1 |
PAN ASM; OIL
EXC. ENGINE OIL TEMPERATURE GAUGE<UG3>
|
8-94394-711-1 |
01 |
1 |
9710-0004 |
● |
|
|
|
|
|
| |
1 |
PAN ASM; OIL
|
8-94394-711-1 |
01 |
1 |
9710-0004 |
|
● |
● |
|
|
|
| |
1 |
PAN ASM; OIL
|
8-94394-711-2 |
01 |
1 |
0005- |
|
● |
● |
|
|
|
| |
1 |
PAN ASM; OIL
ENGINE OIL TEMPERATURE GAUGE<UG3>
|
8-94395-691-1 |
01 |
1 |
9510-0004 |
● |
|
|
● |
|
|
| |
1 |
PAN ASM; OIL
ANTI NOISE EQUIPMENT ECE<SLK>,ANTI NOISE
EQUIPMENT VAR2<TAK>
EXC. ENGINE OIL TEMPERATURE GAUGE<UG3>
|
8-94395-608-1 |
01 |
1 |
9510-0004 |
|
|
|
● |
● |
|
| |
1 |
PAN ASM; OIL
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
ANTI NOISE EQUIPMENT ECE<SLK>
|
8-94395-608-1 |
01 |
1 |
0005-0010 |
|
|
|
● |
|
|
| |
1 |
PAN ASM; OIL
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
|
8-94395-608-1 |
01 |
1 |
0005-0010 |
|
|
|
|
|
● |
| |
1 |
PAN ASM; OIL
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
ANTI NOISE EQUIPMENT ECE<SLK>
|
8-94395-608-2 |
01 |
1 |
0011- |
|
|
|
● |
|
|
| |
1 |
PAN ASM; OIL
EXC. EURO2 SPECIFICATION<THN>
|
8-94395-608-2 |
01 |
1 |
0011- |
|
|
|
|
|
● |
| |
1 |
PAN ASM; OIL
EXC. ANTI NOISE EQUIPMENT ECE<SLK>,ANTI NOISE
EQUIPMENT VAR2<TAK>,ENGINE OIL TEMPERATURE
GAUGE<UG3>
|
8-94395-861-1 |
01 |
1 |
9510-0004 |
|
|
|
● |
● |
|
| |
1 |
PAN ASM; OIL
EXC. ANTI NOISE EQUIPMENT ECE<SLK>
|
8-94395-861-1 |
01 |
1 |
0005- |
|
|
|
● |
● |
|
| |
1 |
PAN ASM; OIL
EURO2 SPECIFICATION<THN>
|
8-94395-861-1 |
01 |
1 |
0005- |
|
|
|
|
|
● |
| |
1 |
PAN ASM; OIL
|
8-94394-711-0 |
01 |
1 |
9702-9709 |
|
● |
|
|
|
|
| |
2 |
GAUGE; OIL LEVEL
|
1-11760-396-0 |
01 |
1 |
9510-0004 |
● |
● |
● |
● |
● |
|
| |
2 |
GAUGE; OIL LEVEL
|
1-11760-396-1 |
01 |
1 |
0005- |
|
● |
● |
● |
● |
● |
| |
5 |
GASKET; PLUG,OIL DRAIN
ALSO INCLUDED IN GASKET SET(ENGINE).
ID=24.4
|
1-09623-057-0 |
01 |
1 |
0005- |
|
● |
● |
● |
● |
● |
| |
5 |
GASKET; PLUG,OIL DRAIN
ALSO INCLUDED IN GASKET SET(ENGINE).
ID=24.4
|
1-09623-057-0 |
01 |
1 |
9510-0004 |
● |
● |
● |
● |
● |
|
| |
6 |
PLUG; OIL DRAIN
M20X16.5
|
9-09662-012-0 |
01 |
1 |
9510-0004 |
● |
● |
● |
● |
● |
|
| |
6 |
PLUG; OIL DRAIN
M20X16.5
|
9-09662-012-0 |
01 |
1 |
0005- |
|
● |
● |
● |
● |
● |
| |
8 |
TUBE; GUIDE,OIL LEVEL GAUGE
(B)
|
1-11766-452-0 |
01 |
1 |
9510-0004 |
● |
● |
● |
● |
● |
|
| |
8 |
TUBE; GUIDE,OIL LEVEL GAUGE
(B)
|
1-11766-452-0 |
01 |
1 |
0005- |
|
● |
● |
● |
● |
● |
| |
8 |
TUBE; GUIDE,OIL LEVEL GAUGE
(A)
|
8-94395-114-2 |
01 |
1 |
9510-0004 |
● |
● |
● |
● |
● |
|
| |
8 |
TUBE; GUIDE,OIL LEVEL GAUGE
(A)
|
8-94395-114-2 |
01 |
1 |
0005-0009 |
|
● |
● |
● |
● |
● |
| |
8 |
TUBE; GUIDE,OIL LEVEL GAUGE
(A)
|
8-94395-114-3 |
01 |
1 |
0010- |
|
● |
● |
● |
● |
|
| |
8 |
TUBE; GUIDE,OIL LEVEL GAUGE
EMISSION SYSTEM ECE REQUIREMENTS<SFV>,EURO2
SPECIFICATION<THN>
(A)
|
8-94395-114-3 |
01 |
1 |
0010- |
|
|
|
|
|
● |
| |
8 |
TUBE; GUIDE,OIL LEVEL GAUGE
EXC. EMISSION SYSTEM ECE REQUIREMENTS<SFV>,
EURO2 SPECIFICATION<THN>
(A)
|
8-94392-176-1 |
01 |
1 |
0011- |
|
|
|
|
|
● |
| |
9 |
GASKET; GUIDE TUBE,OIL LEVEL GAUGE
ALSO INCLUDED IN GASKET SET(ENGINE).
