4-11 — FRONT HUB AND DRUM OR ROTOR (#4464) — 266 parça

38 53 33 37 35 37 27 34 34 22 17 28 15 21 20 23 19 5 30 13 12 10 35 6 4 1 3 35 35 35 36

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
1	CAP; HUB,FRT AXLE FRT & RR SPR LONG SPAN<W55> OD=156	9-42313-123-2	02	1	9101-9504	●	●
1	CAP; HUB,FRT AXLE OD=156	9-42313-123-2	02	1	9505-	●	●
1	CAP; HUB,FRT AXLE EXC. FRT & RR SPR LONG SPAN<W55> OD=136	1-42313-007-1	02	1	9101-9504	●	●
3	BOLT; HUB CAP,FRT WHEEL M8X14 W/LK WASHER	9-01900-814-0	12	1	9101-9204	●	●
3	BOLT; HUB CAP,FRT WHEEL M8X14 W/LK WASHER	0-50040-814-0	12	1	9205-9509	●	●
3	BOLT; HUB CAP,FRT WHEEL M8X12 FLANGE	0-28080-812-0	12	1	9510-0512	●	●
3	BOLT; HUB CAP,FRT WHEEL M8X12 FLANGE	0-28050-812-0	12	1	0601-	●	●
4	GASKET; HUB CAP,FRT WHEEL FRT & RR SPR LONG SPAN<W55>	1-42319-029-0	02	1	9101-9504	●	●
4	GASKET; HUB CAP,FRT WHEEL	1-42319-029-0	02	1	9505-9906	●	●
4	GASKET; HUB CAP,FRT WHEEL	1-42319-185-2	02	1	9907-	●	●
4	GASKET; HUB CAP,FRT WHEEL EXC. FRT & RR SPR LONG SPAN<W55>	1-42319-028-0	02	1	9101-9504	●	●
5	BOLT; LK WASHER FRT & RR SPR LONG SPAN<W55> M6X16 W/LK WASHER	0-50040-616-0	04	1	9101-9403	●	●
5	BOLT; LK WASHER M6X16 W/LK WASHER	0-50040-616-0	04	1	9404-9701	●	●
5	BOLT; LK WASHER M6X16 FLANGE	0-28680-616-0	04	1	9702-0512	●	●
5	BOLT; LK WASHER M6X16 FLANGE	0-28650-616-0	04	1	0601-0707	●	●
5	BOLT; LK WASHER M6X16 HEX SOCKET	8-98084-271-0	04	1	0708-1201	●	●
5	BOLT; LK WASHER M6X16 HEX SOCKET	8-98200-943-0	04	1	1202-	●	●
5	BOLT; LK WASHER EXC. FRT & RR SPR LONG SPAN<W55> M6X16 W/LK WASHER	0-50040-616-0	06	1	9101-9403	●	●
6	WASHER; LK,FRT HUB FRT & RR SPR LONG SPAN<W55> ID=48	1-09533-012-1	02	1	9101-9504	●	●
6	WASHER; LK,FRT HUB ID=48	1-09533-012-1	02	1	9505-0707	●	●
6	WASHER; LK,FRT HUB ID=48	8-98084-561-0	02	1	0708-	●	●
6	WASHER; LK,FRT HUB EXC. FRT & RR SPR LONG SPAN<W55> ID=39	1-09841-003-0	02	1	9101-9504	●	●
10	NUT; FRT HUB BRG FRT & RR SPR LONG SPAN<W55> M48	1-09840-012-3	02	1	9101-9504	●	●
10	NUT; FRT HUB BRG M48	1-09840-012-5	02	1	9505-	●	●
10	NUT; FRT HUB BRG EXC. FRT & RR SPR LONG SPAN<W55> M39	1-09840-018-1	02	1	9101-9403	●	●
10	NUT; FRT HUB BRG EXC. FRT & RR SPR LONG SPAN<W55> M39	1-09840-019-1	02	1	9404-9504	●	●
12	WASHER; LK,FRT HUB BRG FRT & RR SPR LONG SPAN<W55> ID=48	1-09533-016-0	02	1	9101-9504	●	●
12	WASHER; LK,FRT HUB BRG ID=48	1-09533-016-0	02	1	9505-0911	●	●
12	WASHER; LK,FRT HUB BRG ID=48	8-98156-755-0	02	1	0912-	●	●
13	BEARING; HUB OUTER,FRT AXLE FRT & RR SPR LONG SPAN<W55> NSK	1-09812-084-0	02	1	9101-9504	●	●
13	BEARING; HUB OUTER,FRT AXLE NSK	1-09812-084-0	02	1	9505-9809	●	●
13	BEARING; HUB OUTER,FRT AXLE JTEKT	1-09812-234-0	02	1	9810-	●	●
13	BEARING; HUB OUTER,FRT AXLE FRT & RR SPR LONG SPAN<W55> JTEKT	1-09812-085-0	02	1	9101-9504	●	●
13	BEARING; HUB OUTER,FRT AXLE JTEKT	1-09812-085-0	02	1	9505-9809	●	●
13	BEARING; HUB OUTER,FRT AXLE EXC. FRT & RR SPR LONG SPAN<W55> NSK	9-00093-146-0	02	1	9101-9504	●	●
13	BEARING; HUB OUTER,FRT AXLE EXC. FRT & RR SPR LONG SPAN<W55> KOYO	9-00093-147-1	02	1	9101-9504	●	●
15	PIN; WHEEL,FRT AXLE BRK SYSTEM FULL AIR DUAL CIRCUIT(Z06) DISC WHEEL 10STUD 22.5X8.25 165-13<QM8>,DISC WHEEL10STUD 20X7.00T<Q58>,DISC WHEEL 10STUD 20X7.50V 165-12<Q64> FRT & RR SPR LONG SPAN<W55> M22,M22 L=100 M22X48.8,M22X55.5 RH THREAD	1-42337-011-1	20	1	9101-9504	●	●
15	PIN; WHEEL,FRT AXLE INTERNATIONAL STD ISO<B3V> M22,M22 L=103 M22X42.8,M22X55.5 RH THREAD	1-42337-044-0	20	1	9505-0210	●	●
