Isuzu WW
▶
SUV
▶
UBS
▶
50658 - UBS-RHD
▶
0 - Engine, Emission, Engine Electrical
▶
0-72 - VAPORIZER
▶
0-72 — VAPORIZER
(#43312) — 14 parça
12
21
50
14
13
52
35
42
53
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
12
03.655 NUT; ADJ PLATE,AIR PUMP
00.854 M8 FLANGE
5-09440-005-0
01
1
9112-
13
03.655 WASHER; LK,BRKT (A)
00.002 ID=10.2
9-09150-610-0
02
1
9112-9405
14
03.655 BOLT; BRKT (A) TO C/BL
M10X40
9-01061-055-0
02
1
9112-9405
14
03.655 BOLT; BRKT (A) TO C/BL
00.685 M10X50 FLANGE
0-28081-050-0
02
1
9406-
21
03.655 BOLT; AIR PUMP BRKT (A)
M10X30
8-94238-617-0
01
1
9112-
35
03.680 CLIP; CABLE,FRT
03.671
8-94160-679-0
01
1
9112-
42
03.670 WASHER; LK,ASV
00.206 ID=6.1
9-09150-506-0
01
1
9112-
50
01.428 STUD; ADJ PLATE,AIR PUMP
03.901 M8X25 L=37
9-04110-825-0
01
1
9112-9204
50
01.428 STUD; ADJ PLATE,AIR PUMP
M8X20 L=32
9-04110-820-0
01
1
9205-
52
03.655 BRACKET; AIR PUMP,ENG SIDE
8-94140-911-1
01
1
9112-9502
52
03.655 BRACKET; AIR PUMP,ENG SIDE
8-97129-607-0
01
1
9503-
53
03.425 NUT; CLIP
16.176 M6
9-09110-406-0
01
1
9112-9208
53
03.425 NUT; CLIP
00.413
9-09110-506-0
01
1
9209-9504
53
03.425 NUT; CLIP
16.176 M6
9-09110-406-0
01
1
9505-
