0-85D — AUTO TIMER; INJECTION PUMP (#38464) — 25 parça

51 52 47 46 48 49 20 43 41 40 38 50 31

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
20	03.330 SHIM; INNER SPRING,TIMER,INJ PUM T=0.60 ASM PART: A = 8-97132-678-3, 97132678, B = 8-97132-679-2, 97132679, C = 8-97132-680-4, 97132680, D = 8-97132-681-2, 97132681, E = 8-97172-535-1, 97172535, F = 8-97172-536-0, 97172536, G = 8-97182-352-0, 97182352, H = 8-97188-187-2, 97188187, I = 8-97228-828-1, 97228828, J = 8-97228-829-1, 97228829	8-94227-495-0	01	1	-
31	03.330 SCREW; TIMER COVER,INJ PUMP ASM PART: A = 8-97132-678-3, 97132678, B = 8-97132-679-2, 97132679, C = 8-97132-680-4, 97132680, D = 8-97132-681-2, 97132681, E = 8-97172-535-1, 97172535, F = 8-97172-536-0, 97172536, G = 8-97182-352-0, 97182352, H = 8-97188-187-2, 97188187, I = 8-97228-828-1, 97228828, J = 8-97228-829-1, 97228829	8-94313-276-0	02	1	-
38	03.318 COVER; TIMER,INJ PUMP ASM PART: A = 8-97132-678-3, 97132678, B = 8-97132-679-2, 97132679, C = 8-97132-680-4, 97132680, D = 8-97132-681-2, 97132681, E = 8-97172-535-1, 97172535, F = 8-97172-536-0, 97172536, G = 8-97182-352-0, 97182352, H = 8-97188-187-2, 97188187, I = 8-97228-828-1, 97228828, J = 8-97228-829-1, 97228829	8-94473-120-0	01	1	-
40	03.330 GASKET; TIMER COVER,INJ PUMP 03.306 ASM PART: A = 8-97132-678-3, 97132678, C = 8-97132-680-4, 97132680, E = 8-97172-535-1, 97172535	8-94227-491-0	01	1	0106-
40	03.330 GASKET; TIMER COVER,INJ PUMP 03.306 ASM PART: H = 8-97188-187-2, 97188187, I = 8-97228-828-1, 97228828, J = 8-97228-829-1, 97228829	8-94227-491-0	01	1	-
40	03.330 GASKET; TIMER COVER,INJ PUMP ASM PART: A = 8-97132-678-3, 97132678, C = 8-97132-680-4, 97132680, E = 8-97172-535-1, 97172535	8-94433-763-0	01	1	-0105
40	03.330 GASKET; TIMER COVER,INJ PUMP ASM PART: B = 8-97132-679-2, 97132679, D = 8-97132-681-2, 97132681, F = 8-97172-536-0, 97172536, G = 8-97182-352-0, 97182352	8-94433-763-0	01	1	-
41	03.330 SHIM; OUTER SPRING,TIMER,INJ PUM 03.320, T=2.40 ASM PART: A = 8-97132-678-3, 97132678, B = 8-97132-679-2, 97132679, C = 8-97132-680-4, 97132680, D = 8-97132-681-2, 97132681, E = 8-97172-535-1, 97172535, F = 8-97172-536-0, 97172536, G = 8-97182-352-0, 97182352, H = 8-97188-187-2, 97188187, I = 8-97228-828-1, 97228828, J = 8-97228-829-1, 97228829	8-94121-620-0	AR	1	-
41	03.330 SHIM; OUTER SPRING,TIMER,INJ PUM T=0.60 ASM PART: A = 8-97132-678-3, 97132678, B = 8-97132-679-2, 97132679, C = 8-97132-680-4, 97132680, D = 8-97132-681-2, 97132681, E = 8-97172-535-1, 97172535, F = 8-97172-536-0, 97172536, G = 8-97182-352-0, 97182352, H = 8-97188-187-2, 97188187, I = 8-97228-828-1, 97228828, J = 8-97228-829-1, 97228829	8-94227-495-0	AR	1	-
