◀ 🏠 ▶ Isuzu WW ▶ PICKUP ▶ TFR ▶ 50725 - TFR/TFS-RHD ▶ 7 - Interior Trim, Emblems / Labels, Seats, Mirrors ▶ 7-10 - CAUTION PLATE AND LABEL ▶
7-10 — CAUTION PLATE AND LABEL (#41063) — 70 parça
çizim 69302
2 2 107 9 1 9
BalonParca AdiParca NoAdetTipApplied Date A B C D E F G H
1 04.017 PLATE; CAUTION,SHIFT PATTERN
4ZD1 ENG(LW3),4ZE1 ENG(RLJ),6VD1 ENG(RLV) CAUTION SPANISH<YN1> 		8-97108-716-0 01 1 9611- ● ● ● ●
1 04.017 PLATE; CAUTION,SHIFT PATTERN
4ZD1 ENG(LW3),4ZE1 ENG(RLJ),6VD1 ENG(RLV) EXC. CAUTION SPANISH<YN1> 		8-97108-715-0 01 1 9611- ● ● ● ●
2 03.680 LABEL; FUEL CAUTION
4JA1 ENG(RLE),4JB1 ENG(RLF) RR BODY DOUBLE WALL SIDE LOCK OUTER HOOK(S7S),RR BODY DBL WALL SIDE LO CK INNER HOOK(7LZ),RR BODY DBL WALLSIDE LOCK INNER & OUTER HOOK(7TM) (B) 		8-97135-605-0 01 1 9611- ● ● ● ● ● ● ● ●
2 03.680 LABEL; FUEL CAUTION
4ZE1 ENG(RLJ),6VD1 ENG(RLV) AUSTRALIA EQUIPMENT(RR3) 08.808 (A) 		8-94206-917-1 01 1 9611- ● ● ● ● ● ●
9 08.808 PLATE; NAME,SPD RANGE
4JA1 ENG(RLE) CAUTION SPANISH<YN1> REAR AXLE LOW GEARED(6ST) EXC. SPEEDOMETER MILE<UC1> (A) 		8-94381-055-0 01 1 9611-9611 ● ● ● ●
9 08.808 PLATE; NAME,SPD RANGE
4JA1 ENG(RLE) M/T MSG 5 SPEED(M75) CAUTION SPANISH<YN1> REAR AXLE LOW GEARED(6ST) EXC. SPEEDOMETER MILE<UC1> (A) 		8-94381-055-0 01 1 9612- ● ● ● ●
9 08.808 PLATE; NAME,SPD RANGE
4JB1 ENG(RLF) CAUTION SPANISH<YN1> (A) 		8-94381-055-0 01 1 9612- ● ● ●
9 08.808 PLATE; NAME,SPD RANGE
4JA1 ENG(RLE) CAUTION SPANISH<YN1> EXC. SPEEDOMETER MILE<UC1>,REAR AXLE LOW GEARED(6ST),M/T LOW GEARED(6WF) (A) 		8-94331-887-0 01 1 9611- ● ● ● ●
9 08.808 PLATE; NAME,SPD RANGE
4JA1 ENG(RLE) M/T MSG 5 SPEED(M75) SPEEDOMETER MILE<UC1> REAR AXLE LOW GEARED(6ST) EXC. CAUTION SPANISH<YN1> (A) 		8-94381-053-0 01 1 9611- ● ● ● ●
9 08.808 PLATE; NAME,SPD RANGE
4JA1 ENG(RLE) UNITED KINGDOM EQUIPMENT(EK3) EXC. HONG KONG EQUIPMENT(PQ1) (A) 		8-94381-053-0 01 1 9611- ● ●
9 08.808 PLATE; NAME,SPD RANGE
4JA1 ENG(RLE) REAR AXLE LOW GEARED(6ST) EXC. UNITED KINGDOM EQUIPMENT(EK3), SPEEDOMETER MILE<UC1>,CAUTION SPANISH<YN1> (A) 		8-94381-054-0 01 1 9611-9611 ● ● ● ●
