1 |
HEAD ASM; CYL
|
1-11110-774-9 |
01 |
1 |
9603-9607 |
● |
|
|
|
|
| |
1 |
HEAD ASM; CYL
|
1-11110-872-1 |
01 |
1 |
9608-9710 |
● |
|
|
|
|
| |
1 |
HEAD ASM; CYL
|
1-11110-891-0 |
01 |
1 |
9711-9804 |
● |
|
|
|
|
| |
1 |
HEAD ASM; CYL
|
1-11110-902-0 |
01 |
1 |
9805-9904 |
● |
● |
|
|
|
| |
1 |
HEAD ASM; CYL
|
1-11110-902-5 |
01 |
1 |
9905- |
● |
● |
● |
|
|
| |
1 |
HEAD ASM; CYL
|
1-11110-861-8 |
01 |
1 |
9707-9904 |
|
|
|
● |
|
| |
1 |
HEAD ASM; CYL
|
1-11110-861-9 |
01 |
1 |
9905- |
|
|
|
|
● |
| |
2 |
GASKET; CYL HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
|
1-11141-227-2 |
01 |
1 |
9603-9607 |
● |
|
|
|
|
| |
2 |
GASKET; CYL HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
|
1-11141-264-0 |
01 |
1 |
9608-9802 |
● |
|
|
|
|
| |
2 |
GASKET; CYL HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
|
1-11141-271-0 |
01 |
1 |
9803-9804 |
● |
|
|
|
|
| |
2 |
GASKET; CYL HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
|
1-11141-271-0 |
01 |
1 |
9805-9904 |
● |
● |
|
|
|
| |
2 |
GASKET; CYL HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
|
1-11141-271-2 |
01 |
1 |
9905- |
● |
● |
● |
|
|
| |
2 |
GASKET; CYL HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
|
1-11141-265-1 |
01 |
1 |
9707-9904 |
|
|
|
● |
|
| |
2 |
GASKET; CYL HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
|
1-11141-265-3 |
01 |
1 |
9905- |
|
|
|
|
● |
| |
3 |
BOLT; CYL HD TO BLOCK
(A)
M10X35 FLANGE
|
0-28181-035-0 |
02 |
1 |
9603-9706 |
● |
|
|
|
|
| |
3 |
BOLT; CYL HD TO BLOCK
(A)
M10X35 FLANGE
|
0-28181-035-0 |
02 |
1 |
9707-9804 |
● |
|
|
● |
|
| |
3 |
BOLT; CYL HD TO BLOCK
(A)
M10X35 FLANGE
|
0-28181-035-0 |
02 |
1 |
9805-9904 |
● |
● |
|
● |
|
| |
3 |
BOLT; CYL HD TO BLOCK
(B)
M12X110
|
1-09030-089-0 |
01 |
1 |
9603-9607 |
● |
|
|
|
|
| |
3 |
BOLT; CYL HD TO BLOCK
(C)
M12X120
|
1-09044-070-0 |
01 |
1 |
9603-9607 |
● |
|
|
|
|
| |
3 |
BOLT; CYL HD TO BLOCK
(C)
M12X120 FLANGE
|
0-28186-212-0 |
01 |
1 |
9608-9706 |
● |
|
|
|
|
| |
3 |
BOLT; CYL HD TO BLOCK
(C)
M12X120 FLANGE
|
0-28186-212-0 |
01 |
1 |
9707-9804 |
● |
|
|
● |
|
| |
3 |
BOLT; CYL HD TO BLOCK
(C)
M12X120 FLANGE
|
0-28186-212-0 |
01 |
1 |
9805-9904 |
● |
● |
|
● |
|
| |
3 |
BOLT; CYL HD TO BLOCK
(D)
M18X115
|
1-09070-114-0 |
06 |
1 |
9603-9706 |
● |
|
|
|
|
| |
3 |
BOLT; CYL HD TO BLOCK
(D)
M18X115
|
1-09070-114-1 |
06 |
1 |
9707-9804 |
● |
|
|
● |
|
| |
3 |
BOLT; CYL HD TO BLOCK
(D)
M18X115
|
1-09070-114-2 |
06 |
1 |
9805-9805 |
● |
● |
|
● |
|
| |
3 |
