1 |
COMPRESSOR ASM; AIR
SEE FIG-NO 0-39 FOR COMPONENT.
|
1-19100-268-9 |
01 |
1 |
9603-9607 |
● |
|
|
|
|
| |
1 |
COMPRESSOR ASM; AIR
SEE FIG-NO 0-39 FOR COMPONENT.
|
1-19100-300-1 |
01 |
1 |
9608-9706 |
● |
|
|
|
|
| |
1 |
COMPRESSOR ASM; AIR
SEE FIG-NO 0-39 FOR COMPONENT.
|
1-19100-300-1 |
01 |
1 |
9707-9804 |
● |
● |
|
|
|
| |
1 |
COMPRESSOR ASM; AIR
SEE FIG-NO 0-39 FOR COMPONENT.
|
1-19100-300-2 |
01 |
1 |
9805-9904 |
● |
● |
● |
|
|
| |
1 |
COMPRESSOR ASM; AIR
SEE FIG-NO 0-39 FOR COMPONENT.
|
1-19100-300-5 |
01 |
1 |
9905- |
● |
|
● |
● |
● |
| |
2 |
GASKET; AIR CMPR
ALSO INCLUDED IN GASKET SET(ENGINE).
|
1-09623-476-0 |
01 |
1 |
9603-9706 |
● |
|
|
|
|
| |
2 |
GASKET; AIR CMPR
ALSO INCLUDED IN GASKET SET(ENGINE).
|
1-09623-476-0 |
01 |
1 |
9707-9804 |
● |
● |
|
|
|
| |
2 |
GASKET; AIR CMPR
ALSO INCLUDED IN GASKET SET(ENGINE).
|
1-09623-476-0 |
01 |
1 |
9805-9904 |
● |
● |
● |
|
|
| |
2 |
GASKET; AIR CMPR
ALSO INCLUDED IN GASKET SET(ENGINE).
|
1-09623-476-0 |
01 |
1 |
9905- |
● |
|
● |
● |
● |
| |
3 |
KEY; COUPLING,INJ PUMP
|
9-08055-622-0 |
01 |
1 |
9603-9706 |
● |
|
|
|
|
| |
3 |
KEY; COUPLING,INJ PUMP
|
9-08055-622-0 |
01 |
1 |
9707-9804 |
● |
● |
|
|
|
| |
3 |
KEY; COUPLING,INJ PUMP
|
9-08055-622-0 |
01 |
1 |
9805-9904 |
● |
● |
● |
|
|
| |
3 |
KEY; COUPLING,INJ PUMP
|
9-08055-622-0 |
01 |
1 |
9905- |
● |
|
● |
● |
● |
| |
5 |
BOLT; AIR CMPR FIX
(A)
M14X128
|
8-94399-253-1 |
01 |
1 |
9603-9706 |
● |
|
|
|
|
| |
5 |
BOLT; AIR CMPR FIX
(A)
M14X128
|
8-94399-253-1 |
01 |
1 |
9707-9804 |
● |
● |
|
|
|
| |
5 |
BOLT; AIR CMPR FIX
(A)
M14X128
|
8-94399-253-1 |
01 |
1 |
9805-9904 |
● |
● |
● |
|
|
| |
5 |
BOLT; AIR CMPR FIX
(B)
M14X90
|
9-91666-490-0 |
01 |
1 |
9603-9706 |
● |
|
|
|
|
| |
5 |
BOLT; AIR CMPR FIX
(B)
M14X90
|
9-91666-490-0 |
01 |
1 |
9707-9804 |
● |
● |
|
|
|
| |
5 |
BOLT; AIR CMPR FIX
AIR CONDITIONER MANUAL CONTROL(C60)
(A)
M14X140
|
1-09020-112-0 |
01 |
1 |
9603-9706 |
● |
|
|
|
|
| |
5 |
BOLT; AIR CMPR FIX
AIR CONDITIONER MANUAL CONTROL(C60)
(A)
M14X140
|
1-09020-112-0 |
01 |
1 |
9707-9802 |
● |
● |
|
|
|
| |
5 |
BOLT; AIR CMPR FIX
EXC. AIR CONDITIONER MANUAL CONTROL(C60)
(C)
M14X100
|
9-91666-400-0 |
01 |
1 |
9603-9804 |
● |
|
|
|
|
| |
5 |
BOLT; AIR CMPR FIX
EXC. AIR CONDITIONER MANUAL CONTROL(C60)
(C)
M14X100
|
9-91666-400-0 |
01 |
1 |
9805-9904 |
● |
|
● |
|
|
| |
5 |
BOLT; AIR CMPR FIX
AIR CONDITIONER MANUAL CONTROL(C60)
(B)
M14X140
|
1-09020-112-0 |
01 |
1 |
9803-9804 |
● |
● |
|
|
|
| |
5 |
BOLT; AIR CMPR FIX
AIR CONDITIONER MANUAL CONTROL(C60)
(A)
M14X140
|
1-09020-112-0 |
01 |
1 |
9805-9903 |
● |
● |
● |
|
|
| |
5 |
