24 |
CLIP; FUEL HOSE
MIDDLE CHASSIS(FV***F)
WHEEL BASE 4600MM(46W)
FUEL TANK 200L+200L<NF7>
(A)
ID=17.1
|
8-94122-679-0 |
02 |
1 |
9701-9803 |
|
● |
|
|
|
|
| |
24 |
CLIP; FUEL HOSE
FUEL TANK 200L+200L<NF7>
(A)
ID=17.1
|
8-94122-679-0 |
02 |
1 |
9804-0004 |
|
● |
|
|
|
|
| |
24 |
CLIP; FUEL HOSE
MIDDLE CHASSIS(FV***F)
WHEEL BASE 4600MM(46W)
FUEL TANK 200L+200L<NF7>
(B)
ID=19 H=25 L=25
|
9-09917-035-0 |
02 |
1 |
9701-9803 |
|
● |
|
|
|
|
| |
24 |
CLIP; FUEL HOSE
FUEL TANK 200L+200L<NF7>
(B)
ID=19 H=25 L=25
|
9-09917-035-0 |
02 |
1 |
9804-0004 |
|
● |
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
(A)
L=760
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9601-9609 |
● |
|
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
(A)
L=760
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9601-9609 |
|
● |
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
BRAKE SYSTEM AIR OVER HYDRAULIC DUAL
CIRCUIT(Z05)
(A)
L=760
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9610-9810 |
● |
● |
● |
● |
● |
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
(A)
L=760
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9811-0004 |
● |
● |
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
TAIWAN EQUIPMENT(WW5)
(A)
L=1050
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9811-0004 |
● |
|
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
FUEL TANK 400L<SDH>
COLOMBIA EQUIPMENT(WJ2)
(A)
L=820
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0005-0006 |
● |
|
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
FUEL TANK 200L FRAME SIDE<N20>
(A)
L=820
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0007-0209 |
● |
● |
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
FUEL TANK 400L<SDH>
COLOMBIA EQUIPMENT(WJ2)
(A)
L=820
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0007-0209 |
● |
|
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
FUEL TANK 200L FRAME SIDE<N20>
TAIL PIPE SINGLE HORIZONTAL TURN LEFT<SBR>
(A)
L=820
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0210-0607 |
● |
● |
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
FUEL TANK 400L<SDH>
COLOMBIA EQUIPMENT(WJ2)
(A)
L=820
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0210-0607 |
● |
|
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
FUEL TANK 200L FRAME SIDE<N20>
TAIL PIPE SINGLE HORIZONTAL TURN LEFT<SBR>
(A)
L=820
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0608-0612 |
● |
● |
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
FUEL TANK 400L<SDH>
COLOMBIA EQUIPMENT(WJ2)
(A)
L=820
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0608-0612 |
● |
|
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
FUEL TANK 200L FRAME SIDE<N20>
TAIL PIPE SINGLE HORIZONTAL TURN LEFT<SBR>
(A)
L=820
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0608-0612 |
|
|
|
|
|
● |
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
FUEL TANK 200L FRAME SIDE<N20>
TAIL PIPE SINGLE HORIZONTAL TURN LEFT<SBR>
(A)
L=820
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0701- |
● |
● |
|
|
|
● |
| |
32 |
PIPE; DELIVERY,FUEL TANK
SHORT CHASSIS(FV***C)
TAIL PIPE SINGLE HORIZONTAL TURN LEFT<SBR>
(A)
L=820
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0701- |
● |
● |
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
FUEL TANK 400L<SDH>
COLOMBIA EQUIPMENT(WJ2)
(A)
L=820
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0701- |
● |
|
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
FUEL TANK 200L FRAME SIDE<N20>
TAIL PIPE SINGLE HORIZONTAL TURN LEFT<SBR>
(B)
L=1650
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0011-0209 |
● |
● |
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
FUEL TANK 200L FRAME SIDE<N20>
TAIL PIPE SINGLE HORIZONTAL TURN LEFT<SBR>
(B)
L=1850
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0210-0607 |
● |
● |
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
FUEL TANK 200L FRAME SIDE<N20>
