Isuzu WW
▶
PICKUP
▶
TFR
▶
50800 - TFR/TFS-RHD
▶
2 - Clutch, Transmission, Trans Axle
▶
2-43 - AUTO TRANS CONTROL VALVE; UPPER BODY
▶
2-43 — AUTO TRANS CONTROL VALVE; UPPER BODY
(#45657) — 14 parça
119
185
119
129
126
113
113
230
183
158
182
19
235
210
157
206
158
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
19
04.265 VALVE; ACCUMLATOR CONT,UPR VLV
6VD1 ENG(RLV)
8-96014-338-0
01
1
9804-
113
04.265 VALVE ASM; CONT,A/T
6VD1 ENG(RLV)
8-96017-360-0
01
1
9804-
119
04.265 BOLT; VLV BODY,A/T
6VD1 ENG(RLV)
8-96017-270-0
07
1
9804-
126
04.265 GASKET; VALVE BODY
6VD1 ENG(RLV)
8-96017-399-0
01
1
9804-
129
04.265 PLATE; SEPARATOR,SIDE
6VD1 ENG(RLV)
8-96017-395-0
01
1
9804-
157
04.115 SOLENOID; CONV CLU
6VD1 ENG(RLV)
8-96014-183-0
01
1
9804-
158
04.115 BOLT; SOLENOID
6VD1 ENG(RLV)
8-00117-461-0
02
1
9804-
182
04.115 SOLENOID; FORCE MOTOR
6VD1 ENG(RLV)
8-08677-314-0
01
1
9804-
183
04.115 RETAINER; FORCE MOTOR
6VD1 ENG(RLV)
8-96016-954-0
01
1
9804-
185
04.265 GASKET; ADAPTER TO TRANSFER PLAT
6VD1 ENG(RLV)
8-96017-400-0
01
1
9804-
206
04.265 RING; SNAP
6VD1 ENG(RLV) 04.233
8-05258-185-0
01
1
9804-
210
04.265 STRAINER
6VD1 ENG(RLV)
8-96041-009-0
01
1
9804-
230
04.115 HARNESS ASM; CABLE,A/T CONT
6VD1 ENG(RLV)
8-96018-278-0
01
1
9804-
235
04.265 VALVE; ACCUMULATOR
6VD1 ENG(RLV)
8-05258-806-0
01
1
9804-