15	PIN; WHEEL,FRT AXLE INTERNATIONAL STD ISO<B3V> M22X42.8,M22X55.5 RH THREAD	1-42337-067-1	20	1	0211-	●	●
15	PIN; WHEEL,FRT AXLE FRT & RR SPR LONG SPAN<W55> EXC. DISC WHEEL 10STUD 22.5X8.25 165-13<QM8>,DISC WHEEL 10STUD 20X7.00T<Q58>,DISC WHEEL 10STUD 20X7.50V 165-12<Q64> M20X37.5 LH THREAD,M22X55.5 RH THREAD	1-42332-047-0	08	1	9101-9504	●	●
15	PIN; WHEEL,FRT AXLE EXC. INTERNATIONAL STD ISO<B3V> M24X37.5 LH THREAD,M22X57.5 RH THREAD	1-42332-109-0	08	1	9505-0610	●	●
15	PIN; WHEEL,FRT AXLE EXC. INTERNATIONAL STD ISO<B3V> M24X37.5 LH THREAD,M22X57.5 RH THREAD	1-42332-150-1	08	1	0611-0701	●	●
15	PIN; WHEEL,FRT AXLE EXC. INTERNATIONAL STD ISO<B3V> M24X37.5 LH THREAD,M22X57.5 RH THREAD	1-42332-109-1	08	1	0702-0705	●	●
15	PIN; WHEEL,FRT AXLE EXC. INTERNATIONAL STD ISO<B3V> M24X37.5 LH THREAD,M22X57.5 RH THREAD	1-42332-109-1	08	1	0706-	●
15	PIN; WHEEL,FRT AXLE EXC. INTERNATIONAL STD ISO<B3V>,PROVISIONS ANTILOCK BRAKE SYSTEM<8MG> M24X37.5 LH THREAD,M22X57.5 RH THREAD	1-42332-109-1	08	1	0706-		●
15	PIN; WHEEL,FRT AXLE FRT & RR SPR LONG SPAN<W55> EXC. DISC WHEEL 10STUD 22.5X8.25 165-13<QM8>,DISC WHEEL 10STUD 20X7.00T<Q58>,DISC WHEEL 10STUD 20X7.50V 165-12<Q64> M20X37.5,M22X55.5 RH THREAD	1-42331-047-0	08	1	9101-9504	●	●
15	PIN; WHEEL,FRT AXLE EXC. INTERNATIONAL STD ISO<B3V> M24X37.5,M22X57.5 RH THREAD	1-42331-109-0	08	1	9505-0610	●	●
15	PIN; WHEEL,FRT AXLE EXC. INTERNATIONAL STD ISO<B3V> M24X37.5,M22X57.5 RH THREAD	1-42331-150-1	08	1	0611-0701	●	●
15	PIN; WHEEL,FRT AXLE EXC. INTERNATIONAL STD ISO<B3V> M24X37.5,M22X57.5 RH THREAD	1-42331-109-1	08	1	0702-0705	●	●
15	PIN; WHEEL,FRT AXLE EXC. INTERNATIONAL STD ISO<B3V> M24X37.5,M22X57.5 RH THREAD	1-42331-109-1	08	1	0706-	●
15	PIN; WHEEL,FRT AXLE EXC. INTERNATIONAL STD ISO<B3V>,PROVISIONS ANTILOCK BRAKE SYSTEM<8MG> M24X37.5,M22X57.5 RH THREAD	1-42331-109-1	08	1	0706-		●
15	PIN; WHEEL,FRT AXLE EXC. FRT & RR SPR LONG SPAN<W55> M20X37.5 LH THREAD,M22X49.5 RH THREAD	1-42332-058-0	08	1	9101-9504	●	●
15	PIN; WHEEL,FRT AXLE EXC. FRT & RR SPR LONG SPAN<W55> M20X37.5,M22X49.5 RH THREAD	1-42331-058-0	08	1	9101-9504	●	●
17	HUB; FRT AXLE BRK SYSTEM FULL AIR DUAL CIRCUIT(Z06) DISC WHEEL 10STUD 22.5X8.25 165-13<QM8>,DISC WHEEL10STUD 20X7.00T<Q58>,DISC WHEEL 10STUD 20X7.50V 165-12<Q64> FRT & RR SPR LONG SPAN<W55>	1-42312-055-0	02	1	9101-9404	●	●
17	HUB; FRT AXLE BRK SYSTEM FULL AIR DUAL CIRCUIT(Z06) DISC WHEEL 10STUD 22.5X8.25 165-13<QM8>,DISC WHEEL10STUD 20X7.00T<Q58>,DISC WHEEL 10STUD 20X7.50V 165-12<Q64> FRT & RR SPR LONG SPAN<W55>	1-42312-100-0	02	1	9405-9504	●	●
17	HUB; FRT AXLE INTERNATIONAL STD ISO<B3V>	1-42312-100-1	02	1	9505-	●	●
17	HUB; FRT AXLE FRT & RR SPR LONG SPAN<W55> EXC. DISC WHEEL 10STUD 22.5X8.25 165-13<QM8>,DISC WHEEL 10STUD 20X7.00T<Q58>,DISC WHEEL 10STUD 20X7.50V 165-12<Q64>	1-42312-047-2	02	1	9101-9211	●	●
17	HUB; FRT AXLE FRT & RR SPR LONG SPAN<W55> EXC. DISC WHEEL 10STUD 22.5X8.25 165-13<QM8>,DISC WHEEL 10STUD 20X7.00T<Q58>,DISC WHEEL 10STUD 20X7.50V 165-12<Q64>	1-42312-111-0	02	1	9212-9404	●	●
17	HUB; FRT AXLE FRT & RR SPR LONG SPAN<W55> EXC. DISC WHEEL 10STUD 22.5X8.25 165-13<QM8>,DISC WHEEL 10STUD 20X7.00T<Q58>,DISC WHEEL 10STUD 20X7.50V 165-12<Q64>	1-42312-109-0	02	1	9405-9504	●	●
17	HUB; FRT AXLE EXC. INTERNATIONAL STD ISO<B3V>	1-42312-109-0	02	1	9505-9506	●	●
17	HUB; FRT AXLE EXC. INTERNATIONAL STD ISO<B3V>	1-42312-128-2	02	1	9507-0705	●	●
17	HUB; FRT AXLE EXC. INTERNATIONAL STD ISO<B3V>	1-42312-128-2	02	1	0706-	●