9 08.808 PLATE; NAME,SPD RANGE
4JA1 ENG(RLE) M/T LOW GEARED(6WF) EXC. UNITED KINGDOM EQUIPMENT(EK3), SPEEDOMETER MILE<UC1>,CAUTION SPANISH<YN1>,REAR AXLE LOW GEARED(6ST) (A) 		8-94381-054-0 01 1 9611-9611 ● ● ● ●
9 08.808 PLATE; NAME,SPD RANGE
4JA1 ENG(RLE),4JB1 ENG(RLF) AUSTRALIA EQUIPMENT(RR3) (A) 		8-94381-054-0 01 1 9611-9611 ● ● ●
9 08.808 PLATE; NAME,SPD RANGE
4JA1 ENG(RLE) UNITED KINGDOM EQUIPMENT(EK3) HONG KONG EQUIPMENT(PQ1) (A) 		8-94381-054-0 01 1 9611-9611 ●
9 08.808 PLATE; NAME,SPD RANGE
4JA1 ENG(RLE) REAR AXLE LOW GEARED(6ST) EXC. UNITED KINGDOM EQUIPMENT(EK3), SPEEDOMETER MILE<UC1>,CAUTION SPANISH<YN1> (A) 		8-94381-054-0 01 1 9612- ● ● ● ●
9 08.808 PLATE; NAME,SPD RANGE
4JA1 ENG(RLE) M/T LOW GEARED(6WF) EXC. UNITED KINGDOM EQUIPMENT(EK3), SPEEDOMETER MILE<UC1>,CAUTION SPANISH<YN1>,REAR AXLE LOW GEARED(6ST) (A) 		8-94381-054-0 01 1 9612- ● ● ● ●
9 08.808 PLATE; NAME,SPD RANGE
4JA1 ENG(RLE) AUSTRALIA EQUIPMENT(RR3) (A) 		8-94381-054-0 01 1 9612- ● ● ●
9 08.808 PLATE; NAME,SPD RANGE
4JB1 ENG(RLF) EXC. CAUTION SPANISH<YN1> (A) 		8-94381-054-0 01 1 9612- ● ● ●
9 08.808 PLATE; NAME,SPD RANGE
4JA1 ENG(RLE) UNITED KINGDOM EQUIPMENT(EK3) HONG KONG EQUIPMENT(PQ1) (A) 		8-94381-054-0 01 1 9612- ●
9 08.808 PLATE; NAME,SPD RANGE
4JA1 ENG(RLE) SPEEDOMETER MILE<UC1> EXC. CAUTION SPANISH<YN1>,REAR AXLELOW GEARED(6ST) (A) 		8-94332-957-0 01 1 9611- ● ● ● ●
9 08.808 PLATE; NAME,SPD RANGE
4JA1 ENG(RLE) EXC. UNITED KINGDOM EQUIPMENT(EK3), SPEEDOMETER MILE<UC1>,CAUTION SPANISH<YN1>,REAR AXLE LOW GEARED(6ST),M /T LOW GEARED(6WF) (A) 		8-94423-384-0 01 1 9611- ● ● ● ●
9 08.808 PLATE; NAME,SPD RANGE
4JA1 ENG(RLE) CAUTION SPANISH<YN1> M/T LOW GEARED(6WF) EXC. SPEEDOMETER MILE<UC1> (B) 		8-97039-424-0 01 1 9611- ● ● ● ●
9 08.808 PLATE; NAME,SPD RANGE
4JB1 ENG(RLF) TURBOCHARGER<K51> CAUTION SPANISH<YN1> EXC. SPEEDOMETER MILE<UC1> (B) 		8-97039-424-0 01 1 9611- ● ● ●
9 08.808 PLATE; NAME,SPD RANGE
