Isuzu WW
▶
TRUCKS
▶
NPR
▶
50971 - NPR/NQR(THAILAND)
▶
8 - Chassis Electrical, Heating / Air Conditioning, Wipers, Radio
▶
8-25 - SWITCH AND RELAY; INSTRUMENT PANEL
▶
8-25 — SWITCH AND RELAY; INSTRUMENT PANEL
(#42882) — 36 parça
Tümü
A - NPC5SF
B - NPC5SK
C - NPC5SN
◀
[825A] (NO.3) (5 parça)
[825A] (NO.5) (3 parça)
[825A] (NO.2) (13 parça)
[825A] (NO.1) (9 parça)
[825A] (NO.4) (6 parça)
▶
29
30
257
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
C
29
SWITCH; DOOR
8-97855-032-3
01
1
0309-
●
●
●
30
SCREW; DOOR SW
M5X16
8-94279-341-0
01
1
0309-
●
●
●
257
COVER; HOLE,SW
(A) THA
8-94229-914-1
01
1
0309-
●
●
●
257
COVER; HOLE,SW
PTO TRANSMISSION SIDE<V66> (B)
8-94310-890-0
01
1
0309-
●
●
●
257
COVER; HOLE,SW
EXC. ROOM LAMP SWITCH<7KL> (C)
8-97136-694-0
01
1
0309-
●
●
●
85
311
191
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
C
85
RELAY; HEADLAMP
24V 12.5A MATSUSHITA THA
8-97262-933-0
01
1
0309-
●
●
●
191
RELAY; EXH BRK CUT
24V 12.5A MATSUSHITA THA
8-97262-933-0
01
1
0309-
●
●
●
311
RELAY; CORNERING LAMP
24V 12.5A MATSUSHITA THA
8-97262-933-0
01
1
0309-
●
●
●
1
263
3
8
615
10
21
26
8
12
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
C
1
SWITCH; COMB
INTERMITTENT WIPER<C13>
8-97364-076-0
01
1
0309-
●
●
●
1
SWITCH; COMB
EXC. INTERMITTENT WIPER<C13>
8-97364-072-0
01
1
0309-
●
●
●
3
SCREW; COMB SW
M5X20 W/LK WASHER
9-03910-520-0
04
1
0309-
●
●
●
8
SWITCH; POWER WINDOW
POWER WINDOW FRT DOOR<A32>
8-97214-398-0
01
1
0309-
●
●
●
8
SWITCH; POWER WINDOW
POWER WINDOW FRT DOOR<A32> DRIVER SIDE
8-97315-176-0
01
1
0309-
●
●
●
10
SCREW; POWER WINDOW SW
POWER WINDOW FRT DOOR<A32>
8-97219-239-0
02
1
0309-
●
●
●
12
RELAY; POWER WINDOW
POWER WINDOW FRT DOOR<A32> 24V 12.5A MATSUSHITA THA
8-97262-933-0
01
1
0309-
●
●
●
21
SWITCH; CLU
8-97358-248-0
01
1
0309-0403
●
●
●
21
SWITCH; CLU
FLOOR REMOTE SHIFT<M11>
8-97358-248-0
01
1
0404-
●
21
SWITCH; CLU
8-97358-248-0
01
1
0404-
●
●
26
SWITCH; ACCEL
8-97358-315-0
01
1
0309-
●
●
●
263
COVER; SW
POWER WINDOW FRT DOOR<A32>
8-97219-234-0
01
1
0309-
●
●
●
615
SPRING; POWER WINDOW SW
POWER WINDOW FRT DOOR<A32>
8-97219-238-0
01
1
0309-
●
●
●
249
372
96
257
307
307
257
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
C
96
SWITCH; FOG LAMP
8-97170-441-0
01
1
0309-
●
●
●
249
SWITCH; HAZARD
8-97202-475-0
01
1
0309-
●
●
●
257
COVER; HOLE,SW
(A) THA
8-94229-914-1
01
1
0309-
●
●
●
257
COVER; HOLE,SW
PTO TRANSMISSION SIDE<V66> (B)
8-94310-890-0
01
1
0309-
●
●
●
257
COVER; HOLE,SW
EXC. ROOM LAMP SWITCH<7KL> (C)
8-97136-694-0
01
1
0309-
●
●
●
307
BULB ASM; SW
28V 40MA
8-97116-331-0
02
1
0309-
●
●
●
307
BULB ASM; SW
ROOM LAMP SWITCH<7KL> 28V 40MA
8-97116-331-0
01
1
0309-
●
●
●
307
BULB ASM; SW
28V 40MA
8-97116-331-0
01
1
0309-
●
●
●
372
SWITCH; ROOM LAMP
ROOM LAMP SWITCH<7KL>
8-97136-693-0
01
1
0309-
●
●
●
321
584
39
186
315
649
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
C
39
RELAY; DOOR LK
AUTO DOOR LOCK<AU4>
8-97177-214-0
01
1
0309-
●
●
●
186
BRACKET; RELAY BOX
EXC. TIRE SIZE 8.25-16<7QP>
8-97088-652-1
01
1
0309-
●
●
●
315
RELAY; EXH BRAKE CONT
24V 12.5A MATSUSHITA THA
8-97262-933-0
01
1
0309-
●
●
●
321
BOLT; RELAY
AUTO DOOR LOCK<AU4> M5X20
8-94436-927-0
01
1
0309-
●
●
●
584
RELAY; TIMING
4HE1 ENG<RLY> 24V 12.5A MATSUSHITA THA
8-97262-933-0
01
1
0309-
●
●
649
RELAY; DUMMIEST GLOW
4HE1 ENG<RLY> 24V 50A
8-97173-947-0
01
1
0309-
●
●