BOLT; CYL HD TO BLOCK
(E)
M18X159
|
1-09070-115-0 |
20 |
1 |
9603-9706 |
● |
|
|
|
|
| |
3 |
BOLT; CYL HD TO BLOCK
(E)
M18X159
|
1-09070-115-1 |
20 |
1 |
9707-9804 |
● |
|
|
● |
|
| |
3 |
BOLT; CYL HD TO BLOCK
(E)
M18X159
|
1-09070-115-2 |
20 |
1 |
9805-9805 |
● |
● |
|
● |
|
| |
3 |
BOLT; CYL HD TO BLOCK
(D)
M18X115
|
1-09070-114-2 |
06 |
1 |
9806-9902 |
● |
● |
|
● |
|
| |
3 |
BOLT; CYL HD TO BLOCK
(D)
M18X115 FLANGE
|
1-09070-141-0 |
06 |
1 |
9903-9904 |
● |
● |
|
● |
|
| |
3 |
BOLT; CYL HD TO BLOCK
(E)
M18X159
|
1-09070-115-2 |
20 |
1 |
9806-9902 |
● |
● |
|
● |
|
| |
3 |
BOLT; CYL HD TO BLOCK
(E)
M18X159
|
1-09070-142-0 |
20 |
1 |
9903-9904 |
● |
● |
|
● |
|
| |
3 |
BOLT; CYL HD TO BLOCK
(A)
M10X35 FLANGE
|
0-28181-035-0 |
02 |
1 |
9905- |
● |
● |
● |
|
● |
| |
3 |
BOLT; CYL HD TO BLOCK
(C)
M12X120 FLANGE
|
0-28186-212-0 |
01 |
1 |
9905- |
● |
● |
● |
|
● |
| |
3 |
BOLT; CYL HD TO BLOCK
(D)
M18X115 FLANGE
|
1-09070-141-0 |
06 |
1 |
9905- |
● |
● |
● |
|
● |
| |
3 |
BOLT; CYL HD TO BLOCK
(E)
M18X159
|
1-09070-142-0 |
20 |
1 |
9905- |
● |
● |
● |
|
● |
| |
4 |
GUIDE; VLV
|
1-11721-004-0 |
24 |
1 |
9603-9706 |
● |
|
|
|
|
| |
4 |
GUIDE; VLV
|
1-11721-004-0 |
24 |
1 |
9707-9804 |
● |
|
|
● |
|
| |
4 |
GUIDE; VLV
|
1-11721-004-0 |
24 |
1 |
9805-9904 |
● |
● |
|
● |
|
| |
4 |
GUIDE; VLV
|
1-11721-004-0 |
24 |
1 |
9905-0005 |
● |
● |
● |
|
● |
| |
4 |
GUIDE; VLV
|
1-11721-012-0 |
24 |
1 |
0006- |
● |
● |
● |
|
● |
| |
5 |
SEAT; VLV INSERT
(A) EXHAUST
|
1-11711-057-4 |
12 |
1 |
9603-9710 |
● |
|
|
|
|
| |
5 |
SEAT; VLV INSERT
(A) EXHAUST
|
1-11711-076-0 |
12 |
1 |
9711-9804 |
● |
|
|
|
|
| |
5 |
SEAT; VLV INSERT
(A) EXHAUST
|
1-11711-076-0 |
12 |
1 |
9805-9904 |
● |
● |
|
|
|
| |
5 |
SEAT; VLV INSERT
(A) EXHAUST
|
1-11711-076-0 |
12 |
1 |
9905- |
● |
● |
● |
|
|
| |
5 |
SEAT; VLV INSERT
(B) INLET
|
1-11715-091-1 |
12 |
1 |
9603-9611 |
● |
|
|
|
|
| |
5 |
SEAT; VLV INSERT
(B) INLET
|
1-11715-107-0 |
12 |
1 |
9612-9710 |
● |
|
|
|
|
| |
5 |
SEAT; VLV INSERT
(B) INLET
|
1-11715-111-0 |
12 |
1 |
9711-9804 |
● |
|
|
|
|
| |
5 |
SEAT; VLV INSERT
(B) INLET
|
1-11715-111-0 |
12 |
1 |
9805-9904 |
● |
● |
|
|
|
| |
5 |
SEAT; VLV INSERT
(B) INLET
|
1-11715-111-0 |
12 |
1 |
9905- |
● |
● |
● |
|
|
| |
5 |
SEAT; VLV INSERT
(A) EXHAUST
|
1-11711-070-0 |
12 |
1 |
9707-9904 |
|
|
|
● |
|
| |
5 |
SEAT; VLV INSERT
(A) EXHAUST
|
1-11711-070-0 |
12 |
1 |
9905-0005 |
|
|
|
|
● |
| |
5 |
SEAT; VLV INSERT
(A) EXHAUST
|
1-11711-077-0 |
12 |
1 |
0006- |
|
|