17	HUB; FRT AXLE EXC. INTERNATIONAL STD ISO<B3V>,PROVISIONS ANTILOCK BRAKE SYSTEM<8MG>	1-42312-128-2	02	1	0706-		●
17	HUB; FRT AXLE EXC. FRT & RR SPR LONG SPAN<W55>	1-42312-037-1	02	1	9101-9211	●	●
17	HUB; FRT AXLE EXC. FRT & RR SPR LONG SPAN<W55>	1-42312-113-0	02	1	9212-9504	●	●
19	BEARING; HUB INNER,FRT AXLE FRT & RR SPR LONG SPAN<W55> NSK	1-09812-142-0	02	1	9101-9504	●	●
19	BEARING; HUB INNER,FRT AXLE NSK	1-09812-142-0	02	1	9505-9809	●	●
19	BEARING; HUB INNER,FRT AXLE JTEKT	1-09812-231-0	02	1	9810-	●	●
19	BEARING; HUB INNER,FRT AXLE FRT & RR SPR LONG SPAN<W55> JTEKT	1-09812-143-0	02	1	9101-9504	●	●
19	BEARING; HUB INNER,FRT AXLE JTEKT	1-09812-143-0	02	1	9505-9809	●	●
19	BEARING; HUB INNER,FRT AXLE EXC. FRT & RR SPR LONG SPAN<W55> JTEKT	9-00093-114-0	02	1	9101-9504	●	●
20	COVER; HUB BRG INNER FRT & RR SPR LONG SPAN<W55>	1-42319-039-0	02	1	9101-9504	●	●
20	COVER; HUB BRG INNER	1-42319-039-0	02	1	9505-	●	●
21	RING; SNAP,HUB FRT & RR SPR LONG SPAN<W55> (B)	1-09587-017-0	02	1	9101-9504	●	●
21	RING; SNAP,HUB (B)	1-09587-017-0	02	1	9505-	●	●
21	RING; SNAP,HUB EXC. FRT & RR SPR LONG SPAN<W55> (A)	9-09950-164-0	02	1	9101-9504	●	●
22	COVER SET; FRT BRK DRUM BRK SYSTEM AIR OVER HYDRAULIC DUAL CIRCUIT(Z05)	1-47151-458-1	02	1	9101-0203	●	●
22	COVER SET; FRT BRK DRUM BRK SYSTEM FULL AIR DUAL CIRCUIT(Z06)	1-47151-459-1	02	1	9101-9802	●	●
22	COVER SET; FRT BRK DRUM BRK SYSTEM FULL AIR DUAL CIRCUIT(Z06) EXC. AUTO ADJUSTER BRAKE<BCU>	1-47151-459-1	02	1	9803-0203	●	●
22	COVER SET; FRT BRK DRUM	1-47151-459-1	02	1	0204-	●	●
22	COVER SET; FRT BRK DRUM BRK SYSTEM FULL AIR DUAL CIRCUIT(Z06) BRK LINING D2129 NON ASBESTOS<BCL> AUTO ADJUSTER BRAKE<BCU> EXC. INTERNATIONAL STD ISO<B3V>,AUSTRALIA EQUIPMENT<RR3>	1-47151-630-0	02	1	9803-0203	●	●
23	DRUM; BRK,FRT PROVISIONS ANTILOCK BRAKE SYSTEM<8MG>	1-42315-380-0	02	1	0706-		●
23	DRUM; BRK,FRT BRK SYSTEM FULL AIR DUAL CIRCUIT(Z06) DISC WHEEL 10STUD 22.5X8.25 165-13<QM8>,DISC WHEEL10STUD 20X7.00T<Q58>,DISC WHEEL 10STUD 20X7.50V 165-12<Q64> FRT & RR SPR LONG SPAN<W55>	1-42315-218-4	02	1	9101-9504	●	●
23	DRUM; BRK,FRT INTERNATIONAL STD ISO<B3V>	1-42315-337-0	02	1	9505-0705	●	●
23	DRUM; BRK,FRT INTERNATIONAL STD ISO<B3V>	1-42315-337-0	02	1	0706-	●
23	DRUM; BRK,FRT INTERNATIONAL STD ISO<B3V> EXC. PROVISIONS ANTILOCK BRAKE SYSTEM<8MG>	1-42315-337-0	02	1	0706-		●
23	DRUM; BRK,FRT FRT & RR SPR LONG SPAN<W55> EXC. DISC WHEEL 10STUD 22.5X8.25 165-13<QM8>,DISC WHEEL 10STUD 20X7.00T<Q58>,DISC WHEEL 10STUD 20X7.50V 165-12<Q64> H=195	1-42315-208-1	02	1	9101-9504	●	●
23	DRUM; BRK,FRT EXC. FRT & RR SPR LONG SPAN<W55> H=195	1-42315-208-1	02	1	9101-9504	●	●
23	DRUM; BRK,FRT EXC. INTERNATIONAL STD ISO<B3V>	1-42315-336-1	02	1	9505-0308	●	●
23	DRUM; BRK,FRT EXC. INTERNATIONAL STD ISO<B3V>	1-42315-355-0	02	1	0309-0705	●	●
23	DRUM; BRK,FRT EXC. INTERNATIONAL STD ISO<B3V>	1-42315-355-0	02	1	0706-	●
23	DRUM; BRK,FRT EXC. INTERNATIONAL STD ISO<B3V>,PROVISIONS ANTILOCK BRAKE SYSTEM<8MG>	1-42315-355-0	02	1	0706-		●
27	NUT; WHEEL PIN,FRT AXLE BRK SYSTEM FULL AIR DUAL CIRCUIT(Z06) DISC WHEEL 10STUD 22.5X8.25 165-13<QM8>,DISC WHEEL10STUD 20X7.00T<Q58>,DISC WHEEL 10STUD 20X7.50V 165-12<Q64> FRT & RR SPR LONG SPAN<W55> M22	1-09400-071-0	20	1	9101-9504	●	●
27	NUT; WHEEL PIN,FRT AXLE INTERNATIONAL STD ISO<B3V> M22	1-09400-071-0	20	1	9505-	●	●
27	NUT; WHEEL PIN,FRT AXLE FRT & RR SPR LONG SPAN<W55> EXC. DISC WHEEL 10STUD 22.5X8.25 165-13<QM8>,DISC WHEEL 10STUD 20X7.00T<Q58>,DISC WHEEL 10STUD 20X7.50V 165-12<Q64> M22	1-09400-037-0	16	1	9101-9504	●	●