TAIL PIPE SINGLE HORIZONTAL TURN LEFT<SBR>
(B)
L=1850
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0608-0612 |
● |
● |
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
FUEL TANK 200L FRAME SIDE<N20>
TAIL PIPE SINGLE HORIZONTAL TURN LEFT<SBR>
(B)
L=1850
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0608-0612 |
|
|
|
|
|
● |
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
FUEL TANK 200L FRAME SIDE<N20>
TAIL PIPE SINGLE HORIZONTAL TURN LEFT<SBR>
(B)
L=1850
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0701- |
● |
● |
|
|
|
● |
| |
32 |
PIPE; DELIVERY,FUEL TANK
SHORT CHASSIS(FV***C)
TAIL PIPE SINGLE HORIZONTAL TURN LEFT<SBR>
(B)
L=1850
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0701- |
● |
● |
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
FUEL TANK 200L FRAME SIDE<N20>
EXC. TAIL PIPE SINGLE HORIZONTAL TURN
LEFT<SBR>
(B)
L=1600
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0210-0612 |
● |
● |
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
SHORT CHASSIS(FV***C)
EXC. TAIL PIPE SINGLE HORIZONTAL TURN
LEFT<SBR>
(B)
L=1600
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0701- |
● |
● |
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
FUEL TANK 200L FRAME SIDE<N20>
EXC. TAIL PIPE SINGLE HORIZONTAL TURN
LEFT<SBR>
(B)
L=1600
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0701- |
● |
● |
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
(B)
L=1350
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9601-9806 |
● |
● |
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
(B)
L=1350
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9807-9810 |
● |
● |
|
|
● |
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
EXC. TAIWAN EQUIPMENT(WW5)
(B)
L=1350
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9811-0004 |
● |
● |
|
|
● |
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
SHORT CHASSIS(FV***C)
(A)
L=1300
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9601-9705 |
|
● |
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
SHORT CHASSIS(FV***C)
(A)
L=1300
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9706-9806 |
● |
● |
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
SHORT CHASSIS(FV***C)
(A)
L=1300
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9807-9810 |
● |
● |
|
|
● |
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
TAIWAN EQUIPMENT(WW5)
(B)
L=1300
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9811-0004 |
● |
● |
● |
● |
● |
● |
| |
32 |
PIPE; DELIVERY,FUEL TANK
SHORT CHASSIS(FV***C)
(B)
L=1300
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9811-0004 |
● |
● |
|
|
● |
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
FUEL TANK 200L FRAME SIDE<N20>
(A)
L=1300
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0005-0006 |
● |
● |
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
FUEL TANK 200L FRAME SIDE<N20>
(B)
L=1350
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0007-0010 |
● |
● |
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
FUEL TANK 200L FRAME SIDE<N20>
EXC. TAIL PIPE SINGLE HORIZONTAL TURN
LEFT<SBR>
(B)
L=1350
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0011-0209 |
● |
● |
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
FUEL TANK 200L FRAME SIDE<N20>
EXC. TAIL PIPE SINGLE HORIZONTAL TURN
LEFT<SBR>
(A)
L=600
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0210-0612 |
● |
● |
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
SHORT CHASSIS(FV***C)
EXC. TAIL PIPE SINGLE HORIZONTAL TURN
LEFT<SBR>
(A)
L=600
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0701- |
● |
● |
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
FUEL TANK 200L FRAME SIDE<N20>
EXC. TAIL PIPE SINGLE HORIZONTAL TURN
LEFT<SBR>
(A)
L=600
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0701- |
● |
● |
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
SHORT CHASSIS(FV***C)
(B)
L=2000
