Sayfa 1-10 - Isuzu EPC

1-10 — RADIATOR (#43081) — 225 parça

131 1 16 81 2 132 70 21 51 21 62 75 74 27 23 22 23 59 57 25 27 26 58 22 74 518 56 26 25 204 240 62 74 518 205

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B	C
1	RADIATOR ASM 4HK1-TCS ENG<RJS>	8-97377-241-0	01	1	0510-	●	●
1	RADIATOR ASM 4HG1-T ENG<RDP> M/T MYY5T<RSM> THA	8-97940-295-1	01	1	0508-	●		●
1	RADIATOR ASM 4HE1-TCS ENG<RDS> THA	8-97942-216-0	01	1	0508-	●	●
2	GUIDE; FAN 4HK1-TCS ENG<RJS> (A)	8-97350-995-0	01	1	0510-	●	●
2	GUIDE; FAN 4HE1-TCS ENG<RDS> (A)	8-97068-803-0	01	1	0508-	●	●
2	GUIDE; FAN 4HK1-TCS ENG<RJS> (B)	8-97333-268-0	01	1	0510-	●	●
2	GUIDE; FAN 4HG1-T ENG<RDP> M/T MYY5T<RSM> (B) THA	8-97942-319-0	01	1	0508-	●		●
2	GUIDE; FAN 4HE1-TCS ENG<RDS> (B) THA	8-97218-802-1	01	1	0508-	●	●
16	CAP; RAD 4HK1-TCS ENG<RJS> THA	8-97239-187-0	01	1	0510-	●	●
16	CAP; RAD 4HG1-T ENG<RDP> M/T MYY5T<RSM> THA	8-97940-668-0	01	1	0508-	●		●
16	CAP; RAD 4HE1-TCS ENG<RDS> THA	8-97940-668-0	01	1	0508-	●	●
21	SEAL; RAD 4HK1-TCS ENG<RJS> (C)	8-97332-382-0	01	1	0510-	●	●
21	SEAL; RAD 4HG1-T ENG<RDP> M/T MYY5T<RSM> (B) THA	8-97940-664-0	01	1	0508-	●		●
21	SEAL; RAD 4HG1-T ENG<RDP> M/T MYY5T<RSM> (A) THA	8-97940-665-0	01	1	0508-	●		●
22	BRACKET; RAD MTG 4HK1-TCS ENG<RJS>	8-97333-280-0	01	1	0510-	●	●
22	BRACKET; RAD MTG 4HK1-TCS ENG<RJS>	8-97333-281-0	01	1	0510-	●	●
22	BRACKET; RAD MTG 4HG1-T ENG<RDP> EXC. FRAME STRAIGHT TYPE<7KJ> THA	8-97918-331-0	02	1	0508-	●
22	BRACKET; RAD MTG 4HG1-T ENG<RDP> THA	8-97918-331-0	02	1	0508-			●
22	BRACKET; RAD MTG 4HE1-TCS ENG<RDS> FRAME STRAIGHT TYPE<7KJ> THA	8-97918-330-0	02	1	0508-	●
22	BRACKET; RAD MTG 4HE1-TCS ENG<RDS> THA	8-97918-330-0	02	1	0508-		●
23	NUT; RAD MTG 4HG1-T ENG<RDP>,4HE1-TCS ENG<RDS> M10 FLANGE	5-09440-006-0	04	1	0508-	●	●	●
25	BOLT; BRKT 4HK1-TCS ENG<RJS> M8X12 FLANGE	0-28080-812-0	08	1	0510-	●	●
25	BOLT; BRKT 4HG1-T ENG<RDP>,4HE1-TCS ENG<RDS> M8 FLANGE	0-91150-108-0	04	1	0508-	●	●	●
25	BOLT; BRKT 4HG1-T ENG<RDP>,4HE1-TCS ENG<RDS> M10X30 FLANGE	0-28681-030-0	04	1	0508-0512	●	●	●
25	BOLT; BRKT 4HG1-T ENG<RDP>,4HE1-TCS ENG<RDS> M10X30 FLANGE THA	0-28651-030-0	04	1	0601-	●	●	●
26	BUFFER; RAD,LWR THA	8-97916-760-0	02	1	0508-	●	●	●
27	BUFFER; RAD,UPR THA	8-97916-770-0	02	1	0508-	●	●	●
