1 |
00.646 CRANKSHAFT
|
8-97352-534-2 |
01 |
1 |
0301-0501 |
● |
|
| |
1 |
00.646 CRANKSHAFT
|
8-97352-534-3 |
01 |
1 |
0502-0509 |
|
● |
| |
1 |
00.646 CRANKSHAFT
|
8-98029-270-0 |
01 |
1 |
0510- |
|
● |
| |
10 |
00.094 METAL SET; CRANKSHAFT,STANDARD
BLUE
|
8-97219-456-0 |
05 |
1 |
0301-0307 |
● |
|
| |
10 |
00.094 METAL SET; CRANKSHAFT,STANDARD
BLACK
|
8-97219-457-0 |
05 |
1 |
0301-0307 |
● |
|
| |
10 |
00.094 METAL SET; CRANKSHAFT,STANDARD
BROWN
|
8-97219-458-0 |
05 |
1 |
0301-0307 |
● |
|
| |
10 |
00.094 METAL SET; CRANKSHAFT,STANDARD
BLUE
|
8-97372-076-0 |
05 |
1 |
0308-0501 |
● |
|
| |
10 |
00.094 METAL SET; CRANKSHAFT,STANDARD
BLUE
|
8-97372-076-1 |
05 |
1 |
0502- |
|
● |
| |
10 |
00.094 METAL SET; CRANKSHAFT,STANDARD
BLACK
|
8-97372-077-0 |
05 |
1 |
0308-0501 |
● |
|
| |
10 |
00.094 METAL SET; CRANKSHAFT,STANDARD
BLACK
|
8-97372-077-1 |
05 |
1 |
0502- |
|
● |
| |
10 |
00.094 METAL SET; CRANKSHAFT,STANDARD
BROWN
|
8-97372-078-0 |
05 |
1 |
0308-0501 |
● |
|
| |
10 |
00.094 METAL SET; CRANKSHAFT,STANDARD
BROWN
|
8-97372-078-1 |
05 |
1 |
0502- |
|
● |
| |
12 |
00.666 FLYWHEEL
|
8-97330-892-0 |
01 |
1 |
0301-0501 |
● |
|
| |
12 |
00.666 FLYWHEEL
|
8-97326-227-2 |
01 |
1 |
0502- |
|
● |
| |
24 |
00.659 BOLT; DAMPER
M16X42
|
8-97028-733-0 |
04 |
1 |
0301-0501 |
● |
|
| |
24 |
00.659 BOLT; DAMPER
M16X42
|
8-97028-733-0 |
04 |
1 |
0502- |
|
● |
| |
28 |
00.728 GEAR; CR/SHF
Z=42
|
8-94394-342-4 |
01 |
1 |
0301-0501 |
● |
|
| |
28 |
00.728 GEAR; CR/SHF
Z=42
|
8-94394-342-4 |
01 |
1 |
0502- |
|
● |
| |
34 |
00.738 PIN; GEAR SETTING
OD=5 L=6
|
9-09878-626-0 |
01 |
1 |
0301-0501 |
● |
|
| |
34 |
00.738 PIN; GEAR SETTING
OD=5 L=6
|
9-09878-626-0 |
01 |
1 |
0502- |
|
● |
| |
35 |
00.673 GEAR; RING
Z=138
|
8-97046-366-0 |
01 |
1 |
0301-0501 |
● |
|
| |
35 |
00.673 GEAR; RING
Z=138
|
8-97046-366-1 |
01 |
1 |
0502- |
|
● |
| |
38 |
00.862 WASHER; FLYWHEEL
|
8-97170-830-1 |
01 |
1 |
0502-0502 |
|
● |
| |
38 |
00.862 WASHER; FLYWHEEL
ID=55 OD=110
|
8-94397-496-1 |
01 |
1 |
0301-0501 |
● |
|
| |
38 |
00.862 WASHER; FLYWHEEL
ID=55 OD=110
|
8-94397-496-1 |
01 |
1 |
0502- |
|
● |
| |
40 |
00.669 BOLT; FLYWHEEL
M16X42
|
8-97178-013-0 |
08 |
1 |
0301-0501 |
● |
|
| |
40 |
00.669 BOLT; FLYWHEEL
M16X42
|
8-97178-013-0 |
08 |
1 |
0502- |
|
● |
| |
42 |
00.095 WASHER; THRUST,CR/SHF
(A)
|
8-94399-277-0 |
01 |
1 |
0301-0501 |
● |
|
| |
42 |
00.095 WASHER; THRUST,CR/SHF
(A)
|
8-94399-277-0 |
01 |
1 |
0502-0703 |
|
● |
| |
42 |
00.095 WASHER; THRUST,CR/SHF
(A)
|
8-97386-548-0 |
01 |
1 |
0704- |
|
● |
| |
42 |
00.095 WASHER; THRUST,CR/SHF
(B)
|
8-94399-283-0 |
02 |
1 |
0301-0501 |
● |
|
| |
42 |
00.095 WASHER; THRUST,CR/SHF
(B)
|
8-94399-283-0 |
02 |
1 |
0502-0703 |
|
● |
| |
42 |
00.095 WASHER; THRUST,CR/SHF
(B)
|
8-97386-549-0 |
02 |
1 |
0704- |
|
● |
| |
49 |
00.669 BEARING; PILOT
|
8-97258-239-0 |
01 |
1 |
0301-0501 |
● |
|
| |
49 |
00.669 BEARING; PILOT
|
8-97258-239-0 |
01 |
1 |
0502- |
|
● |
| |
56 |
00.659 PULLEY; CR/SHF DAMPER
4-GROOVE
|
8-97222-031-3 |
01 |
1 |
0301-0501 |
● |
|
| |
56 |
00.659 PULLEY; CR/SHF DAMPER
4-GROOVE
|
8-97222-031-3 |
01 |
1 |
0502- |
|
● |
| |
57 |
00.662 PIN; PULLEY
08.939
OD=8 L=20
|
9-08160-820-0 |
02 |
1 |
0301-0304 |
● |
|
| |
57 |
00.662 PIN; PULLEY
00.862
OD=8 L=20
|
9-08150-820-0 |
02 |
1 |
0305-0501 |
● |
|
| |
57 |
00.662 PIN; PULLEY
00.862
OD=8 L=20
|
9-08150-820-0 |
02 |
1 |
0502- |
|
● |
| |
61 |
00.659 PULLEY; FAN DRIVE
2-GROOVE
|
8-97174-757-3 |
01 |
1 |
0301-0501 |
● |
|
| |
61 |
00.659 PULLEY; FAN DRIVE
2-GROOVE
|
8-97364-396-1 |
01 |
1 |
0502- |
|
● |
| |
63 |
00.629 PISTON
ALSO INCLUDED IN LINER SET.