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9601-9705 |
|
● |
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
SHORT CHASSIS(FV***C)
(B)
L=2000
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9706-9806 |
● |
● |
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
SHORT CHASSIS(FV***C)
(B)
L=2000
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9807-0004 |
● |
● |
|
|
● |
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
FUEL TANK 200L FRAME SIDE<N20>
(B)
L=2000
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0005-0006 |
● |
● |
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
SHORT CHASSIS(FV***C)
(B)
L=3600
SERVICED BY L=8000
|
0-01260-800-0 |
01 |
1 |
9601-9701 |
|
|
● |
● |
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
WHEEL BASE 4200MM(42W)
(B)
L=3600
SERVICED BY L=8000
|
0-01260-800-0 |
01 |
1 |
9601-9701 |
|
|
● |
● |
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
WHEEL BASE 4200MM(42W)
(B)
L=3600
SERVICED BY L=8000
|
0-01260-800-0 |
01 |
1 |
9702-0004 |
|
|
● |
● |
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
SHORT CHASSIS(FV***C)
(A)
L=1100
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9601-9701 |
|
|
● |
● |
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
SHORT CHASSIS(FV***C)
(A)
L=460
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9702-9709 |
|
|
● |
● |
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
SHORT CHASSIS(FV***C)
(A)
L=460
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9710-9803 |
|
|
● |
● |
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5500MM(55W)
EURO2 SPECIFICATION<THN>
(A)
L=460
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9710-9803 |
|
|
● |
● |
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
SHORT CHASSIS(FV***C)
(A)
L=460
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9804-0004 |
|
|
● |
● |
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
CHILE EQUIPMENT(TDK),COLOMBIA EQUIPMENT(WJ2)
(A)
L=460
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9804-0004 |
|
|
● |
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
FUEL TANK 200L FRAME SIDE<N20>
(A)
L=460
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0005-0607 |
|
|
● |
● |
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
FUEL TANK 200L FRAME SIDE<N20>
(A)
L=460
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0608-0612 |
|
|
● |
● |
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
SHORT CHASSIS(FV***C)
(A)
L=460
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0701- |
|
|
● |
● |
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
FUEL TANK 200L FRAME SIDE<N20>
(A)
L=460
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0701- |
|
|
● |
● |
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
SHORT CHASSIS(FV***C)
(B)
L=4500
SERVICED BY L=8000
|
0-01260-800-0 |
01 |
1 |
9702-0004 |
|
|
● |
● |
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
FUEL TANK 200L FRAME SIDE<N20>
(B)
L=3800
SERVICED BY L=8000
|
0-01260-800-0 |
01 |
1 |
0005-0607 |
|
|
● |
● |
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
FUEL TANK 200L FRAME SIDE<N20>
(B)
L=3800
SERVICED BY L=8000
|
0-01260-800-0 |
01 |
1 |
0608-0612 |
|
|
● |
● |
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
SHORT CHASSIS(FV***C)
(B)
L=3800
SERVICED BY L=8000
|
0-01260-800-0 |
01 |
1 |
0701- |
|
|
● |
● |
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
FUEL TANK 200L FRAME SIDE<N20>
(B)
L=3800
SERVICED BY L=8000
|
0-01260-800-0 |
01 |
1 |
0701- |
|
|
● |
● |
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
WHEEL BASE 4200MM(42W),WHEEL BASE 4600MM(46W),
WHEEL BASE 5000MM(50W)
(A)
L=600
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9601-9803 |
|
|
● |
● |
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
WHEEL BASE 4200MM(42W),WHEEL BASE 4600MM(46W),
WHEEL BASE 5000MM(50W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