ID=11
|
5-09623-002-0 |
02 |
1 |
9510-0004 |
● |
● |
● |
● |
● |
|
| |
9 |
GASKET; GUIDE TUBE,OIL LEVEL GAUGE
ALSO INCLUDED IN GASKET SET(ENGINE).
ID=11
|
5-09623-002-0 |
02 |
1 |
0005-0112 |
|
● |
● |
● |
● |
● |
| |
9 |
GASKET; GUIDE TUBE,OIL LEVEL GAUGE
ALSO INCLUDED IN GASKET SET(ENGINE).
ID=11
|
1-09623-469-0 |
02 |
1 |
0201- |
|
● |
● |
● |
● |
● |
| |
10 |
BOLT; GUIDE TUBE
ENGINE OIL TEMPERATURE GAUGE<UG3>
(B)
M8X12 FLANGE
|
0-28080-812-0 |
01 |
1 |
9510-0004 |
● |
|
|
|
|
|
| |
10 |
BOLT; GUIDE TUBE
(B)
M8X12 FLANGE
|
0-28080-812-0 |
01 |
1 |
9510-0004 |
|
● |
|
|
● |
|
| |
10 |
BOLT; GUIDE TUBE
EXC. ANTI NOISE EQUIPMENT ECE<SLK>
(B)
M8X12 FLANGE
|
0-28080-812-0 |
01 |
1 |
9510-0004 |
|
|
|
● |
|
|
| |
10 |
BOLT; GUIDE TUBE
EXC. ANTI NOISE EQUIPMENT ECE<SLK>
(B)
M8X12 FLANGE
|
0-28080-812-0 |
01 |
1 |
0005-0010 |
|
● |
|
● |
● |
|
| |
10 |
BOLT; GUIDE TUBE
EURO2 SPECIFICATION<THN>
(B)
M8X12 FLANGE
|
0-28080-812-0 |
01 |
1 |
0005-0010 |
|
|
|
|
|
● |
| |
10 |
BOLT; GUIDE TUBE
EXC. ANTI NOISE EQUIPMENT ECE<SLK>
(B)
M8X12 FLANGE
|
0-28080-812-0 |
01 |
1 |
0011-0512 |
|
● |
|
● |
● |
|
| |
10 |
BOLT; GUIDE TUBE
EXC. EMISSION SYSTEM ECE REQUIREMENTS<SFV>
(B)
M8X12 FLANGE
|
0-28080-812-0 |
01 |
1 |
0011-0512 |
|
|
|
|
|
● |
| |
10 |
BOLT; GUIDE TUBE
EXC. ANTI NOISE EQUIPMENT ECE<SLK>
(B)
M8X12 FLANGE
|
0-28050-812-0 |
01 |
1 |
0601- |
|
● |
|
● |
● |
|
| |
10 |
BOLT; GUIDE TUBE
EXC. EMISSION SYSTEM ECE REQUIREMENTS<SFV>
(B)
M8X12 FLANGE
|
0-28050-812-0 |
01 |
1 |
0601- |
|
|
|
|
|
● |
| |
10 |
BOLT; GUIDE TUBE
ENGINE OIL TEMPERATURE GAUGE<UG3>
(B)
M8X30 FLANGE
|
0-28080-830-0 |
01 |
1 |
9510-9802 |
● |
|
|
|
|
|
| |
10 |
BOLT; GUIDE TUBE
(B)
M8X30 FLANGE
|
0-28080-830-0 |
01 |
1 |
9510-9802 |
|
● |
|
● |
● |
|
| |
10 |
BOLT; GUIDE TUBE
ENGINE OIL TEMPERATURE GAUGE<UG3>
(B)
M8X30 FLANGE
|
0-28080-830-0 |
01 |
1 |
9803-0004 |
● |
|
|
|
|
|
| |
10 |
BOLT; GUIDE TUBE
(B)
M8X30 FLANGE
|
0-28080-830-0 |
01 |
1 |
9803-0004 |
|
● |
|
|
● |
|
| |
10 |
BOLT; GUIDE TUBE
EXC. ANTI NOISE EQUIPMENT ECE<SLK>
(B)
M8X30 FLANGE
|
0-28080-830-0 |
01 |
1 |
9803-0004 |
|
|
|
● |
|
|
| |
10 |
BOLT; GUIDE TUBE
EXC. ANTI NOISE EQUIPMENT ECE<SLK>
(B)
M8X30 FLANGE
|
0-28080-830-0 |
01 |
1 |
0005-0512 |
|
● |
|
● |
● |
|
| |
10 |
BOLT; GUIDE TUBE
EURO2 SPECIFICATION<THN>
(B)
M8X30 FLANGE
|
0-28080-830-0 |
01 |
1 |
0005-0512 |
|
|
|
|
|
● |
| |
10 |
BOLT; GUIDE TUBE
EXC. ANTI NOISE EQUIPMENT ECE<SLK>
(B)
M8X30 FLANGE
|
0-28050-830-0 |
01 |
1 |
0601- |
|
● |
|
● |
● |
|
| |
10 |
BOLT; GUIDE TUBE
EURO2 SPECIFICATION<THN>
(B)
M8X30 FLANGE
|
0-28050-830-0 |
01 |
1 |
0601- |
|
|
|
|
|
● |
| |
10 |
BOLT; GUIDE TUBE
EXC. ENGINE OIL TEMPERATURE GAUGE<UG3>
(B)
M8X20 FLANGE
|
0-28080-820-0 |
02 |
1 |
9710-0004 |
● |
|
|
|
|
|
| |
10 |
BOLT; GUIDE TUBE
(B)
