8 |
06.803 BOX ASM; STRG UNIT
ASM PART: A = 8-97173-467-3, 97173467, B = 8-97251-843-1, 97251843
|
8-97202-845-1 |
01 |
1 |
- |
| |
9 |
06.806 PLUG; FILLER,STRG UNIT
ASM PART: A = 8-97173-467-3, 97173467
|
8-97014-820-0 |
01 |
1 |
- |
| |
9 |
06.806 PLUG; FILLER,STRG UNIT
ASM PART: B = 8-97251-843-1, 97251843
|
8-97014-820-0 |
02 |
1 |
- |
| |
13 |
06.786 BEARING; SHAFT,BOX SIDE,STRG UNI
ASM PART: A = 8-97173-467-3, 97173467, B = 8-97251-843-1, 97251843
|
8-97014-828-0 |
01 |
1 |
- |
| |
14 |
06.850 SHAFT; SECTOR,STRG UNIT
ASM PART: A = 8-97173-467-3, 97173467, B = 8-97251-843-1, 97251843
|
8-97202-843-0 |
01 |
1 |
- |
| |
19 |
06.807 COVER; SIDE STRG UNIT
ASM PART: A = 8-97173-467-3, 97173467, B = 8-97251-843-1, 97251843
|
8-97014-933-1 |
01 |
1 |
- |
| |
23 |
06.822 SCREW; ADJ,SECTOR SHAFT,STRG UNI
ASM PART: A = 8-97173-467-3, 97173467, B = 8-97251-843-1, 97251843
|
8-97014-842-0 |
01 |
1 |
- |
| |
24 |
06.822 RETAINER; STRG UNIT
ASM PART: A = 8-97173-467-3, 97173467, B = 8-97251-843-1, 97251843
|
8-97014-841-0 |
01 |
1 |
- |
| |
30 |
06.809 BOLT; COVER STRG UNIT
(A) ASM PART: A = 8-97173-467-3, 97173467
|
8-97014-836-0 |
03 |
1 |
- |
| |
30 |
06.809 BOLT; COVER STRG UNIT
(A) ASM PART: B = 8-97251-843-1, 97251843
|
8-97014-836-0 |
03 |
1 |
-0212 |
| |
30 |
06.809 BOLT; COVER STRG UNIT
(A) ASM PART: B = 8-97251-843-1, 97251843
|
8-97014-836-0 |
04 |
1 |
0301- |
| |
30 |
06.809 BOLT; COVER STRG UNIT
(B) ASM PART: A = 8-97173-467-3, 97173467
|
8-97209-716-0 |
01 |
1 |
- |
| |
30 |
06.809 BOLT; COVER STRG UNIT
(B) ASM PART: B = 8-97251-843-1, 97251843
|
8-97209-716-0 |
01 |
1 |
-0212 |
| |
32 |
06.822 NUT; ADJ SCREW,STRG UNIT
ASM PART: A = 8-97173-467-3, 97173467, B = 8-97251-843-1, 97251843
|
8-97014-834-0 |
01 |
1 |
- |
| |
33 |
06.806 PLUG; DRAIN,STRG UNIT
ASM PART: A = 8-97173-467-3, 97173467
|
8-97014-820-0 |
02 |
1 |
- |
| |
35 |
06.586 HOUSING & SCREW ASM; STRG UNIT
ASM PART: A = 8-97173-467-3, 97173467
|
8-97218-597-0 |
01 |
1 |
- |
| |
35 |
06.586 HOUSING & SCREW ASM; STRG UNIT
ASM PART: B = 8-97251-843-1, 97251843
|
8-97264-470-0 |
01 |
1 |
-0212 |
| |
35 |
06.586 HOUSING & SCREW ASM; STRG UNIT
ASM PART: B = 8-97251-843-1, 97251843
|
8-97287-220-0 |
01 |
1 |
0301- |
| |
42 |
06.586 HOUSING & SEAL ASM; STRG UNIT
ASM PART: A = 8-97173-467-3, 97173467
|
8-97078-175-0 |
01 |
1 |
- |
| |
50 |
06.586 HOUSING ASM; VALVE STRG UNIT
ASM PART: A = 8-97173-467-3, 97173467
|
8-97078-176-0 |
01 |
1 |
- |
| |
54 |
06.835 CASE; BEARING STRG UNIT
ASM PART: A = 8-97173-467-3, 97173467
|
8-97014-810-0 |
01 |
1 |
- |
| |
56 |
06.560 PLUG & SEAL ASM; STRG UNIT
06.850
ASM PART: A = 8-97173-467-3, 97173467
|
8-97076-364-1 |
01 |
1 |
- |
| |
58 |
06.835 BEARING; HSG STRG UNIT
ASM PART: A = 8-97173-467-3, 97173467
|
8-97014-812-0 |
01 |
1 |
- |
| |
72 |
06.550 BOLT; HSG FIX STRG UNIT
ASM PART: A = 8-97173-467-3, 97173467, B = 8-97251-843-1, 97251843
|
1-44519-110-0 |
04 |
1 |
- |
| |
177 |
06.822 TUBE; BALL BRG STRG UNIT
ASM PART: A = 8-97173-467-3, 97173467
|
8-97077-537-0 |
02 |
1 |
- |
| |
178 |
06.822 CLIP; BALL TUBE STRG UNIT
ASM PART: A = 8-97173-467-3, 97173467
|
8-97014-808-0 |
01 |
1 |
- |
| |
199 |
06.521 WASHER; WAVE,STRG UNIT
ASM PART: A = 8-97173-467-3, 97173467
|
8-97201-812-0 |
01 |
1 |
- |