27	NUT; WHEEL PIN,FRT AXLE EXC. FRT & RR SPR LONG SPAN<W55> M22	1-09400-037-0	16	1	9101-9504	●	●
27	NUT; WHEEL PIN,FRT AXLE EXC. INTERNATIONAL STD ISO<B3V> M22	9-09110-522-0	16	1	9505-9609	●	●
27	NUT; WHEEL PIN,FRT AXLE EXC. INTERNATIONAL STD ISO<B3V> M22 FLANGE	1-09440-055-0	16	1	9610-9904	●	●
27	NUT; WHEEL PIN,FRT AXLE EXC. INTERNATIONAL STD ISO<B3V> M22 FLANGE	1-09440-065-0	16	1	9905-0705	●	●
27	NUT; WHEEL PIN,FRT AXLE EXC. INTERNATIONAL STD ISO<B3V> M22 FLANGE	1-09440-065-0	16	1	0706-	●
27	NUT; WHEEL PIN,FRT AXLE EXC. INTERNATIONAL STD ISO<B3V>,PROVISIONS ANTILOCK BRAKE SYSTEM<8MG> M22 FLANGE	1-09440-065-0	16	1	0706-		●
28	SEAL; OIL,FRT HUB FRT & RR SPR LONG SPAN<W55> OD=140	1-09625-041-0	02	1	9101-9504	●	●
28	SEAL; OIL,FRT HUB OD=140	1-09625-041-0	02	1	9505-	●	●
28	SEAL; OIL,FRT HUB EXC. FRT & RR SPR LONG SPAN<W55> OD=128	1-09625-129-0	02	1	9101-9504	●	●
30	RING; EXCITER,FRT HUB PROVISIONS ANTILOCK BRAKE SYSTEM<8MG>	1-42319-173-0	02	1	0706-		●
33	WASHER; LK,DRUM COVER ID=10.2	9-09150-510-0	12	1	9101-9108	●	●
33	WASHER; LK,DRUM COVER ID=16.2	9-09150-816-0	04	1	9505-0603	●	●
33	WASHER; LK,DRUM COVER ID=16.2	0-91510-816-0	04	1	0604-	●	●
34	COVER; CHECK HOLE,DRUM COVER	1-09333-095-0	04	1	9101-9501	●	●
34	COVER; CHECK HOLE,DRUM COVER	1-09333-151-0	04	1	9502-	●	●
35	BOLT; DRUM COVER PROVISIONS ANTILOCK BRAKE SYSTEM<8MG> (D) M12X40	0-20851-240-0	02	1	0706-		●
35	BOLT; DRUM COVER PROVISIONS ANTILOCK BRAKE SYSTEM<8MG> (E) M16X59 FLANGE	1-09044-002-2	02	1	0706-		●
35	BOLT; DRUM COVER PROVISIONS ANTILOCK BRAKE SYSTEM<8MG> (C) M16X74 FLANGE	1-09044-057-2	02	1	0706-		●
35	BOLT; DRUM COVER (A) M10X16	9-02041-016-0	12	1	9101-9108	●	●
35	BOLT; DRUM COVER (A) M10X16 W/LK WASHER	9-01901-016-0	12	1	9109-9204	●	●
35	BOLT; DRUM COVER (A) M10X16 FLANGE	0-28081-016-0	12	1	9205-9410	●	●
35	BOLT; DRUM COVER (A) M10X16 W/LK WASHER	0-50041-016-0	12	1	9411-0906	●	●
35	BOLT; DRUM COVER (A) M10X16 W/LK WASHER	0-50541-016-0	12	1	0907-	●	●
35	BOLT; DRUM COVER BRK SYSTEM AIR OVER HYDRAULIC DUAL CIRCUIT(Z05) (B) M16X52	1-09044-001-2	04	1	9505-0203	●	●
35	BOLT; DRUM COVER BRK SYSTEM FULL AIR DUAL CIRCUIT(Z06) (B) M16X59 FLANGE	1-09044-002-2	04	1	9505-0203	●	●
35	BOLT; DRUM COVER (B) M16X59 FLANGE	1-09044-002-2	04	1	0204-0705	●	●
35	BOLT; DRUM COVER (B) M16X59 FLANGE	1-09044-002-2	04	1	0706-	●
35	BOLT; DRUM COVER EXC. PROVISIONS ANTILOCK BRAKE SYSTEM<8MG> (B) M16X59 FLANGE	1-09044-002-2	04	1	0706-		●
35	BOLT; DRUM COVER BRK SYSTEM FULL AIR DUAL CIRCUIT(Z06) EXC. AUTO ADJUSTER BRAKE<BCU> (A) M10X16 W/LK WASHER	0-50041-016-0	24	1	0111-0111	●	●
36	BOLT; BACK PLATE BRK SYSTEM AIR OVER HYDRAULIC DUAL CIRCUIT(Z05) FRT & RR SPR LONG SPAN<W55> M16X52	1-09044-001-1	04	1	9101-9504	●	●
36	BOLT; BACK PLATE BRK SYSTEM FULL AIR DUAL CIRCUIT(Z06) FRT & RR SPR LONG SPAN<W55> M16X59 FLANGE	1-09044-002-1	04	1	9101-9504	●	●
36	BOLT; BACK PLATE EXC. FRT & RR SPR LONG SPAN<W55> M16X61	1-09040-058-1	04	1	9101-9504	●	●
37	WASHER; LK,BACK PLATE FRT & RR SPR LONG SPAN<W55> ID=16.2	9-09150-516-0	04	1	9101-9401	●	●
37	WASHER; LK,BACK PLATE FRT & RR SPR LONG SPAN<W55> ID=16.2	9-09150-816-0	04	1	9402-9504	●	●
37	WASHER; LK,BACK PLATE EXC. FRT & RR SPR LONG SPAN<W55> ID=16.2	9-09150-616-0	08	1	9101-9401	●	●
37	WASHER; LK,BACK PLATE EXC. FRT & RR SPR LONG SPAN<W55> ID=16.2	9-09150-816-0	08	1	9402-9504	●	●
38	NUT; BACK PLATE FRT & RR SPR LONG SPAN<W55> M16	9-99110-416-0	04	1	9101-9504	●	●