M8X20 FLANGE
|
0-28080-820-0 |
02 |
1 |
9710-0004 |
|
|
● |
|
|
|
| |
10 |
BOLT; GUIDE TUBE
(B)
M8X20 FLANGE
|
0-28080-820-0 |
02 |
1 |
0005-0512 |
|
|
● |
|
|
|
| |
10 |
BOLT; GUIDE TUBE
(B)
M8X20 FLANGE
|
0-28050-820-0 |
02 |
1 |
0601- |
|
|
● |
|
|
|
| |
10 |
BOLT; GUIDE TUBE
(C)
M8X16 FLANGE
|
0-28080-816-0 |
01 |
1 |
9510-0004 |
● |
● |
● |
● |
● |
|
| |
10 |
BOLT; GUIDE TUBE
(C)
M8X16 FLANGE
|
0-28080-816-0 |
01 |
1 |
0005-0512 |
|
● |
● |
● |
● |
● |
| |
10 |
BOLT; GUIDE TUBE
(C)
M8X16 FLANGE
|
0-28050-816-0 |
01 |
1 |
0601- |
|
● |
● |
● |
● |
● |
| |
10 |
BOLT; GUIDE TUBE
(A)
M8X25 FLANGE
|
0-28680-825-0 |
02 |
1 |
9607-9612 |
● |
● |
● |
● |
● |
|
| |
10 |
BOLT; GUIDE TUBE
(A)
M8X20 FLANGE
|
0-28680-820-0 |
02 |
1 |
9701-0004 |
● |
● |
● |
● |
● |
|
| |
10 |
BOLT; GUIDE TUBE
(A)
M8X20 FLANGE
|
0-28680-820-0 |
02 |
1 |
0005-0512 |
|
● |
● |
● |
● |
● |
| |
10 |
BOLT; GUIDE TUBE
(A)
M8X20 FLANGE
|
0-28650-820-0 |
02 |
1 |
0601- |
|
● |
● |
● |
● |
● |
| |
10 |
BOLT; GUIDE TUBE
ANTI NOISE EQUIPMENT VAR2<TAK>
EXC. HEATER & DEFROSTER(C41)
(B)
M8X30 FLANGE
|
0-28080-830-0 |
02 |
1 |
9803-9805 |
|
|
|
● |
|
|
| |
10 |
BOLT; GUIDE TUBE
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
ANTI NOISE EQUIPMENT ECE<SLK>,ANTI NOISE
EQUIPMENT VAR2<TAK>
(B)
M8X30 FLANGE
|
0-28080-830-0 |
02 |
1 |
9806-0004 |
|
|
|
● |
|
|
| |
10 |
BOLT; GUIDE TUBE
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
ANTI NOISE EQUIPMENT ECE<SLK>
(B)
M8X30 FLANGE
|
0-28080-830-0 |
02 |
1 |
0005-0512 |
|
|
|
● |
|
|
| |
10 |
BOLT; GUIDE TUBE
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
(B)
M8X30 FLANGE
|
0-28080-830-0 |
02 |
1 |
0005-0512 |
|
|
|
|
|
● |
| |
10 |
BOLT; GUIDE TUBE
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
ANTI NOISE EQUIPMENT ECE<SLK>
(B)
M8X30 FLANGE
|
0-28050-830-0 |
02 |
1 |
0601- |
|
|
|
● |
|
|
| |
10 |
BOLT; GUIDE TUBE
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
(B)
M8X30 FLANGE
|
0-28050-830-0 |
02 |
1 |
0601- |
|
|
|
|
|
● |
| |
10 |
BOLT; GUIDE TUBE
EXC. EMISSION SYSTEM ECE REQUIREMENTS<SFV>,
EURO2 SPECIFICATION<THN>
(B)
M8X35 FLANGE
|
0-28680-835-0 |
01 |
1 |
0011-0512 |
|
|
|
|
|
● |
| |
10 |
BOLT; GUIDE TUBE
EXC. EMISSION SYSTEM ECE REQUIREMENTS<SFV>,
EURO2 SPECIFICATION<THN>
(B)
M8X35 FLANGE
|
0-28650-835-0 |
01 |
1 |
0601- |
|
|
|
|
|
● |
| |
12 |
BRACKET; TUBE,OIL LEVEL GAUGE
ENGINE OIL TEMPERATURE GAUGE<UG3>
|
8-94395-150-0 |
01 |
1 |
9510-9802 |
● |
|
|
|
|
|
| |
12 |
BRACKET; TUBE,OIL LEVEL GAUGE
|
8-94395-150-0 |
01 |
1 |
9510-9802 |
|
● |
|
● |
● |
|
| |
12 |
BRACKET; TUBE,OIL LEVEL GAUGE
ENGINE OIL TEMPERATURE GAUGE<UG3>
|
8-94395-150-0 |
01 |
1 |
9803-0004 |
● |
|
|
|
|
|
| |
12 |
BRACKET; TUBE,OIL LEVEL GAUGE
|
8-94395-150-0 |
01 |
1 |
9803-0004 |
|
● |
|
|
● |
|
| |
12 |
