 04.785 M10 FLANGE	0-91150-110-0	02	1	0102-0112	●
158	03.330 NUT; INJ PUMP 04.785 M10 FLANGE	0-91150-110-0	02	1	0201-0501	●		●
158	03.330 NUT; INJ PUMP 04.785 M10 FLANGE	0-91150-110-0	02	1	0502-0602		●	●
158	03.330 NUT; INJ PUMP 03.162 M10 FLANGE	0-91180-110-0	02	1	0603-		●	●
158	03.330 NUT; INJ PUMP 00.685 M12 FLANGE	0-91250-112-0	01	1	0102-0501	●
158	03.330 NUT; INJ PUMP 00.685 M12 FLANGE	0-91250-112-0	01	1	0502-0602		●
158	03.330 NUT; INJ PUMP 03.704 M12 FLANGE	0-91280-112-0	01	1	0603-		●
161	03.340 STUD; INJ PUMP 00.724 M10X46.5 L=58.5	8-97066-386-1	02	1	0102-0112	●
161	03.340 STUD; INJ PUMP 00.724 M10X46.5 L=58.5	8-97066-386-1	02	1	0201-0212	●		●
161	03.340 STUD; INJ PUMP M10X46.5 L=58.5	8-97363-237-0	02	1	0301-0501	●		●
161	03.340 STUD; INJ PUMP M10X46.5 L=58.5	8-97363-237-0	02	1	0502-0910		●	●
161	03.340 STUD; INJ PUMP 00.724 M10X46.5 L=58.5	8-97066-386-1	02	1	0911-		●	●
219	03.162 GASKET ALSO INCLUDED IN GASKET SET(ENGINE). 03.163 ID=14.2 OD=19.2	1-09630-085-0	02	1	0201-1312			●
219	03.162 GASKET ALSO INCLUDED IN GASKET SET(ENGINE). 01.531 ID=14.2 OD=19.2	8-98251-345-0	02	1	1401-			●
226	03.163 PIPE; FUEL	8-97203-567-0	01	1	0201-			●

19 113 18 17 16 68 122 68 107 36 62 63 31 66 66 2 364 161 2 393 158 15 1 2 221 170 2 84 80 78 56 220

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B	C
1	03.306 PUMP ASM; INJ SEE FIG-NO 0-80 - 0-85 FOR COMPONENT.	8-97212-186-1	01	1	0102-0501	●
1	03.306 PUMP ASM; INJ SEE FIG-NO 0-80 - 0-85 FOR COMPONENT.	8-97212-935-1	01	1	0502-		●
1	03.306 PUMP ASM; INJ SEE FIG-NO 0-80 - 0-85 FOR COMPONENT. HIGH ALTITUDE COMPENSATOR(EE2)	8-97203-383-0	01	1	0201-			●
1	03.306 PUMP ASM; INJ SEE FIG-NO 0-80 - 0-85 FOR COMPONENT. EXC. HIGH ALTITUDE COMPENSATOR(EE2)	8-97203-380-0	01	1	0201-0506			●
1	03.306 PUMP ASM; INJ SEE FIG-NO 0-80 - 0-85 FOR COMPONENT. EXC. AIR CONDITIONER MANUAL CONT(C60), HIGH ALTITUDE COMPENSATOR(EE2)	8-97203-380-0	01	1	0507-0507			●
1	03.306 PUMP ASM; INJ SEE FIG-NO 0-80 - 0-85 FOR COMPONENT. EXC. HIGH ALTITUDE COMPENSATOR(EE2)	8-97203-380-0	01	1	0508-			●
2	03.330 BOLT; INJ PUMP 03.890 (A) M10X70 FLANGE	0-28181-070-0	01	1	0102-0112	●
2	03.330 BOLT; INJ PUMP 03.890 (A) M10X70 FLANGE	0-28181-070-0	01	1	0201-0501	●		●
2	03.330 BOLT; INJ PUMP 03.890 (A) M10X70 FLANGE	0-28181-070-0	01	1	0502-0512		●	●