38	NUT; BACK PLATE EXC. FRT & RR SPR LONG SPAN<W55> M16	9-99110-416-0	08	1	9101-9504	●	●
53	NUT; DRUM COVER M16	9-99110-416-0	04	1	9505-9902	●	●
53	NUT; DRUM COVER M16	9-99110-516-0	04	1	9903-0512	●	●
53	NUT; DRUM COVER M16	0-91110-516-0	04	1	0601-	●	●

38 53 33 37 35 37 34 34 22 27 15 28 21 23 5 19 13 17 10 6 4 1 3 35 36

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
1	CAP; HUB,FRT AXLE FRT & RR SPR LONG SPAN<W55> OD=156	9-42313-123-2	02	1	9101-9504	●	●
1	CAP; HUB,FRT AXLE OD=156	9-42313-123-2	02	1	9505-	●	●
1	CAP; HUB,FRT AXLE EXC. FRT & RR SPR LONG SPAN<W55> OD=136	1-42313-007-1	02	1	9101-9504	●	●
3	BOLT; HUB CAP,FRT WHEEL M8X14 W/LK WASHER	9-01900-814-0	12	1	9101-9204	●	●
3	BOLT; HUB CAP,FRT WHEEL M8X14 W/LK WASHER	0-50040-814-0	12	1	9205-9509	●	●
3	BOLT; HUB CAP,FRT WHEEL M8X12 FLANGE	0-28080-812-0	12	1	9510-0512	●	●
3	BOLT; HUB CAP,FRT WHEEL M8X12 FLANGE	0-28050-812-0	12	1	0601-	●	●
4	GASKET; HUB CAP,FRT WHEEL FRT & RR SPR LONG SPAN<W55>	1-42319-029-0	02	1	9101-9504	●	●
4	GASKET; HUB CAP,FRT WHEEL	1-42319-029-0	02	1	9505-9906	●	●
4	GASKET; HUB CAP,FRT WHEEL	1-42319-185-2	02	1	9907-	●	●
4	GASKET; HUB CAP,FRT WHEEL EXC. FRT & RR SPR LONG SPAN<W55>	1-42319-028-0	02	1	9101-9504	●	●
5	BOLT; LK WASHER FRT & RR SPR LONG SPAN<W55> M6X16 W/LK WASHER	0-50040-616-0	04	1	9101-9403	●	●
5	BOLT; LK WASHER M6X16 W/LK WASHER	0-50040-616-0	04	1	9404-9701	●	●
5	BOLT; LK WASHER M6X16 FLANGE	0-28680-616-0	04	1	9702-0512	●	●
5	BOLT; LK WASHER M6X16 FLANGE	0-28650-616-0	04	1	0601-0707	●	●
5	BOLT; LK WASHER M6X16 HEX SOCKET	8-98084-271-0	04	1	0708-1201	●	●
5	BOLT; LK WASHER M6X16 HEX SOCKET	8-98200-943-0	04	1	1202-	●	●
5	BOLT; LK WASHER EXC. FRT & RR SPR LONG SPAN<W55> M6X16 W/LK WASHER	0-50040-616-0	06	1	9101-9403	●	●
6	WASHER; LK,FRT HUB FRT & RR SPR LONG SPAN<W55> ID=48	1-09533-012-1	02	1	9101-9504	●	●
6	WASHER; LK,FRT HUB ID=48	1-09533-012-1	02	1	9505-0707	●	●
6	WASHER; LK,FRT HUB ID=48	8-98084-561-0	02	1	0708-	●	●
6	WASHER; LK,FRT HUB EXC. FRT & RR SPR LONG SPAN<W55> ID=39	1-09841-003-0	02	1	9101-9504	●	●
10	NUT; FRT HUB BRG FRT & RR SPR LONG SPAN<W55> M48	1-09840-012-3	02	1	9101-9504	●	●
10	NUT; FRT HUB BRG M48	1-09840-012-5	02	1	9505-	●	●
10	NUT; FRT HUB BRG EXC. FRT & RR SPR LONG SPAN<W55> M39	1-09840-018-1	02	1	9101-9403	●	●
10	NUT; FRT HUB BRG EXC. FRT & RR SPR LONG SPAN<W55> M39	1-09840-019-1	02	1	9404-9504	●	●
13	BEARING; HUB OUTER,FRT AXLE FRT & RR SPR LONG SPAN<W55> NSK	1-09812-084-0	02	1	9101-9504	●	●
13	BEARING; HUB OUTER,FRT AXLE NSK	1-09812-084-0	02	1	9505-9809	●	●
13	BEARING; HUB OUTER,FRT AXLE JTEKT	1-09812-234-0	02	1	9810-	●	●
13	BEARING; HUB OUTER,FRT AXLE FRT & RR SPR LONG SPAN<W55> JTEKT	1-09812-085-0	02	1	9101-9504	●	●
13	BEARING; HUB OUTER,FRT AXLE JTEKT	1-09812-085-0	02	1	9505-9809	●	●
13	BEARING; HUB OUTER,FRT AXLE EXC. FRT & RR SPR LONG SPAN<W55> NSK	9-00093-146-0	02	1	9101-9504	●	●
13	BEARING; HUB OUTER,FRT AXLE EXC. FRT & RR SPR LONG SPAN<W55> KOYO	9-00093-147-1	02	1	9101-9504	●	●
15	PIN; WHEEL,FRT AXLE BRK SYSTEM FULL AIR DUAL CIRCUIT(Z06) DISC WHEEL 10STUD 22.5X8.25 165-13<QM8>,DISC WHEEL10STUD 20X7.00T<Q58>,DISC WHEEL 10STUD 20X7.50V 165-12<Q64> FRT & RR SPR LONG SPAN<W55> M22,M22 L=100 M22X48.8,M22X55.5 RH THREAD	1-42337-011-1	20	1	9101-9504	●	●
15	PIN; WHEEL,FRT AXLE INTERNATIONAL STD ISO<B3V> M22,M22 L=103 M22X42.8,M22X55.5 RH THREAD	1-42337-044-0	20	1	9505-0210	●	●
15	PIN; WHEEL,FRT AXLE INTERNATIONAL STD ISO<B3V> M22X42.8,M22X55.5 RH THREAD	1-42337-067-1	20	1	0211-	●	●