EXC. CHILE EQUIPMENT(TDK),COLOMBIA
EQUIPMENT(WJ2)
(A)
L=600
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9804-9901 |
|
|
● |
● |
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
WHEEL BASE 4200MM(42W),WHEEL BASE 4600MM(46W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
EXC. CHILE EQUIPMENT(TDK),COLOMBIA
EQUIPMENT(WJ2)
(A)
L=600
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9902-0004 |
|
|
● |
● |
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
FUEL TANK 400L<SDH>
COLOMBIA EQUIPMENT(WJ2)
(B)
L=1900
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0005- |
● |
|
|
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
WHEEL BASE 4600MM(46W)
(B)
L=3750
SERVICED BY L=8000
|
0-01260-800-0 |
01 |
1 |
9601-0004 |
|
|
● |
● |
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5000MM(50W)
(B)
L=5050
SERVICED BY L=8000
|
0-01260-800-0 |
01 |
1 |
9601-9709 |
|
|
● |
● |
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5000MM(50W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
(B)
L=5050
SERVICED BY L=8000
|
0-01260-800-0 |
01 |
1 |
9710-9803 |
|
|
● |
● |
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5500MM(55W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
EURO2 SPECIFICATION<THN>
(B)
L=5050
SERVICED BY L=8000
|
0-01260-800-0 |
01 |
1 |
9710-9803 |
|
|
● |
● |
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5000MM(50W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
(B)
L=5050
SERVICED BY L=8000
|
0-01260-800-0 |
01 |
1 |
9804-0004 |
|
|
● |
● |
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5500MM(55W)
(A)
L=700
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9601-9803 |
|
|
● |
● |
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5000MM(50W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
CHILE EQUIPMENT(TDK),COLOMBIA EQUIPMENT(WJ2)
(B)
L=5900
SERVICED BY L=8000
|
0-01260-800-0 |
01 |
1 |
9804-0004 |
|
|
● |
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5500MM(55W)
(B)
L=3850
SERVICED BY L=8000
|
0-01260-800-0 |
01 |
1 |
9601-9709 |
|
|
● |
● |
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5500MM(55W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
EXC. EURO2 SPECIFICATION<THN>
(B)
L=3850
SERVICED BY L=8000
|
0-01260-800-0 |
01 |
1 |
9710-9803 |
|
|
● |
● |
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5500MM(55W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
EXC. CHILE EQUIPMENT(TDK),COLOMBIA
EQUIPMENT(WJ2)
(B)
L=3850
SERVICED BY L=8000
|
0-01260-800-0 |
01 |
1 |
9804-0004 |
|
|
● |
● |
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5500MM(55W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
EXC. CHILE EQUIPMENT(TDK),COLOMBIA
EQUIPMENT(WJ2)
(A)
L=700
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9805-9901 |
|
|
● |
● |
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
EXC. CHILE EQUIPMENT(TDK),COLOMBIA
EQUIPMENT(WJ2)
(A)
L=700
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9902-0004 |
|
|
● |
● |
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
FUEL TANK 400L<SDH>
(A)
L=980
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0102- |
|
|
● |
|
|
|
| |
32 |
PIPE; DELIVERY,FUEL TANK
FUEL TANK 400L<SDH>
(B)
L=2800
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0102- |
|
|
● |
|
|
|
| |
35 |
PIPE; FUEL TANK,RETURN
L=1750
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9601-9609 |
● |
|
|
|
|
|
| |
35 |
PIPE; FUEL TANK,RETURN
MIDDLE CHASSIS(FV***F)
L=1750
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9601-9609 |
|
● |
|
|
|
|
| |
35 |
PIPE; FUEL TANK,RETURN
BRAKE SYSTEM AIR OVER HYDRAULIC DUAL
CIRCUIT(Z05)
L=1750
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9610-9810 |
● |
● |
● |
● |
● |
|
| |
35 |
PIPE; FUEL TANK,RETURN
MIDDLE CHASSIS(FV***F)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
L=1750
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9811-0004 |
● |
● |
|
|
● |
|
| |