|
|
● |
| |
5 |
SEAT; VLV INSERT
(B) INLET
|
1-11715-105-1 |
12 |
1 |
9707-9904 |
|
|
|
● |
|
| |
5 |
SEAT; VLV INSERT
(B) INLET
|
1-11715-105-1 |
12 |
1 |
9905-0005 |
|
|
|
|
● |
| |
5 |
SEAT; VLV INSERT
(B) INLET
|
1-11715-112-0 |
12 |
1 |
0006- |
|
|
|
|
● |
| |
8 |
CUP; SEALING,WATER JACKET
(A)
OD=32
|
1-09600-012-1 |
03 |
1 |
9603-9603 |
● |
|
|
|
|
| |
8 |
CUP; SEALING,WATER JACKET
(A)
OD=32
|
1-09600-012-1 |
03 |
1 |
9604-9804 |
● |
|
|
|
|
| |
8 |
CUP; SEALING,WATER JACKET
(A)
OD=32
|
1-09600-012-1 |
03 |
1 |
9805-9904 |
● |
● |
|
|
|
| |
8 |
CUP; SEALING,WATER JACKET
(A)
OD=32
|
1-09600-012-2 |
03 |
1 |
9905- |
● |
● |
● |
|
|
| |
8 |
CUP; SEALING,WATER JACKET
(B)
OD=25
|
1-09600-016-0 |
09 |
1 |
9603-9804 |
● |
|
|
|
|
| |
8 |
CUP; SEALING,WATER JACKET
(B)
OD=25
|
1-09600-016-0 |
09 |
1 |
9805-9904 |
● |
● |
|
|
|
| |
8 |
CUP; SEALING,WATER JACKET
(C)
OD=12.3
|
5-09600-013-0 |
02 |
1 |
9603-9701 |
● |
|
|
|
|
| |
8 |
CUP; SEALING,WATER JACKET
(D)
OD=16
|
5-11129-006-0 |
06 |
1 |
9603-9706 |
● |
|
|
|
|
| |
8 |
CUP; SEALING,WATER JACKET
(D)
OD=16
|
5-11129-006-0 |
06 |
1 |
9707-9801 |
● |
|
|
● |
|
| |
8 |
CUP; SEALING,WATER JACKET
(E)
OD=18
|
5-11219-008-0 |
12 |
1 |
9603-9706 |
● |
|
|
|
|
| |
8 |
CUP; SEALING,WATER JACKET
(E)
OD=18
|
5-11219-008-0 |
12 |
1 |
9707-9801 |
● |
|
|
● |
|
| |
8 |
CUP; SEALING,WATER JACKET
(F)
OD=40
|
8-94241-637-0 |
18 |
1 |
9603-9706 |
● |
|
|
|
|
| |
8 |
CUP; SEALING,WATER JACKET
(F)
OD=40
|
8-94241-637-0 |
18 |
1 |
9707-9801 |
● |
|
|
● |
|
| |
8 |
CUP; SEALING,WATER JACKET
(C)
OD=12.3
|
5-09600-013-0 |
02 |
1 |
9702-9706 |
● |
|
|
|
|
| |
8 |
CUP; SEALING,WATER JACKET
(C)
OD=12.3
|
5-09600-013-0 |
02 |
1 |
9707-9804 |
● |
|
|
● |
|
| |
8 |
CUP; SEALING,WATER JACKET
(C)
OD=12.3
|
5-09600-013-0 |
02 |
1 |
9805-9903 |
● |
● |
|
● |
|
| |
8 |
CUP; SEALING,WATER JACKET
(D)
OD=16
|
5-11129-006-0 |
06 |
1 |
9802-9804 |
● |
|
|
● |
|
| |
8 |
CUP; SEALING,WATER JACKET
(D)
OD=16
|
5-11129-006-0 |
06 |
1 |
9805-9904 |
● |
● |
|
● |
|
| |
8 |
CUP; SEALING,WATER JACKET
(E)
OD=18
|
5-11219-008-0 |
12 |
1 |
9802-9802 |
● |
|
|
● |
|
| |
8 |
CUP; SEALING,WATER JACKET
(B)
OD=25
|
1-09600-016-0 |
09 |
1 |
9905- |
● |
● |
● |
|
|
| |
8 |
CUP; SEALING,WATER JACKET
(E)
OD=18
|
5-11219-008-0 |
12 |
1 |
9803-9804 |
● |
|
|
● |
|
| |
8 |
CUP; SEALING,WATER JACKET
(E)
OD=18
|
5-11219-008-0 |
12 |
1 |
9805-9903 |
● |
● |
|
● |
|
| |
8 |
CUP; SEALING,WATER JACKET
(F)
OD=40
|
8-94241-637-0 |
18 |
1 |
9802-9804 |