51	PLUG; DRAIN 4HK1-TCS ENG<RJS> W/GASKET THA	8-97171-437-0	01	1	0510-	●	●
51	PLUG; DRAIN 4HG1-T ENG<RDP> M/T MYY5T<RSM> THA	8-97940-673-0	01	1	0508-	●		●
51	PLUG; DRAIN 4HE1-TCS ENG<RDS> THA	8-97940-673-0	01	1	0508-	●	●
56	STAY; RAD 4HG1-T ENG<RDP> EXC. FRAME STRAIGHT TYPE<7KJ>	8-97330-456-0	01	1	0508-	●
56	STAY; RAD 4HG1-T ENG<RDP>	8-97330-456-0	01	1	0508-			●
56	STAY; RAD 4HE1-TCS ENG<RDS>	8-97073-424-2	01	1	0508-	●	●
56	STAY; RAD 4HK1-TCS ENG<RJS>	8-97032-802-2	01	1	0510-	●	●
57	WASHER; PL,STAY ID=10.5 OD=18	9-09160-510-0	01	1	0508-0611	●	●	●
57	WASHER; PL,STAY ID=10.5	0-91610-510-0	01	1	0612-	●	●	●
58	WASHER; CURVED,STAY ID=12	8-97011-676-0	01	1	0508-	●	●	●
59	PIN; SNAP,STAY L=32.6	8-94202-777-0	01	1	0508-	●	●	●
62	BOLT; STAY (B) M8X45	8-94401-350-0	01	1	0508-	●	●	●
62	BOLT; STAY 4HG1-T ENG<RDP> M/T MYY5T<RSM> (A) M8X12 FLANGE	0-28080-812-0	02	1	0508-0509	●		●
62	BOLT; STAY 4HE1-TCS ENG<RDS> (A) M8X12 FLANGE	0-28080-812-0	02	1	0508-0509	●	●
62	BOLT; STAY 4HG1-T ENG<RDP> M/T MYY5T<RSM> (A) M8X12 FLANGE	0-28080-812-0	02	1	0510-	●		●
62	BOLT; STAY 4HE1-TCS ENG<RDS>,4HK1-TCS ENG<RJS> (A) M8X12 FLANGE	0-28080-812-0	02	1	0510-	●	●
70	STAY; RAD 4HK1-TCS ENG<RJS>	8-97333-269-0	01	1	0510-	●	●
70	STAY; RAD 4HG1-T ENG<RDP> M/T MYY5T<RSM> THA	8-97940-660-0	01	1	0508-	●		●
70	STAY; RAD 4HE1-TCS ENG<RDS> THA	8-97940-660-0	01	1	0508-	●	●
74	WASHER; PL,CUSHION RUBBER 4HG1-T ENG<RDP>,4HE1-TCS ENG<RDS> (B) ID=10.5 OD=26	9-09160-710-0	01	1	0508-	●	●	●
74	WASHER; PL,CUSHION RUBBER (A) ID=8.5 OD=36	8-94221-082-0	02	1	0508-	●	●	●
75	BOLT; CUSHION RUBBER,RAD MTG 4HG1-T ENG<RDP>,4HE1-TCS ENG<RDS> M8X63	8-94249-446-0	01	1	0508-	●	●	●
81	SCREW; FAN GUIDE,RAD 4HG1-T ENG<RDP> M/T MYY5T<RSM> THA	8-97940-658-0	04	1	0508-	●		●
116	WASHER; PL,BRKT 4HK1-TCS ENG<RJS> ID=8.4 THA	9-09160-508-0	08	1	0510-	●	●
131	CLIP; ENG SIDE TOP ID=40	8-97245-216-0	01	1	0508-	●	●	●
132	CLIP; HOSE,ENG SIDE BOTTOM ID=50	8-97245-217-0	01	1	0508-	●	●	●
204	GUIDE ASM; AIR 4HK1-TCS ENG<RJS>	8-97332-962-1	01	1	0510-	●	●
204	GUIDE ASM; AIR 4HG1-T ENG<RDP> AIR CONDITIONER MANUAL CONT<C60>	8-97038-894-1	01	1	0508-	●		●
205	BOLT; AIR GUIDE 4HG1-T ENG<RDP> AIR CONDITIONER MANUAL CONT<C60> M6X12 FLANGE	0-28080-612-0	04	1	0508-0512	●		●
205	BOLT; AIR GUIDE 4HG1-T ENG<RDP> AIR CONDITIONER MANUAL CONT<C60> M6X12 FLANGE THA	0-28050-612-0	04	1	0601-	●		●