35 |
PIPE; FUEL TANK,RETURN
TAIWAN EQUIPMENT(WW5)
L=1900
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9811-0004 |
● |
|
|
|
|
|
| |
35 |
PIPE; FUEL TANK,RETURN
SHORT CHASSIS(FV***C)
L=1300
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9601-9705 |
|
● |
|
|
|
|
| |
35 |
PIPE; FUEL TANK,RETURN
SHORT CHASSIS(FV***C)
L=1300
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9706-9806 |
● |
● |
|
|
|
|
| |
35 |
PIPE; FUEL TANK,RETURN
SHORT CHASSIS(FV***C)
L=1300
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
9807-0004 |
● |
● |
|
|
● |
|
| |
35 |
PIPE; FUEL TANK,RETURN
SHORT CHASSIS(FV***C)
L=4350
SERVICED BY L=8000
|
0-01260-800-0 |
01 |
1 |
9601-0004 |
|
|
● |
● |
|
|
| |
35 |
PIPE; FUEL TANK,RETURN
MIDDLE CHASSIS(FV***F)
WHEEL BASE 4200MM(42W)
L=3250
SERVICED BY L=8000
|
0-01260-800-0 |
01 |
1 |
9601-0004 |
|
|
● |
● |
|
|
| |
35 |
PIPE; FUEL TANK,RETURN
MIDDLE CHASSIS(FV***F)
WHEEL BASE 4600MM(46W)
L=3450
SERVICED BY L=8000
|
0-01260-800-0 |
01 |
1 |
9601-0004 |
|
|
● |
● |
|
|
| |
35 |
PIPE; FUEL TANK,RETURN
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5000MM(50W)
L=4250
SERVICED BY L=8000
|
0-01260-800-0 |
01 |
1 |
9601-9803 |
|
|
● |
● |
|
|
| |
35 |
PIPE; FUEL TANK,RETURN
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5000MM(50W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
EXC. CHILE EQUIPMENT(TDK),COLOMBIA
EQUIPMENT(WJ2)
L=4250
SERVICED BY L=8000
|
0-01260-800-0 |
01 |
1 |
9804-0004 |
|
|
● |
● |
|
|
| |
35 |
PIPE; FUEL TANK,RETURN
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5500MM(55W)
L=3550
SERVICED BY L=8000
|
0-01260-800-0 |
01 |
1 |
9601-9709 |
|
|
● |
● |
|
|
| |
35 |
PIPE; FUEL TANK,RETURN
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5500MM(55W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
EXC. EURO2 SPECIFICATION<THN>
L=3550
SERVICED BY L=8000
|
0-01260-800-0 |
01 |
1 |
9710-9803 |
|
|
● |
● |
|
|
| |
35 |
PIPE; FUEL TANK,RETURN
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5500MM(55W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
EXC. CHILE EQUIPMENT(TDK),COLOMBIA
EQUIPMENT(WJ2)
L=3550
SERVICED BY L=8000
|
0-01260-800-0 |
01 |
1 |
9804-0004 |
|
|
● |
● |
|
|
| |
35 |
PIPE; FUEL TANK,RETURN
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5500MM(55W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
EURO2 SPECIFICATION<THN>
L=5050
SERVICED BY L=8000
|
0-01260-800-0 |
01 |
1 |
9710-9803 |
|
|
● |
● |
|
|
| |
35 |
PIPE; FUEL TANK,RETURN
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5500MM(55W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
CHILE EQUIPMENT(TDK),COLOMBIA EQUIPMENT(WJ2)
L=5050
SERVICED BY L=8000
|
0-01260-800-0 |
01 |
1 |
9804-0004 |
|
|
● |
● |
|
|
| |
35 |
PIPE; FUEL TANK,RETURN
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5000MM(50W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
CHILE EQUIPMENT(TDK),COLOMBIA EQUIPMENT(WJ2)
L=5900
SERVICED BY L=8000
|
0-01260-800-0 |
01 |
1 |
9804-0004 |
|
|
● |
|
|
|
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
MIDDLE CHASSIS(FV***F)
(B)
L=250
|
5-09707-030-1 |
01 |
1 |
0012-0201 |
● |
● |
|
|
|
|
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
MIDDLE CHASSIS(FV***F)
FUEL TANK 200L FRAME SIDE<N20>
(B)
L=250
|
5-09707-030-1 |
02 |
1 |
0202-0607 |
● |
● |
|
|
|
|
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
MIDDLE CHASSIS(FV***F)
FUEL TANK 200L FRAME SIDE<N20>
(B)
L=250
|
5-09707-030-1 |
02 |
1 |
0608-1306 |
● |
● |
|
|
|
● |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
FUEL TANK 200L FRAME SIDE<N20>
(B)
L=250
|
5-09707-030-1 |
02 |
1 |
1307- |
● |
● |
|
|
|
● |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
MIDDLE CHASSIS(FV***F)
FUEL TANK 400L<SDH>
(B)
L=250
|
5-09707-030-1 |
04 |
1 |
0202- |
● |
● |
|
|
|
|
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
(A)
ID=14
|
1-09704-102-0 |
06 |
1 |
9601-9803 |
● |
● |
● |
● |
|
|