4JA1 ENG(RLE) CAUTION SPANISH<YN1> EXC. SPEEDOMETER MILE<UC1>,M/T LOW GEARED(6WF) (B) 		8-94331-889-0 01 1 9611- ● ● ● ●
9 08.808 PLATE; NAME,SPD RANGE
4JA1 ENG(RLE) M/T LOW GEARED(6WF) EXC. SPEEDOMETER MILE<UC1>,CAUTION SPANISH<YN1> (B) 		8-97039-423-0 01 1 9611- ● ● ● ●
9 08.808 PLATE; NAME,SPD RANGE
4JA1 ENG(RLE) SPEEDOMETER MILE<UC1> EXC. CAUTION SPANISH<YN1>,M/T LOW GEARED(6WF) (B) 		8-94332-958-0 01 1 9611- ● ● ● ●
9 08.808 PLATE; NAME,SPD RANGE
4JA1 ENG(RLE) UNITED KINGDOM EQUIPMENT(EK3) EXC. HONG KONG EQUIPMENT(PQ1) (B) 		8-94332-958-0 01 1 9611- ● ●
9 08.808 PLATE; NAME,SPD RANGE
4JA1 ENG(RLE) SPEEDOMETER MILE<UC1> M/T LOW GEARED(6WF) EXC. CAUTION SPANISH<YN1> (B) 		8-97039-422-0 01 1 9611- ● ● ● ●
9 08.808 PLATE; NAME,SPD RANGE
4JA1 ENG(RLE) EXC. UNITED KINGDOM EQUIPMENT(EK3), SPEEDOMETER MILE<UC1>,CAUTION SPANISH<YN1>,M/T LOW GEARED(6WF) (B) 		8-94331-888-0 01 1 9611- ● ● ● ●
9 08.808 PLATE; NAME,SPD RANGE
4JA1 ENG(RLE) UNITED KINGDOM EQUIPMENT(EK3) HONG KONG EQUIPMENT(PQ1) (B) 		8-94331-888-0 01 1 9611- ● ●
9 08.808 PLATE; NAME,SPD RANGE
4JB1 ENG(RLF) SPEEDOMETER MILE<UC1> (B) 		8-97021-925-0 01 1 9611- ● ● ●
9 08.808 PLATE; NAME,SPD RANGE
4JB1 ENG(RLF) TURBOCHARGER<K51> EXC. SPEEDOMETER MILE<UC1>,CAUTION SPANISH<YN1> (B) 		8-97013-728-0 01 1 9611- ● ● ●
107 08.808 LABEL; FREE WHEEL HUB
AUTO LOCKING HUB(S1Y) CAUTION SPANISH<YN1> 		8-97108-671-1 01 1 9611- ● ● ● ●
107 08.808 LABEL; FREE WHEEL HUB
AUTO LOCKING HUB(S1Y) EXC. CAUTION SPANISH<YN1> 		8-97108-672-1 01 1 9611- ● ● ● ●
107 08.808 LABEL; FREE WHEEL HUB
AUSTRALIA EQUIPMENT(RR3) EXC. MANUAL LOCKING HUB(ED2) 		8-97108-672-1 01 1 9611- ● ● ●
107 08.808 LABEL; FREE WHEEL HUB
MANUAL LOCKING HUB(ED2) CAUTION SPANISH<YN1> 		8-97108-674-1 01 1 9611- ● ● ● ●
107 08.808 LABEL; FREE WHEEL HUB
MANUAL LOCKING HUB(ED2) EXC. CAUTION SPANISH<YN1> 		8-97108-673-1 01 1 9611- ● ● ● ●
çizim 70311
94 7 90 135 59 38 4 4 8 5 5
BalonParca AdiParca NoAdetTipApplied Date A B C D E F G H
4 00.004 LABEL; ENG MAINTENANCE