BRACKET; TUBE,OIL LEVEL GAUGE
EXC. ANTI NOISE EQUIPMENT ECE<SLK>
|
8-94395-150-0 |
01 |
1 |
9803-0004 |
|
|
|
● |
|
|
| |
12 |
BRACKET; TUBE,OIL LEVEL GAUGE
EXC. ANTI NOISE EQUIPMENT ECE<SLK>
|
8-94395-150-0 |
01 |
1 |
0005- |
|
● |
|
● |
● |
|
| |
12 |
BRACKET; TUBE,OIL LEVEL GAUGE
EURO2 SPECIFICATION<THN>
|
8-94395-150-0 |
01 |
1 |
0005- |
|
|
|
|
|
● |
| |
12 |
BRACKET; TUBE,OIL LEVEL GAUGE
EXC. ENGINE OIL TEMPERATURE GAUGE<UG3>
|
8-94395-843-0 |
01 |
1 |
9710-0004 |
● |
|
|
|
|
|
| |
12 |
BRACKET; TUBE,OIL LEVEL GAUGE
|
8-94395-843-0 |
01 |
1 |
9710-0004 |
|
|
● |
|
|
|
| |
12 |
BRACKET; TUBE,OIL LEVEL GAUGE
|
8-94395-843-0 |
01 |
1 |
0005- |
|
|
● |
|
|
|
| |
12 |
BRACKET; TUBE,OIL LEVEL GAUGE
ANTI NOISE EQUIPMENT VAR2<TAK>
EXC. HEATER & DEFROSTER(C41)
|
8-94394-903-0 |
01 |
1 |
9803-9805 |
|
|
|
● |
|
|
| |
12 |
BRACKET; TUBE,OIL LEVEL GAUGE
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
ANTI NOISE EQUIPMENT ECE<SLK>,ANTI NOISE
EQUIPMENT VAR2<TAK>
|
8-94394-903-0 |
01 |
1 |
9806-0004 |
|
|
|
● |
|
|
| |
12 |
BRACKET; TUBE,OIL LEVEL GAUGE
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
ANTI NOISE EQUIPMENT ECE<SLK>
|
8-94394-903-0 |
01 |
1 |
0005- |
|
|
|
● |
|
|
| |
12 |
BRACKET; TUBE,OIL LEVEL GAUGE
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
|
8-94394-903-0 |
01 |
1 |
0005- |
|
|
|
|
|
● |
| |
12 |
BRACKET; TUBE,OIL LEVEL GAUGE
EXC. EMISSION SYSTEM ECE REQUIREMENTS<SFV>,
EURO2 SPECIFICATION<THN>
|
8-94392-600-0 |
01 |
1 |
0011- |
|
|
|
|
|
● |
| |
23 |
BOLT; OIL PAN
ENGINE OIL TEMPERATURE GAUGE<UG3>
(A)
M8X18 FLANGE
|
0-28080-818-0 |
30 |
1 |
9510-9811 |
● |
|
|
|
|
|
| |
23 |
BOLT; OIL PAN
EXC. AIR CONDITIONER MANUAL CONTROL(C60)
(A)
M8X18 FLANGE
|
0-28080-818-0 |
30 |
1 |
9510-9811 |
|
|
|
● |
● |
|
| |
23 |
BOLT; OIL PAN
(A)
M8X18 FLANGE
|
0-28080-818-0 |
30 |
1 |
9510-9811 |
|
● |
|
|
|
|
| |
23 |
BOLT; OIL PAN
(A)
M8X18 FLANGE
|
0-28080-818-0 |
30 |
1 |
9812-0004 |
● |
● |
● |
● |
● |
|
| |
23 |
BOLT; OIL PAN
(A)
M8X18 FLANGE
|
0-28080-818-0 |
30 |
1 |
0005-0205 |
|
● |
● |
● |
● |
● |
| |
23 |
BOLT; OIL PAN
EXC. AIR CONDITIONER MANUAL CONTROL(C60)
(A)
M8X18 FLANGE
|
0-28080-818-0 |
30 |
1 |
0206-0210 |
|
● |
|
● |
● |
|
| |
23 |
BOLT; OIL PAN
(A)
M8X18 FLANGE
|
0-28080-818-0 |
30 |
1 |
0206-0210 |
|
|
● |
|
|
|
| |
23 |
BOLT; OIL PAN
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
HEATER & DEFROSTER(C41)
(A)
M8X18 FLANGE
|
0-28080-818-0 |
30 |
1 |
0206-0210 |
|
|
|
|
|
● |
| |
23 |
BOLT; OIL PAN
EURO2 SPECIFICATION<THN>
(A)
M8X18 FLANGE
|
0-28080-818-0 |
30 |
1 |
0206-0210 |
|
|
|
|
|
● |
| |
23 |
BOLT; OIL PAN
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
ANTI NOISE EQUIPMENT ECE<SLK>
(A)
M8X18 FLANGE
|
0-28080-818-0 |
30 |
1 |
0211-0305 |
|
|
|
● |
|
|
| |
23 |
BOLT; OIL PAN
