2 |
WHEEL; DISC
DISC WHEEL SPARE<N79>
DISC WHEEL 10STUD 20X7.00T(Q58)
EXC. HEAVY DUTY PACKAGE TRUCK<RD2>
(A)
|
1-42350-167-1 |
01 |
1 |
9202-9301 |
● |
● |
| |
2 |
WHEEL; DISC
DISC WHEEL 10STUD 20X7.00T(Q58)
SPARE TIRE & DISC WHEEL REAR<R46>,SPARE TIRE &
DISC WHEEL FRONT TIRE ONE<WH2>
EXC. DISC WHEEL SPARE<N79>,HEAVY DUTY PACKAGE
TRUCK<RD2>
(A)
|
1-42350-167-1 |
01 |
1 |
9202-9301 |
● |
● |
| |
2 |
WHEEL; DISC
DISC WHEEL SPARE<N79>
DISC WHEEL 10STUD 20X7.00T(Q58)
(A)
|
1-42350-447-0 |
01 |
1 |
9302- |
● |
● |
| |
2 |
WHEEL; DISC
DISC WHEEL 10STUD 20X7.00T(Q58)
SPARE TIRE & DISC WHEEL REAR<R46>
EXC. DISC WHEEL SPARE<N79>
(A)
|
1-42350-447-0 |
01 |
1 |
9302- |
● |
● |
| |
2 |
WHEEL; DISC
DISC WHEEL SPARE<N79>
DISC WHEEL 10STUD 22.5X7.50 162-12(Q87)
DISC WHEEL SPECIAL PAINTED LIGHT ARGENT<SKD>
(B)
|
1-42350-338-2 |
01 |
1 |
9202-9312 |
● |
● |
| |
2 |
WHEEL; DISC
DISC WHEEL 10STUD 22.5X7.50 162-12(Q87)
SPARE TIRE & DISC WHEEL REAR<R46>,SPARE TIRE &
DISC WHEEL FRONT TIRE ONE<WH2>
DISC WHEEL SPECIAL PAINTED LIGHT ARGENT<SKD>
EXC. DISC WHEEL SPARE<N79>
(B)
|
1-42350-338-2 |
01 |
1 |
9202-9312 |
● |
● |
| |
2 |
WHEEL; DISC
DISC WHEEL SPARE<N79>
DISC WHEEL 10STUD 22.5X7.50 162-12(Q87)
DISC WHEEL SPECIAL PAINTED LIGHT ARGENT<SKD>
(B)
|
1-42350-464-0 |
01 |
1 |
9401-9406 |
● |
● |
| |
2 |
WHEEL; DISC
DISC WHEEL 10STUD 22.5X7.50 162-12(Q87)
SPARE TIRE & DISC WHEEL REAR<R46>,SPARE TIRE &
DISC WHEEL FRONT TIRE ONE<WH2>
DISC WHEEL SPECIAL PAINTED LIGHT ARGENT<SKD>
EXC. DISC WHEEL SPARE<N79>
(B)
|
1-42350-464-0 |
01 |
1 |
9401-9406 |
● |
● |
| |
2 |
WHEEL; DISC
DISC WHEEL SPARE<N79>
DISC WHEEL 10STUD 22.5X7.50 162-12(Q87)
DISC WHEEL SPECIAL PAINTED WHITE<W20>
(B)
|
1-42350-278-2 |
01 |
1 |
9407- |
● |
● |
| |
2 |
WHEEL; DISC
DISC WHEEL 10STUD 22.5X7.50 162-12(Q87)
SPARE TIRE & DISC WHEEL REAR<R46>
DISC WHEEL SPECIAL PAINTED WHITE<W20>
EXC. DISC WHEEL SPARE<N79>
(B)
|
1-42350-278-2 |
01 |
1 |
9407- |
● |
● |
| |
2 |
WHEEL; DISC
DISC WHEEL SPARE<N79>
DISC WHEEL 8STUD 22.5X7.50 162-12(QM2)
DISC WHEEL SPECIAL PAINTED LIGHT ARGENT<SKD>
(C)
|