● |
|
|
● |
|
| |
8 |
CUP; SEALING,WATER JACKET
(F)
OD=40
|
8-94241-637-0 |
18 |
1 |
9805-9904 |
● |
● |
|
● |
|
| |
8 |
CUP; SEALING,WATER JACKET
(C)
OD=12.3
|
5-09600-013-0 |
02 |
1 |
9904-9904 |
● |
● |
|
● |
|
| |
8 |
CUP; SEALING,WATER JACKET
(E)
OD=18
|
5-11219-008-0 |
12 |
1 |
9904-9904 |
● |
● |
|
● |
|
| |
8 |
CUP; SEALING,WATER JACKET
(A)
OD=32
|
1-09600-012-1 |
02 |
1 |
9707-9904 |
|
|
|
● |
|
| |
8 |
CUP; SEALING,WATER JACKET
(B)
OD=25
|
1-09600-016-0 |
10 |
1 |
9707-9904 |
|
|
|
● |
|
| |
8 |
CUP; SEALING,WATER JACKET
(B)
OD=25
|
1-09600-016-0 |
10 |
1 |
9905- |
|
|
|
|
● |
| |
8 |
CUP; SEALING,WATER JACKET
(A)
OD=32
|
1-09600-012-2 |
02 |
1 |
9905- |
|
|
|
|
● |
| |
8 |
CUP; SEALING,WATER JACKET
(C)
OD=12.3
|
5-09600-013-0 |
02 |
1 |
9905- |
● |
● |
● |
|
● |
| |
8 |
CUP; SEALING,WATER JACKET
(D)
OD=16
|
5-11129-006-0 |
06 |
1 |
9905- |
● |
● |
● |
|
● |
| |
8 |
CUP; SEALING,WATER JACKET
(E)
OD=18
|
5-11219-008-0 |
12 |
1 |
9905- |
● |
● |
● |
|
● |
| |
8 |
CUP; SEALING,WATER JACKET
(F)
OD=40
|
8-94241-637-0 |
18 |
1 |
9905- |
● |
● |
● |
|
● |
| |
9 |
STUD; INL MANIF
M10X13,M10X17 L=65
|
1-09309-008-0 |
12 |
1 |
9603-9706 |
● |
|
|
|
|
| |
9 |
STUD; INL MANIF
M10X13,M10X17 L=65
|
1-09309-008-0 |
12 |
1 |
9707-9804 |
● |
|
|
● |
|
| |
9 |
STUD; INL MANIF
M10X13,M10X17 L=65
|
1-09309-008-0 |
12 |
1 |
9805-9904 |
● |
● |
|
● |
|
| |
9 |
STUD; INL MANIF
M10X13,M10X17 L=65
|
1-09309-008-0 |
12 |
1 |
9905- |
● |
● |
● |
|
● |
| |
10 |
PLUG; GLOW
SHORT CHASSIS&LHD(EXZ6MC)
GLOW SYSTEM-FAST DIESEL ENGINE<KM6>
|
9-82513-928-9 |
06 |
1 |
9603-9809 |
● |
|
|
|
|
| |
10 |
PLUG; GLOW
SHORT CHASSIS&LHD(EXZ6MC)
GLOW SYSTEM-FAST DIESEL ENGINE<KM6>
|
1-82513-043-0 |
06 |
1 |
9810-9904 |
● |
|
|
|
|
| |
10 |
PLUG; GLOW
SHORT CHASSIS&LHD(EXZ6MC)
GLOW SYSTEM-FAST DIESEL ENGINE<KM6>
|
1-82513-043-2 |
06 |
1 |
9905- |
|
● |
|
|
|
| |
11 |
CONNECTOR; GLOW PLUG
SHORT CHASSIS&LHD(EXZ6MC)
GLOW SYSTEM-FAST DIESEL ENGINE<KM6>
|
1-19732-030-1 |
01 |
1 |
9603-9904 |
● |
|
|
|
|
| |
11 |
CONNECTOR; GLOW PLUG
SHORT CHASSIS&LHD(EXZ6MC)
GLOW SYSTEM-FAST DIESEL ENGINE<KM6>
|
1-19732-030-2 |
01 |
1 |
9905- |
|
● |
|
|
|
| |
12 |
HANGER; ENG,RR
(A) REAR
|
1-11777-149-2 |
02 |
1 |
9603-9706 |
● |
|
|
|
|
| |
12 |
HANGER; ENG,RR
(A) REAR
|
1-11777-149-2 |
02 |
1 |
9707-9804 |
● |
|
|
● |
|
| |
12 |
HANGER; ENG,RR
(A) REAR
|
1-11777-149-2 |
02 |
1 |
9805-9904 |
● |
● |
|
● |
|
| |
12 |
HANGER; ENG,RR
(B) FRONT
|
1-11777-156-2 |
01 |
1 |
9603-9607 |
● |
|
|
