Isuzu WW
▶
TRUCKS
▶
NKR
▶
50945 - NKR(EUROPE)-LHD
▶
0 - Engine, Emission, Engine Electrical
▶
0-42 - FUEL PUMP AND PIPE
▶
0-42 — FUEL PUMP AND PIPE
(#42003) — 10 parça
Tümü
A - 4JH1 ENG
B - 4JH1-TC ENG
322
324
323
320
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
320
03.890 VALVE; CHECK
DUAL RR TIRE(NKC***) FRIGID ZONE VAR.2(W54)
8-97367-794-0
01
1
0308-0506
●
320
03.890 VALVE; CHECK
DUAL RR TIRE(NKC***) FRIGID ZONE VAR.2(W54)
8-97367-794-0
01
1
0507-0606
●
322
03.890 BOLT; FUEL FILTER
DUAL RR TIRE(NKC***) FRIGID ZONE VAR.2(W54) 01.251 M8X60 FLANGE
0-28080-860-0
02
1
0308-0506
●
322
03.890 BOLT; FUEL FILTER
DUAL RR TIRE(NKC***) FRIGID ZONE VAR.2(W54) 01.251 M8X60 FLANGE
0-28080-860-0
02
1
0507-0512
●
322
03.890 BOLT; FUEL FILTER
DUAL RR TIRE(NKC***) FRIGID ZONE VAR.2(W54) 04.686 M8X60 FLANGE
0-28050-860-0
02
1
0601-0606
●
323
03.890 NUT; FUEL FILTER
DUAL RR TIRE(NKC***) FRIGID ZONE VAR.2(W54) 01.540 M8 FLANGE
0-91150-208-0
02
1
0308-0506
●
323
03.890 NUT; FUEL FILTER
DUAL RR TIRE(NKC***) FRIGID ZONE VAR.2(W54) 01.540 M8 FLANGE
0-91150-208-0
02
1
0507-0602
●
323
03.890 NUT; FUEL FILTER
DUAL RR TIRE(NKC***) FRIGID ZONE VAR.2(W54) 01.540 M8 FLANGE
0-91180-208-0
02
1
0603-0606
●
324
03.890 SPACER; DISTANCE,FUEL FILTER
DUAL RR TIRE(NKC***) FRIGID ZONE VAR.2(W54)
1-13666-052-0
02
1
0308-0506
●
324
03.890 SPACER; DISTANCE,FUEL FILTER
DUAL RR TIRE(NKC***) FRIGID ZONE VAR.2(W54)
1-13666-052-0
02
1
0507-0606
●
Seçili parçaları sepete ekle
İpucu: çizimdeki balona veya tablodaki
Balon
sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