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
(A)
M8X18 FLANGE
|
0-28080-818-0 |
30 |
1 |
0211-0305 |
|
|
|
|
|
● |
| |
23 |
BOLT; OIL PAN
EXC. AIR CONDITIONER MANUAL CONTROL(C60)
(A)
M8X18 FLANGE
|
0-28080-818-0 |
30 |
1 |
0306- |
|
● |
|
● |
● |
|
| |
23 |
BOLT; OIL PAN
(A)
M8X18 FLANGE
|
0-28080-818-0 |
30 |
1 |
0306- |
|
|
● |
|
|
|
| |
23 |
BOLT; OIL PAN
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
HEATER & DEFROSTER(C41)
(A)
M8X18 FLANGE
|
0-28080-818-0 |
30 |
1 |
0306- |
|
|
|
|
|
● |
| |
23 |
BOLT; OIL PAN
EURO2 SPECIFICATION<THN>
(A)
M8X18 FLANGE
|
0-28080-818-0 |
30 |
1 |
0306- |
|
|
|
|
|
● |
| |
23 |
BOLT; OIL PAN
EXC. ENGINE OIL TEMPERATURE GAUGE<UG3>
(A)
M8X18 FLANGE
|
0-28080-818-0 |
28 |
1 |
9710-9811 |
● |
|
|
|
|
|
| |
23 |
BOLT; OIL PAN
AIR CONDITIONER MANUAL CONTROL(C60)
(A)
M8X18 FLANGE
|
0-28080-818-0 |
28 |
1 |
9710-9811 |
|
|
|
|
● |
|
| |
23 |
BOLT; OIL PAN
(A)
M8X18 FLANGE
|
0-28080-818-0 |
28 |
1 |
9710-9811 |
|
|
● |
|
|
|
| |
23 |
BOLT; OIL PAN
AIR CONDITIONER MANUAL CONTROL(C60)
(A)
M8X18 FLANGE
|
0-28080-818-0 |
28 |
1 |
9812-9901 |
|
|
|
|
● |
|
| |
23 |
BOLT; OIL PAN
AIR CONDITIONER MANUAL CONTROL(C60)
(A)
M8X18 FLANGE
|
0-28080-818-0 |
28 |
1 |
9902-0004 |
● |
|
|
|
● |
|
| |
23 |
BOLT; OIL PAN
AIR CONDITIONER MANUAL CONTROL(C60)
(A)
M8X18 FLANGE
|
0-28080-818-0 |
28 |
1 |
0005-0010 |
|
|
|
|
● |
● |
| |
23 |
BOLT; OIL PAN
AIR CONDITIONER MANUAL CONTROL(C60)
(A)
M8X18 FLANGE
|
0-28080-818-0 |
28 |
1 |
0011-0210 |
|
|
|
|
● |
● |
| |
23 |
BOLT; OIL PAN
EXC. EMISSION SYSTEM ECE REQUIREMENTS<SFV>,
EURO2 SPECIFICATION<THN>
(A)
M8X18 FLANGE
|
0-28080-818-0 |
28 |
1 |
0011-0210 |
|
|
|
|
|
● |
| |
23 |
BOLT; OIL PAN
AIR CONDITIONER MANUAL CONTROL(C60)
(A)
M8X18 FLANGE
|
0-28080-818-0 |
28 |
1 |
0211- |
|
|
|
● |
● |
● |
| |
23 |
BOLT; OIL PAN
EXC. EMISSION SYSTEM ECE REQUIREMENTS<SFV>,
EURO2 SPECIFICATION<THN>
(A)
M8X18 FLANGE
|
0-28080-818-0 |
28 |
1 |
0211- |
|
|
|
|
|
● |
| |
23 |
BOLT; OIL PAN
EXC. ENGINE OIL TEMPERATURE GAUGE<UG3>
(B)
M8X28 FLANGE
|
0-28080-828-0 |
02 |
1 |
9710-9811 |
● |
|
|
|
|
|
| |
23 |
BOLT; OIL PAN
AIR CONDITIONER MANUAL CONTROL(C60)
(B)
M8X28 FLANGE
|
0-28080-828-0 |
02 |
1 |
9710-9811 |
|
|
|
|
● |
|
| |
23 |
BOLT; OIL PAN
(B)
M8X28 FLANGE
|
0-28080-828-0 |
02 |
1 |
9710-9811 |
|
|
● |
|
|
|
| |
23 |
BOLT; OIL PAN
AIR CONDITIONER MANUAL CONTROL(C60)
(B)
M8X28 FLANGE
|
0-28080-828-0 |
02 |
1 |
9812-9901 |
|
|
|
|
● |
|
| |
23 |
BOLT; OIL PAN
AIR CONDITIONER MANUAL CONTROL(C60)
(B)
M8X28 FLANGE
|
0-28080-828-0 |
02 |
1 |
9902-0004 |
● |
|
|
|
● |
|
| |
23 |
BOLT; OIL PAN
AIR CONDITIONER MANUAL CONTROL(C60)
(B)
M8X28 FLANGE
|
0-28080-828-0 |
02 |
1 |
0005-0010 |
|
|
|
|
● |
● |
| |
23 |
BOLT; OIL PAN
AIR CONDITIONER MANUAL CONTROL(C60)
(B)
M8X28 FLANGE
|