205	BOLT; AIR GUIDE 4HK1-TCS ENG<RJS> M6X10 FLANGE	0-28080-610-0	04	1	0510-0512	●	●
205	BOLT; AIR GUIDE 4HK1-TCS ENG<RJS> M6X10 FLANGE THA	0-28050-610-0	04	1	0601-	●	●
240	NUT; STAY M8 FLANGE	8-94178-701-0	01	1	0508-	●	●	●
518	NUT 4HK1-TCS ENG<RJS> (B) M8 FLANGE	0-91150-108-0	02	1	0510-	●	●
518	NUT (A) M8 FLANGE THA	5-09440-005-0	02	1	0508-0805	●	●	●
518	NUT (A) M8 FLANGE THA	8-97581-233-0	02	1	0806-	●	●	●

131 421 92 2 132 92 100 100 80 92 1 421 82 305 427 80 2 16 21 70 62 518 74 27 59 57 58 56 240 518 51 26 542 506 62 91 205 482 542 204

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B	C
1	RADIATOR ASM 4HK1-TCS ENG<RJS>	8-97377-241-0	01	1	0510-	●	●
1	RADIATOR ASM 4HG1-T ENG<RDP> M/T MYY5T<RSM> THA	8-97940-295-1	01	1	0508-	●		●
1	RADIATOR ASM 4HE1-TCS ENG<RDS> THA	8-97942-216-0	01	1	0508-	●	●
2	GUIDE; FAN 4HK1-TCS ENG<RJS> (A)	8-97350-995-0	01	1	0510-	●	●
2	GUIDE; FAN 4HE1-TCS ENG<RDS> (A)	8-97068-803-0	01	1	0508-	●	●
2	GUIDE; FAN 4HK1-TCS ENG<RJS> (B)	8-97333-268-0	01	1	0510-	●	●
2	GUIDE; FAN 4HG1-T ENG<RDP> M/T MYY5T<RSM> (B) THA	8-97942-319-0	01	1	0508-	●		●
2	GUIDE; FAN 4HE1-TCS ENG<RDS> (B) THA	8-97218-802-1	01	1	0508-	●	●
16	CAP; RAD 4HK1-TCS ENG<RJS> THA	8-97239-187-0	01	1	0510-	●	●
16	CAP; RAD 4HG1-T ENG<RDP> M/T MYY5T<RSM> THA	8-97940-668-0	01	1	0508-	●		●
16	CAP; RAD 4HE1-TCS ENG<RDS> THA	8-97940-668-0	01	1	0508-	●	●
21	SEAL; RAD 4HK1-TCS ENG<RJS> (C)	8-97332-382-0	01	1	0510-	●	●
21	SEAL; RAD 4HG1-T ENG<RDP> M/T MYY5T<RSM> (B) THA	8-97940-664-0	01	1	0508-	●		●
21	SEAL; RAD 4HG1-T ENG<RDP> M/T MYY5T<RSM> (A) THA	8-97940-665-0	01	1	0508-	●		●
26	BUFFER; RAD,LWR THA	8-97916-760-0	02	1	0508-	●	●	●
27	BUFFER; RAD,UPR THA	8-97916-770-0	02	1	0508-	●	●	●
51	PLUG; DRAIN 4HK1-TCS ENG<RJS> W/GASKET THA	8-97171-437-0	01	1	0510-	●	●
51	PLUG; DRAIN 4HG1-T ENG<RDP> M/T MYY5T<RSM> THA	8-97940-673-0	01	1	0508-	●		●
51	PLUG; DRAIN 4HE1-TCS ENG<RDS> THA	8-97940-673-0	01	1	0508-	●	●
56	STAY; RAD 4HG1-T ENG<RDP> EXC. FRAME STRAIGHT TYPE<7KJ>	8-97330-456-0	01	1	0508-	●
56	STAY; RAD 4HG1-T ENG<RDP>	8-97330-456-0	01	1	0508-			●
56	STAY; RAD 4HE1-TCS ENG<RDS>	8-97073-424-2	01	1	0508-	●	●
56	STAY; RAD 4HK1-TCS ENG<RJS>	8-97032-802-2	01	1	0510-	●	●