BOLT; AIR CMPR FIX
(B)
M14X90
|
9-91666-490-0 |
01 |
1 |
9805-9904 |
● |
● |
● |
|
|
| |
5 |
BOLT; AIR CMPR FIX
AIR CONDITIONER MANUAL CONTROL(C60)
(A)
M14X140
|
1-09020-112-0 |
01 |
1 |
9904-9904 |
● |
● |
● |
|
|
| |
5 |
BOLT; AIR CMPR FIX
(A)
M14X128
|
8-94399-253-1 |
01 |
1 |
9905- |
● |
|
● |
● |
● |
| |
5 |
BOLT; AIR CMPR FIX
(B)
M14X90
|
9-91666-490-0 |
01 |
1 |
9905- |
● |
|
● |
● |
● |
| |
5 |
BOLT; AIR CMPR FIX
AIR CONDITIONER MANUAL CONTROL(C60)
(A)
M14X140
|
1-09020-112-0 |
01 |
1 |
9905- |
● |
|
● |
● |
● |
| |
5 |
BOLT; AIR CMPR FIX
HEATER & DEFROSTER(C41)
(C)
M14X100
|
9-91666-400-0 |
01 |
1 |
9905- |
● |
|
● |
● |
● |
| |
6 |
NUT; AIR CMPR
M14 FLANGE
|
0-91150-114-0 |
01 |
1 |
9603-9706 |
● |
|
|
|
|
| |
6 |
NUT; AIR CMPR
M14 FLANGE
|
0-91150-114-0 |
01 |
1 |
9707-9804 |
● |
● |
|
|
|
| |
6 |
NUT; AIR CMPR
M14 FLANGE
|
0-91150-114-0 |
01 |
1 |
9805-9904 |
● |
● |
● |
|
|
| |
6 |
NUT; AIR CMPR
M14 FLANGE
|
0-91150-114-0 |
01 |
1 |
9905- |
● |
|
● |
● |
● |
| |
8 |
WASHER; PL,AIR CMPR
ID=15 OD=26
|
9-09164-514-0 |
03 |
1 |
9603-9706 |
● |
|
|
|
|
| |
8 |
WASHER; PL,AIR CMPR
ID=15 OD=26
|
9-09164-514-0 |
03 |
1 |
9707-9804 |
● |
● |
|
|
|
| |
8 |
WASHER; PL,AIR CMPR
ID=15 OD=26
|
9-09164-514-0 |
03 |
1 |
9805-9904 |
● |
● |
● |
|
|
| |
8 |
WASHER; PL,AIR CMPR
ID=15 OD=26
|
9-09164-514-0 |
03 |
1 |
9905- |
● |
|
● |
● |
● |
| |
19 |
GEAR; INJ PUMP
Z=54
|
1-12524-087-6 |
01 |
1 |
9603-9604 |
● |
|
|
|
|
| |
19 |
GEAR; INJ PUMP
Z=54
|
1-12524-111-1 |
01 |
1 |
9605-9706 |
● |
|
|
|
|
| |
19 |
GEAR; INJ PUMP
Z=54
|
1-12524-111-1 |
01 |
1 |
9707-9804 |
● |
● |
|
|
|
| |
19 |
GEAR; INJ PUMP
Z=54
|
1-12524-111-1 |
01 |
1 |
9805-9904 |
● |
● |
● |
|
|
| |
19 |
GEAR; INJ PUMP
Z=54
|
1-12524-111-1 |
01 |
1 |
9905- |
● |
|
● |
● |
● |
| |
20 |
BOLT; GEAR TO SHAFT
M12X39 FLANGE
|
1-09070-116-0 |
05 |
1 |
9603-9706 |
● |
|
|
|
|
| |
20 |
BOLT; GEAR TO SHAFT
M12X39 FLANGE
|
1-09070-116-0 |
05 |
1 |
9707-9804 |
● |
● |
|
|
|
| |
20 |
BOLT; GEAR TO SHAFT
M12X39 FLANGE
|
1-09070-116-0 |
05 |
1 |
9805-9904 |
● |
● |
● |
|
|
| |
20 |
BOLT; GEAR TO SHAFT
M12X39 FLANGE
|
1-09070-116-0 |
05 |
1 |
9905- |
● |
|
● |
● |
● |
| |
24 |
POINTER; AIR CMPR
|
1-11327-017-0 |
01 |
1 |
9603-9706 |
● |
|
|
|
|
| |
24 |
POINTER; AIR CMPR
|
1-11327-017-0 |
01 |
1 |
9707-9804 |
● |
● |
|
|
|
| |
24 |
POINTER; AIR CMPR
|
1-11327-017-0 |
01 |
1 |
9805-9904 |
● |
● |
● |
|
|
| |
24 |
POINTER; AIR CMPR
|
1-11327-017-1 |
01 |
1 |
9905- |
● |
|
● |
● |
● |
| |
27 |
HOSE; AIR CMPR,SUCTION
(B)
|
0-02117-080-0 |
02 |
1 |
9603-9706 |
● |
|
|
|
|
| |
27 |
HOSE; AIR CMPR,SUCTION
(B)
|
0-02117-080-0 |
