Isuzu WW
▶
TRUCKS
▶
FSS
▶
11124 - FSS(RHD)EURO2/4
▶
0 - Engine, Emission, Engine Electrical
▶
0-42 - FUEL PUMP AND PIPE
▶
0-42 — FUEL PUMP AND PIPE
(#37708) — 17 parça
221
150
150
150
221
258
159
91
148
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
91
BRACKET; FUEL PIPE TO INL MANIF
FSS STD CAB(FC****)
8-98033-979-0
01
1
0712-0811
91
BRACKET; FUEL PIPE TO INL MANIF
8-98033-979-0
01
1
0812-
148
BOLT; BRKT
FSS STD CAB(FC****) M6X12 FLANGE
0-28050-612-0
01
1
0712-0811
148
BOLT; BRKT
M6X12 FLANGE
0-28050-612-0
01
1
0812-
150
GASKET; FUEL PIPE
ALSO INCLUDED IN GASKET SET(ENG. & HEAD) FSS STD CAB(FC****) (A) ID=10.2 OD=15.2
1-09630-083-0
02
1
0712-0811
150
GASKET; FUEL PIPE
ALSO INCLUDED IN GASKET SET(ENG. & HEAD) (A) ID=10.2 OD=15.2
1-09630-083-0
02
1
0812-
150
GASKET; FUEL PIPE
ALSO INCLUDED IN GASKET SET(ENG. & HEAD) FSS STD CAB(FC****) (B) ID=10.6
8-97240-975-0
01
1
0712-0811
150
GASKET; FUEL PIPE
ALSO INCLUDED IN GASKET SET(ENG. & HEAD) (B) ID=10.6
8-97240-975-0
01
1
0812-0908
150
GASKET; FUEL PIPE
ALSO INCLUDED IN GASKET SET(ENG. & HEAD) (B) ID=10.2 OD=17
8-98079-755-0
01
1
0909-
159
BOLT; CLIP
FSS STD CAB(FC****) M6X12 FLANGE
0-28050-612-0
01
1
0712-0811
159
BOLT; CLIP
M6X12 FLANGE
0-28050-612-0
01
1
0812-
159
BOLT; CLIP
FSS STD CAB(FC****) M6X16 FLANGE
0-28050-616-0
01
1
0712-0811
159
BOLT; CLIP
M6X16 FLANGE
0-28050-616-0
01
1
0812-
221
BOLT; FUEL PIPE
FSS STD CAB(FC****) M10X21 FLANGE
8-94396-711-0
02
1
0712-0811
221
BOLT; FUEL PIPE
M10X21 FLANGE
8-94396-711-0
02
1
0812-
258
PIPE ASM; FUEL,LEAK OFF
FSS STD CAB(FC****)
8-98055-815-1
01
1
0712-0811
258
PIPE ASM; FUEL,LEAK OFF
8-98055-815-1
01
1
0812-
