2 |
ROTOR; GEN
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0
|
8-97128-039-0 |
01 |
1 |
- |
| |
2 |
ROTOR; GEN
THA ASM PART: C = 8-97911-590-2, D = 8-97920-935-2
|
8-97918-730-0 |
01 |
1 |
- |
| |
3 |
BEARING; ROTOR,GEN
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0,
C = 8-97911-590-2
|
1-81229-466-1 |
01 |
1 |
- |
| |
3 |
BEARING; ROTOR,GEN
THA ASM PART: D = 8-97920-935-2
|
8-97921-129-0 |
01 |
1 |
- |
| |
5 |
HOLDER; BRUSH,GEN
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0
|
8-97128-045-0 |
01 |
1 |
- |
| |
5 |
HOLDER; BRUSH,GEN
THA ASM PART: C = 8-97911-590-2, D = 8-97920-935-2
|
8-97918-736-0 |
01 |
1 |
- |
| |
6 |
REGULATOR ASM; VOLTAGE,GEN
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0
|
8-97128-032-0 |
01 |
1 |
- |
| |
6 |
REGULATOR ASM; VOLTAGE,GEN
THA ASM PART: C = 8-97911-590-2, D = 8-97920-935-2
|
8-97918-746-0 |
01 |
1 |
- |
| |
9 |
COVER; FELT WASHER,ROTOR,GEN
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0,
C = 8-97911-590-2
|
1-81214-102-0 |
01 |
1 |
- |
| |
9 |
COVER; FELT WASHER,ROTOR,GEN
THA ASM PART: D = 8-97920-935-2
|
8-97921-128-0 |
01 |
1 |
- |
| |
10 |
RECTIFIER; GEN
(A), THA
ASM PART: A = 8-97115-044-0, B = 8-97252-388-0
|
8-97128-042-0 |
01 |
1 |
- |
| |
10 |
RECTIFIER; GEN
(B), THA
ASM PART: A = 8-97115-044-0, B = 8-97252-388-0
|
8-97128-043-0 |
01 |
1 |
- |
| |
10 |
RECTIFIER; GEN
(A), THA
ASM PART: C = 8-97911-590-2, D = 8-97920-935-2
|
8-97918-733-0 |
01 |
1 |
- |
| |
10 |
RECTIFIER; GEN
(B), THA
ASM PART: C = 8-97911-590-2, D = 8-97920-935-2
|
8-97918-734-0 |
01 |
1 |
- |
| |
11 |
COVER; RR,GEN
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0
|
8-97128-040-0 |
01 |
1 |
- |
| |
11 |
COVER; RR,GEN
THA ASM PART: C = 8-97911-590-2, D = 8-97920-935-2
|
8-97918-731-0 |
01 |
1 |
- |
| |
15 |
RETAINER; ROTOR,GEN
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0
|
8-97128-038-0 |
01 |
1 |
- |
| |
15 |
RETAINER; ROTOR,GEN
THA ASM PART: C = 8-97911-590-2, D = 8-97920-935-2
|
8-97918-729-0 |
01 |
1 |
- |
| |
17 |
COVER ASM; FRT,GEN
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0
|
8-97128-037-0 |
01 |
1 |
- |
| |
17 |
COVER ASM; FRT,GEN
THA ASM PART: C = 8-97911-590-2, D = 8-97920-935-2
|
8-97918-728-0 |
01 |
1 |
- |
| |
18 |
NUT; PULLEY,GEN
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0,
C = 8-97911-590-2
|
8-94167-948-0 |
01 |
1 |
- |
| |
18 |
NUT; PULLEY,GEN
THA ASM PART: D = 8-97920-935-2
|
8-97921-123-0 |
01 |
1 |
- |
| |
19 |
PULLEY; GEN
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0
|
8-97128-036-0 |
01 |
1 |
- |
| |
19 |
PULLEY; GEN
THA ASM PART: C = 8-97911-590-2, D = 8-97920-935-2
|
8-97918-726-1 |