02 |
1 |
9707-9804 |
● |
● |
|
|
|
| |
27 |
HOSE; AIR CMPR,SUCTION
(B)
|
0-02117-080-0 |
02 |
1 |
9805-9904 |
● |
● |
● |
|
|
| |
27 |
HOSE; AIR CMPR,SUCTION
(A)
|
1-09360-916-0 |
02 |
1 |
9603-9706 |
● |
|
|
|
|
| |
27 |
HOSE; AIR CMPR,SUCTION
(A)
|
1-09360-916-0 |
02 |
1 |
9707-9804 |
● |
● |
|
|
|
| |
27 |
HOSE; AIR CMPR,SUCTION
(A)
|
1-09360-916-0 |
02 |
1 |
9805-9904 |
● |
● |
● |
|
|
| |
27 |
HOSE; AIR CMPR,SUCTION
(B)
|
0-02117-080-0 |
02 |
1 |
9905- |
● |
|
● |
● |
● |
| |
27 |
HOSE; AIR CMPR,SUCTION
(A)
|
1-09360-916-0 |
02 |
1 |
9905- |
● |
|
● |
● |
● |
| |
28 |
CLIP; HOSE,AIR CMPR
ID=22.7
|
8-94466-382-0 |
08 |
1 |
9603-9706 |
● |
|
|
|
|
| |
28 |
CLIP; HOSE,AIR CMPR
ID=22.7
|
8-94466-382-0 |
08 |
1 |
9707-9804 |
● |
● |
|
|
|
| |
28 |
CLIP; HOSE,AIR CMPR
ID=22.7
|
8-94466-382-0 |
08 |
1 |
9805-9904 |
● |
● |
● |
|
|
| |
28 |
CLIP; HOSE,AIR CMPR
ID=22.7
|
8-94466-382-0 |
08 |
1 |
9905- |
● |
|
● |
● |
● |
| |
31 |
PIPE; AIR,AIR CMPR SUCTION
(A)
|
1-19192-659-0 |
01 |
1 |
9603-9804 |
● |
|
|
|
|
| |
31 |
PIPE; AIR,AIR CMPR SUCTION
(A)
|
1-19192-659-0 |
01 |
1 |
9805-9904 |
● |
|
● |
|
|
| |
31 |
PIPE; AIR,AIR CMPR SUCTION
(B)
|
1-19192-993-0 |
01 |
1 |
9603-9804 |
● |
|
|
|
|
| |
31 |
PIPE; AIR,AIR CMPR SUCTION
(B)
|
1-19192-993-0 |
01 |
1 |
9805-9904 |
● |
|
● |
|
|
| |
31 |
PIPE; AIR,AIR CMPR SUCTION
(A)
|
1-19192-991-0 |
01 |
1 |
9707-9904 |
|
● |
|
|
|
| |
31 |
PIPE; AIR,AIR CMPR SUCTION
(B)
|
1-19192-992-0 |
01 |
1 |
9707-9904 |
|
● |
|
|
|
| |
31 |
PIPE; AIR,AIR CMPR SUCTION
CAB UP +110MM<TGG>
(A)
|
1-19192-991-0 |
01 |
1 |
9905- |
|
|
● |
|
|
| |
31 |
PIPE; AIR,AIR CMPR SUCTION
SHORT CHASSIS&RHD(EXZ5MC)
(A)
|
1-19192-991-0 |
01 |
1 |
9905- |
|
|
|
|
● |
| |
31 |
PIPE; AIR,AIR CMPR SUCTION
CAB UP +110MM<TGG>
(B)
|
1-19192-992-0 |
01 |
1 |
9905- |
|
|
● |
|
|
| |
31 |
PIPE; AIR,AIR CMPR SUCTION
SHORT CHASSIS&RHD(EXZ5MC)
(B)
|
1-19192-992-0 |
01 |
1 |
9905- |
|
|
|
|
● |
| |
31 |
PIPE; AIR,AIR CMPR SUCTION
(A)
|
1-19192-659-0 |
01 |
1 |
9905- |
● |
|
|
● |
|
| |
31 |
PIPE; AIR,AIR CMPR SUCTION
EXC. CAB UP +110MM<TGG>
(A)
|
1-19192-659-0 |
01 |
1 |
9905- |
|
|
● |
|
|
| |
31 |
PIPE; AIR,AIR CMPR SUCTION
(B)
|
1-19192-993-0 |
01 |
1 |
9905- |
● |
|
|
● |
|
| |
31 |
PIPE; AIR,AIR CMPR SUCTION
EXC. CAB UP +110MM<TGG>
(B)
|
1-19192-993-0 |
01 |
1 |
9905- |
|
|
● |
|
|
| |
33 |
NUT; PIPE FIX
M8 FLANGE
|
0-91150-108-0 |
02 |
1 |
9603-9706 |
● |
|
|
|
|
| |
33 |
NUT; PIPE FIX
M8 FLANGE
|
0-91150-108-0 |
02 |
1 |
9707-9804 |
● |
● |
|
|
|
| |
33 |
NUT; PIPE FIX
M8 FLANGE
|
0-91150-108-0 |
02 |
1 |
9805-9904 |
● |
● |
● |
|
|
| |
33 |