2	03.330 BOLT; INJ PUMP 02.277 (A) M10X70 FLANGE	0-28151-070-0	01	1	0601-		●	●
2	03.330 BOLT; INJ PUMP (B) M12X70 FLANGE	0-28181-270-0	01	1	0102-0112	●
2	03.330 BOLT; INJ PUMP (B) M12X70 FLANGE	0-28181-270-0	01	1	0201-0501	●		●
2	03.330 BOLT; INJ PUMP (B) M12X70 FLANGE	0-28181-270-0	01	1	0502-0512		●	●
2	03.330 BOLT; INJ PUMP 00.206 (B) M12X70 FLANGE	0-28151-270-0	01	1	0601-		●	●
2	03.330 BOLT; INJ PUMP (C) M12X110	0-28186-211-0	01	1	0102-0501	●
2	03.330 BOLT; INJ PUMP (C) M12X110	0-28186-211-0	01	1	0502-0512		●
2	03.330 BOLT; INJ PUMP (C) M12X110 FLANGE	0-28156-211-0	01	1	0601-		●
2	03.330 BOLT; INJ PUMP 03.162 (D) M14X27 FLANGE	1-09675-086-0	01	1	0102-0501	●
2	03.330 BOLT; INJ PUMP 03.162 (D) M14X27 FLANGE	1-09675-086-0	01	1	0502-		●
2	03.330 BOLT; INJ PUMP (C) M12X90 FLANGE	0-28181-290-0	01	1	0201-0512			●
2	03.330 BOLT; INJ PUMP (C) M12X90 FLANGE	0-28151-290-0	01	1	0601-			●
2	03.330 BOLT; INJ PUMP 03.162 (D) M14X27 FLANGE	1-09675-086-0	02	1	0201-			●
2	03.330 BOLT; INJ PUMP 03.162 (E) M14X30	8-97203-957-0	01	1	0201-			●
15	03.340 COUPLING ASM; INJ PUMP SEE FIG-NO 0-87 FOR COMPONENT.	8-97218-999-0	01	1	0102-0301	●
15	03.340 COUPLING ASM; INJ PUMP SEE FIG-NO 0-87 FOR COMPONENT.	8-97367-625-0	01	1	0302-0501	●
15	03.340 COUPLING ASM; INJ PUMP SEE FIG-NO 0-87 FOR COMPONENT.	8-97218-999-0	01	1	0502-		●
16	03.330 PIPE; INJ NO.1	8-97148-963-4	01	1	0102-0501	●
16	03.330 PIPE; INJ NO.1	8-97148-963-4	01	1	0502-		●
16	03.330 PIPE; INJ NO.1	8-97123-374-0	01	1	0201-			●
17	03.330 PIPE; INJ NO.2	8-97148-964-3	01	1	0102-0501	●
17	03.330 PIPE; INJ NO.2	8-97148-964-3	01	1	0502-		●
17	03.330 PIPE; INJ NO.2	8-97123-375-0	01	1	0201-			●
18	03.330 PIPE; INJ NO.3	8-97148-965-4	01	1	0102-0501	●
18	03.330 PIPE; INJ NO.3	8-97148-965-4	01	1	0502-		●
18	03.330 PIPE; INJ NO.3	8-97123-376-0	01	1	0201-			●
19	03.330 PIPE; INJ NO.4	8-97148-966-3	01	1	0102-0501	●
19	03.330 PIPE; INJ NO.4	8-97148-966-3	01	1	0502-		●
19	03.330 PIPE; INJ NO.4	8-97123-377-1	01	1	0201-			●
31	03.332 NOZZLE ASM; INJ	8-97148-960-1	04	1	0102-0501	●
31	03.332 NOZZLE ASM; INJ	8-97148-960-1	04	1	0502-		●
31	03.332 NOZZLE ASM; INJ	8-97119-812-0	04	1	0201-			●
36	03.332 GASKET; RETURN PIPE,NOZZLE HOLDE ALSO INCLUDED IN GASKET SET(ENG. & HEAD) ID=8.6	8-94395-214-0	04	1	0102-0112	●
36	03.332 GASKET; RETURN PIPE,NOZZLE HOLDE ALSO INCLUDED IN GASKET SET(ENG. & HEAD) ID=8.6	8-94395-214-0	04	1	0201-0501	●		●