01 |
1 |
- |
| |
20 |
FAN; GEN
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0
|
1-81223-008-0 |
01 |
1 |
- |
| |
20 |
FAN; GEN
THA ASM PART: C = 8-97911-590-2, D = 8-97920-935-2
|
8-97918-727-0 |
01 |
1 |
- |
| |
21 |
BOLT; THROUGH,GEN
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0,
C = 8-97911-590-2
|
5-81229-106-0 |
04 |
1 |
- |
| |
21 |
BOLT; THROUGH,GEN
THA ASM PART: D = 8-97920-935-2
|
8-97921-124-0 |
04 |
1 |
- |
| |
22 |
STATOR; GEN
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0
|
8-97128-048-0 |
01 |
1 |
- |
| |
22 |
STATOR; GEN
THA ASM PART: C = 8-97911-590-2, D = 8-97920-935-2
|
8-97918-739-0 |
01 |
1 |
- |
| |
24 |
SCREW; RECTIFIER,GEN
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0,
C = 8-97911-590-2
|
1-81229-419-0 |
03 |
1 |
- |
| |
24 |
SCREW; RECTIFIER,GEN
THA ASM PART: D = 8-97920-935-2
|
8-97921-726-0 |
03 |
1 |
- |
| |
25 |
BUSHING; INSULATION TERMINAL
(A), THA
ASM PART: A = 8-97115-044-0, B = 8-97252-388-0,
C = 8-97911-590-2
|
1-81229-410-0 |
01 |
1 |
- |
| |
25 |
BUSHING; INSULATION TERMINAL
(B) LOWER, THA
ASM PART: A = 8-97115-044-0, B = 8-97252-388-0,
C = 8-97911-590-2
|
1-81229-411-0 |
02 |
1 |
- |
| |
25 |
BUSHING; INSULATION TERMINAL
(B) UPPER, THA
ASM PART: A = 8-97115-044-0, B = 8-97252-388-0,
C = 8-97911-590-2
|
5-81229-105-0 |
02 |
1 |
- |
| |
25 |
BUSHING; INSULATION TERMINAL
(C), THA
ASM PART: A = 8-97115-044-0, B = 8-97252-388-0
|
8-97128-044-0 |
01 |
1 |
- |
| |
25 |
BUSHING; INSULATION TERMINAL
(C), THA
ASM PART: C = 8-97911-590-2, D = 8-97920-935-2
|
8-97918-735-0 |
01 |
1 |
- |
| |
25 |
BUSHING; INSULATION TERMINAL
(B) UPPER, THA
ASM PART: D = 8-97920-935-2
|
8-97921-139-0 |
02 |
1 |
- |
| |
25 |
BUSHING; INSULATION TERMINAL
(A), THA
ASM PART: D = 8-97920-935-2
|
8-97921-140-0 |
01 |
1 |
- |
| |
25 |
BUSHING; INSULATION TERMINAL
(B) LOWER, THA
ASM PART: D = 8-97920-935-2
|
8-97921-141-0 |
02 |
1 |
- |
| |
27 |
NUT; RECTIFIER,GEN
(A), M6
ASM PART: A = 8-97115-044-0, B = 8-97252-388-0,
C = 8-97911-590-2
|
8-94206-186-0 |
01 |
1 |
- |
| |
27 |
NUT; RECTIFIER,GEN
(B), THA
ASM PART: A = 8-97115-044-0, B = 8-97252-388-0,
C = 8-97911-590-2
|
8-94206-188-0 |
06 |
1 |
- |
| |
27 |
NUT; RECTIFIER,GEN
(A), THA
ASM PART: D = 8-97920-935-2
|
8-97921-722-0 |
01 |
1 |
- |
| |
27 |
NUT; RECTIFIER,GEN
(B), THA
ASM PART: D = 8-97920-935-2
|
8-97921-725-0 |
06 |
1 |
- |
| |
29 |
BRUSH; GEN
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0
|
8-97128-046-0 |
02 |
1 |
- |
| |
29 |
BRUSH; GEN
THA ASM PART: C = 8-97911-590-2, D = 8-97920-935-2
|
8-97918-737-0 |
02 |
1 |
- |
| |
30 |
SPRING; BRUSH,GEN
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0,