NUT; PIPE FIX
M8 FLANGE
|
0-91150-108-0 |
02 |
1 |
9905- |
● |
|
● |
● |
● |
| |
34 |
NUT; LK SUCTION PIPE
|
9-09840-254-0 |
02 |
1 |
9603-9706 |
● |
|
|
|
|
| |
34 |
NUT; LK SUCTION PIPE
|
9-09840-254-0 |
02 |
1 |
9707-9804 |
● |
● |
|
|
|
| |
34 |
NUT; LK SUCTION PIPE
|
9-09840-254-0 |
02 |
1 |
9805-9904 |
● |
● |
● |
|
|
| |
34 |
NUT; LK SUCTION PIPE
|
9-09840-254-0 |
02 |
1 |
9905- |
● |
|
● |
● |
● |
| |
49 |
PIPE; AIR,CHARGE
(A)
|
9-19119-032-0 |
02 |
1 |
9603-9706 |
● |
|
|
|
|
| |
49 |
PIPE; AIR,CHARGE
(A)
|
9-19119-032-0 |
02 |
1 |
9707-9804 |
● |
● |
|
|
|
| |
49 |
PIPE; AIR,CHARGE
(A)
|
9-19119-032-0 |
02 |
1 |
9805-9904 |
● |
● |
● |
|
|
| |
49 |
PIPE; AIR,CHARGE
INJ PUMP HIGH ALTITUDE ANEROID COMPENSATOR(YC4)
(B)
|
1-19192-985-0 |
01 |
1 |
9604-9904 |
● |
|
|
|
|
| |
49 |
PIPE; AIR,CHARGE
EXC. INJ PUMP HIGH ALTITUDE ANEROID COMPENSATOR
(YC4)
(B)
|
1-19192-661-2 |
01 |
1 |
9603-9706 |
● |
|
|
|
|
| |
49 |
PIPE; AIR,CHARGE
EXC. INJ PUMP HIGH ALTITUDE ANEROID COMPENSATOR
(YC4)
(B)
|
1-19192-661-2 |
01 |
1 |
9707-9804 |
● |
|
|
|
|
| |
49 |
PIPE; AIR,CHARGE
(B)
|
1-19192-661-2 |
01 |
1 |
9707-9804 |
|
● |
|
|
|
| |
49 |
PIPE; AIR,CHARGE
EXC. INJ PUMP HIGH ALTITUDE ANEROID COMPENSATOR
(YC4)
(B)
|
1-19192-661-2 |
01 |
1 |
9805-9904 |
● |
|
|
|
|
| |
49 |
PIPE; AIR,CHARGE
(B)
|
1-19192-661-2 |
01 |
1 |
9805-9904 |
|
● |
● |
|
|
| |
49 |
PIPE; AIR,CHARGE
(B)
|
1-19192-661-2 |
01 |
1 |
9905- |
● |
|
● |
● |
● |
| |
49 |
PIPE; AIR,CHARGE
(A)
|
9-19119-032-0 |
02 |
1 |
9905- |
● |
|
● |
● |
● |
| |
51 |
BOLT; EYE,AIR PIPE TO CMPR
(B)
M24X39
|
1-09675-175-1 |
02 |
1 |
9603-9706 |
● |
|
|
|
|
| |
51 |
BOLT; EYE,AIR PIPE TO CMPR
(B)
M24X39
|
1-09675-175-1 |
02 |
1 |
9707-9804 |
● |
● |
|
|
|
| |
51 |
BOLT; EYE,AIR PIPE TO CMPR
(B)
M24X39
|
1-09675-175-1 |
02 |
1 |
9805-9904 |
● |
● |
● |
|
|
| |
51 |
BOLT; EYE,AIR PIPE TO CMPR
EXC. EURO2 SPECIFICATION<THN>
(A)
M10X21 FLANGE
|
1-09675-077-0 |
01 |
1 |
9603-9804 |
● |
|
|
|
|
| |
51 |
BOLT; EYE,AIR PIPE TO CMPR
EXC. EURO2 SPECIFICATION<THN>
(A)
M10X21 FLANGE
|
1-09675-077-0 |
01 |
1 |
9805-9904 |
● |
|
|
|
|
| |
51 |
BOLT; EYE,AIR PIPE TO CMPR
(A)
M10X21 FLANGE
|
1-09675-077-0 |
01 |
1 |
9805-9904 |
|
|
● |
|
|
| |
51 |
BOLT; EYE,AIR PIPE TO CMPR
(A)
M10X21 FLANGE
|
1-09675-077-0 |
01 |
1 |
9905- |
● |
|
|
● |
|
| |
51 |
BOLT; EYE,AIR PIPE TO CMPR
EXC. ELECTRONIC GOV RED3(KG5)
(A)
M10X21 FLANGE
|
1-09675-077-0 |
01 |
1 |
9905- |
|
|
● |
|
|
| |
51 |
BOLT; EYE,AIR PIPE TO CMPR
(B)
M24X39
|
1-09675-175-1 |
02 |
1 |
9905- |
● |
|
● |
● |
● |
| |
52 |
GASKET; EYE BOLT,AIR PIPE
ALSO INCLUDED IN GASKET SET(ENGINE).