GRADE=AX
|
8-97251-696-0 |
04 |
1 |
0301-0501 |
● |
|
| |
63 |
00.629 PISTON
ALSO INCLUDED IN LINER SET.
NON GRADE
|
8-97602-800-0 |
04 |
1 |
0502- |
|
● |
| |
63 |
00.629 PISTON
ALSO INCLUDED IN LINER SET.
GRADE=CX
|
8-97251-697-0 |
04 |
1 |
0301-0501 |
● |
|
| |
68 |
00.643 RING SET; PISTON,STANDARD
ALSO INCLUDED IN LINER SET.
|
8-97166-992-1 |
04 |
1 |
0301-0501 |
● |
|
| |
68 |
00.643 RING SET; PISTON,STANDARD
ALSO INCLUDED IN LINER SET.
|
8-97603-423-1 |
04 |
1 |
0502- |
|
● |
| |
73 |
00.616 METAL SET; CONN ROD,STANDARD
GREEN
|
8-94395-757-1 |
04 |
1 |
0301-0501 |
● |
|
| |
73 |
00.616 METAL SET; CONN ROD,STANDARD
GREEN
|
8-94395-757-1 |
04 |
1 |
0502-0701 |
|
● |
| |
73 |
00.616 METAL SET; CONN ROD,STANDARD
GREEN
|
8-98064-282-0 |
04 |
1 |
0702-0706 |
|
● |
| |
73 |
00.616 METAL SET; CONN ROD,STANDARD
GREEN
|
8-98055-480-0 |
04 |
1 |
0707- |
|
● |
| |
73 |
00.616 METAL SET; CONN ROD,STANDARD
YELLOW
|
8-97131-186-1 |
04 |
1 |
0301-0501 |
● |
|
| |
73 |
00.616 METAL SET; CONN ROD,STANDARD
YELLOW
|
8-97131-186-1 |
04 |
1 |
0502-0701 |
|
● |
| |
73 |
00.616 METAL SET; CONN ROD,STANDARD
YELLOW
|
8-98064-281-0 |
04 |
1 |
0702-0706 |
|
● |
| |
73 |
00.616 METAL SET; CONN ROD,STANDARD
YELLOW
|
8-98055-479-0 |
04 |
1 |
0707- |
|
● |
| |
83 |
00.636 PIN; PISTON
ALSO INCLUDED IN LINER SET.
|
8-94396-731-1 |
04 |
1 |
0301-0501 |
● |
|
| |
83 |
00.636 PIN; PISTON
ALSO INCLUDED IN LINER SET.
|
8-94396-731-1 |
04 |
1 |
0502- |
|
● |
| |
84 |
00.603 ROD ASM; CONN
|
8-94399-661-2 |
04 |
1 |
0301-0501 |
● |
|
| |
84 |
00.603 ROD ASM; CONN
|
8-94399-661-2 |
04 |
1 |
0502-0706 |
|
● |
| |
84 |
00.603 ROD ASM; CONN
|
8-98018-425-2 |
04 |
1 |
0707- |
|
● |
| |
85 |
00.613 BUSHING; CONNROD
ALSO INCLUDED IN LINER SET.
|
8-94394-613-0 |
04 |
1 |
0301-0501 |
● |
|
| |
85 |
00.613 BUSHING; CONNROD
ALSO INCLUDED IN LINER SET.
|
8-94394-613-0 |
04 |
1 |
0502-0706 |
|
● |
| |
85 |
00.613 BUSHING; CONNROD
ALSO INCLUDED IN LINER SET.
|
8-94391-794-1 |
04 |
1 |
0707- |
|
● |
| |
86 |
00.623 BOLT; CONNROD
M13X57 FLANGE
|
1-12235-035-0 |
08 |
1 |
0301-0501 |
● |
|
| |
86 |
00.623 BOLT; CONNROD
M13X57 FLANGE
|
1-12235-035-0 |
08 |
1 |
0502-1004 |
|
● |
| |
86 |
00.623 BOLT; CONNROD
M13X57 FLANGE
|
8-98091-141-0 |
08 |
1 |
1005- |
|
● |
| |
126 |
00.639 RING; SNAP,PISTON PIN
ALSO INCLUDED IN LINER SET.
|
1-09587-081-1 |
08 |
1 |
0301-0501 |
● |
|
| |
126 |
00.639 RING; SNAP,PISTON PIN
ALSO INCLUDED IN LINER SET.
|
1-09587-081-1 |
08 |
1 |
0502- |
|
● |
