Isuzu WW
▶
SUV
▶
UES
▶
50754 - UES(4DOOR)-LHD
▶
6 - Exterior Body, Glass Mounting, Door Trim, Molding
▶
6-88 - HARD COVER AND TARPAULIN
▶
6-88 — HARD COVER AND TARPAULIN
(#42629) — 39 parça
33
33
35
67
72
68
116
45
67
23
113
42
72
68
48
46
47
114
64
55
38
54
142
94
115
117
117
33
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
23
PATCH; HINGE,HATCH GATE
8-97125-000-0
04
1
9707-
33
SEAL; HATCH GATE
(A)
8-97124-151-2
01
1
9707-
33
SEAL; HATCH GATE
(C)
8-97147-977-3
01
1
9707-9908
33
SEAL; HATCH GATE
(C)
8-97222-128-0
01
1
9909-
33
SEAL; HATCH GATE
(B)
8-97147-976-3
01
1
9707-9908
33
SEAL; HATCH GATE
(B)
8-97222-127-0
01
1
9909-
35
HINGE; TONNEAU COVER
8-97125-494-7
01
1
9707-
35
HINGE; TONNEAU COVER
8-97125-493-7
01
1
9707-
38
NUT; HINGE
M6 FLANGE
8-94253-333-0
04
1
9707-
42
GRIP; HATCH GATE HANDLE
8-97180-049-0
01
1
9707-
45
SCREW; HANDLE
M6X12 W/LK&PL WASHER
8-94279-329-0
02
1
9707-
46
FASTENER; STRIKER
8-94198-964-1
01
1
9707-
47
STRIKER; TONNEAU COVER
8-97166-568-0
01
1
9707-
48
SCREW; STRIKER
M6X12 W/LK&PL WASHER
8-94279-329-0
02
1
9707-
54
LOCK ASM; TONNEAU COVER
SPARE TIRE UNDER FLOOR MTG<7PF>
8-97136-018-4
01
1
9707-0008
54
LOCK ASM; TONNEAU COVER
SPARE TIRE UNDER FLOOR MTG<7PF>
8-97289-655-0
01
1
0009-
54
LOCK ASM; TONNEAU COVER
EXC. SPARE TIRE UNDER FLOOR MTG<7PF>
8-97124-135-4
01
1
9707-0008
54
LOCK ASM; TONNEAU COVER
EXC. SPARE TIRE UNDER FLOOR MTG<7PF>
8-97289-653-0
01
1
0009-
55
BOLT; TONNEAU COVER LOCK
M6X16 W/LK&PL WASHER
8-97146-388-0
03
1
9707-9808
55
BOLT; TONNEAU COVER LOCK
M6X16 FLANGE
0-28480-616-0
03
1
9809-
64
STAY ASM; GAS,HATCH GATE
8-97124-871-3
01
1
9707-
64
STAY ASM; GAS,HATCH GATE
8-97124-131-3
01
1
9707-
67
FASTENER; GAS STAY
8-94198-640-1
02
1
9707-
68
STUD; BALL,GAS STAY
8-94243-335-0
02
1
9707-
72
SPACER; BALL STUD
8-97164-710-0
02
1
9707-9811
72
SPACER; BALL STUD
8-97218-954-0
02
1
9812-9908
72
SPACER; BALL STUD
8-97222-129-0
02
1
9909-
94
ACTUATOR; HATCH GATE
AUTO DOOR LOCK<AU4> ANTI THEFT<UA6>
8-97145-567-4
01
1
9707-0307
94
ACTUATOR; HATCH GATE
ANTI THEFT<UA6>
8-97145-567-4
01
1
0308-
94
ACTUATOR; HATCH GATE
AUTO DOOR LOCK<AU4> EXC. ANTI THEFT<UA6>
8-97124-134-4
01
1
9707-0307
94
ACTUATOR; HATCH GATE
EXC. ANTI THEFT<UA6>
8-97124-134-4
01
1
0308-
113
SCREW; HINGE
M6X12 W/LK&PL WASHER
8-94279-329-0
04
1
9707-0008
113
SCREW; HINGE
M6X18 W/PL WASHER
8-97289-644-0
04
1
0009-
114
BOLT; STAY
M6X16 FLANGE
8-97803-298-0
04
1
9707-
115
NUT; ACTUATOR
AUTO DOOR LOCK<AU4> M6 FLANGE
8-97063-399-0
02
1
9707-0307
115
NUT; ACTUATOR
M6 FLANGE
8-97063-399-0
02
1
0308-
116
PATCH; GLASS HANDLE
8-97125-000-0
02
1
9707-
117
BOLT; HINGE,TAIL GATE
M8X30
8-97035-384-0
04
1
9707-
142
SCREW; SWITCH
ANTI THEFT<UA6>
8-97164-810-0
01
1
9707-