0-28080-828-0 |
02 |
1 |
0011-0210 |
|
|
|
|
● |
● |
| |
23 |
BOLT; OIL PAN
EXC. EMISSION SYSTEM ECE REQUIREMENTS<SFV>,
EURO2 SPECIFICATION<THN>
(B)
M8X28 FLANGE
|
0-28080-828-0 |
02 |
1 |
0011-0210 |
|
|
|
|
|
● |
| |
23 |
BOLT; OIL PAN
AIR CONDITIONER MANUAL CONTROL(C60)
(B)
M8X28 FLANGE
|
0-28080-828-0 |
02 |
1 |
0211- |
|
|
|
● |
● |
● |
| |
23 |
BOLT; OIL PAN
EXC. EMISSION SYSTEM ECE REQUIREMENTS<SFV>,
EURO2 SPECIFICATION<THN>
(B)
M8X28 FLANGE
|
0-28080-828-0 |
02 |
1 |
0211- |
|
|
|
|
|
● |
| |
23 |
BOLT; OIL PAN
AIR CONDITIONER MANUAL CONTROL(C60)
(A)
M8X18 FLANGE
|
0-28080-818-0 |
28 |
1 |
9510-9709 |
|
|
|
|
● |
|
| |
23 |
BOLT; OIL PAN
AIR CONDITIONER MANUAL CONTROL(C60)
(B)
M8X28 FLANGE
|
0-28080-828-0 |
02 |
1 |
9510-9709 |
|
|
|
|
● |
|
| |
24 |
NUT; OIL PAN
M8 FLANGE
|
0-91150-108-0 |
04 |
1 |
9510-0004 |
● |
● |
● |
● |
● |
|
| |
24 |
NUT; OIL PAN
M8 FLANGE
|
0-91150-108-0 |
04 |
1 |
0005-0602 |
|
● |
● |
● |
● |
● |
| |
24 |
NUT; OIL PAN
M8 FLANGE
|
0-91180-108-0 |
04 |
1 |
0603- |
|
● |
● |
● |
● |
● |
| |
47 |
CLIP; HOSE,AIR BREATHER
|
1-11369-115-0 |
01 |
1 |
9706-0004 |
● |
● |
● |
● |
● |
|
| |
47 |
CLIP; HOSE,AIR BREATHER
|
1-11369-115-0 |
01 |
1 |
0005-1506 |
|
● |
● |
● |
● |
● |
| |
47 |
CLIP; HOSE,AIR BREATHER
|
8-98303-447-0 |
01 |
1 |
1507- |
|
● |
● |
● |
● |
● |
| |
47 |
CLIP; HOSE,AIR BREATHER
|
1-11369-115-0 |
01 |
1 |
9510-9705 |
● |
● |
● |
● |
● |
|
| |
49 |
NUT; GUIDE TUBE
M8
|
9-09110-408-0 |
02 |
1 |
9510-9606 |
● |
● |
● |
● |
● |
|
| |
49 |
NUT; GUIDE TUBE
M8 FLANGE
|
0-91150-108-0 |
02 |
1 |
9607-0004 |
● |
● |
● |
● |
● |
|
| |
49 |
NUT; GUIDE TUBE
M8 FLANGE
|
0-91150-108-0 |
02 |
1 |
0005-0602 |
|
● |
● |
● |
● |
● |
| |
49 |
NUT; GUIDE TUBE
M8 FLANGE
|
0-91180-108-0 |
02 |
1 |
0603- |
|
● |
● |
● |
● |
● |
| |
59 |
CLIP; HARNESS
ENGINE OIL TEMPERATURE GAUGE<UG3>
L=180
|
1-09707-162-1 |
01 |
1 |
9510-0004 |
● |
|
|
● |
|
|
| |
115 |
NUT; OIL PAN COVER
ANTI NOISE EQUIPMENT ECE<SLK>,ANTI NOISE
EQUIPMENT VAR2<TAK>
M8 FLANGE
|
0-91150-108-0 |
04 |
1 |
9510-0004 |
|
|
|
● |
● |
|
| |
115 |
NUT; OIL PAN COVER
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
ANTI NOISE EQUIPMENT ECE<SLK>
M8 FLANGE
|
0-91150-108-0 |
04 |
1 |
0005-0602 |
|
|
|
● |
|
|
| |
115 |
NUT; OIL PAN COVER
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
M8 FLANGE
|
0-91150-108-0 |
04 |
1 |
0005-0602 |
|
|
|
|
|
● |
| |
115 |
NUT; OIL PAN COVER
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
ANTI NOISE EQUIPMENT ECE<SLK>
M8 FLANGE
|
0-91180-108-0 |
04 |
1 |
0603- |
|
|
|
● |
|
|
| |
115 |
NUT; OIL PAN COVER
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
M8 FLANGE
|
0-91180-108-0 |
04 |
1 |
0603- |
|
|
|
|
|
● |
| |
118 |
GASKET; PLUG,OIL HTR
ENGINE OIL TEMPERATURE GAUGE<UG3>
ID=16.2 OD=24
|