41	03.330 SHIM; OUTER SPRING,TIMER,INJ PUM T=0.70 ASM PART: A = 8-97132-678-3, 97132678, B = 8-97132-679-2, 97132679, C = 8-97132-680-4, 97132680, D = 8-97132-681-2, 97132681, E = 8-97172-535-1, 97172535, F = 8-97172-536-0, 97172536, G = 8-97182-352-0, 97182352, H = 8-97188-187-2, 97188187, I = 8-97228-828-1, 97228828, J = 8-97228-829-1, 97228829	8-94227-496-0	AR	1	-
41	03.330 SHIM; OUTER SPRING,TIMER,INJ PUM T=0.90 ASM PART: A = 8-97132-678-3, 97132678, B = 8-97132-679-2, 97132679, C = 8-97132-680-4, 97132680, D = 8-97132-681-2, 97132681, E = 8-97172-535-1, 97172535, F = 8-97172-536-0, 97172536, G = 8-97182-352-0, 97182352, H = 8-97188-187-2, 97188187, I = 8-97228-828-1, 97228828, J = 8-97228-829-1, 97228829	8-94227-497-0	AR	1	-
41	03.330 SHIM; OUTER SPRING,TIMER,INJ PUM T=1.00 ASM PART: A = 8-97132-678-3, 97132678, B = 8-97132-679-2, 97132679, C = 8-97132-680-4, 97132680, D = 8-97132-681-2, 97132681, E = 8-97172-535-1, 97172535, F = 8-97172-536-0, 97172536, G = 8-97182-352-0, 97182352, H = 8-97188-187-2, 97188187, I = 8-97228-828-1, 97228828, J = 8-97228-829-1, 97228829	8-94227-498-0	AR	1	-
41	03.330 SHIM; OUTER SPRING,TIMER,INJ PUM T=1.20 ASM PART: A = 8-97132-678-3, 97132678, B = 8-97132-679-2, 97132679, C = 8-97132-680-4, 97132680, D = 8-97132-681-2, 97132681, E = 8-97172-535-1, 97172535, F = 8-97172-536-0, 97172536, G = 8-97182-352-0, 97182352, H = 8-97188-187-2, 97188187, I = 8-97228-828-1, 97228828, J = 8-97228-829-1, 97228829	8-94227-499-0	AR	1	-
43	03.340 SPRING; PISTON,TIMER,INJ PUMP K=2.25KG/MM ASM PART: B = 8-97132-679-2, 97132679, D = 8-97132-681-2, 97132681, F = 8-97172-536-0, 97172536, I = 8-97228-828-1, 97228828, J = 8-97228-829-1, 97228829	8-94174-833-0	01	1	-
43	03.340 SPRING; PISTON,TIMER,INJ PUMP K=2.25KG/MM ASM PART: A = 8-97132-678-3, 97132678, C = 8-97132-680-4, 97132680	8-94174-833-0	01	1	0106-
43	03.340 SPRING; PISTON,TIMER,INJ PUMP K=2.05KG/MM ASM PART: A = 8-97132-678-3, 97132678, B = 8-97132-679-2, 97132679, C = 8-97132-680-4, 97132680, D = 8-97132-681-2, 97132681, E = 8-97172-535-1, 97172535, F = 8-97172-536-0, 97172536, G = 8-97182-352-0, 97182352, H = 8-97188-187-2, 97188187, I = 8-97228-828-1, 97228828, J = 8-97228-829-1, 97228829	8-94174-835-0	01	1	-
43	03.340 SPRING; PISTON,TIMER,INJ PUMP K=1.75KG/MM ASM PART: A = 8-97132-678-3, 97132678, C = 8-97132-680-4, 97132680, E = 8-97172-535-1, 97172535, G = 8-97182-352-0, 97182352, H = 8-97188-187-2, 97188187, I = 8-97228-828-1, 97228828	8-97045-508-0	01	1	-
43	03.340 SPRING; PISTON,TIMER,INJ PUMP L=40.6 ASM PART: A = 8-97132-678-3, 97132678, B = 8-97132-679-2, 97132679, C = 8-97132-680-4, 97132680, D = 8-97132-681-2, 97132681, E = 8-97172-535-1, 97172535, F = 8-97172-536-0, 97172536, G = 8-97182-352-0, 97182352, H = 8-97188-187-2, 97188187, I = 8-97228-828-1, 97228828, J = 8-97228-829-1, 97228829	8-97125-524-0	01	1	-
