◀ 🏠 ▶ Isuzu WW ▶ TRUCKS ▶ NKR ▶ 50809 - NKR-LHD ▶ 0 - Engine, Emission, Engine Electrical ▶ 0-01 - PARTIAL ENGINE ▶
0-01 — PARTIAL ENGINE (#43185) — 39 parça
çizim 7570
1
BalonParca AdiParca NoAdetTipApplied Date A B C D
1 00.033 ENGINE ASM; PARTIAL 5-87310-599-5 01 1 0201- ●
1 00.033 ENGINE ASM; PARTIAL
CHILE EQUIPMENT(6KB) 		5-87310-419-1 01 1 9811-0012 ●
1 00.033 ENGINE ASM; PARTIAL
BRAZIL EQUIPMENT(RWF),CHILE EQUIPMENT(6KB) 		5-87310-419-1 01 1 0101-0105 ●
1 00.033 ENGINE ASM; PARTIAL 5-87310-419-2 01 1 0106-0202 ●
1 00.033 ENGINE ASM; PARTIAL 5-87310-640-1 01 1 0203- ●
1 00.033 ENGINE ASM; PARTIAL
TAIWAN EQUIPMENT(RWV) 		5-87310-269-2 01 1 9811-0105 ●
1 00.033 ENGINE ASM; PARTIAL
TURBOCHARGER<K51> CHARGE AIR COOLER<6PL> 		5-87310-529-4 01 1 9811-0209 ●
1 00.033 ENGINE ASM; PARTIAL
TURBOCHARGER<K51> CHARGE AIR COOLER<6PL> 		5-87310-678-1 01 1 0210- ●
1 00.033 ENGINE ASM; PARTIAL
TURBOCHARGER<K51> EXC. CHARGE AIR COOLER<6PL> 		5-87310-423-3 01 1 9811-0209 ●
1 00.033 ENGINE ASM; PARTIAL
TURBOCHARGER<K51> EXC. CHARGE AIR COOLER<6PL> 		5-87310-677-1 01 1 0210- ●
1 00.033 ENGINE ASM; PARTIAL
EXC. TURBOCHARGER<K51> 		5-87310-350-2 01 1 9811- ●
1 00.033 ENGINE ASM; PARTIAL 5-87310-493-1 01 1 9811-9902 ●
1 00.033 ENGINE ASM; PARTIAL 5-87310-539-4 01 1 9903- ●
çizim 8595
1
BalonParca AdiParca NoAdetTipApplied Date A B C D
1 00.033 ENGINE ASM; PARTIAL 5-87310-599-5 01 1 0201- ●
1 00.033 ENGINE ASM; PARTIAL
CHILE EQUIPMENT(6KB) 		5-87310-419-1 01 1 9811-0012 ●
1 00.033 ENGINE ASM; PARTIAL
BRAZIL EQUIPMENT(RWF),CHILE EQUIPMENT(6KB) 		5-87310-419-1 01 1 0101-0105 ●
1 00.033 ENGINE ASM; PARTIAL 5-87310-419-2 01 1 0106-0202 ●
1 00.033 ENGINE ASM; PARTIAL 5-87310-640-1 01 1 0203- ●
1 00.033 ENGINE ASM; PARTIAL
TAIWAN EQUIPMENT(RWV) 		5-87310-269-2 01 1 9811-0105 ●
1 00.033 ENGINE ASM; PARTIAL
TURBOCHARGER<K51> CHARGE AIR COOLER<6PL> 		5-87310-529-4 01 1 9811-0209 ●
1 00.033 ENGINE ASM; PARTIAL
TURBOCHARGER<K51> CHARGE AIR COOLER<6PL> 		5-87310-678-1 01 1 0210- ●
1 00.033 ENGINE ASM; PARTIAL
TURBOCHARGER<K51> EXC. CHARGE AIR COOLER<6PL> 		5-87310-423-3 01 1 9811-0209 ●
1 00.033 ENGINE ASM; PARTIAL
TURBOCHARGER<K51> EXC. CHARGE AIR COOLER<6PL> 		5-87310-677-1 01 1 0210- ●
1 00.033 ENGINE ASM; PARTIAL
EXC. TURBOCHARGER<K51> 		5-87310-350-2 01 1 9811- ●
1 00.033 ENGINE ASM; PARTIAL 5-87310-493-1 01 1 9811-9902 ●
1 00.033 ENGINE ASM; PARTIAL 5-87310-539-4 01 1 9903- ●
çizim 10647
1
BalonParca AdiParca NoAdetTipApplied Date A B C D
1 00.033 ENGINE ASM; PARTIAL 5-87310-599-5 01 1 0201- ●
1 00.033 ENGINE ASM; PARTIAL
CHILE EQUIPMENT(6KB) 		5-87310-419-1 01 1 9811-0012 ●
1 00.033 ENGINE ASM; PARTIAL
BRAZIL EQUIPMENT(RWF),CHILE EQUIPMENT(6KB) 		5-87310-419-1 01 1 0101-0105 ●
1 00.033 ENGINE ASM; PARTIAL 5-87310-419-2 01 1 0106-0202 ●
1 00.033 ENGINE ASM; PARTIAL 5-87310-640-1 01 1 0203- ●
1 00.033 ENGINE ASM; PARTIAL
TAIWAN EQUIPMENT(RWV) 		5-87310-269-2 01 1 9811-0105 ●
1 00.033 ENGINE ASM; PARTIAL
TURBOCHARGER<K51> CHARGE AIR COOLER<6PL> 		5-87310-529-4 01 1 9811-0209 ●
1 00.033 ENGINE ASM; PARTIAL
TURBOCHARGER<K51> CHARGE AIR COOLER<6PL> 		5-87310-678-1 01 1 0210- ●
1 00.033 ENGINE ASM; PARTIAL
TURBOCHARGER<K51> EXC. CHARGE AIR COOLER<6PL> 		5-87310-423-3 01 1 9811-0209 ●
1 00.033 ENGINE ASM; PARTIAL
TURBOCHARGER<K51> EXC. CHARGE AIR COOLER<6PL> 		5-87310-677-1 01 1 0210- ●
1 00.033 ENGINE ASM; PARTIAL
EXC. TURBOCHARGER<K51> 		5-87310-350-2 01 1 9811- ●
1 00.033 ENGINE ASM; PARTIAL 5-87310-493-1 01 1 9811-9902 ●
1 00.033 ENGINE ASM; PARTIAL 5-87310-539-4 01 1 9903- ●