|
|
| |
12 |
HANGER; ENG,RR
(B) FRONT
|
1-11777-216-1 |
01 |
1 |
9608-9706 |
● |
|
|
|
|
| |
12 |
HANGER; ENG,RR
(B) FRONT
|
1-11777-216-1 |
01 |
1 |
9707-9804 |
● |
|
|
● |
|
| |
12 |
HANGER; ENG,RR
(B) FRONT
|
1-11777-216-1 |
01 |
1 |
9805-9904 |
● |
● |
|
● |
|
| |
12 |
HANGER; ENG,RR
(A) REAR
|
1-11777-149-2 |
02 |
1 |
9905- |
● |
● |
● |
|
● |
| |
12 |
HANGER; ENG,RR
(B) FRONT
|
1-11777-216-1 |
01 |
1 |
9905- |
● |
● |
● |
|
● |
| |
14 |
STUD; EXH MANIF
(A)
M10X95 L=110
|
1-09302-063-0 |
15 |
1 |
9603-9706 |
● |
|
|
|
|
| |
14 |
STUD; EXH MANIF
(A)
M10X95 L=110
|
1-09302-063-0 |
15 |
1 |
9707-9804 |
● |
|
|
● |
|
| |
14 |
STUD; EXH MANIF
(A)
M10X95 L=110
|
1-09302-063-0 |
15 |
1 |
9805-9904 |
● |
● |
|
● |
|
| |
14 |
STUD; EXH MANIF
(B)
M10X130 L=145
|
1-09302-107-0 |
03 |
1 |
9603-9706 |
● |
|
|
|
|
| |
14 |
STUD; EXH MANIF
(B)
M10X130 L=145
|
1-09302-107-0 |
03 |
1 |
9707-9804 |
● |
|
|
● |
|
| |
14 |
STUD; EXH MANIF
(B)
M10X130 L=145
|
1-09302-107-0 |
03 |
1 |
9805-9904 |
● |
● |
|
● |
|
| |
14 |
STUD; EXH MANIF
(B)
M10X130 L=145
|
1-09302-107-0 |
03 |
1 |
9905- |
● |
● |
● |
|
● |
| |
14 |
STUD; EXH MANIF
(A)
M10X95 L=110
|
1-09302-063-0 |
15 |
1 |
9905- |
● |
● |
● |
|
● |
| |
23 |
NUT; CAM BRKT
M4 FLANGE
|
1-09440-004-0 |
14 |
1 |
9603-9706 |
● |
|
|
|
|
| |
23 |
NUT; CAM BRKT
M4 FLANGE
|
1-09440-004-0 |
14 |
1 |
9707-9804 |
● |
|
|
● |
|
| |
23 |
NUT; CAM BRKT
M4 FLANGE
|
1-09440-004-0 |
14 |
1 |
9805-9904 |
● |
● |
|
● |
|
| |
23 |
NUT; CAM BRKT
M4 FLANGE
|
1-09440-004-0 |
14 |
1 |
9905- |
● |
● |
● |
|
● |
| |
25 |
PLUG; CYL HD
M14X9
|
9-99202-314-0 |
01 |
1 |
9603-9706 |
● |
|
|
|
|
| |
25 |
PLUG; CYL HD
M14X9
|
9-99202-314-0 |
01 |
1 |
9707-9804 |
● |
|
|
● |
|
| |
25 |
PLUG; CYL HD
M14X9
|
9-99202-314-0 |
01 |
1 |
9805-9904 |
● |
● |
|
● |
|
| |
25 |
PLUG; CYL HD
M14X9
|
9-99202-314-0 |
01 |
1 |
9905- |
● |
● |
● |
|
● |
| |
41 |
BOLT; ENG HANGER
(A)
M12X50 FLANGE
|
0-28191-250-0 |
04 |
1 |
9603-9706 |
● |
|
|
|
|
| |
41 |
BOLT; ENG HANGER
(A)
M12X50 FLANGE
|
0-28191-250-0 |
04 |
1 |
9707-9804 |
● |
|
|
● |
|
| |
41 |
BOLT; ENG HANGER
(A)
M12X50 FLANGE
|
0-28191-250-0 |
04 |
1 |
9805-9904 |
● |
● |
|
● |
|
| |
41 |
BOLT; ENG HANGER
(B)
M12X35 FLANGE
|
0-28791-235-0 |
02 |
1 |
9603-9607 |
● |
|
|
|
|
| |
41 |
BOLT; ENG HANGER
(B)
M12X25 FLANGE
|
0-28191-225-0 |
02 |
1 |
9608-9706 |
● |
|
|
|
|
| |
41 |
BOLT; ENG HANGER
(B)
M12X25 FLANGE
|
0-28191-225-0 |
02 |
1 |
9707-9804 |
● |
|
|
● |
|
| |
41 |
BOLT; ENG HANGER