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
(A)
ID=14
|
1-09704-102-0 |
06 |
1 |
9804-0004 |
● |
● |
● |
● |
● |
|
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
(A)
ID=14
|
1-09704-102-0 |
06 |
1 |
0005-0607 |
● |
● |
● |
● |
|
|
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
(A)
ID=14
|
1-09704-102-0 |
06 |
1 |
0608- |
● |
● |
● |
● |
|
● |
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
(B)
L=250
|
5-09707-030-0 |
01 |
1 |
9601-9803 |
● |
● |
● |
● |
|
|
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
(B)
L=250
|
5-09707-030-1 |
01 |
1 |
9804-9903 |
● |
● |
● |
● |
● |
|
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
MIDDLE CHASSIS(FV***F)
(B)
L=250
|
5-09707-030-1 |
01 |
1 |
9904-0004 |
● |
● |
|
|
● |
|
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
(B)
L=250
|
5-09707-030-1 |
01 |
1 |
9904-0004 |
|
|
● |
● |
|
|
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
MIDDLE CHASSIS(FV***F)
(B)
L=250
|
5-09707-030-1 |
01 |
1 |
0005-0011 |
● |
● |
|
|
|
|
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
(B)
L=250
|
5-09707-030-1 |
01 |
1 |
0005-0011 |
|
|
● |
● |
|
|
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
FUEL TANK 400L<SDH>
(B)
L=250
|
5-09707-030-1 |
06 |
1 |
0012-0201 |
|
|
● |
|
|
|
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
FUEL TANK 400L<SDH>
(B)
L=250
|
5-09707-030-1 |
07 |
1 |
0202-0612 |
|
|
● |
|
|
|
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
MIDDLE CHASSIS(FV***F)
FUEL TANK 400L<SDH>
(B)
L=250
|
5-09707-030-1 |
07 |
1 |
0701- |
|
|
● |
|
|
|
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
FUEL TANK 200L FRAME SIDE<N20>
(B)
L=250
|
5-09707-030-1 |
04 |
1 |
0012-0201 |
|
|
● |
● |
|
|
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
FUEL TANK 200L FRAME SIDE<N20>
(B)
L=250
|
5-09707-030-1 |
05 |
1 |
0202-0612 |
|
|
● |
● |
|
|
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
SHORT CHASSIS(FV***C)
(B)
L=250
|
5-09707-030-1 |
05 |
1 |
0701- |
|
|
● |
● |
|
|
| |
41 |
CLIP; FUEL PIPE,FUEL TANK
MIDDLE CHASSIS(FV***F)
FUEL TANK 200L FRAME SIDE<N20>
(B)
L=250
|
5-09707-030-1 |
05 |
1 |
0701- |
|
|
● |
● |
|
|
| |
55 |
COVER; PIPE,FUEL TANK
MIDDLE CHASSIS(FV***F)
(A) L=1300
|
1-09360-677-1 |
01 |
1 |
0012-0607 |
● |
● |
|
|
|
|
| |
55 |
COVER; PIPE,FUEL TANK
FUEL TANK 200L FRAME SIDE<N20>
(A) L=1300
|
1-09360-677-1 |
01 |
1 |
0012-0607 |
|
|
● |
● |
|
|
| |
55 |
COVER; PIPE,FUEL TANK
MIDDLE CHASSIS(FV***F)
(A)
L=150
SERVICED BY L=1300
|
1-09360-677-1 |
01 |
1 |
0608-0612 |
● |
● |
|
|
|
● |
| |
55 |
COVER; PIPE,FUEL TANK
FUEL TANK 200L FRAME SIDE<N20>
(A)
L=150
SERVICED BY L=1300
|
1-09360-677-1 |
01 |
1 |
0608-0612 |
|
|
● |
● |
|
|
| |
55 |
COVER; PIPE,FUEL TANK
MIDDLE CHASSIS(FV***F)
(A)
L=150
SERVICED BY L=1300
|
1-09360-677-1 |
01 |
1 |
0701-1306 |
● |
● |
|
|
|
● |
| |
55 |
COVER; PIPE,FUEL TANK
SHORT CHASSIS(FV***C)
(A)
L=150
SERVICED BY L=1300
|
1-09360-677-1 |
01 |
1 |
0701-1306 |
|
|
● |
● |
|
|
| |
55 |
COVER; PIPE,FUEL TANK
MIDDLE CHASSIS(FV***F)
FUEL TANK 200L FRAME SIDE<N20>
(A)
L=150
SERVICED BY L=1300
|
1-09360-677-1 |
01 |
1 |
0701-1306 |
|
|
● |
● |
|
|
| |
55 |
COVER; PIPE,FUEL TANK
(A)
L=150
SERVICED BY L=1300
|
1-09360-677-1 |
01 |
1 |
1307- |
● |
● |
|
|
|
|
| |
55 |
COVER; PIPE,FUEL TANK
SHORT CHASSIS(FV***C)
(A)
L=150
SERVICED BY L=1300
|
1-09360-677-1 |
01 |
1 |
1307- |
|
|
● |
● |
|
|
| |
55 |
COVER; PIPE,FUEL TANK
MIDDLE CHASSIS(FV***F)
FUEL TANK 200L FRAME SIDE<N20>
(A)
L=150
SERVICED BY L=1300
|
1-09360-677-1 |
01 |
1 |
1307- |
|
|
● |
● |
|
|
| |
55 |
COVER; PIPE,FUEL TANK
MIDDLE CHASSIS(FV***F)
(A)
L=150
SERVICED BY L=1300
|
1-09360-677-1 |
01 |
1 |
1307- |
|
|
|
|
|
● |
| |
55 |
COVER; PIPE,FUEL TANK
(A)
L=150
SERVICED BY L=1300
|
1-09360-677-1 |
01 |
1 |
9601-9803 |
● |
● |
● |
● |
|
|
| |
55 |
COVER; PIPE,FUEL TANK
(A)
L=150
SERVICED BY L=1300
|
1-09360-677-1 |
01 |
1 |
9804-9903 |
● |
● |
● |
● |
● |
|
| |
55 |