1-42350-327-0 |
01 |
1 |
9202-9204 |
● |
● |
| |
2 |
WHEEL; DISC
DISC WHEEL 8STUD 22.5X7.50 162-12(QM2)
SPARE TIRE & DISC WHEEL REAR<R46>,SPARE TIRE &
DISC WHEEL FRONT TIRE ONE<WH2>
DISC WHEEL SPECIAL PAINTED LIGHT ARGENT<SKD>
EXC. DISC WHEEL SPARE<N79>
(C)
|
1-42350-327-0 |
01 |
1 |
9202-9204 |
● |
● |
| |
2 |
WHEEL; DISC
DISC WHEEL SPARE<N79>
DISC WHEEL 10STUD 22.5X7.50 162-12(Q87)
DISC WHEEL SPECIAL PAINTED LIGHT ARGENT<SKD>
(C)
|
1-42350-411-3 |
01 |
1 |
9205- |
● |
● |
| |
2 |
WHEEL; DISC
DISC WHEEL 8STUD 22.5X7.50 162-12(QM2)
SPARE TIRE & DISC WHEEL REAR<R46>,SPARE TIRE &
DISC WHEEL FRONT TIRE ONE<WH2>
DISC WHEEL SPECIAL PAINTED LIGHT ARGENT<SKD>
EXC. DISC WHEEL SPARE<N79>
(C)
|
1-42350-411-3 |
01 |
1 |
9205- |
● |
● |
| |
2 |
WHEEL; DISC
DISC WHEEL SPARE<N79>
DISC WHEEL 8STUD 20X6.50T 152-11(Q50)
(A)
|
1-42350-012-3 |
01 |
1 |
9202-9206 |
● |
● |
| |
2 |
WHEEL; DISC
DISC WHEEL 8STUD 20X6.50T 152-11(Q50)
SPARE TIRE & DISC WHEEL REAR<R46>,SPARE TIRE &
DISC WHEEL FRONT TIRE ONE<WH2>
EXC. DISC WHEEL SPARE<N79>
(A)
|
1-42350-012-3 |
01 |
1 |
9202-9206 |
● |
● |
| |
2 |
WHEEL; DISC
DISC WHEEL SPARE<N79>
DISC WHEEL 8STUD 20X6.50T 152-11(Q50)
(A)
|
1-42350-268-2 |
01 |
1 |
9207- |
● |
● |
| |
2 |
WHEEL; DISC
DISC WHEEL 8STUD 20X6.50T 152-11(Q50)
SPARE TIRE & DISC WHEEL REAR<R46>,SPARE TIRE &
DISC WHEEL FRONT TIRE ONE<WH2>
EXC. DISC WHEEL SPARE<N79>
(A)
|
1-42350-268-2 |
01 |
1 |
9207- |
● |
● |
| |
2 |
WHEEL; DISC
DISC WHEEL SPARE<N79>
DISC WHEEL 8STUD 20X7.00T 162-12(Q54)
(A)
|
1-42350-131-3 |
01 |
1 |
9202-9402 |
● |
● |
| |
2 |
WHEEL; DISC
DISC WHEEL 8STUD 20X7.00T 162-12(Q54)
SPARE TIRE & DISC WHEEL REAR<R46>,SPARE TIRE &
DISC WHEEL FRONT TIRE ONE<WH2>
EXC. DISC WHEEL SPARE<N79>
(A)
|
1-42350-131-3 |
01 |
1 |
9202-9402 |
● |
● |
| |
2 |
WHEEL; DISC
DISC WHEEL SPARE<N79>
DISC WHEEL 8STUD 20X7.00T 162-12(Q54)
(A)
|
1-42350-478-0 |
01 |
1 |
9403- |
● |
● |
| |
2 |
WHEEL; DISC
DISC WHEEL 8STUD 20X7.00T 162-12(Q54)
SPARE TIRE & DISC WHEEL REAR<R46>,SPARE TIRE &
DISC WHEEL FRONT TIRE ONE<WH2>
EXC. DISC WHEEL SPARE<N79>
(A)
|