36	03.332 GASKET; RETURN PIPE,NOZZLE HOLDE ALSO INCLUDED IN GASKET SET(ENG. & HEAD) ID=8.6	8-94395-214-0	04	1	0502-1312		●	●
36	03.332 GASKET; RETURN PIPE,NOZZLE HOLDE ALSO INCLUDED IN GASKET SET(ENG. & HEAD) ID=8.6	8-98246-930-0	04	1	1401-		●	●
56	03.332 COVER NOISE PACK FOR REGULATION VAR.2<7TF> 03.306	8-97170-784-0	01	1	0502-		●
62	03.332 NUT; NOZZLE HOLDER 07.633 M8 FLANGE	0-91150-108-0	08	1	0102-0112	●
62	03.332 NUT; NOZZLE HOLDER 07.633 M8 FLANGE	0-91150-108-0	08	1	0201-0501	●		●
62	03.332 NUT; NOZZLE HOLDER 07.633 M8 FLANGE	0-91150-108-0	08	1	0502-0602		●	●
62	03.332 NUT; NOZZLE HOLDER 01.062 M8 FLANGE	0-91180-108-0	08	1	0603-		●	●
63	03.163 PIPE; FUEL,NOZZLE LEAK OFF	8-97148-969-2	01	1	0102-0501	●
63	03.163 PIPE; FUEL,NOZZLE LEAK OFF	8-97148-969-2	01	1	0502-		●
63	03.163 PIPE; FUEL,NOZZLE LEAK OFF	8-97118-895-0	01	1	0201-			●
66	03.332 GASKET; INJ NOZZLE ALSO INCLUDED IN GASKET SET(ENG. & HEAD) (B)	8-94326-439-0	04	1	0102-0112	●
66	03.332 GASKET; INJ NOZZLE ALSO INCLUDED IN GASKET SET(ENG. & HEAD) (B)	8-94326-439-0	04	1	0201-0501	●		●
66	03.332 GASKET; INJ NOZZLE ALSO INCLUDED IN GASKET SET(ENG. & HEAD) (B)	8-94326-439-0	04	1	0502-		●	●
66	03.332 GASKET; INJ NOZZLE ALSO INCLUDED IN GASKET SET(ENG. & HEAD) (A)	8-97171-922-0	04	1	0102-0501	●
66	03.332 GASKET; INJ NOZZLE ALSO INCLUDED IN GASKET SET(ENG. & HEAD) (A)	8-97171-922-0	04	1	0502-		●
66	03.332 GASKET; INJ NOZZLE ALSO INCLUDED IN GASKET SET(ENG. & HEAD) (A) ID=7.2 OD=15.0 T=6.6	8-97171-331-0	04	1	0201-			●
68	03.162 CLIP; INJ PIPE	8-97213-049-0	06	1	0102-0501	●
68	03.162 CLIP; INJ PIPE	8-97213-049-0	06	1	0502-		●
78	03.330 BOLT; BRKT TO C/BL 04.785 M10X20 FLANGE	0-28781-020-0	01	1	0102-0501	●
78	03.330 BOLT; BRKT TO C/BL 04.785 M10X20 FLANGE	0-28781-020-0	01	1	0502-0512		●
78	03.330 BOLT; BRKT TO C/BL 02.343 M10X20 FLANGE	0-28751-020-0	01	1	0601-		●
78	03.330 BOLT; BRKT TO C/BL 04.785 M10X20 FLANGE	0-28781-020-0	02	1	0201-0512			●
78	03.330 BOLT; BRKT TO C/BL 02.343 M10X20 FLANGE	0-28751-020-0	02	1	0601-			●
80	03.306 BRACKET; PUMP (A)	8-97148-958-1	01	1	0102-0501	●
80	03.306 BRACKET; PUMP (A)	8-97148-958-1	01	1	0502-		●
80	03.306 BRACKET; PUMP (B)	8-97136-677-0	01	1	0201-			●
84	03.330 NUT; BRKT TO BRKT 07.243 M12 FLANGE	0-91150-212-0	01	1	0102-0501	●
84	03.330 NUT; BRKT TO BRKT 07.243 M12 FLANGE	0-91150-212-0	01	1	0502-0602		●