57	WASHER; PL,STAY ID=10.5 OD=18	9-09160-510-0	01	1	0508-0611	●	●	●
57	WASHER; PL,STAY ID=10.5	0-91610-510-0	01	1	0612-	●	●	●
58	WASHER; CURVED,STAY ID=12	8-97011-676-0	01	1	0508-	●	●	●
59	PIN; SNAP,STAY L=32.6	8-94202-777-0	01	1	0508-	●	●	●
62	BOLT; STAY (B) M8X45	8-94401-350-0	01	1	0508-	●	●	●
62	BOLT; STAY 4HG1-T ENG<RDP> M/T MYY5T<RSM> (A) M8X12 FLANGE	0-28080-812-0	02	1	0508-0509	●		●
62	BOLT; STAY 4HE1-TCS ENG<RDS> (A) M8X12 FLANGE	0-28080-812-0	02	1	0508-0509	●	●
62	BOLT; STAY 4HG1-T ENG<RDP> M/T MYY5T<RSM> (A) M8X12 FLANGE	0-28080-812-0	02	1	0510-	●		●
62	BOLT; STAY 4HE1-TCS ENG<RDS>,4HK1-TCS ENG<RJS> (A) M8X12 FLANGE	0-28080-812-0	02	1	0510-	●	●
70	STAY; RAD 4HK1-TCS ENG<RJS>	8-97333-269-0	01	1	0510-	●	●
70	STAY; RAD 4HG1-T ENG<RDP> M/T MYY5T<RSM> THA	8-97940-660-0	01	1	0508-	●		●
70	STAY; RAD 4HE1-TCS ENG<RDS> THA	8-97940-660-0	01	1	0508-	●	●
74	WASHER; PL,CUSHION RUBBER 4HG1-T ENG<RDP>,4HE1-TCS ENG<RDS> (B) ID=10.5 OD=26	9-09160-710-0	01	1	0508-	●	●	●
74	WASHER; PL,CUSHION RUBBER (A) ID=8.5 OD=36	8-94221-082-0	02	1	0508-	●	●	●
80	BOLT; FAN GUIDE 4HE1-TCS ENG<RDS>,4HK1-TCS ENG<RJS> (B) M8X30 W/LK&PL WASHER	0-50140-830-0	03	1	0510-0512	●	●
80	BOLT; FAN GUIDE 4HE1-TCS ENG<RDS>,4HK1-TCS ENG<RJS> (B) M8X30 W/LK&PL WASHER	0-50640-830-0	03	1	0601-0806	●	●
80	BOLT; FAN GUIDE 4HE1-TCS ENG<RDS>,4HK1-TCS ENG<RJS> (B) M8X30 FLANGE THA	0-28650-830-0	03	1	0807-	●	●
80	BOLT; FAN GUIDE 4HE1-TCS ENG<RDS> (A) M6X12 FLANGE	0-28080-612-0	04	1	0508-	●	●
80	BOLT; FAN GUIDE 4HE1-TCS ENG<RDS> (B) M8X30 W/LK&PL WASHER	0-50140-830-0	03	1	0508-0509	●	●
80	BOLT; FAN GUIDE 4HE1-TCS ENG<RDS>,4HK1-TCS ENG<RJS> (B) M8X30 W/LK&PL WASHER	0-50140-830-0	03	1	0510-0701	●	●
80	BOLT; FAN GUIDE 4HE1-TCS ENG<RDS>,4HK1-TCS ENG<RJS> (B) M8X30 W/LK&PL WASHER	0-50640-830-0	03	1	0702-	●	●
80	BOLT; FAN GUIDE 4HK1-TCS ENG<RJS> (A) M6X12 FLANGE	0-28080-612-0	04	1	0510-	●	●
82	COVER; FAN,RAD 4HK1-TCS ENG<RJS>	8-97332-330-0	01	1	0510-	●	●
82	COVER; FAN,RAD 4HE1-TCS ENG<RDS> THA	8-97218-799-0	01	1	0508-	●	●
91	WASHER; PL 4HK1-TCS ENG<RJS> ID=6.4 OD=18	9-09160-706-0	04	1	0510-0605	●	●
91	WASHER; PL 4HK1-TCS ENG<RJS> ID=6.4 OD=18	0-91610-706-0	04	1	0606-	●	●
92	BRACKET; FAN GUIDE 4HK1-TCS ENG<RJS> (B)	8-97350-996-0	01	1	0510-	●	●
92	BRACKET; FAN GUIDE 4HK1-TCS ENG<RJS> (C)	8-97350-997-0	01	1	0510-	●	●