(B)
ID=24.5 OD=32
|
9-09571-424-0 |
04 |
1 |
9603-9706 |
● |
|
|
|
|
| |
52 |
GASKET; EYE BOLT,AIR PIPE
ALSO INCLUDED IN GASKET SET(ENGINE).
(B)
ID=24.5 OD=32
|
9-09571-424-0 |
04 |
1 |
9707-9804 |
● |
● |
|
|
|
| |
52 |
GASKET; EYE BOLT,AIR PIPE
ALSO INCLUDED IN GASKET SET(ENGINE).
(B)
ID=24.5 OD=32
|
9-09571-424-0 |
04 |
1 |
9805-9904 |
● |
● |
● |
|
|
| |
52 |
GASKET; EYE BOLT,AIR PIPE
ALSO INCLUDED IN GASKET SET(ENGINE).
EXC. EURO2 SPECIFICATION<THN>
(A)
ID=10.2 OD=15.2
|
1-09630-083-0 |
02 |
1 |
9603-9804 |
● |
|
|
|
|
| |
52 |
GASKET; EYE BOLT,AIR PIPE
ALSO INCLUDED IN GASKET SET(ENGINE).
EXC. EURO2 SPECIFICATION<THN>.
(A)
ID=10.2 OD=15.2
|
1-09630-083-0 |
02 |
1 |
9805-9904 |
● |
|
|
|
|
| |
52 |
GASKET; EYE BOLT,AIR PIPE
ALSO INCLUDED IN GASKET SET(ENGINE).
(A)
ID=10.2 OD=15.2
|
1-09630-083-0 |
02 |
1 |
9805-9904 |
|
|
● |
|
|
| |
52 |
GASKET; EYE BOLT,AIR PIPE
ALSO INCLUDED IN GASKET SET(ENGINE).
|
1-09630-083-0 |
02 |
1 |
9905- |
● |
|
|
● |
|
| |
52 |
GASKET; EYE BOLT,AIR PIPE
ALSO INCLUDED IN GASKET SET(ENGINE).
EXC. ELECTRONIC GOV RED3(KG5)
(A)
ID=10.2 OD=15.2
|
1-09630-083-0 |
02 |
1 |
9905- |
|
|
● |
|
|
| |
52 |
GASKET; EYE BOLT,AIR PIPE
ALSO INCLUDED IN GASKET SET(ENGINE).
(B)
ID=24.5 OD=32
|
9-09571-424-0 |
04 |
1 |
9905- |
● |
|
● |
● |
● |
| |
68 |
SLEEVE; RUBBER
ID=18 OD=22 L=25
|
8-94412-773-0 |
02 |
1 |
9603-9706 |
● |
|
|
|
|
| |
68 |
SLEEVE; RUBBER
ID=18 OD=22 L=25
|
8-94412-773-0 |
02 |
1 |
9707-9804 |
● |
● |
|
|
|
| |
68 |
SLEEVE; RUBBER
ID=18 OD=22 L=25
|
8-94412-773-0 |
02 |
1 |
9805-9902 |
● |
● |
● |
|
|
| |
68 |
SLEEVE; RUBBER
EURO2 SPECIFICATION<THN>
ID=18 OD=22 L=25
|
8-94412-773-0 |
02 |
1 |
9903-9904 |
● |
|
|
|
|
| |
68 |
SLEEVE; RUBBER
SHORT CHASSIS&RHD(EXZ5MC)
ID=18 OD=22 L=25
|
8-94412-773-0 |
02 |
1 |
9903-9904 |
|
● |
|
|
|
| |
68 |
SLEEVE; RUBBER
EXC. EURO2 SPECIFICATION<THN>
ID=18 OD=22 L=25
|
8-94412-773-0 |
01 |
1 |
9903-9904 |
● |
|
|
|
|
| |
68 |
SLEEVE; RUBBER
ID=18 OD=22 L=25
|
8-94412-773-0 |
01 |
1 |
9903-9904 |
|
● |
● |
|
|
| |
68 |
SLEEVE; RUBBER
ID=18 OD=22 L=25
|
8-94412-773-0 |
02 |
1 |
9905- |
|
|
● |
|
● |
| |
68 |
SLEEVE; RUBBER
ID=18 OD=22 L=25
|
8-94412-773-0 |
01 |
1 |
9905- |
● |
|
● |
● |
● |
| |
70 |
WASHER; LK
ID=12.2
|
9-09150-512-0 |
01 |
1 |
9603-9706 |
● |
|
|
|
|
| |
70 |
WASHER; LK
ID=12.2
|
9-09150-512-0 |
01 |
1 |
9707-9804 |
● |
● |
|
|
|
| |
70 |
WASHER; LK
ID=12.2
|
9-09150-512-0 |
01 |
1 |
9805-9904 |
● |
● |
● |
|
|