15	PIN; WHEEL,FRT AXLE FRT & RR SPR LONG SPAN<W55> EXC. DISC WHEEL 10STUD 22.5X8.25 165-13<QM8>,DISC WHEEL 10STUD 20X7.00T<Q58>,DISC WHEEL 10STUD 20X7.50V 165-12<Q64> M20X37.5 LH THREAD,M22X55.5 RH THREAD	1-42332-047-0	08	1	9101-9504	●	●
15	PIN; WHEEL,FRT AXLE EXC. INTERNATIONAL STD ISO<B3V> M24X37.5 LH THREAD,M22X57.5 RH THREAD	1-42332-109-0	08	1	9505-0610	●	●
15	PIN; WHEEL,FRT AXLE EXC. INTERNATIONAL STD ISO<B3V> M24X37.5 LH THREAD,M22X57.5 RH THREAD	1-42332-150-1	08	1	0611-0701	●	●
15	PIN; WHEEL,FRT AXLE EXC. INTERNATIONAL STD ISO<B3V> M24X37.5 LH THREAD,M22X57.5 RH THREAD	1-42332-109-1	08	1	0702-0705	●	●
15	PIN; WHEEL,FRT AXLE EXC. INTERNATIONAL STD ISO<B3V> M24X37.5 LH THREAD,M22X57.5 RH THREAD	1-42332-109-1	08	1	0706-	●
15	PIN; WHEEL,FRT AXLE EXC. INTERNATIONAL STD ISO<B3V>,PROVISIONS ANTILOCK BRAKE SYSTEM<8MG> M24X37.5 LH THREAD,M22X57.5 RH THREAD	1-42332-109-1	08	1	0706-		●
15	PIN; WHEEL,FRT AXLE FRT & RR SPR LONG SPAN<W55> EXC. DISC WHEEL 10STUD 22.5X8.25 165-13<QM8>,DISC WHEEL 10STUD 20X7.00T<Q58>,DISC WHEEL 10STUD 20X7.50V 165-12<Q64> M20X37.5,M22X55.5 RH THREAD	1-42331-047-0	08	1	9101-9504	●	●
15	PIN; WHEEL,FRT AXLE EXC. INTERNATIONAL STD ISO<B3V> M24X37.5,M22X57.5 RH THREAD	1-42331-109-0	08	1	9505-0610	●	●
15	PIN; WHEEL,FRT AXLE EXC. INTERNATIONAL STD ISO<B3V> M24X37.5,M22X57.5 RH THREAD	1-42331-150-1	08	1	0611-0701	●	●
15	PIN; WHEEL,FRT AXLE EXC. INTERNATIONAL STD ISO<B3V> M24X37.5,M22X57.5 RH THREAD	1-42331-109-1	08	1	0702-0705	●	●
15	PIN; WHEEL,FRT AXLE EXC. INTERNATIONAL STD ISO<B3V> M24X37.5,M22X57.5 RH THREAD	1-42331-109-1	08	1	0706-	●
15	PIN; WHEEL,FRT AXLE EXC. INTERNATIONAL STD ISO<B3V>,PROVISIONS ANTILOCK BRAKE SYSTEM<8MG> M24X37.5,M22X57.5 RH THREAD	1-42331-109-1	08	1	0706-		●
15	PIN; WHEEL,FRT AXLE EXC. FRT & RR SPR LONG SPAN<W55> M20X37.5 LH THREAD,M22X49.5 RH THREAD	1-42332-058-0	08	1	9101-9504	●	●
15	PIN; WHEEL,FRT AXLE EXC. FRT & RR SPR LONG SPAN<W55> M20X37.5,M22X49.5 RH THREAD	1-42331-058-0	08	1	9101-9504	●	●
17	HUB; FRT AXLE BRK SYSTEM FULL AIR DUAL CIRCUIT(Z06) DISC WHEEL 10STUD 22.5X8.25 165-13<QM8>,DISC WHEEL10STUD 20X7.00T<Q58>,DISC WHEEL 10STUD 20X7.50V 165-12<Q64> FRT & RR SPR LONG SPAN<W55>	1-42312-055-0	02	1	9101-9404	●	●
17	HUB; FRT AXLE BRK SYSTEM FULL AIR DUAL CIRCUIT(Z06) DISC WHEEL 10STUD 22.5X8.25 165-13<QM8>,DISC WHEEL10STUD 20X7.00T<Q58>,DISC WHEEL 10STUD 20X7.50V 165-12<Q64> FRT & RR SPR LONG SPAN<W55>	1-42312-100-0	02	1	9405-9504	●	●
17	HUB; FRT AXLE INTERNATIONAL STD ISO<B3V>	1-42312-100-1	02	1	9505-	●	●
17	HUB; FRT AXLE FRT & RR SPR LONG SPAN<W55> EXC. DISC WHEEL 10STUD 22.5X8.25 165-13<QM8>,DISC WHEEL 10STUD 20X7.00T<Q58>,DISC WHEEL 10STUD 20X7.50V 165-12<Q64>	1-42312-047-2	02	1	9101-9211	●	●
17	HUB; FRT AXLE FRT & RR SPR LONG SPAN<W55> EXC. DISC WHEEL 10STUD 22.5X8.25 165-13<QM8>,DISC WHEEL 10STUD 20X7.00T<Q58>,DISC WHEEL 10STUD 20X7.50V 165-12<Q64>	1-42312-111-0	02	1	9212-9404	●	●
17	HUB; FRT AXLE FRT & RR SPR LONG SPAN<W55> EXC. DISC WHEEL 10STUD 22.5X8.25 165-13<QM8>,DISC WHEEL 10STUD 20X7.00T<Q58>,DISC WHEEL 10STUD 20X7.50V 165-12<Q64>	1-42312-109-0	02	1	9405-9504	●	●
17	HUB; FRT AXLE EXC. INTERNATIONAL STD ISO<B3V>	1-42312-109-0	02	1	9505-9506	●	●
17	HUB; FRT AXLE EXC. INTERNATIONAL STD ISO<B3V>	1-42312-128-2	02	1	9507-0705	●	●
17	HUB; FRT AXLE EXC. INTERNATIONAL STD ISO<B3V>	1-42312-128-2	02	1	0706-	●
17	HUB; FRT AXLE EXC. INTERNATIONAL STD ISO<B3V>,PROVISIONS ANTILOCK BRAKE SYSTEM<8MG>	1-42312-128-2	02	1	0706-		●