46	03.330 CLIP; HOLDER PIN,TIMER,INJ PUMP ASM PART: A = 8-97132-678-3, 97132678, B = 8-97132-679-2, 97132679, C = 8-97132-680-4, 97132680, D = 8-97132-681-2, 97132681, E = 8-97172-535-1, 97172535, F = 8-97172-536-0, 97172536, G = 8-97182-352-0, 97182352, H = 8-97188-187-2, 97188187, I = 8-97228-828-1, 97228828, J = 8-97228-829-1, 97228829	8-94227-488-0	01	1	-
47	03.340 PIN; HOLDER PIN,TIMER,INJ PUMP ASM PART: A = 8-97132-678-3, 97132678, B = 8-97132-679-2, 97132679, C = 8-97132-680-4, 97132680, D = 8-97132-681-2, 97132681, E = 8-97172-535-1, 97172535, F = 8-97172-536-0, 97172536, G = 8-97182-352-0, 97182352, H = 8-97188-187-2, 97188187, I = 8-97228-828-1, 97228828, J = 8-97228-829-1, 97228829	8-94227-487-0	01	1	-
48	03.340 PIN; ROLLER HOLDER,TIMER,INJ PUM ASM PART: A = 8-97132-678-3, 97132678, B = 8-97132-679-2, 97132679, C = 8-97132-680-4, 97132680, D = 8-97132-681-2, 97132681, E = 8-97172-535-1, 97172535, F = 8-97172-536-0, 97172536, G = 8-97182-352-0, 97182352, H = 8-97188-187-2, 97188187, I = 8-97228-828-1, 97228828, J = 8-97228-829-1, 97228829	8-94227-486-0	01	1	-
49	03.330 PISTON; TIMER,INJ PUMP ASM PART: A = 8-97132-678-3, 97132678, B = 8-97132-679-2, 97132679, C = 8-97132-680-4, 97132680, D = 8-97132-681-2, 97132681, E = 8-97172-535-1, 97172535, F = 8-97172-536-0, 97172536, G = 8-97182-352-0, 97182352, H = 8-97188-187-2, 97188187, I = 8-97228-828-1, 97228828, J = 8-97228-829-1, 97228829	8-94426-069-0	01	1	-
50	03.340 SLIDER; TIMER PISTON,INJ PUMP ASM PART: A = 8-97132-678-3, 97132678, B = 8-97132-679-2, 97132679, C = 8-97132-680-4, 97132680, D = 8-97132-681-2, 97132681, E = 8-97172-535-1, 97172535, F = 8-97172-536-0, 97172536, G = 8-97182-352-0, 97182352, H = 8-97188-187-2, 97188187, I = 8-97228-828-1, 97228828, J = 8-97228-829-1, 97228829	8-94227-493-0	01	1	-
51	03.340 GASKET; TIMING SENSOR,INJ PUMP 03.306 ASM PART: A = 8-97132-678-3, 97132678, B = 8-97132-679-2, 97132679, C = 8-97132-680-4, 97132680, D = 8-97132-681-2, 97132681, E = 8-97172-535-1, 97172535, F = 8-97172-536-0, 97172536, G = 8-97182-352-0, 97182352, H = 8-97188-187-2, 97188187, I = 8-97228-828-1, 97228828, J = 8-97228-829-1, 97228829	8-94227-671-0	01	1	-
52	03.340 SENSOR; TIMING,TACHOMETER,INJ PU ASM PART: A = 8-97132-678-3, 97132678, B = 8-97132-679-2, 97132679, C = 8-97132-680-4, 97132680, D = 8-97132-681-2, 97132681, E = 8-97172-535-1, 97172535, F = 8-97172-536-0, 97172536, G = 8-97182-352-0, 97182352, H = 8-97188-187-2, 97188187, I = 8-97228-828-1, 97228828, J = 8-97228-829-1, 97228829	8-94403-289-1	01	1	-

İpucu: çizimdeki balona veya tablodaki Balon sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