92	BRACKET; FAN GUIDE 4HK1-TCS ENG<RJS> (A)	8-97350-998-0	01	1	0510-	●	●
92	BRACKET; FAN GUIDE 4HE1-TCS ENG<RDS> (B)	8-97148-940-0	01	1	0508-	●	●
92	BRACKET; FAN GUIDE 4HE1-TCS ENG<RDS> (C)	8-97148-941-1	01	1	0508-	●	●
92	BRACKET; FAN GUIDE 4HE1-TCS ENG<RDS> (A)	8-97189-394-1	01	1	0508-	●	●
100	RUBBER; MTG 4HE1-TCS ENG<RDS>	1-09337-027-0	06	1	0508-0509	●	●
100	RUBBER; MTG 4HE1-TCS ENG<RDS>,4HK1-TCS ENG<RJS>	1-09337-027-0	06	1	0510-	●	●
116	WASHER; PL,BRKT 4HK1-TCS ENG<RJS> ID=8.4 THA	9-09160-508-0	08	1	0510-	●	●
131	CLIP; ENG SIDE TOP ID=40	8-97245-216-0	01	1	0508-	●	●	●
132	CLIP; HOSE,ENG SIDE BOTTOM ID=50	8-97245-217-0	01	1	0508-	●	●	●
204	GUIDE ASM; AIR 4HK1-TCS ENG<RJS>	8-97332-962-1	01	1	0510-	●	●
204	GUIDE ASM; AIR 4HG1-T ENG<RDP> AIR CONDITIONER MANUAL CONT<C60>	8-97038-894-1	01	1	0508-	●		●
205	BOLT; AIR GUIDE 4HG1-T ENG<RDP> AIR CONDITIONER MANUAL CONT<C60> M6X12 FLANGE	0-28080-612-0	04	1	0508-0512	●		●
205	BOLT; AIR GUIDE 4HG1-T ENG<RDP> AIR CONDITIONER MANUAL CONT<C60> M6X12 FLANGE THA	0-28050-612-0	04	1	0601-	●		●
205	BOLT; AIR GUIDE 4HK1-TCS ENG<RJS> M6X10 FLANGE	0-28080-610-0	04	1	0510-0512	●	●
205	BOLT; AIR GUIDE 4HK1-TCS ENG<RJS> M6X10 FLANGE THA	0-28050-610-0	04	1	0601-	●	●
240	NUT; STAY M8 FLANGE	8-94178-701-0	01	1	0508-	●	●	●
305	CLIP; FAN COVER TO FAN GUIDE 4HE1-TCS ENG<RDS>	1-09470-009-0	12	1	0508-	●	●
305	CLIP; FAN COVER TO FAN GUIDE 4HK1-TCS ENG<RJS>	1-09470-009-0	12	1	0510-	●	●
421	BOLT; BRKT FAN GUIDE 4HE1-TCS ENG<RDS> (A) M10X18 FLANGE	0-28181-018-0	02	1	0508-0509	●	●
421	BOLT; BRKT FAN GUIDE 4HE1-TCS ENG<RDS>,4HK1-TCS ENG<RJS> (A) M10X18 FLANGE	0-28181-018-0	02	1	0510-	●	●
421	BOLT; BRKT FAN GUIDE 4HE1-TCS ENG<RDS> (B) M10X20 FLANGE	0-28181-020-0	02	1	0508-0509	●	●
421	BOLT; BRKT FAN GUIDE 4HE1-TCS ENG<RDS>,4HK1-TCS ENG<RJS> (B) M10X20 FLANGE	0-28181-020-0	02	1	0510-0512	●	●
421	BOLT; BRKT FAN GUIDE 4HE1-TCS ENG<RDS>,4HK1-TCS ENG<RJS> (B) M10X20 FLANGE THA	0-28151-020-0	02	1	0601-	●	●
427	CLIP; FAN GUIDE 4HK1-TCS ENG<RJS>	1-09470-009-0	01	1	0510-	●	●
482	NUT; AIR GUIDE 4HK1-TCS ENG<RJS> M6 FLANGE	0-91150-106-0	04	1	0510-0602	●	●
482	NUT; AIR GUIDE 4HK1-TCS ENG<RJS> M6 FLANGE THA	0-91180-106-0	04	1	0603-	●	●
506	PLATE; RAD 4HK1-TCS ENG<RJS>	8-97330-527-1	02	1	0510-	●	●