17	HUB; FRT AXLE EXC. FRT & RR SPR LONG SPAN<W55>	1-42312-037-1	02	1	9101-9211	●	●
17	HUB; FRT AXLE EXC. FRT & RR SPR LONG SPAN<W55>	1-42312-113-0	02	1	9212-9504	●	●
19	BEARING; HUB INNER,FRT AXLE FRT & RR SPR LONG SPAN<W55> NSK	1-09812-142-0	02	1	9101-9504	●	●
19	BEARING; HUB INNER,FRT AXLE NSK	1-09812-142-0	02	1	9505-9809	●	●
19	BEARING; HUB INNER,FRT AXLE JTEKT	1-09812-231-0	02	1	9810-	●	●
19	BEARING; HUB INNER,FRT AXLE FRT & RR SPR LONG SPAN<W55> JTEKT	1-09812-143-0	02	1	9101-9504	●	●
19	BEARING; HUB INNER,FRT AXLE JTEKT	1-09812-143-0	02	1	9505-9809	●	●
19	BEARING; HUB INNER,FRT AXLE EXC. FRT & RR SPR LONG SPAN<W55> JTEKT	9-00093-114-0	02	1	9101-9504	●	●
21	RING; SNAP,HUB FRT & RR SPR LONG SPAN<W55> (B)	1-09587-017-0	02	1	9101-9504	●	●
21	RING; SNAP,HUB (B)	1-09587-017-0	02	1	9505-	●	●
21	RING; SNAP,HUB EXC. FRT & RR SPR LONG SPAN<W55> (A)	9-09950-164-0	02	1	9101-9504	●	●
22	COVER SET; FRT BRK DRUM BRK SYSTEM AIR OVER HYDRAULIC DUAL CIRCUIT(Z05)	1-47151-458-1	02	1	9101-0203	●	●
22	COVER SET; FRT BRK DRUM BRK SYSTEM FULL AIR DUAL CIRCUIT(Z06)	1-47151-459-1	02	1	9101-9802	●	●
22	COVER SET; FRT BRK DRUM BRK SYSTEM FULL AIR DUAL CIRCUIT(Z06) EXC. AUTO ADJUSTER BRAKE<BCU>	1-47151-459-1	02	1	9803-0203	●	●
22	COVER SET; FRT BRK DRUM	1-47151-459-1	02	1	0204-	●	●
22	COVER SET; FRT BRK DRUM BRK SYSTEM FULL AIR DUAL CIRCUIT(Z06) BRK LINING D2129 NON ASBESTOS<BCL> AUTO ADJUSTER BRAKE<BCU> EXC. INTERNATIONAL STD ISO<B3V>,AUSTRALIA EQUIPMENT<RR3>	1-47151-630-0	02	1	9803-0203	●	●
23	DRUM; BRK,FRT PROVISIONS ANTILOCK BRAKE SYSTEM<8MG>	1-42315-380-0	02	1	0706-		●
23	DRUM; BRK,FRT BRK SYSTEM FULL AIR DUAL CIRCUIT(Z06) DISC WHEEL 10STUD 22.5X8.25 165-13<QM8>,DISC WHEEL10STUD 20X7.00T<Q58>,DISC WHEEL 10STUD 20X7.50V 165-12<Q64> FRT & RR SPR LONG SPAN<W55>	1-42315-218-4	02	1	9101-9504	●	●
23	DRUM; BRK,FRT INTERNATIONAL STD ISO<B3V>	1-42315-337-0	02	1	9505-0705	●	●
23	DRUM; BRK,FRT INTERNATIONAL STD ISO<B3V>	1-42315-337-0	02	1	0706-	●
23	DRUM; BRK,FRT INTERNATIONAL STD ISO<B3V> EXC. PROVISIONS ANTILOCK BRAKE SYSTEM<8MG>	1-42315-337-0	02	1	0706-		●
23	DRUM; BRK,FRT FRT & RR SPR LONG SPAN<W55> EXC. DISC WHEEL 10STUD 22.5X8.25 165-13<QM8>,DISC WHEEL 10STUD 20X7.00T<Q58>,DISC WHEEL 10STUD 20X7.50V 165-12<Q64> H=195	1-42315-208-1	02	1	9101-9504	●	●
23	DRUM; BRK,FRT EXC. FRT & RR SPR LONG SPAN<W55> H=195	1-42315-208-1	02	1	9101-9504	●	●
23	DRUM; BRK,FRT EXC. INTERNATIONAL STD ISO<B3V>	1-42315-336-1	02	1	9505-0308	●	●
23	DRUM; BRK,FRT EXC. INTERNATIONAL STD ISO<B3V>	1-42315-355-0	02	1	0309-0705	●	●
23	DRUM; BRK,FRT EXC. INTERNATIONAL STD ISO<B3V>	1-42315-355-0	02	1	0706-	●
23	DRUM; BRK,FRT EXC. INTERNATIONAL STD ISO<B3V>,PROVISIONS ANTILOCK BRAKE SYSTEM<8MG>	1-42315-355-0	02	1	0706-		●
27	NUT; WHEEL PIN,FRT AXLE BRK SYSTEM FULL AIR DUAL CIRCUIT(Z06) DISC WHEEL 10STUD 22.5X8.25 165-13<QM8>,DISC WHEEL10STUD 20X7.00T<Q58>,DISC WHEEL 10STUD 20X7.50V 165-12<Q64> FRT & RR SPR LONG SPAN<W55> M22	1-09400-071-0	20	1	9101-9504	●	●
27	NUT; WHEEL PIN,FRT AXLE INTERNATIONAL STD ISO<B3V> M22	1-09400-071-0	20	1	9505-	●	●
27	NUT; WHEEL PIN,FRT AXLE FRT & RR SPR LONG SPAN<W55> EXC. DISC WHEEL 10STUD 22.5X8.25 165-13<QM8>,DISC WHEEL 10STUD 20X7.00T<Q58>,DISC WHEEL 10STUD 20X7.50V 165-12<Q64> M22	1-09400-037-0	16	1	9101-9504	●	●
27	NUT; WHEEL PIN,FRT AXLE EXC. FRT & RR SPR LONG SPAN<W55> M22	1-09400-037-0	16	1	9101-9504	●	●
27	NUT; WHEEL PIN,FRT AXLE EXC. INTERNATIONAL STD ISO<B3V> M22	9-09110-522-0	16	1	9505-9609	●	●