(B)
M12X25 FLANGE
|
0-28191-225-0 |
02 |
1 |
9805-9904 |
● |
● |
|
● |
|
| |
41 |
BOLT; ENG HANGER
(A)
M12X50 FLANGE
|
0-28191-250-0 |
04 |
1 |
9905- |
● |
● |
● |
|
● |
| |
41 |
BOLT; ENG HANGER
(B)
M12X25 FLANGE
|
0-28191-225-0 |
02 |
1 |
9905- |
● |
● |
● |
|
● |
| |
55 |
WASHER; PL,CYL HD TO BLOCK
ID=18.2 OD=29
|
1-09503-032-0 |
26 |
1 |
9603-9706 |
● |
|
|
|
|
| |
55 |
WASHER; PL,CYL HD TO BLOCK
ID=18.2 OD=29
|
1-09503-032-0 |
26 |
1 |
9707-9804 |
● |
|
|
● |
|
| |
55 |
WASHER; PL,CYL HD TO BLOCK
ID=18.2 OD=29
|
1-09503-032-0 |
26 |
1 |
9805-9904 |
● |
● |
|
● |
|
| |
55 |
WASHER; PL,CYL HD TO BLOCK
ID=18.2 OD=29
|
1-09503-032-0 |
26 |
1 |
9905- |
● |
● |
● |
|
● |
| |
57 |
SLEEVE; NOZZLE HOLDER
|
1-11129-043-0 |
06 |
1 |
9603-9804 |
● |
|
|
|
|
| |
57 |
SLEEVE; NOZZLE HOLDER
|
1-11129-049-0 |
06 |
1 |
9707-9804 |
|
|
|
● |
|
| |
57 |
SLEEVE; NOZZLE HOLDER
|
1-11129-057-1 |
06 |
1 |
9805-9904 |
● |
● |
|
● |
|
| |
57 |
SLEEVE; NOZZLE HOLDER
|
1-11129-057-1 |
06 |
1 |
9905-0005 |
● |
● |
● |
|
● |
| |
57 |
SLEEVE; NOZZLE HOLDER
|
1-11129-058-0 |
06 |
1 |
0006- |
● |
● |
● |
|
● |
| |
58 |
GASKET; SLEEVE,NOZZLE HOLDER
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
|
9-09565-330-0 |
06 |
1 |
9603-9706 |
● |
|
|
|
|
| |
58 |
GASKET; SLEEVE,NOZZLE HOLDER
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
|
9-09565-330-0 |
06 |
1 |
9707-9804 |
● |
|
|
● |
|
| |
58 |
GASKET; SLEEVE,NOZZLE HOLDER
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
|
9-09565-330-0 |
06 |
1 |
9805-9904 |
● |
● |
|
● |
|
| |
58 |
GASKET; SLEEVE,NOZZLE HOLDER
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
|
9-09565-330-0 |
06 |
1 |
9905-0005 |
● |
● |
● |
|
● |
| |
58 |
GASKET; SLEEVE,NOZZLE HOLDER
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
(A)
ID=30.9 BLACK
|
8-97233-126-0 |
06 |
1 |
0006- |
● |
● |
● |
|
● |
| |
58 |
GASKET; SLEEVE,NOZZLE HOLDER
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
(B)
ID=30.9 RED
|
8-97233-127-0 |
06 |
1 |
0006- |
● |
● |
● |
|
● |
| |
59 |
GUIDE; BRIDGE
|
1-11729-005-0 |
12 |
1 |
9603-9706 |
● |
|
|
|
|
| |
59 |
GUIDE; BRIDGE
|
1-11729-005-0 |
12 |
1 |
9707-9804 |
● |
|
|
● |
|
| |
59 |
GUIDE; BRIDGE
|
1-11729-005-0 |
12 |
1 |
9805-9904 |
● |
● |
|
● |
|
| |
59 |
GUIDE; BRIDGE
|
1-11729-005-0 |
12 |
1 |
9905- |
● |
● |
● |
|
● |
| |
73 |
GASKET; PLUG,HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
ID=14.2 OD=19.2
|
1-09630-085-0 |
01 |
1 |
9603-9706 |
● |
|
|
|
|
| |
73 |