518	NUT 4HK1-TCS ENG<RJS> (B) M8 FLANGE	0-91150-108-0	02	1	0510-	●	●
518	NUT (A) M8 FLANGE THA	5-09440-005-0	02	1	0508-0805	●	●	●
518	NUT (A) M8 FLANGE THA	8-97581-233-0	02	1	0806-	●	●	●
542	BRACKET; AIR GUIDE 4HK1-TCS ENG<RJS>	8-97332-963-0	01	1	0510-	●	●
542	BRACKET; AIR GUIDE 4HK1-TCS ENG<RJS>	8-97332-964-0	01	1	0510-	●	●

92 421 2 92 132 100 100 80 92 131 421 82 305 1 27 22 23 80 297 2 16 25 26 74 518 51 70 62 75 59 57 74 58 27 23 56 22 26 25 240 74 62 518

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B	C
1	RADIATOR ASM 4HK1-TCS ENG<RJS>	8-97377-241-0	01	1	0510-	●	●
1	RADIATOR ASM 4HG1-T ENG<RDP> M/T MYY5T<RSM> THA	8-97940-295-1	01	1	0508-	●		●
1	RADIATOR ASM 4HE1-TCS ENG<RDS> THA	8-97942-216-0	01	1	0508-	●	●
2	GUIDE; FAN 4HK1-TCS ENG<RJS> (A)	8-97350-995-0	01	1	0510-	●	●
2	GUIDE; FAN 4HE1-TCS ENG<RDS> (A)	8-97068-803-0	01	1	0508-	●	●
2	GUIDE; FAN 4HK1-TCS ENG<RJS> (B)	8-97333-268-0	01	1	0510-	●	●
2	GUIDE; FAN 4HG1-T ENG<RDP> M/T MYY5T<RSM> (B) THA	8-97942-319-0	01	1	0508-	●		●
2	GUIDE; FAN 4HE1-TCS ENG<RDS> (B) THA	8-97218-802-1	01	1	0508-	●	●
16	CAP; RAD 4HK1-TCS ENG<RJS> THA	8-97239-187-0	01	1	0510-	●	●
16	CAP; RAD 4HG1-T ENG<RDP> M/T MYY5T<RSM> THA	8-97940-668-0	01	1	0508-	●		●
16	CAP; RAD 4HE1-TCS ENG<RDS> THA	8-97940-668-0	01	1	0508-	●	●
22	BRACKET; RAD MTG 4HK1-TCS ENG<RJS>	8-97333-280-0	01	1	0510-	●	●
22	BRACKET; RAD MTG 4HK1-TCS ENG<RJS>	8-97333-281-0	01	1	0510-	●	●
22	BRACKET; RAD MTG 4HG1-T ENG<RDP> EXC. FRAME STRAIGHT TYPE<7KJ> THA	8-97918-331-0	02	1	0508-	●
22	BRACKET; RAD MTG 4HG1-T ENG<RDP> THA	8-97918-331-0	02	1	0508-			●
22	BRACKET; RAD MTG 4HE1-TCS ENG<RDS> FRAME STRAIGHT TYPE<7KJ> THA	8-97918-330-0	02	1	0508-	●
22	BRACKET; RAD MTG 4HE1-TCS ENG<RDS> THA	8-97918-330-0	02	1	0508-		●
23	NUT; RAD MTG 4HG1-T ENG<RDP>,4HE1-TCS ENG<RDS> M10 FLANGE	5-09440-006-0	04	1	0508-	●	●	●
25	BOLT; BRKT 4HK1-TCS ENG<RJS> M8X12 FLANGE	0-28080-812-0	08	1	0510-	●	●
25	BOLT; BRKT 4HG1-T ENG<RDP>,4HE1-TCS ENG<RDS> M8 FLANGE	0-91150-108-0	04	1	0508-	●	●	●
25	BOLT; BRKT 4HG1-T ENG<RDP>,4HE1-TCS ENG<RDS> M10X30 FLANGE	0-28681-030-0	04	1	0508-0512	●	●	●
25	BOLT; BRKT 4HG1-T ENG<RDP>,4HE1-TCS ENG<RDS> M10X30 FLANGE THA	0-28651-030-0	04	1	0601-	●	●	●
26	BUFFER; RAD,LWR THA	8-97916-760-0	02	1	0508-	●	●	●
27	BUFFER; RAD,UPR THA	8-97916-770-0	02	1	0508-	●	●	●