COVER; PIPE,FUEL TANK
MIDDLE CHASSIS(FV***F)
(A)
L=150
SERVICED BY L=1300
|
1-09360-677-1 |
01 |
1 |
9904-0004 |
● |
● |
|
|
● |
|
| |
55 |
COVER; PIPE,FUEL TANK
(A)
L=150
SERVICED BY L=1300
|
1-09360-677-1 |
01 |
1 |
9904-0004 |
|
|
● |
● |
|
|
| |
55 |
COVER; PIPE,FUEL TANK
MIDDLE CHASSIS(FV***F)
(A)
L=150
SERVICED BY L=1300
|
1-09360-677-1 |
01 |
1 |
0005-0011 |
● |
● |
|
|
|
|
| |
55 |
COVER; PIPE,FUEL TANK
(A)
L=150
SERVICED BY L=1300
|
1-09360-677-1 |
01 |
1 |
0005-0011 |
|
|
● |
● |
|
|
| |
55 |
COVER; PIPE,FUEL TANK
FUEL TANK 400L<SDH>
(A)
L=150
SERVICED BY L=1300
|
1-09360-677-1 |
02 |
1 |
0012-0612 |
|
|
● |
|
|
|
| |
55 |
COVER; PIPE,FUEL TANK
MIDDLE CHASSIS(FV***F)
FUEL TANK 400L<SDH>
(A)
L=150
SERVICED BY L=1300
|
1-09360-677-1 |
02 |
1 |
0701- |
|
|
● |
|
|
|
| |
55 |
COVER; PIPE,FUEL TANK
(B)
L=350
|
1-09360-460-1 |
01 |
1 |
9607- |
|
|
● |
● |
|
|
| |
55 |
COVER; PIPE,FUEL TANK
(C)
L=800
|
1-09361-018-0 |
01 |
1 |
0006- |
|
|
● |
● |
|
|
| |
64 |
NUT; CLIP
MIDDLE CHASSIS(FV***F)
FUEL TANK 200L FRAME SIDE<N20>
TAIL PIPE SINGLE HORIZONTAL TURN LEFT<SBR>
M8 FLANGE
|
0-91150-108-0 |
06 |
1 |
0010-0109 |
● |
|
|
|
|
|
| |
64 |
NUT; CLIP
MIDDLE CHASSIS(FV***F)
M8
|
9-09110-408-0 |
03 |
1 |
9601-9606 |
● |
● |
|
|
|
|
| |
64 |
NUT; CLIP
MIDDLE CHASSIS(FV***F)
M8 FLANGE
|
0-91150-108-0 |
03 |
1 |
9607-9806 |
● |
● |
|
|
|
|
| |
64 |
NUT; CLIP
MIDDLE CHASSIS(FV***F)
M8 FLANGE
|
0-91150-108-0 |
03 |
1 |
9807-0004 |
● |
● |
|
|
● |
|
| |
64 |
NUT; CLIP
SHORT CHASSIS(FV***C)
M8
|
9-09110-408-0 |
05 |
1 |
9601-9606 |
|
● |
|
|
|
|
| |
64 |
NUT; CLIP
SHORT CHASSIS(FV***C)
M8 FLANGE
|
0-91150-108-0 |
05 |
1 |
9607-9705 |
|
● |
|
|
|
|
| |
64 |
NUT; CLIP
SHORT CHASSIS(FV***C)
M8 FLANGE
|
0-91150-108-0 |
05 |
1 |
9706-9806 |
● |
● |
|
|
|
|
| |
64 |
NUT; CLIP
SHORT CHASSIS(FV***C)
M8 FLANGE
|
0-91150-108-0 |
05 |
1 |
9807-0004 |
● |
● |
|
|
● |
|
| |
64 |
NUT; CLIP
FUEL TANK 400L<SDH>
COLOMBIA EQUIPMENT(WJ2)
M8 FLANGE
|
0-91150-108-0 |
03 |
1 |
0005-0109 |
● |
|
|
|
|
|
| |
64 |
NUT; CLIP
FUEL TANK 200L FRAME SIDE<N20>
TAIL PIPE SINGLE HORIZONTAL TURN LEFT<SBR>
M8 FLANGE
|
0-91150-108-0 |
01 |
1 |
0110-0602 |
● |
|
|
|
|
|
| |
64 |
NUT; CLIP
FUEL TANK 200L FRAME SIDE<N20>
TAIL PIPE SINGLE HORIZONTAL TURN LEFT<SBR>
M8 FLANGE
|
0-91180-108-0 |
01 |
1 |
0603-0607 |
● |
|
|
|
|
|
| |
64 |
NUT; CLIP
FUEL TANK 200L FRAME SIDE<N20>
TAIL PIPE SINGLE HORIZONTAL TURN LEFT<SBR>
M8 FLANGE
|
0-91180-108-0 |
01 |
1 |
0608-0612 |
● |
|
|
|
|
|
| |
64 |
NUT; CLIP
MIDDLE CHASSIS(FV***F)
FUEL TANK 200L FRAME SIDE<N20>
TAIL PIPE SINGLE HORIZONTAL TURN LEFT<SBR>
M8 FLANGE
|
0-91180-108-0 |
01 |
1 |
0608-0612 |
|
|
|
|
|
● |
| |
64 |
NUT; CLIP
MIDDLE CHASSIS(FV***F)
FUEL TANK 200L FRAME SIDE<N20>
TAIL PIPE SINGLE HORIZONTAL TURN LEFT<SBR>
M8 FLANGE
|
0-91180-108-0 |
01 |
1 |
0701- |
● |
|
|
|
|
● |
| |
64 |
NUT; CLIP
SHORT CHASSIS(FV***C)
TAIL PIPE SINGLE HORIZONTAL TURN LEFT<SBR>
M8 FLANGE
|
0-91180-108-0 |
01 |
1 |
0701- |
● |
|
|
|
|
|
| |
64 |
NUT; CLIP
SHORT CHASSIS(FV***C)
M8
|
9-09110-408-0 |
13 |
1 |
9601-9606 |
|
|
● |
● |
|
|
| |
64 |
NUT; CLIP
SHORT CHASSIS(FV***C)
M8 FLANGE
|
0-91150-108-0 |
13 |
1 |
9607-0004 |
|
|
● |
● |
|
|
| |
64 |
NUT; CLIP
FUEL TANK 200L FRAME SIDE<N20>
M8 FLANGE
|
0-91150-108-0 |
11 |
1 |
0005-0602 |
|
|
● |
● |
|
|
| |
64 |
NUT; CLIP
FUEL TANK 200L FRAME SIDE<N20>
M8 FLANGE
|
0-91180-108-0 |
11 |
1 |
0603- |
|
|
● |
● |
|
|
| |
64 |
NUT; CLIP
MIDDLE CHASSIS(FV***F)
WHEEL BASE 4200MM(42W),WHEEL BASE 4600MM(46W),
WHEEL BASE 5500MM(55W)
M8
|
9-09110-408-0 |
09 |
1 |
9601-9606 |
|
|
● |
● |
|
|
| |
64 |
NUT; CLIP
MIDDLE CHASSIS(FV***F)
WHEEL BASE 4200MM(42W),WHEEL BASE 4600MM(46W),
WHEEL BASE 5500MM(55W)
M8 FLANGE
|
0-91150-108-0 |
09 |
1 |
9607-9709 |
|
|
● |
● |
|
|
| |
64 |
NUT; CLIP
MIDDLE CHASSIS(FV***F)
WHEEL BASE 4200MM(42W),WHEEL BASE 4600MM(46W),
WHEEL BASE 5500MM(55W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