C = 8-97911-590-2
|
5-81216-002-0 |
02 |
1 |
- |
| |
30 |
SPRING; BRUSH,GEN
THA ASM PART: D = 8-97920-935-2
|
8-97921-143-0 |
02 |
1 |
- |
| |
33 |
WIRE; LEAD,GEN
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0
|
8-97128-049-0 |
01 |
1 |
- |
| |
33 |
WIRE; LEAD,GEN
THA ASM PART: C = 8-97911-590-2
|
8-97918-740-0 |
01 |
1 |
- |
| |
33 |
WIRE; LEAD,GEN
THA ASM PART: D = 8-97920-935-2
|
8-97921-727-0 |
01 |
1 |
- |
| |
36 |
SCREW; FRT COVER
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0,
C = 8-97911-590-2
|
1-81229-406-0 |
03 |
1 |
- |
| |
36 |
SCREW; FRT COVER
THA ASM PART: D = 8-97920-935-2
|
8-97921-131-0 |
03 |
1 |
- |
| |
37 |
BUSHING; RR COVER,GEN
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0
|
8-97128-041-0 |
01 |
1 |
- |
| |
37 |
BUSHING; RR COVER,GEN
THA ASM PART: C = 8-97911-590-2, D = 8-97920-935-2
|
8-97918-732-0 |
01 |
1 |
- |
| |
49 |
BUSHING; RECTIFIER,GEN
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0,
C = 8-97911-590-2
|
1-81229-413-0 |
01 |
1 |
- |
| |
49 |
BUSHING; RECTIFIER,GEN
THA ASM PART: D = 8-97920-935-2
|
8-97921-146-0 |
01 |
1 |
- |
| |
57 |
COVER; BRUSH,GEN
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0
|
8-97128-047-0 |
01 |
1 |
- |
| |
57 |
COVER; BRUSH,GEN
THA ASM PART: C = 8-97911-590-2, D = 8-97920-935-2
|
8-97918-738-0 |
01 |
1 |
- |
| |
65 |
CONDENSER; GEN
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0
|
8-97128-050-0 |
01 |
1 |
- |
| |
65 |
CONDENSER; GEN
THA ASM PART: C = 8-97911-590-2, D = 8-97920-935-2
|
8-97918-741-0 |
01 |
1 |
- |
| |
69 |
CLIP; WIRE,GEN
THA ASM PART: D = 8-97920-935-2
|
8-97921-716-0 |
01 |
1 |
- |
| |
81 |
SPACER; ROTOR,GEN
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0,
C = 8-97911-590-2
|
1-81229-403-0 |
01 |
1 |
- |
| |
81 |
SPACER; ROTOR,GEN
THA ASM PART: D = 8-97920-935-2
|
8-97921-133-0 |
01 |
1 |
- |
| |
83 |
RING; SLIP,ROTOR,GEN
THA ASM PART: C = 8-97911-590-2
|
1-81229-404-0 |
01 |
1 |
- |
| |
83 |
RING; SLIP,ROTOR,GEN
THA ASM PART: D = 8-97920-935-2
|
8-97921-134-0 |
01 |
1 |
- |
| |
85 |
SPACER; PULLEY,GEN
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0,
C = 8-97911-590-2
|
1-81229-415-0 |
01 |
1 |
- |
| |
85 |
SPACER; PULLEY,GEN
THA ASM PART: D = 8-97920-935-2
|
8-97921-126-0 |
01 |
1 |
- |
| |
90 |
PUMP ASM; VAC,GEN
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0
|
8-97128-033-0 |
01 |
1 |
- |
| |
90 |
PUMP ASM; VAC,GEN
THA ASM PART: C = 8-97911-590-2
|
8-97918-742-0 |
01 |
1 |
- |
| |
90 |
PUMP ASM; VAC,GEN
THA ASM PART: D = 8-97920-935-2
|
8-97921-728-0 |
01 |
1 |
- |
| |
93 |
GASKET; CONN,VAC PUMP
THA ASM PART: D = 8-97920-935-2
|
8-97921-215-0 |