51	PLUG; DRAIN 4HK1-TCS ENG<RJS> W/GASKET THA	8-97171-437-0	01	1	0510-	●	●
51	PLUG; DRAIN 4HG1-T ENG<RDP> M/T MYY5T<RSM> THA	8-97940-673-0	01	1	0508-	●		●
51	PLUG; DRAIN 4HE1-TCS ENG<RDS> THA	8-97940-673-0	01	1	0508-	●	●
56	STAY; RAD 4HG1-T ENG<RDP> EXC. FRAME STRAIGHT TYPE<7KJ>	8-97330-456-0	01	1	0508-	●
56	STAY; RAD 4HG1-T ENG<RDP>	8-97330-456-0	01	1	0508-			●
56	STAY; RAD 4HE1-TCS ENG<RDS>	8-97073-424-2	01	1	0508-	●	●
56	STAY; RAD 4HK1-TCS ENG<RJS>	8-97032-802-2	01	1	0510-	●	●
57	WASHER; PL,STAY ID=10.5 OD=18	9-09160-510-0	01	1	0508-0611	●	●	●
57	WASHER; PL,STAY ID=10.5	0-91610-510-0	01	1	0612-	●	●	●
58	WASHER; CURVED,STAY ID=12	8-97011-676-0	01	1	0508-	●	●	●
59	PIN; SNAP,STAY L=32.6	8-94202-777-0	01	1	0508-	●	●	●
62	BOLT; STAY (B) M8X45	8-94401-350-0	01	1	0508-	●	●	●
62	BOLT; STAY 4HG1-T ENG<RDP> M/T MYY5T<RSM> (A) M8X12 FLANGE	0-28080-812-0	02	1	0508-0509	●		●
62	BOLT; STAY 4HE1-TCS ENG<RDS> (A) M8X12 FLANGE	0-28080-812-0	02	1	0508-0509	●	●
62	BOLT; STAY 4HG1-T ENG<RDP> M/T MYY5T<RSM> (A) M8X12 FLANGE	0-28080-812-0	02	1	0510-	●		●
62	BOLT; STAY 4HE1-TCS ENG<RDS>,4HK1-TCS ENG<RJS> (A) M8X12 FLANGE	0-28080-812-0	02	1	0510-	●	●
70	STAY; RAD 4HK1-TCS ENG<RJS>	8-97333-269-0	01	1	0510-	●	●
70	STAY; RAD 4HG1-T ENG<RDP> M/T MYY5T<RSM> THA	8-97940-660-0	01	1	0508-	●		●
70	STAY; RAD 4HE1-TCS ENG<RDS> THA	8-97940-660-0	01	1	0508-	●	●
74	WASHER; PL,CUSHION RUBBER 4HG1-T ENG<RDP>,4HE1-TCS ENG<RDS> (B) ID=10.5 OD=26	9-09160-710-0	01	1	0508-	●	●	●
74	WASHER; PL,CUSHION RUBBER (A) ID=8.5 OD=36	8-94221-082-0	02	1	0508-	●	●	●
75	BOLT; CUSHION RUBBER,RAD MTG 4HG1-T ENG<RDP>,4HE1-TCS ENG<RDS> M8X63	8-94249-446-0	01	1	0508-	●	●	●
80	BOLT; FAN GUIDE 4HE1-TCS ENG<RDS>,4HK1-TCS ENG<RJS> (B) M8X30 W/LK&PL WASHER	0-50140-830-0	03	1	0510-0512	●	●
80	BOLT; FAN GUIDE 4HE1-TCS ENG<RDS>,4HK1-TCS ENG<RJS> (B) M8X30 W/LK&PL WASHER	0-50640-830-0	03	1	0601-0806	●	●
80	BOLT; FAN GUIDE 4HE1-TCS ENG<RDS>,4HK1-TCS ENG<RJS> (B) M8X30 FLANGE THA	0-28650-830-0	03	1	0807-	●	●
80	BOLT; FAN GUIDE 4HE1-TCS ENG<RDS> (A) M6X12 FLANGE	0-28080-612-0	04	1	0508-	●	●
80	BOLT; FAN GUIDE 4HE1-TCS ENG<RDS> (B) M8X30 W/LK&PL WASHER	0-50140-830-0	03	1	0508-0509	●	●
80	BOLT; FAN GUIDE 4HE1-TCS ENG<RDS>,4HK1-TCS ENG<RJS> (B) M8X30 W/LK&PL WASHER	0-50140-830-0	03	1	0510-0701	●	●