9-09571-416-0 |
01 |
1 |
9510-0004 |
● |
|
|
● |
|
|
| |
119 |
PLUG; OIL HTR BLIND
ENGINE OIL TEMPERATURE GAUGE<UG3>
(A)
|
5-09600-009-0 |
01 |
1 |
9510-0004 |
● |
|
|
● |
|
|
| |
119 |
PLUG; OIL HTR BLIND
ENGINE OIL TEMPERATURE GAUGE<UG3>
(B)
|
5-09600-010-0 |
01 |
1 |
9510-0004 |
● |
|
|
● |
|
|
| |
120 |
GASKET; PLUG,OIL HTR BLIND
ALSO INCLUDED IN GASKET SET(ENGINE).
ENGINE OIL TEMPERATURE GAUGE<UG3>
ID=36.5 OD=44
|
9-09571-436-0 |
01 |
1 |
9510-0004 |
● |
|
|
● |
|
|
| |
121 |
COVER; OIL PAN
ANTI NOISE EQUIPMENT ECE<SLK>,ANTI NOISE
EQUIPMENT VAR2<TAK>
EXC. ENGINE OIL TEMPERATURE GAUGE<UG3>
|
8-94395-613-2 |
01 |
1 |
9510-0004 |
|
|
|
● |
● |
|
| |
121 |
COVER; OIL PAN
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
ANTI NOISE EQUIPMENT ECE<SLK>
|
8-94395-613-2 |
01 |
1 |
0005- |
|
|
|
● |
|
|
| |
121 |
COVER; OIL PAN
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
|
8-94395-613-2 |
01 |
1 |
0005- |
|
|
|
|
|
● |
| |
121 |
COVER; OIL PAN
ENGINE OIL TEMPERATURE GAUGE<UG3>
|
8-94395-689-1 |
01 |
1 |
9511-0004 |
|
|
|
● |
|
|
| |
122 |
BRACKET; OIL PAN COVER
ANTI NOISE EQUIPMENT ECE<SLK>,ANTI NOISE
EQUIPMENT VAR2<TAK>
|
8-94396-827-0 |
04 |
1 |
9510-0004 |
|
|
|
● |
● |
|
| |
122 |
BRACKET; OIL PAN COVER
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
ANTI NOISE EQUIPMENT ECE<SLK>
|
8-94396-827-0 |
04 |
1 |
0005- |
|
|
|
● |
|
|
| |
122 |
BRACKET; OIL PAN COVER
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
|
8-94396-827-0 |
04 |
1 |
0005- |
|
|
|
|
|
● |
| |
128 |
RUBBER; MTG,OIL PAN
ANTI NOISE EQUIPMENT ECE<SLK>,ANTI NOISE
EQUIPMENT VAR2<TAK>
|
1-09337-024-0 |
08 |
1 |
9510-0004 |
|
|
|
● |
● |
|
| |
128 |
RUBBER; MTG,OIL PAN
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
ANTI NOISE EQUIPMENT ECE<SLK>
|
1-09337-024-0 |
08 |
1 |
0005- |
|
|
|
● |
|
|
| |
128 |
RUBBER; MTG,OIL PAN
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
|
1-09337-024-0 |
08 |
1 |
0005- |
|
|
|
|
|
● |
| |
132 |
WASHER; PL,OIL PAN COVER
ANTI NOISE EQUIPMENT ECE<SLK>,ANTI NOISE
EQUIPMENT VAR2<TAK>
ID=8.4 OD=22
|
9-09160-708-0 |
04 |
1 |
9510-0004 |
|
|
|
● |
● |
|
| |
132 |
WASHER; PL,OIL PAN COVER
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
ANTI NOISE EQUIPMENT ECE<SLK>
ID=8.4 OD=22
|
9-09160-708-0 |
04 |
1 |
0005-0605 |
|
|
|
● |
|
|
| |
132 |
WASHER; PL,OIL PAN COVER
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
ID=8.4 OD=22
|
9-09160-708-0 |
04 |
1 |
0005-0605 |
|
|
|
|
|
● |
| |
132 |
WASHER; PL,OIL PAN COVER
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
ANTI NOISE EQUIPMENT ECE<SLK>
ID=8.4 OD=22
|
0-91610-708-0 |
04 |
1 |
0606- |
|
|
|
● |
|
|
| |
132 |
WASHER; PL,OIL PAN COVER
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
ID=8.4 OD=22
|
0-91610-708-0 |
04 |
1 |
0606- |
|
|
|