1-42350-478-0 |
01 |
1 |
9403- |
● |
● |
| |
2 |
WHEEL; DISC
DISC WHEEL 10STUD 20X7.00T(Q58)
EXC. HEAVY DUTY PACKAGE TRUCK<RD2>
(A)
|
1-42350-167-1 |
06 |
1 |
9202-9301 |
● |
● |
| |
2 |
WHEEL; DISC
DISC WHEEL 10STUD 20X7.00T(Q58)
EXC. HEAVY DUTY PACKAGE TRUCK<RD2>
(A)
|
1-42350-447-0 |
06 |
1 |
9302- |
● |
● |
| |
2 |
WHEEL; DISC
DISC WHEEL 10STUD 22.5X7.50 162-12(Q87)
DISC WHEEL SPECIAL PAINTED LIGHT ARGENT<SKD>
(B)
|
1-42350-338-2 |
06 |
1 |
9202-9312 |
● |
● |
| |
2 |
WHEEL; DISC
DISC WHEEL 10STUD 22.5X7.50 162-12(Q87)
DISC WHEEL SPECIAL PAINTED LIGHT ARGENT<SKD>
(B)
|
1-42350-464-0 |
06 |
1 |
9401-9406 |
● |
● |
| |
2 |
WHEEL; DISC
DISC WHEEL 10STUD 22.5X7.50 162-12(Q87)
DISC WHEEL SPECIAL PAINTED WHITE<W20>
(B)
|
1-42350-278-2 |
06 |
1 |
9407- |
● |
● |
| |
2 |
WHEEL; DISC
DISC WHEEL 8STUD 22.5X7.50 162-12(QM2)
DISC WHEEL SPECIAL PAINTED LIGHT ARGENT<SKD>
(C)
|
1-42350-327-0 |
06 |
1 |
9202-9204 |
● |
● |
| |
2 |
WHEEL; DISC
DISC WHEEL 8STUD 22.5X7.50 162-12(QM2)
DISC WHEEL SPECIAL PAINTED LIGHT ARGENT<SKD>
(C)
|
1-42350-411-3 |
06 |
1 |
9205- |
● |
● |
| |
2 |
WHEEL; DISC
DISC WHEEL 8STUD 20X6.50T 152-11(Q50)
(A)
|
1-42350-012-3 |
06 |
1 |
9202-9206 |
● |
● |
| |
2 |
WHEEL; DISC
DISC WHEEL 8STUD 20X6.50T 152-11(Q50)
(A)
|
1-42350-268-2 |
06 |
1 |
9207- |
● |
● |
| |
2 |
WHEEL; DISC
DISC WHEEL 8STUD 20X7.00T 162-12(Q54)
(A)
|
1-42350-131-3 |
06 |
1 |
9202-9402 |
● |
● |
| |
2 |
WHEEL; DISC
DISC WHEEL 8STUD 20X7.00T 162-12(Q54)
(A)
|
1-42350-478-0 |
06 |
1 |
9403- |
● |
● |
| |
2 |
WHEEL; DISC
DISC WHEEL SPARE<N79>
DISC WHEEL 10STUD 20X7.00T(Q58)
HEAVY DUTY PACKAGE TRUCK<RD2>
(A)
|
1-42350-442-0 |
01 |
1 |
9206-9301 |
|
● |
| |
2 |
WHEEL; DISC
DISC WHEEL 10STUD 20X7.00T(Q58)
HEAVY DUTY PACKAGE TRUCK<RD2>
SPARE TIRE & DISC WHEEL REAR<R46>,SPARE TIRE &
DISC WHEEL FRONT TIRE ONE<WH2>
EXC. DISC WHEEL SPARE<N79>
(A)
|
1-42350-442-0 |
01 |
1 |
9206-9301 |
|
● |
| |
2 |
WHEEL; DISC
DISC WHEEL 10STUD 20X7.00T(Q58)
HEAVY DUTY PACKAGE TRUCK<RD2>
(A)
|
1-42350-442-0 |
06 |
1 |
9206-9301 |
|
● |
| |
3 |
NUT; WHEEL,FRT AXLE