27	NUT; WHEEL PIN,FRT AXLE EXC. INTERNATIONAL STD ISO<B3V> M22 FLANGE	1-09440-055-0	16	1	9610-9904	●	●
27	NUT; WHEEL PIN,FRT AXLE EXC. INTERNATIONAL STD ISO<B3V> M22 FLANGE	1-09440-065-0	16	1	9905-0705	●	●
27	NUT; WHEEL PIN,FRT AXLE EXC. INTERNATIONAL STD ISO<B3V> M22 FLANGE	1-09440-065-0	16	1	0706-	●
27	NUT; WHEEL PIN,FRT AXLE EXC. INTERNATIONAL STD ISO<B3V>,PROVISIONS ANTILOCK BRAKE SYSTEM<8MG> M22 FLANGE	1-09440-065-0	16	1	0706-		●
28	SEAL; OIL,FRT HUB FRT & RR SPR LONG SPAN<W55> OD=140	1-09625-041-0	02	1	9101-9504	●	●
28	SEAL; OIL,FRT HUB OD=140	1-09625-041-0	02	1	9505-	●	●
28	SEAL; OIL,FRT HUB EXC. FRT & RR SPR LONG SPAN<W55> OD=128	1-09625-129-0	02	1	9101-9504	●	●
33	WASHER; LK,DRUM COVER ID=10.2	9-09150-510-0	12	1	9101-9108	●	●
33	WASHER; LK,DRUM COVER ID=16.2	9-09150-816-0	04	1	9505-0603	●	●
33	WASHER; LK,DRUM COVER ID=16.2	0-91510-816-0	04	1	0604-	●	●
34	COVER; CHECK HOLE,DRUM COVER	1-09333-095-0	04	1	9101-9501	●	●
34	COVER; CHECK HOLE,DRUM COVER	1-09333-151-0	04	1	9502-	●	●
35	BOLT; DRUM COVER PROVISIONS ANTILOCK BRAKE SYSTEM<8MG> (D) M12X40	0-20851-240-0	02	1	0706-		●
35	BOLT; DRUM COVER PROVISIONS ANTILOCK BRAKE SYSTEM<8MG> (E) M16X59 FLANGE	1-09044-002-2	02	1	0706-		●
35	BOLT; DRUM COVER PROVISIONS ANTILOCK BRAKE SYSTEM<8MG> (C) M16X74 FLANGE	1-09044-057-2	02	1	0706-		●
35	BOLT; DRUM COVER (A) M10X16	9-02041-016-0	12	1	9101-9108	●	●
35	BOLT; DRUM COVER (A) M10X16 W/LK WASHER	9-01901-016-0	12	1	9109-9204	●	●
35	BOLT; DRUM COVER (A) M10X16 FLANGE	0-28081-016-0	12	1	9205-9410	●	●
35	BOLT; DRUM COVER (A) M10X16 W/LK WASHER	0-50041-016-0	12	1	9411-0906	●	●
35	BOLT; DRUM COVER (A) M10X16 W/LK WASHER	0-50541-016-0	12	1	0907-	●	●
35	BOLT; DRUM COVER BRK SYSTEM AIR OVER HYDRAULIC DUAL CIRCUIT(Z05) (B) M16X52	1-09044-001-2	04	1	9505-0203	●	●
35	BOLT; DRUM COVER BRK SYSTEM FULL AIR DUAL CIRCUIT(Z06) (B) M16X59 FLANGE	1-09044-002-2	04	1	9505-0203	●	●
35	BOLT; DRUM COVER (B) M16X59 FLANGE	1-09044-002-2	04	1	0204-0705	●	●
35	BOLT; DRUM COVER (B) M16X59 FLANGE	1-09044-002-2	04	1	0706-	●
35	BOLT; DRUM COVER EXC. PROVISIONS ANTILOCK BRAKE SYSTEM<8MG> (B) M16X59 FLANGE	1-09044-002-2	04	1	0706-		●
35	BOLT; DRUM COVER BRK SYSTEM FULL AIR DUAL CIRCUIT(Z06) EXC. AUTO ADJUSTER BRAKE<BCU> (A) M10X16 W/LK WASHER	0-50041-016-0	24	1	0111-0111	●	●
36	BOLT; BACK PLATE BRK SYSTEM AIR OVER HYDRAULIC DUAL CIRCUIT(Z05) FRT & RR SPR LONG SPAN<W55> M16X52	1-09044-001-1	04	1	9101-9504	●	●
36	BOLT; BACK PLATE BRK SYSTEM FULL AIR DUAL CIRCUIT(Z06) FRT & RR SPR LONG SPAN<W55> M16X59 FLANGE	1-09044-002-1	04	1	9101-9504	●	●
36	BOLT; BACK PLATE EXC. FRT & RR SPR LONG SPAN<W55> M16X61	1-09040-058-1	04	1	9101-9504	●	●
37	WASHER; LK,BACK PLATE FRT & RR SPR LONG SPAN<W55> ID=16.2	9-09150-516-0	04	1	9101-9401	●	●
37	WASHER; LK,BACK PLATE FRT & RR SPR LONG SPAN<W55> ID=16.2	9-09150-816-0	04	1	9402-9504	●	●
37	WASHER; LK,BACK PLATE EXC. FRT & RR SPR LONG SPAN<W55> ID=16.2	9-09150-616-0	08	1	9101-9401	●	●
37	WASHER; LK,BACK PLATE EXC. FRT & RR SPR LONG SPAN<W55> ID=16.2	9-09150-816-0	08	1	9402-9504	●	●
38	NUT; BACK PLATE FRT & RR SPR LONG SPAN<W55> M16	9-99110-416-0	04	1	9101-9504	●	●
38	NUT; BACK PLATE EXC. FRT & RR SPR LONG SPAN<W55> M16	9-99110-416-0	08	1	9101-9504	●	●
53	NUT; DRUM COVER M16	9-99110-416-0	04	1	9505-9902	●	●
53	NUT; DRUM COVER M16	9-99110-516-0	04	1	9903-0512	●	●
53	NUT; DRUM COVER M16	0-91110-516-0	04	1	0601-	●	●

İpucu: çizimdeki balona veya tablodaki Balon sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