4JA1 ENG(RLE) CAUTION SPANISH<YN1> (A) 		8-94332-267-0 01 1 9611- ● ● ● ● ● ● ● ●
4 00.004 LABEL; ENG MAINTENANCE
4JA1 ENG(RLE) EXC. UNITED KINGDOM EQUIPMENT(EK3), CAUTION SPANISH<YN1> (A) 		8-94332-266-0 01 1 9611- ● ● ● ● ● ● ● ●
4 00.004 LABEL; ENG MAINTENANCE
4ZC1 ENG(LR9),4ZD1 ENG(LW3) (B) 		8-94160-628-0 01 1 9611- ● ● ● ● ● ● ●
4 00.004 LABEL; ENG MAINTENANCE
4ZE1 ENG(RLJ) EXC. ELECTRIC FUEL INJECTION<6GG> (B) 		8-94160-628-0 01 1 9611- ● ● ● ● ● ●
4 00.004 LABEL; ENG MAINTENANCE
4JB1 ENG(RLF) CAUTION SPANISH<YN1> (A) 		8-94384-351-0 01 1 9612- ● ● ● ● ● ●
4 00.004 LABEL; ENG MAINTENANCE
4JB1 ENG(RLF) EXC. CAUTION SPANISH<YN1> (A) 		8-94384-349-0 01 1 9611-9612 ● ● ● ● ● ●
4 00.004 LABEL; ENG MAINTENANCE
4JB1 ENG(RLF) EXC. EAST MALAYSIA EQUIPMENT(PM6), WEST MALAYSIA EQUIPMENT(S3D),CAUTION SPANISH<YN1> (A) 		8-94384-349-0 01 1 9701- ● ● ● ● ● ●
4 00.004 LABEL; ENG MAINTENANCE
UNITED KINGDOM EQUIPMENT(EK3) (A) 		8-97044-279-0 01 1 9611- ● ● ● ●
4 00.004 LABEL; ENG MAINTENANCE
4JB1 ENG(RLF) EAST MALAYSIA EQUIPMENT(PM6),WEST MALAYSIA EQUIPMENT(S3D) (A) 		8-97940-255-0 01 1 9701- ● ● ● ●
5 05.880 LABEL; TIRE AIR PRESSURE
4ZC1 ENG(LR9),4ZD1 ENG(LW3),4JA1 ENG(RLE),4JB1 ENG(RLF),4ZE1 ENG(RLJ) EXC. AUSTRALIA EQUIPMENT(RR3), CAUTION SPANISH<YN1> (B) 		8-97145-372-0 01 1 9611- ● ● ● ●
5 05.880 LABEL; TIRE AIR PRESSURE
4ZC1 ENG(LR9),4ZD1 ENG(LW3),4JA1 ENG(RLE),4JB1 ENG(RLF),4ZE1 ENG(RLJ) CAUTION SPANISH<YN1> (B) 		8-97145-373-0 01 1 9611- ● ● ● ●
5 05.880 LABEL; TIRE AIR PRESSURE
4JB1 ENG(RLF),4ZE1 ENG(RLJ) AUSTRALIA EQUIPMENT(RR3) (A) 		8-97017-394-0 01 1 9611- ● ● ●
5 05.880 LABEL; TIRE AIR PRESSURE
6VD1 ENG(RLV) AUSTRALIA EQUIPMENT(RR3) (A) 		8-97189-235-0 01 1 9712-9802 ● ●
5 05.880 LABEL; TIRE AIR PRESSURE
6VD1 ENG(RLV) FRT&RR 215R15 105S 6JJX15 STYLED(AWB) AUSTRALIA EQUIPMENT(RR3) (A) 		8-97189-235-0 01 1 9803- ● ●
5 05.880 LABEL; TIRE AIR PRESSURE
6VD1 ENG(RLV) EXC. AUSTRALIA EQUIPMENT(RR3), CAUTION SPANISH<YN1> (B) 		8-97148-680-0 01 1 9611- ● ●
5 05.880 LABEL; TIRE AIR PRESSURE