GASKET; PLUG,HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
ID=14.2 OD=19.2
|
1-09630-085-0 |
01 |
1 |
9707-9804 |
● |
|
|
● |
|
| |
73 |
GASKET; PLUG,HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
ID=14.2 OD=19.2
|
1-09630-085-0 |
01 |
1 |
9805-9904 |
● |
● |
|
● |
|
| |
73 |
GASKET; PLUG,HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
ID=14.2 OD=19.2
|
1-09630-085-0 |
01 |
1 |
9905- |
● |
● |
● |
|
● |
| |
95 |
GASKET; CYL HD TO GEAR CASE
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
|
1-09623-403-0 |
01 |
1 |
9603-9706 |
● |
|
|
|
|
| |
95 |
GASKET; CYL HD TO GEAR CASE
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
|
1-09623-403-0 |
01 |
1 |
9707-9804 |
● |
|
|
● |
|
| |
95 |
GASKET; CYL HD TO GEAR CASE
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
|
1-09623-403-0 |
01 |
1 |
9805-9904 |
● |
● |
|
● |
|
| |
95 |
GASKET; CYL HD TO GEAR CASE
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
|
1-09623-403-0 |
01 |
1 |
9905- |
● |
● |
● |
|
● |
| |
97 |
DOWEL; CAM BRKT SET
OD=16
|
1-13119-005-0 |
28 |
1 |
9603-9706 |
● |
|
|
|
|
| |
97 |
DOWEL; CAM BRKT SET
OD=16
|
1-13119-005-0 |
28 |
1 |
9707-9804 |
● |
|
|
● |
|
| |
97 |
DOWEL; CAM BRKT SET
OD=16
|
1-13119-005-0 |
28 |
1 |
9805-9904 |
● |
● |
|
● |
|
| |
97 |
DOWEL; CAM BRKT SET
OD=16
|
1-13119-005-0 |
28 |
1 |
9905- |
● |
● |
● |
|
● |
| |
98 |
STUD; CAM BRKT
M12X100 L=120
|
8-94397-322-0 |
14 |
1 |
9603-9706 |
● |
|
|
|
|
| |
98 |
STUD; CAM BRKT
M12X100 L=120
|
8-94397-322-0 |
14 |
1 |
9707-9804 |
● |
|
|
● |
|
| |
98 |
STUD; CAM BRKT
M12X100 L=120
|
8-94397-322-0 |
14 |
1 |
9805-9904 |
● |
● |
|
● |
|
| |
98 |
STUD; CAM BRKT
M12X100 L=120
|
8-94397-322-0 |
14 |
1 |
9905- |
● |
● |
● |
|
● |
| |
103 |
PLUG; HD
M10X7
|
1-09604-094-0 |
01 |
1 |
9603-9706 |
● |
|
|
|
|
| |
103 |
PLUG; HD
M10X7
|
1-09604-094-0 |
01 |
1 |
9707-9804 |
● |
|
|
● |
|
| |
103 |
PLUG; HD
M10X7
|
1-09604-094-0 |
01 |
1 |
9805-9904 |
● |
● |
|
● |
|
| |
103 |
PLUG; HD
M10X7
|
1-09604-094-0 |
01 |
1 |
9905- |
● |
● |
● |
|
● |
| |
104 |
GASKET; PLUG
ALSO INCLUDED IN GASKET SET(ENGINE).
ID=10.2 OD=15.2
|
1-09630-083-0 |
01 |
1 |
9603-9706 |
● |
|
|
|
|
| |
104 |
GASKET; PLUG
ALSO INCLUDED IN GASKET SET(ENGINE).
ID=10.2 OD=15.2
|
1-09630-083-0 |
01 |
1 |
9707-9804 |
● |
|
|
● |
|
| |
104 |
GASKET; PLUG
ALSO INCLUDED IN GASKET SET(ENGINE).
ID=10.2 OD=15.2
|
1-09630-083-0 |
01 |
1 |
9805-9904 |
● |
● |
|
● |
|
| |
104 |
GASKET; PLUG
ALSO INCLUDED IN GASKET SET(ENGINE).