| |
70 |
WASHER; LK
ID=12.2
|
9-09150-512-0 |
01 |
1 |
9905- |
● |
|
● |
● |
● |
| |
71 |
HOSE; FLEX,AIR GOV
L=520
|
0-07030-520-0 |
01 |
1 |
9603-9607 |
● |
|
|
|
|
| |
71 |
HOSE; FLEX,AIR GOV
L=520
|
1-09363-657-0 |
01 |
1 |
9608-9706 |
● |
|
|
|
|
| |
71 |
HOSE; FLEX,AIR GOV
L=520
|
1-09363-657-0 |
01 |
1 |
9707-9802 |
● |
● |
|
|
|
| |
71 |
HOSE; FLEX,AIR GOV
L=520
|
1-09363-657-0 |
01 |
1 |
9803-9804 |
● |
|
|
|
|
| |
71 |
HOSE; FLEX,AIR GOV
L=520
|
1-09363-657-0 |
01 |
1 |
9805-9904 |
● |
|
● |
|
|
| |
71 |
HOSE; FLEX,AIR GOV
L=560
|
1-09363-689-0 |
01 |
1 |
9803-9904 |
|
● |
|
|
|
| |
71 |
HOSE; FLEX,AIR GOV
L=520
|
1-09363-657-0 |
01 |
1 |
9905- |
● |
|
● |
● |
● |
| |
72 |
NUT; GOV HOSE
M12
|
9-09840-280-0 |
01 |
1 |
9603-9706 |
● |
|
|
|
|
| |
72 |
NUT; GOV HOSE
M12
|
9-09840-280-0 |
01 |
1 |
9707-9804 |
● |
● |
|
|
|
| |
72 |
NUT; GOV HOSE
M12
|
9-09840-280-0 |
01 |
1 |
9805-9904 |
● |
● |
● |
|
|
| |
72 |
NUT; GOV HOSE
M12
|
9-09840-280-0 |
01 |
1 |
9905- |
● |
|
● |
● |
● |
| |
79 |
BOLT; EYE,AIR PIPE TO CMPR
M14X27 FLANGE
|
1-09675-086-0 |
02 |
1 |
9603-9706 |
● |
|
|
|
|
| |
79 |
BOLT; EYE,AIR PIPE TO CMPR
M14X27 FLANGE
|
1-09675-086-0 |
02 |
1 |
9707-9804 |
● |
● |
|
|
|
| |
79 |
BOLT; EYE,AIR PIPE TO CMPR
M14X27 FLANGE
|
1-09675-086-0 |
02 |
1 |
9805-9904 |
● |
● |
● |
|
|
| |
79 |
BOLT; EYE,AIR PIPE TO CMPR
M14X27 FLANGE
|
1-09675-086-0 |
02 |
1 |
9905- |
● |
|
● |
● |
● |
| |
80 |
GASKET; AIR PIPE TO CMPR
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
ID=14.2 OD=19.2
|
1-09630-085-0 |
04 |
1 |
9603-9706 |
● |
|
|
|
|
| |
80 |
GASKET; AIR PIPE TO CMPR
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
ID=14.2 OD=19.2
|
1-09630-085-0 |
04 |
1 |
9707-9804 |
● |
● |
|
|
|
| |
80 |
GASKET; AIR PIPE TO CMPR
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
ID=14.2 OD=19.2
|
1-09630-085-0 |
04 |
1 |
9805-9904 |
● |
● |
● |
|
|
| |
80 |
GASKET; AIR PIPE TO CMPR
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
ID=14.2 OD=19.2
|
1-09630-085-0 |
04 |
1 |
9905- |
● |
|
● |
● |
● |
| |
87 |
BOLT; BRKT FIX
M10X18 FLANGE
|
0-28181-018-0 |
02 |
1 |
9603-9604 |
● |
|
|
|
|
| |
87 |
BOLT; BRKT FIX
M10X20 FLANGE
|
0-28181-020-0 |
02 |
1 |
9605-9706 |
● |
|
|
|
|
| |
87 |
BOLT; BRKT FIX
M10X20 FLANGE
|
0-28181-020-0 |
02 |
1 |
9707-9804 |
● |
● |
|
|
|
| |
87 |
BOLT; BRKT FIX
M10X20 FLANGE
|
0-28181-020-0 |
02 |
1 |
9805-9904 |
● |
● |
● |
|
|
| |
87 |
BOLT; BRKT FIX
M10X20 FLANGE