EXC. AUSTRALIA EQUIPMENT(RR3), CAUTION SPANISH<YN1> (B) 		8-97148-680-0 01 1 9611- ● ● ●
5 05.880 LABEL; TIRE AIR PRESSURE
EXC. CAUTION SPANISH<YN1> (B) 		8-97148-680-0 01 1 9611- ●
5 05.880 LABEL; TIRE AIR PRESSURE
6VD1 ENG(RLV) CAUTION SPANISH<YN1> (B) 		8-97148-679-0 01 1 9611- ● ●
5 05.880 LABEL; TIRE AIR PRESSURE
CAUTION SPANISH<YN1> (B) 		8-97148-679-0 01 1 9611- ● ● ● ●
5 05.880 LABEL; TIRE AIR PRESSURE
6VD1 ENG(RLV) FRT&RR 225/70R15C 6JJX15 STYLED(AYG) AUSTRALIA EQUIPMENT(RR3) (A) 		8-97207-576-0 01 1 9803- ● ●
5 05.880 LABEL; TIRE AIR PRESSURE
AUSTRALIA EQUIPMENT(RR3) (A) 		8-97071-646-0 01 1 9611- ● ● ●
7 03.680 LABEL; EMISSION
UNITED KINGDOM EQUIPMENT(EK3) 		8-97165-286-0 01 1 9611- ● ● ● ●
8 03.680 LABEL; FUSE 8-97167-123-0 01 1 9611- ● ● ● ● ● ● ● ●
38 08.808 PLATE; CAUTION,LSV
4JA1 ENG(RLE) UNITED KINGDOM EQUIPMENT(EK3) 		8-97132-100-0 01 1 9611- ● ●
38 08.808 PLATE; CAUTION,LSV
4JA1 ENG(RLE) UNITED KINGDOM EQUIPMENT(EK3) 		8-97132-098-1 01 1 9611- ● ●
59 08.808 PLATE; CAUTION,BATTERY
UNITED KINGDOM EQUIPMENT(EK3) EXC. HONG KONG EQUIPMENT(PQ1) 10 PER 1 SHEET 		8-97116-760-0 01 1 9611- ● ● ● ●
90 08.808 LABEL; CAUTION,TIMING BELT
UNITED KINGDOM EQUIPMENT(EK3) 		8-94481-501-0 01 1 9611- ● ● ● ●
94 08.808 PLATE; CAUTION,EGR PIPE
UNITED KINGDOM EQUIPMENT(EK3) 		8-97113-154-0 01 1 9611-9612 ● ● ● ●
94 08.808 PLATE; CAUTION,EGR PIPE
4JA1 ENG(RLE),4JB1 ENG(RLF) UNITED KINGDOM EQUIPMENT(EK3),EAST MALAYSIA EQUIPMENT(PM6),WEST MALAYSIA EQUIPMENT(S3D) 		8-97113-154-0 01 1 9701- ● ● ● ● ●
135 08.808 PLATE; CAUTION,ENGINE
6VD1 ENG(RLV) AUSTRALIA EQUIPMENT(RR3) 		8-97177-435-0 01 1 9712- ● ● ● ●
çizim 71274
145 21
BalonParca AdiParca NoAdetTipApplied Date A B C D E F G H
21 16.328 PLATE; CAUTION,CHILD LOCK 8-97176-092-0 02 1 9611- ● ●
145 08.808 PLATE; CAUTION,RADIATOR
4JA1 ENG(RLE),4JB1 ENG(RLF),4ZE1 ENG(RLJ) 		8-97124-237-0 01 1 9611-9611 ● ● ● ● ● ● ● ●
145 08.808 PLATE; CAUTION,RADIATOR
4ZE1 ENG(RLJ) ELECTRIC FUEL INJECTION<6GG> 		8-97124-237-0 01 1 9611-9612 ● ● ● ● ● ●