ID=10.2 OD=15.2
|
1-09630-083-0 |
01 |
1 |
9905- |
● |
● |
● |
|
● |
| |
106 |
PLUG; GLOW PLUG HOLE
EXC. GLOW SYSTEM-FAST DIESEL ENGINE<KM6>
|
1-11119-018-0 |
06 |
1 |
9603-9706 |
● |
|
|
|
|
| |
106 |
PLUG; GLOW PLUG HOLE
EXC. GLOW SYSTEM-FAST DIESEL ENGINE<KM6>
|
1-11119-018-0 |
06 |
1 |
9707-9804 |
● |
|
|
|
|
| |
106 |
PLUG; GLOW PLUG HOLE
|
1-11119-018-0 |
06 |
1 |
9707-9804 |
|
|
|
● |
|
| |
106 |
PLUG; GLOW PLUG HOLE
EXC. GLOW SYSTEM-FAST DIESEL ENGINE<KM6>
|
1-11119-018-0 |
06 |
1 |
9805-9903 |
● |
|
|
|
|
| |
106 |
PLUG; GLOW PLUG HOLE
EXC. HONG KONG EQUIPMENT(PQ1)
|
1-11119-018-0 |
06 |
1 |
9805-9903 |
|
|
|
● |
|
| |
106 |
PLUG; GLOW PLUG HOLE
|
1-11119-018-0 |
06 |
1 |
9805-9903 |
|
● |
|
|
|
| |
106 |
PLUG; GLOW PLUG HOLE
EXC. GLOW SYSTEM-FAST DIESEL ENGINE<KM6>
|
1-11119-018-0 |
06 |
1 |
9904-9904 |
● |
|
|
|
|
| |
106 |
PLUG; GLOW PLUG HOLE
|
1-11119-018-0 |
06 |
1 |
9904-9904 |
|
● |
|
● |
|
| |
106 |
PLUG; GLOW PLUG HOLE
EXC. GLOW SYSTEM-FAST DIESEL ENGINE<KM6>
|
1-11119-018-0 |
06 |
1 |
9905- |
● |
|
|
|
● |
| |
106 |
PLUG; GLOW PLUG HOLE
|
1-11119-018-0 |
06 |
1 |
9905- |
|
● |
|
● |
|
| |
180 |
BRACKET SET; CAM,CYL HD
(A)
|
1-12516-148-1 |
01 |
1 |
9603-9706 |
● |
|
|
|
|
| |
180 |
BRACKET SET; CAM,CYL HD
(A)
|
1-12516-148-1 |
01 |
1 |
9707-9804 |
● |
|
|
● |
|
| |
180 |
BRACKET SET; CAM,CYL HD
(A)
|
1-12516-148-1 |
01 |
1 |
9805-9904 |
● |
● |
|
● |
|
| |
180 |
BRACKET SET; CAM,CYL HD
(B)
|
1-12516-152-1 |
06 |
1 |
9603-9706 |
● |
|
|
|
|
| |
180 |
BRACKET SET; CAM,CYL HD
(B)
|
1-12516-152-1 |
06 |
1 |
9707-9804 |
● |
|
|
● |
|
| |
180 |
BRACKET SET; CAM,CYL HD
(B)
|
1-12516-152-1 |
06 |
1 |
9805-9904 |
● |
● |
|
● |
|
| |
180 |
BRACKET SET; CAM,CYL HD
(A)
|
1-12516-148-1 |
01 |
1 |
9905- |
● |
● |
● |
|
● |
| |
180 |
BRACKET SET; CAM,CYL HD
(B)
|
1-12516-152-1 |
06 |
1 |
9905- |
● |
● |
● |
|
● |
| |
181 |
CASE; HEAD GEAR
|
1-11310-057-0 |
01 |
1 |
9603-9607 |
● |
|
|
|
|
| |
181 |
CASE; HEAD GEAR
|
1-11310-058-0 |
01 |
1 |
9608-9706 |
● |
|
|
|
|
| |
181 |
CASE; HEAD GEAR
|
1-11310-058-0 |
01 |
1 |
9707-9804 |
● |
|
|
● |
|
| |
181 |
CASE; HEAD GEAR
|
1-11310-058-0 |
01 |
1 |
9805-9904 |
● |
● |
|
● |
|
| |
181 |
CASE; HEAD GEAR
|
1-11310-058-1 |
01 |
1 |
9905- |
● |
● |
● |
|
● |
| |
182 |
BOLT; CASE
M10X80
|
9-05921-080-0 |
07 |
1 |
9603-9706 |
● |
|
|
|
|
| |
182 |
BOLT; CASE
M10X80
|
9-05921-080-0 |
07 |
1 |
9707-9804 |
● |
|
|
● |
|
| |
182 |
BOLT; CASE
M10X80
|
9-05921-080-0 |
07 |
1 |
9805-9904 |
● |
● |
|
● |
|
| |
182 |
BOLT; CASE
M10X80
|
9-05921-080-0 |
07 |
1 |
9905- |
● |
● |
● |
|
● |
| |
183 |
DOWEL; CYL HEAD
|
1-13119-004-0 |
02 |
1 |
9603-9706 |
● |
|
|
|
|
| |
183 |
DOWEL; CYL HEAD
|
1-13119-004-0 |
02 |
1 |
9707-9804 |
● |
|
|
● |
|
| |
183 |
DOWEL; CYL HEAD
|
1-13119-004-0 |
02 |
1 |
9805-9904 |
● |
● |
|
● |
|
| |
183 |
DOWEL; CYL HEAD
|
1-13119-004-0 |
02 |
1 |
9905- |
● |
● |
● |
|
● |