|
0-28181-020-0 |
02 |
1 |
9905- |
● |
|
● |
● |
● |
| |
90 |
CLIP; HARNESS
EURO2 SPECIFICATION<THN>
L=140
|
5-09707-031-0 |
02 |
1 |
9610-9706 |
● |
|
|
|
|
| |
90 |
CLIP; HARNESS
EURO2 SPECIFICATION<THN>
L=140
|
5-09707-031-1 |
02 |
1 |
9707-9904 |
● |
|
|
|
|
| |
90 |
CLIP; HARNESS
SHORT CHASSIS&RHD(EXZ5MC)
L=140
|
5-09707-031-1 |
02 |
1 |
9707-9904 |
|
● |
|
|
|
| |
90 |
CLIP; HARNESS
L=140
|
5-09707-031-1 |
02 |
1 |
9905- |
|
|
● |
|
● |
| |
94 |
PIPE; AIR,BOOST
EXC. EURO2 SPECIFICATION<THN>
|
1-19192-975-0 |
01 |
1 |
9603-9804 |
● |
|
|
|
|
| |
94 |
PIPE; AIR,BOOST
EXC. EURO2 SPECIFICATION<THN>
|
1-19192-975-0 |
01 |
1 |
9805-9904 |
● |
|
|
|
|
| |
94 |
PIPE; AIR,BOOST
|
1-19192-975-0 |
01 |
1 |
9805-9904 |
|
|
● |
|
|
| |
94 |
PIPE; AIR,BOOST
EURO2 SPECIFICATION<THN>
|
1-19193-109-0 |
01 |
1 |
9905- |
|
|
● |
|
|
| |
94 |
PIPE; AIR,BOOST
|
1-19192-975-0 |
01 |
1 |
9905- |
● |
|
|
● |
|
| |
110 |
CLIP; AIR PIPE
|
1-09701-210-0 |
02 |
1 |
9603-9706 |
● |
|
|
|
|
| |
110 |
CLIP; AIR PIPE
|
1-09701-210-0 |
02 |
1 |
9707-9804 |
● |
● |
|
|
|
| |
110 |
CLIP; AIR PIPE
|
1-09701-210-0 |
02 |
1 |
9805-9904 |
● |
● |
● |
|
|
| |
110 |
CLIP; AIR PIPE
|
1-09701-210-0 |
02 |
1 |
9905- |
● |
|
● |
● |
● |
| |
113 |
BOLT; CLIP,AIR PIPE
M6X40 FLANGE
|
0-28080-640-0 |
01 |
1 |
9603-9706 |
● |
|
|
|
|
| |
113 |
BOLT; CLIP,AIR PIPE
M6X40 FLANGE
|
0-28080-640-0 |
01 |
1 |
9707-9804 |
● |
● |
|
|
|
| |
113 |
BOLT; CLIP,AIR PIPE
M6X40 FLANGE
|
0-28080-640-0 |
01 |
1 |
9805-9904 |
● |
● |
● |
|
|
| |
113 |
BOLT; CLIP,AIR PIPE
M6X40 FLANGE
|
0-28080-640-0 |
01 |
1 |
9905- |
● |
|
● |
● |
● |
| |
115 |
BOLT; AIR PIPE
M10X18 FLANGE
|
0-28181-018-0 |
02 |
1 |
9603-9604 |
● |
|
|
|
|
| |
115 |
BOLT; AIR PIPE
M10X20 FLANGE
|
0-28181-020-0 |
02 |
1 |
9605-9706 |
● |
|
|
|
|
| |
115 |
BOLT; AIR PIPE
M10X20 FLANGE
|
0-28181-020-0 |
02 |
1 |
9707-9804 |
● |
● |
|
|
|
| |
115 |
BOLT; AIR PIPE
M10X20 FLANGE
|
0-28181-020-0 |
02 |
1 |
9805-9904 |
● |
● |
● |
|
|
| |
115 |
BOLT; AIR PIPE
M10X20 FLANGE
|
0-28181-020-0 |
02 |
1 |
9905- |
● |
|
● |
● |
● |
| |
116 |
BRACKET; AIR PIPE
|
1-19199-212-0 |
01 |
1 |
9603-9706 |
● |
|
|
|
|
| |
116 |
BRACKET; AIR PIPE
|
1-19199-212-0 |
01 |
1 |
9707-9804 |
● |
● |
|
|
|
| |
116 |
BRACKET; AIR PIPE
|
1-19199-212-0 |
01 |
1 |
9805-9904 |
● |
● |
● |
|
|
| |
116 |
BRACKET; AIR PIPE
|
1-19199-212-1 |
01 |
1 |
9905- |
● |
|
● |
● |
● |
| |
132 |
NUT; CLIP
EXC. EURO2 SPECIFICATION<THN>
M6 FLANGE