80	BOLT; FAN GUIDE 4HE1-TCS ENG<RDS>,4HK1-TCS ENG<RJS> (B) M8X30 W/LK&PL WASHER	0-50640-830-0	03	1	0702-	●	●
80	BOLT; FAN GUIDE 4HK1-TCS ENG<RJS> (A) M6X12 FLANGE	0-28080-612-0	04	1	0510-	●	●
82	COVER; FAN,RAD 4HK1-TCS ENG<RJS>	8-97332-330-0	01	1	0510-	●	●
82	COVER; FAN,RAD 4HE1-TCS ENG<RDS> THA	8-97218-799-0	01	1	0508-	●	●
92	BRACKET; FAN GUIDE 4HK1-TCS ENG<RJS> (B)	8-97350-996-0	01	1	0510-	●	●
92	BRACKET; FAN GUIDE 4HK1-TCS ENG<RJS> (C)	8-97350-997-0	01	1	0510-	●	●
92	BRACKET; FAN GUIDE 4HK1-TCS ENG<RJS> (A)	8-97350-998-0	01	1	0510-	●	●
92	BRACKET; FAN GUIDE 4HE1-TCS ENG<RDS> (B)	8-97148-940-0	01	1	0508-	●	●
92	BRACKET; FAN GUIDE 4HE1-TCS ENG<RDS> (C)	8-97148-941-1	01	1	0508-	●	●
92	BRACKET; FAN GUIDE 4HE1-TCS ENG<RDS> (A)	8-97189-394-1	01	1	0508-	●	●
100	RUBBER; MTG 4HE1-TCS ENG<RDS>	1-09337-027-0	06	1	0508-0509	●	●
100	RUBBER; MTG 4HE1-TCS ENG<RDS>,4HK1-TCS ENG<RJS>	1-09337-027-0	06	1	0510-	●	●
116	WASHER; PL,BRKT 4HK1-TCS ENG<RJS> ID=8.4 THA	9-09160-508-0	08	1	0510-	●	●
131	CLIP; ENG SIDE TOP ID=40	8-97245-216-0	01	1	0508-	●	●	●
132	CLIP; HOSE,ENG SIDE BOTTOM ID=50	8-97245-217-0	01	1	0508-	●	●	●
240	NUT; STAY M8 FLANGE	8-94178-701-0	01	1	0508-	●	●	●
297	WASHER; PL,FAN GUIDE 4HE1-TCS ENG<RDS> ID=6.4 OD=18	9-09160-706-0	04	1	0508-	●	●
305	CLIP; FAN COVER TO FAN GUIDE 4HE1-TCS ENG<RDS>	1-09470-009-0	12	1	0508-	●	●
305	CLIP; FAN COVER TO FAN GUIDE 4HK1-TCS ENG<RJS>	1-09470-009-0	12	1	0510-	●	●
421	BOLT; BRKT FAN GUIDE 4HE1-TCS ENG<RDS> (A) M10X18 FLANGE	0-28181-018-0	02	1	0508-0509	●	●
421	BOLT; BRKT FAN GUIDE 4HE1-TCS ENG<RDS>,4HK1-TCS ENG<RJS> (A) M10X18 FLANGE	0-28181-018-0	02	1	0510-	●	●
421	BOLT; BRKT FAN GUIDE 4HE1-TCS ENG<RDS> (B) M10X20 FLANGE	0-28181-020-0	02	1	0508-0509	●	●
421	BOLT; BRKT FAN GUIDE 4HE1-TCS ENG<RDS>,4HK1-TCS ENG<RJS> (B) M10X20 FLANGE	0-28181-020-0	02	1	0510-0512	●	●
421	BOLT; BRKT FAN GUIDE 4HE1-TCS ENG<RDS>,4HK1-TCS ENG<RJS> (B) M10X20 FLANGE THA	0-28151-020-0	02	1	0601-	●	●
518	NUT 4HK1-TCS ENG<RJS> (B) M8 FLANGE	0-91150-108-0	02	1	0510-	●	●
518	NUT (A) M8 FLANGE THA	5-09440-005-0	02	1	0508-0805	●	●	●
518	NUT (A) M8 FLANGE THA	8-97581-233-0	02	1	0806-	●	●	●

İpucu: çizimdeki balona veya tablodaki Balon sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