DISC WHEEL 10STUD 20X7.00T(Q58),DISC WHEEL 10STUD
22.5X7.50 162-12(Q87)
M22
|
1-42333-029-0 |
20 |
1 |
9202-9203 |
● |
● |
| |
3 |
NUT; WHEEL,FRT AXLE
DISC WHEEL 10STUD 20X7.00T(Q58),DISC WHEEL 10STUD
22.5X7.50 162-12(Q87)
M22 RH THREAD
|
1-42333-042-0 |
20 |
1 |
9204- |
● |
● |
| |
3 |
NUT; WHEEL,FRT AXLE
EXC. DISC WHEEL 10STUD 20X7.00T(Q58),DISC WHEEL
10STUD 22.5X7.50 162-12(Q87)
M24 LH THREAD
|
1-42334-022-0 |
08 |
1 |
9202- |
● |
● |
| |
3 |
NUT; WHEEL,FRT AXLE
EXC. DISC WHEEL 10STUD 20X7.00T(Q58),DISC WHEEL
10STUD 22.5X7.50 162-12(Q87)
M24
|
1-42333-022-0 |
08 |
1 |
9202- |
● |
● |
| |
4 |
NUT; WHEEL,RR AXLE
DISC WHEEL 10STUD 20X7.00T(Q58),DISC WHEEL 10STUD
22.5X7.50 162-12(Q87)
M22
|
1-42333-029-0 |
20 |
1 |
9202-9203 |
● |
● |
| |
4 |
NUT; WHEEL,RR AXLE
DISC WHEEL 10STUD 20X7.00T(Q58),DISC WHEEL 10STUD
22.5X7.50 162-12(Q87)
M22 RH THREAD
|
1-42333-042-0 |
20 |
1 |
9204- |
● |
● |
| |
4 |
NUT; WHEEL,RR AXLE
EXC. DISC WHEEL 10STUD 20X7.00T(Q58),DISC WHEEL
10STUD 22.5X7.50 162-12(Q87)
M30 LH THREAD
|
1-42334-023-0 |
08 |
1 |
9202- |
● |
● |
| |
4 |
NUT; WHEEL,RR AXLE
EXC. DISC WHEEL 10STUD 20X7.00T(Q58),DISC WHEEL
10STUD 22.5X7.50 162-12(Q87)
M30
|
1-42333-023-0 |
08 |
1 |
9202- |
● |
● |
| |
5 |
NUT; WHEEL,INNER,RR AXLE
EXC. DISC WHEEL 10STUD 20X7.00T(Q58),DISC WHEEL
10STUD 22.5X7.50 162-12(Q87)
OUTER M30,INNER M20 LH THREAD
|
1-42336-005-0 |
08 |
1 |
9202- |
● |
● |
| |
5 |
NUT; WHEEL,INNER,RR AXLE
EXC. DISC WHEEL 10STUD 20X7.00T(Q58),DISC WHEEL
10STUD 22.5X7.50 162-12(Q87)
OUTER M30,INNER M20 RH THREAD
|
1-42335-005-0 |
08 |
1 |
9202- |
● |
● |
| |
16 |
HOLDER; TIRE VALVE,DISC WHEEL
DISC WHEEL 10STUD 20X7.00T(Q58),DISC WHEEL 10STUD
22.5X7.50 162-12(Q87)
L=170
|
1-42370-024-0 |
02 |
1 |
9202- |
● |
● |
| |
31 |
RING; SIDE,DISC WHEEL
DISC WHEEL SPARE<N79>
DISC WHEEL 8STUD 20X6.50T 152-11(Q50),DISC WHEEL
8STUD 20X7.00T 162-12(Q54)
|
1-42355-003-1 |
01 |
1 |
9202-9206 |
● |
● |
| |
31 |
RING; SIDE,DISC WHEEL
DISC WHEEL 8STUD 20X6.50T 152-11(Q50),DISC WHEEL
8STUD 20X7.00T 162-12(Q54)
SPARE TIRE & DISC WHEEL REAR<R46>,SPARE TIRE &