03 |
1 |
- |
| |
93 |
GASKET; CONN,VAC PUMP
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0,
C = 8-97911-590-2
|
9-88130-081-0 |
03 |
1 |
- |
| |
94 |
CONNECTOR; VAC PUMP
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0
|
8-97128-031-0 |
01 |
1 |
- |
| |
94 |
CONNECTOR; VAC PUMP
THA ASM PART: C = 8-97911-590-2, D = 8-97920-935-2
|
8-97918-745-0 |
01 |
1 |
- |
| |
97 |
VALVE; VAC PUMP
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0,
C = 8-97911-590-2
|
8-94456-612-0 |
01 |
1 |
- |
| |
97 |
VALVE; VAC PUMP
THA ASM PART: D = 8-97920-935-2
|
8-97921-210-0 |
01 |
1 |
- |
| |
98 |
BOLT; VAC PUMP
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0,
C = 8-97911-590-2
|
5-09000-134-0 |
01 |
1 |
- |
| |
98 |
BOLT; VAC PUMP
THA ASM PART: D = 8-97920-935-2
|
8-97921-730-0 |
01 |
1 |
- |
| |
99 |
GASKET; VAC PUMP
THA ASM PART: D = 8-97920-935-2
|
8-97921-211-0 |
01 |
1 |
- |
| |
99 |
GASKET; VAC PUMP
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0,
C = 8-97911-590-2
|
9-88130-126-0 |
01 |
1 |
- |
| |
100 |
CONNECTOR; VAC PUMP
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0
|
8-97128-030-0 |
01 |
1 |
- |
| |
100 |
CONNECTOR; VAC PUMP
THA ASM PART: C = 8-97911-590-2, D = 8-97920-935-2
|
8-97918-744-0 |
01 |
1 |
- |
| |
103 |
PIN; VAC PUMP
THA ASM PART: D = 8-97920-935-2
|
8-97921-206-0 |
01 |
1 |
- |
| |
103 |
PIN; VAC PUMP
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0,
C = 8-97911-590-2
|
9-88130-099-0 |
01 |
1 |
- |
| |
104 |
GASKET; FRT COVER,VAC PUMP
(B), THA
ASM PART: A = 8-97115-044-0, B = 8-97252-388-0,
C = 8-97911-590-2
|
5-09623-017-0 |
01 |
1 |
- |
| |
104 |
GASKET; FRT COVER,VAC PUMP
(A), THA
ASM PART: A = 8-97115-044-0, B = 8-97252-388-0,
C = 8-97911-590-2
|
8-94456-608-0 |
01 |
1 |
- |
| |
104 |
GASKET; FRT COVER,VAC PUMP
(B), THA
ASM PART: D = 8-97920-935-2
|
8-97921-204-0 |
01 |
1 |
- |
| |
104 |
GASKET; FRT COVER,VAC PUMP
(A), THA
ASM PART: D = 8-97920-935-2
|
8-97921-208-0 |
01 |
1 |
- |
| |
105 |
WASHER; CONN BOLT,VAC PUMP
THA ASM PART: C = 8-97911-590-2, D = 8-97920-935-2
|
8-97917-009-0 |
02 |
1 |
- |
| |
106 |
BOLT; OIL CONN,VAC PUMP
THA ASM PART: C = 8-97911-590-2, D = 8-97920-935-2
|
8-97917-008-0 |
01 |
1 |
- |
| |
109 |
VANE; VAC PUMP
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0
|
8-97128-034-0 |
04 |
1 |
- |
| |
109 |
VANE; VAC PUMP
THA ASM PART: C = 8-97911-590-2, D = 8-97920-935-2
|
8-97918-743-0 |
04 |
1 |
- |
| |
111 |
BOLT; VAC PUMP
THA ASM PART: A = 8-97115-044-0, B = 8-97252-388-0,
C = 8-97911-590-2
|
8-94456-611-0 |
03 |
1 |
- |
| |
111 |
BOLT; VAC PUMP
THA ASM PART: D = 8-97920-935-2
|
8-97921-729-0 |
03 |
1 |
- |