84	03.330 NUT; BRKT TO BRKT 05.816 M12 FLANGE	0-91180-212-0	01	1	0603-		●
84	03.330 NUT; BRKT TO BRKT 08.917 M10 FLANGE	0-91150-210-0	01	1	0201-0602			●
84	03.330 NUT; BRKT TO BRKT 04.085 M10 FLANGE	0-91180-210-0	01	1	0603-			●
107	03.162 NUT; INJ PIPE CLIP 03.671 M5 FLANGE	8-94178-699-0	03	1	0102-0501	●
107	03.162 NUT; INJ PIPE CLIP 03.671 M5 FLANGE	8-94178-699-0	03	1	0502-		●
113	03.162 CLIP; INJ PIPE	8-97213-050-0	05	1	0102-0501	●
113	03.162 CLIP; INJ PIPE	8-97213-050-0	05	1	0502-		●
113	03.162 CLIP; INJ PIPE	8-97213-050-0	04	1	0201-			●
122	03.162 CLIP; LEAK OFF PIPE	9-09524-662-0	01	1	0102-0501	●
122	03.162 CLIP; LEAK OFF PIPE	9-09524-662-0	01	1	0502-0606		●
122	03.162 CLIP; LEAK OFF PIPE ID=7 L=32	0-95234-662-0	01	1	0607-		●
158	03.330 NUT; INJ PUMP 04.785 M10 FLANGE	0-91150-110-0	02	1	0102-0112	●
158	03.330 NUT; INJ PUMP 04.785 M10 FLANGE	0-91150-110-0	02	1	0201-0501	●		●
158	03.330 NUT; INJ PUMP 04.785 M10 FLANGE	0-91150-110-0	02	1	0502-0602		●	●
158	03.330 NUT; INJ PUMP 03.162 M10 FLANGE	0-91180-110-0	02	1	0603-		●	●
158	03.330 NUT; INJ PUMP 00.685 M12 FLANGE	0-91250-112-0	01	1	0102-0501	●
158	03.330 NUT; INJ PUMP 00.685 M12 FLANGE	0-91250-112-0	01	1	0502-0602		●
158	03.330 NUT; INJ PUMP 03.704 M12 FLANGE	0-91280-112-0	01	1	0603-		●
161	03.340 STUD; INJ PUMP 00.724 M10X46.5 L=58.5	8-97066-386-1	02	1	0102-0112	●
161	03.340 STUD; INJ PUMP 00.724 M10X46.5 L=58.5	8-97066-386-1	02	1	0201-0212	●		●
161	03.340 STUD; INJ PUMP M10X46.5 L=58.5	8-97363-237-0	02	1	0301-0501	●		●
161	03.340 STUD; INJ PUMP M10X46.5 L=58.5	8-97363-237-0	02	1	0502-0910		●	●
161	03.340 STUD; INJ PUMP 00.724 M10X46.5 L=58.5	8-97066-386-1	02	1	0911-		●	●
170	03.332 INSULATOR; INJ PUMP	8-97306-433-2	01	1	0502-		●
220	03.162 CLIP; COVER NOISE PACK FOR REGULATION VAR.2<7TF>	8-97037-154-0	02	1	0502-0502		●
220	03.162 CLIP; COVER NOISE PACK FOR REGULATION VAR.2<7TF>	8-97037-154-0	01	1	0503-		●
221	03.162 CAP; SCREW NOISE PACK FOR REGULATION VAR.2<7TF>	8-97190-450-0	02	1	0502-		●
364	03.900 VALVE; OVER FLOW,INJ PUMP 03.318	1-15619-321-0	01	1	0212-0501	●
364	03.900 VALVE; OVER FLOW,INJ PUMP 03.318	1-15619-321-0	01	1	0502-		●
393	03.340 STUD; COVER 03.335	8-97212-809-0	02	1	0304-0403	●

İpucu: çizimdeki balona veya tablodaki Balon sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