DISC WHEEL FRONT TIRE ONE<WH2>
EXC. DISC WHEEL SPARE<N79>
|
1-42355-003-1 |
01 |
1 |
9202-9206 |
● |
● |
| |
31 |
RING; SIDE,DISC WHEEL
DISC WHEEL SPARE<N79>
DISC WHEEL 8STUD 20X7.00T 162-12(Q54)
|
1-42355-003-1 |
01 |
1 |
9207- |
● |
● |
| |
31 |
RING; SIDE,DISC WHEEL
DISC WHEEL 8STUD 20X7.00T 162-12(Q54)
SPARE TIRE & DISC WHEEL REAR<R46>,SPARE TIRE &
DISC WHEEL FRONT TIRE ONE<WH2>
EXC. DISC WHEEL SPARE<N79>
|
1-42355-003-1 |
01 |
1 |
9207- |
● |
● |
| |
31 |
RING; SIDE,DISC WHEEL
DISC WHEEL 10STUD 20X7.00T(Q58)
|
1-42355-012-1 |
06 |
1 |
9202-9206 |
● |
● |
| |
31 |
RING; SIDE,DISC WHEEL
DISC WHEEL 8STUD 20X6.50T 152-11(Q50),DISC WHEEL
10STUD 20X7.00T(Q58)
|
1-42355-012-1 |
06 |
1 |
9207- |
● |
● |
| |
31 |
RING; SIDE,DISC WHEEL
DISC WHEEL 10STUD 20X7.00T(Q58)
DISC WHEEL SPARE<N79>
|
1-42355-012-1 |
01 |
1 |
9202-9206 |
● |
● |
| |
31 |
RING; SIDE,DISC WHEEL
DISC WHEEL 10STUD 20X7.00T(Q58)
SPARE TIRE & DISC WHEEL REAR<R46>,SPARE TIRE &
DISC WHEEL FRONT TIRE ONE<WH2>
EXC. DISC WHEEL SPARE<N79>
|
1-42355-012-1 |
01 |
1 |
9202-9206 |
● |
● |
| |
31 |
RING; SIDE,DISC WHEEL
DISC WHEEL SPARE<N79>
DISC WHEEL 8STUD 20X6.50T 152-11(Q50),DISC WHEEL
10STUD 20X7.00T(Q58)
|
1-42355-012-1 |
01 |
1 |
9207- |
● |
● |
| |
31 |
RING; SIDE,DISC WHEEL
DISC WHEEL 8STUD 20X6.50T 152-11(Q50),DISC WHEEL
10STUD 20X7.00T(Q58)
SPARE TIRE & DISC WHEEL REAR<R46>,SPARE TIRE &
DISC WHEEL FRONT TIRE ONE<WH2>
EXC. DISC WHEEL SPARE<N79>
|
1-42355-012-1 |
01 |
1 |
9207- |
● |
● |
| |
31 |
RING; SIDE,DISC WHEEL
DISC WHEEL 8STUD 20X6.50T 152-11(Q50),DISC WHEEL
8STUD 20X7.00T 162-12(Q54)
|
1-42355-003-1 |
06 |
1 |
9202-9206 |
● |
● |
| |
31 |
RING; SIDE,DISC WHEEL
DISC WHEEL 8STUD 20X7.00T 162-12(Q54)
|
1-42355-003-1 |
06 |
1 |
9207- |
● |
● |
| |
32 |
CAP; VALVE
DISC WHEEL SPARE<N79>
|
1-42374-001-0 |
07 |
1 |
9304- |
● |
● |
| |
32 |
CAP; VALVE
SPARE TIRE & DISC WHEEL REAR<R46>
EXC. DISC WHEEL SPARE<N79>
|
1-42374-001-0 |
07 |
1 |
9304- |
● |
● |
| |
32 |
CAP; VALVE
EXC. DISC WHEEL SPARE<N79>,SPARE TIRE & DISC
WHEELREAR<R46>
|
1-42374-001-0 |
06 |
1 |
9304- |
● |
● |