|
0-91150-106-0 |
01 |
1 |
9603-9801 |
● |
|
|
|
|
| |
132 |
NUT; CLIP
M6 FLANGE
|
0-91150-106-0 |
01 |
1 |
9802-9802 |
● |
|
|
|
|
| |
132 |
NUT; CLIP
EXC. EURO2 SPECIFICATION<THN>
M6 FLANGE
|
0-91150-106-0 |
01 |
1 |
9803-9804 |
● |
|
|
|
|
| |
132 |
NUT; CLIP
EXC. EURO2 SPECIFICATION<THN>
M6 FLANGE
|
0-91150-106-0 |
01 |
1 |
9805-9904 |
● |
|
|
|
|
| |
132 |
NUT; CLIP
M6 FLANGE
|
0-91150-106-0 |
01 |
1 |
9805-9904 |
|
|
● |
|
|
| |
132 |
NUT; CLIP
M6 FLANGE
|
0-91150-106-0 |
01 |
1 |
9905- |
● |
|
|
● |
|
| |
132 |
NUT; CLIP
EXC. ELECTRONIC GOV RED3(KG5)
M6 FLANGE
|
0-91150-106-0 |
01 |
1 |
9905- |
|
|
● |
|
|
| |
176 |
BOLT; BRKT FIX
M10X135
|
8-94397-139-1 |
01 |
1 |
9603-9706 |
● |
|
|
|
|
| |
176 |
BOLT; BRKT FIX
M10X135
|
8-94397-139-1 |
01 |
1 |
9707-9804 |
● |
● |
|
|
|
| |
176 |
BOLT; BRKT FIX
M10X135
|
8-94397-139-1 |
01 |
1 |
9805-9904 |
● |
● |
● |
|
|
| |
176 |
BOLT; BRKT FIX
M10X135
|
8-94397-139-1 |
01 |
1 |
9905- |
● |
|
● |
● |
● |
| |
179 |
CLIP; PIPE
EXC. EURO2 SPECIFICATION<THN>
|
1-09701-132-0 |
02 |
1 |
9603-9801 |
● |
|
|
|
|
| |
179 |
CLIP; PIPE
|
1-09701-132-0 |
02 |
1 |
9802-9802 |
● |
|
|
|
|
| |
179 |
CLIP; PIPE
EXC. EURO2 SPECIFICATION<THN>
|
1-09701-132-0 |
02 |
1 |
9803-9804 |
● |
|
|
|
|
| |
179 |
CLIP; PIPE
EXC. EURO2 SPECIFICATION<THN>
|
1-09701-132-0 |
02 |
1 |
9805-9904 |
● |
|
|
|
|
| |
179 |
CLIP; PIPE
|
1-09701-132-0 |
02 |
1 |
9805-9904 |
|
|
● |
|
|
| |
179 |
CLIP; PIPE
|
1-09701-132-1 |
02 |
1 |
9905- |
● |
|
|
● |
|
| |
179 |
CLIP; PIPE
EXC. ELECTRONIC GOV RED3(KG5)
|
1-09701-132-1 |
02 |
1 |
9905- |
|
|
● |
|
|
| |
213 |
PIN; AIR CMPR GEAR
OD=5 L=10
|
9-08150-510-0 |
01 |
1 |
9603-9706 |
● |
|
|
|
|
| |
213 |
PIN; AIR CMPR GEAR
OD=5 L=10
|
9-08150-510-0 |
01 |
1 |
9707-9804 |
● |
● |
|
|
|
| |
213 |
PIN; AIR CMPR GEAR
OD=5 L=10
|
9-08150-510-0 |
01 |
1 |
9805-9904 |
● |
● |
● |
|
|
| |
213 |
PIN; AIR CMPR GEAR
OD=5 L=10
|
9-08150-510-0 |
01 |
1 |
9905- |
● |
|
● |
● |
● |
| |
231 |
INSULATOR; HEAD COVER
|
1-19389-208-1 |
01 |
1 |
9707-9904 |
|
● |
|
|
|
| |
231 |
INSULATOR; HEAD COVER
|
1-19389-208-1 |
01 |
1 |
9905- |
|
|
|
|
● |
| |
232 |
BOLT; INSULATOR
M8X12 FLANGE
|
0-28080-812-0 |
01 |
1 |
9707-9904 |
|
● |
|
|
|
| |
232 |
BOLT; INSULATOR
M8X12 FLANGE
|
0-28080-812-0 |
01 |
1 |
9905- |
|
|
|
|
● |
| |
233 |
RING; FRICTION
|
1-12529-003-0 |
01 |
1 |
9707-9904 |
|
● |
|
|
|
| |
233 |
RING; FRICTION
|
1-12529-003-0 |
01 |
1 |
9905- |
|
|
|
|
● |