|
|
● |
| |
141 |
BOLT; BRKT TO OIL PAN FIX
ENGINE OIL TEMPERATURE GAUGE<UG3>
M8X14 FLANGE
|
0-28080-814-0 |
04 |
1 |
9510-0004 |
● |
|
|
● |
|
|
| |
144 |
INSULATOR; OIL PAN
ANTI NOISE EQUIPMENT ECE<SLK>,ANTI NOISE
EQUIPMENT VAR2<TAK>
EXC. ENGINE OIL TEMPERATURE GAUGE<UG3>
(A)
|
8-94395-875-0 |
01 |
1 |
9510-0004 |
|
|
|
● |
● |
|
| |
144 |
INSULATOR; OIL PAN
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
ANTI NOISE EQUIPMENT ECE<SLK>
(A)
|
8-94395-875-0 |
01 |
1 |
0005- |
|
|
|
● |
|
|
| |
144 |
INSULATOR; OIL PAN
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
(A)
|
8-94395-875-0 |
01 |
1 |
0005- |
|
|
|
|
|
● |
| |
144 |
INSULATOR; OIL PAN
ANTI NOISE EQUIPMENT ECE<SLK>,ANTI NOISE
EQUIPMENT VAR2<TAK>
EXC. ENGINE OIL TEMPERATURE GAUGE<UG3>
(B)
|
8-94395-876-0 |
01 |
1 |
9510-0004 |
|
|
|
● |
● |
|
| |
144 |
INSULATOR; OIL PAN
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
ANTI NOISE EQUIPMENT ECE<SLK>
(B)
|
8-94395-876-0 |
01 |
1 |
0005- |
|
|
|
● |
|
|
| |
144 |
INSULATOR; OIL PAN
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
(B)
|
8-94395-876-0 |
01 |
1 |
0005- |
|
|
|
|
|
● |
| |
144 |
INSULATOR; OIL PAN
ANTI NOISE EQUIPMENT ECE<SLK>,ANTI NOISE
EQUIPMENT VAR2<TAK>
(C)
|
8-94395-874-0 |
01 |
1 |
9510-0004 |
|
|
|
● |
● |
|
| |
144 |
INSULATOR; OIL PAN
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
ANTI NOISE EQUIPMENT ECE<SLK>
(C)
|
8-94395-874-0 |
01 |
1 |
0005- |
|
|
|
● |
|
|
| |
144 |
INSULATOR; OIL PAN
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
(C)
|
8-94395-874-0 |
01 |
1 |
0005- |
|
|
|
|
|
● |
| |
144 |
INSULATOR; OIL PAN
ENGINE OIL TEMPERATURE GAUGE<UG3>
(D)
|
8-94395-877-0 |
01 |
1 |
9511-0004 |
|
|
|
● |
|
|
| |
144 |
INSULATOR; OIL PAN
ENGINE OIL TEMPERATURE GAUGE<UG3>
(E)
|
8-94395-878-0 |
01 |
1 |
9511-0004 |
|
|
|
● |
|
|
| |
153 |
THERMOMETER UNIT; OIL
ENGINE OIL TEMPERATURE GAUGE<UG3>
|
1-83161-035-0 |
01 |
1 |
9510-0004 |
● |
|
|
● |
|
|
| |
158 |
PLATE
ENGINE OIL TEMPERATURE GAUGE<UG3>
|
8-94395-311-0 |
01 |
1 |
9510-0004 |
● |
|
|
● |
|
|
| |
160 |
ADAPTER
ENGINE OIL TEMPERATURE GAUGE<UG3>
|
8-94395-312-0 |
01 |
1 |
9510-0004 |
● |
|
|
● |
|
|
| |
161 |
GASKET; ADAPTER
ALSO INCLUDED IN GASKET SET(ENGINE).
ENGINE OIL TEMPERATURE GAUGE<UG3>
|
8-94395-313-0 |
01 |
1 |
9510-0004 |
● |
|
|
● |
|
|
| |
192 |
HOSE; GUIDE TUBE
L=300
|
1-09360-945-1 |
01 |
1 |
9510-0004 |
● |
● |
● |
● |
● |
|
| |
192 |
HOSE; GUIDE TUBE
L=300
|
1-09360-945-1 |
01 |
1 |
0005-0305 |
|
● |
● |
● |
● |
● |
| |
192 |
HOSE; GUIDE TUBE
L=300
|
1-09360-978-0 |
01 |
1 |
0306- |
|
● |
● |
● |
● |
● |
| |
193 |
CLIP; HOSE,GUIDE TUBE
ID=17
|
1-09707-158-0 |
02 |
1 |
9510-0004 |
● |
● |
● |
● |
● |
|
| |
193 |
CLIP; HOSE,GUIDE TUBE
ID=17
|
1-09707-158-0 |
02 |
1 |
0005- |
|
● |
● |
● |
● |
● |
