Isuzu WW
▶
SUV
▶
UCS
▶
50892 - UCS(THAILAND)
▶
6 - Exterior Body, Glass Mounting, Door Trim, Molding
▶
6-52 - REAR DOOR LOCK AND HANDLE
▶
6-52 — REAR DOOR LOCK AND HANDLE
(#41401) — 29 parça
15
29
1
44
14
15
21
50
24
3
38
6
9
11
32
8
30
20
16
17
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
1
HANDLE; OUTSIDE,RR DOOR
8-94330-590-4
01
1
0009-
1
HANDLE; OUTSIDE,RR DOOR
8-94330-589-4
01
1
0009-
3
BOLT; DOOR OUTSIDE HANDLE
M6X8 THA
8-94155-893-0
04
1
0009-
6
BEZEL; INSIDE HANDLE,DOOR LOCK
THA
8-97916-629-0
01
1
0009-
6
BEZEL; INSIDE HANDLE,DOOR LOCK
THA
8-97916-623-0
01
1
0009-
8
HANDLE; INSIDE,RR DOOR
THA
8-97915-231-0
01
1
0009-
8
HANDLE; INSIDE,RR DOOR
THA
8-97915-230-0
01
1
0009-
9
GROMMET; SCREW,INSIDE HANDLE
THA
5-09470-001-0
04
1
0009-
11
SCREW; INSIDE HANDLE
M4X10 TAPPING OVAL-HEAD
0-70680-410-0
02
1
0009-
14
HOLDER; DOOR LK ROD
YELLOW
8-97044-834-0
01
1
0009-
14
HOLDER; DOOR LK ROD
WHITE
8-97037-508-0
01
1
0009-
15
LINK; RR DOOR LK
(A)
8-94330-605-1
01
1
0009-
15
LINK; RR DOOR LK
(B) GRAY
8-97150-671-1
01
1
0009-
15
LINK; RR DOOR LK
(A)
8-94330-604-1
01
1
0009-
15
LINK; RR DOOR LK
(B) GRAY
8-97150-670-1
01
1
0009-
16
CLIP; DOOR LK LINK
GREEN
8-94123-004-1
02
1
0009-
16
CLIP; DOOR LK LINK
WHITE
8-94123-005-1
02
1
0009-
17
LOCK; DOOR,RR DOOR
8-94330-593-6
01
1
0009-
17
LOCK; DOOR,RR DOOR
8-94330-592-6
01
1
0009-
20
SCREW; DOOR LK
M6X16 OVAL-HD
8-94172-523-0
06
1
0009-
21
ACTUATOR; RR DOOR LOCK
8-97141-951-0
01
1
0009-
21
ACTUATOR; RR DOOR LOCK
8-97141-950-0
01
1
0009-
24
ANTIRATTLER; DOOR INSIDE HANDLE
ID=3.8 WHITE
8-94217-699-0
06
1
0009-
29
KNOB; LK LINK,RR DOOR
GRAY THA
8-97152-890-0
02
1
0009-
30
STRIKER; RR DOOR
THA
8-97915-292-0
02
1
0009-
32
SCREW; DOOR STRIKER
M8X20
9-03097-820-0
04
1
0009-
38
SCREW; INSIDE LEVER,RR DOOR LK
M6X16
9-09829-197-0
04
1
0009-
44
GUIDE; HOLE,DOOR LOCK KNOB
GRAY THA
8-97152-748-3
02
1
0009-
50
BOLT; ACTUATOR
M6X8 THA
8-94155-893-0
04
1
0009-