EXC. EURO2 SPECIFICATION<THN>
M8 FLANGE
|
0-91150-108-0 |
09 |
1 |
9710-9803 |
|
|
● |
● |
|
|
| |
64 |
NUT; CLIP
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5000MM(50W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
CHILE EQUIPMENT(TDK),COLOMBIA EQUIPMENT(WJ2)
M8 FLANGE
|
0-91150-108-0 |
16 |
1 |
9804-0004 |
|
|
● |
|
|
|
| |
64 |
NUT; CLIP
FUEL TANK 200L FRAME SIDE<N20>
M8 FLANGE
|
0-91150-108-0 |
05 |
1 |
0005-0009 |
● |
● |
|
|
|
|
| |
64 |
NUT; CLIP
FUEL TANK 200L FRAME SIDE<N20>
EXC. TAIL PIPE SINGLE HORIZONTAL TURN
LEFT<SBR>
M8 FLANGE
|
0-91150-108-0 |
05 |
1 |
0010-0109 |
● |
● |
|
|
|
|
| |
64 |
NUT; CLIP
FUEL TANK 200L FRAME SIDE<N20>
M8 FLANGE
|
0-91150-108-0 |
03 |
1 |
0110-0602 |
● |
● |
|
|
|
|
| |
64 |
NUT; CLIP
FUEL TANK 400L<SDH>
COLOMBIA EQUIPMENT(WJ2)
M8 FLANGE
|
0-91150-108-0 |
03 |
1 |
0110-0602 |
● |
|
|
|
|
|
| |
64 |
NUT; CLIP
FUEL TANK 200L FRAME SIDE<N20>
M8 FLANGE
|
0-91180-108-0 |
03 |
1 |
0603-0607 |
● |
● |
|
|
|
|
| |
64 |
NUT; CLIP
FUEL TANK 400L<SDH>
COLOMBIA EQUIPMENT(WJ2)
M8 FLANGE
|
0-91180-108-0 |
03 |
1 |
0603-0607 |
● |
|
|
|
|
|
| |
64 |
NUT; CLIP
FUEL TANK 200L FRAME SIDE<N20>
M8 FLANGE
|
0-91180-108-0 |
03 |
1 |
0608-0612 |
● |
● |
|
|
|
|
| |
64 |
NUT; CLIP
FUEL TANK 400L<SDH>
COLOMBIA EQUIPMENT(WJ2)
M8 FLANGE
|
0-91180-108-0 |
03 |
1 |
0608-0612 |
● |
|
|
|
|
|
| |
64 |
NUT; CLIP
MIDDLE CHASSIS(FV***F)
FUEL TANK 200L FRAME SIDE<N20>
M8 FLANGE
|
0-91180-108-0 |
03 |
1 |
0608-0612 |
|
|
|
|
|
● |
| |
64 |
NUT; CLIP
MIDDLE CHASSIS(FV***F)
FUEL TANK 200L FRAME SIDE<N20>
M8 FLANGE
|
0-91180-108-0 |
03 |
1 |
0701- |
● |
● |
|
|
|
● |
| |
64 |
NUT; CLIP
SHORT CHASSIS(FV***C)
M8 FLANGE
|
0-91180-108-0 |
03 |
1 |
0701- |
● |
● |
|
|
|
|
| |
64 |
NUT; CLIP
MIDDLE CHASSIS(FV***F)
FUEL TANK 400L<SDH>
COLOMBIA EQUIPMENT(WJ2)
M8 FLANGE
|
0-91180-108-0 |
03 |
1 |
0701- |
● |
|
|
|
|
|
| |
64 |
NUT; CLIP
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5000MM(50W)
M8
|
9-09110-408-0 |
11 |
1 |
9601-9606 |
|
|
● |
● |
|
|
| |
64 |
NUT; CLIP
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5000MM(50W)
M8 FLANGE
|
0-91150-108-0 |
11 |
1 |
9607-9803 |
|
|
● |
● |
|
|
| |
64 |
NUT; CLIP
MIDDLE CHASSIS(FV***F)
WHEEL BASE 4200MM(42W),WHEEL BASE 4600MM(46W),
WHEEL BASE 5500MM(55W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
EXC. CHILE EQUIPMENT(TDK),COLOMBIA
EQUIPMENT(WJ2)
M8 FLANGE
|
0-91150-108-0 |
09 |
1 |
9804-0004 |
|
|
● |
● |
|
|
| |
64 |
NUT; CLIP
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5500MM(55W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
CHILE EQUIPMENT(TDK),COLOMBIA EQUIPMENT(WJ2)
M8 FLANGE
|
0-91150-108-0 |
14 |
1 |
9804-0004 |
|
|
● |
● |
|
|
| |
64 |
NUT; CLIP
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5500MM(55W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
EURO2 SPECIFICATION<THN>
M8 FLANGE
|
0-91150-108-0 |
14 |
1 |
9710-9803 |
|
|
● |
● |
|
|
| |
64 |
NUT; CLIP
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5000MM(50W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
EXC. CHILE EQUIPMENT(TDK),COLOMBIA
EQUIPMENT(WJ2)
M8 FLANGE
|
0-91150-108-0 |
11 |
1 |
9804-0004 |
|
|
● |
● |
|
|
| |
64 |
NUT; CLIP
MIDDLE CHASSIS(FV***F)
FUEL TANK 400L<SDH>
M8 FLANGE
|
0-91150-108-0 |
08 |
1 |
0102-0602 |
|
|
● |
|
|
|
| |
64 |
NUT; CLIP
MIDDLE CHASSIS(FV***F)
FUEL TANK 400L<SDH>
M8 FLANGE
|
0-91180-108-0 |
08 |
1 |
0603- |
|
|
● |
|
|
|
| |
80 |
BOLT; CLIP,FUEL TANK
MIDDLE CHASSIS(FV***F)
WHEEL BASE 4600MM(46W)
FUEL TANK 200L+200L<NF7>
M8X25 FLANGE
|
0-28680-825-0 |
02 |
1 |
9701-9803 |
|
● |
|
|
|
|
| |
80 |
BOLT; CLIP,FUEL TANK
FUEL TANK 200L+200L<NF7>
M8X25 FLANGE
|
0-28680-825-0 |
02 |
1 |
9804-0004 |
|
● |
|
|
|
|
| |
83 |
NUT; CLIP,FUEL TANK
MIDDLE CHASSIS(FV***F)
WHEEL BASE 4600MM(46W)
FUEL TANK 200L+200L<NF7>
M8 FLANGE
|
0-91150-108-0 |
02 |
1 |
9701-9803 |
|
● |
|
|
|
|
| |
83 |
NUT; CLIP,FUEL TANK
FUEL TANK 200L+200L<NF7>
M8 FLANGE
|
0-91150-108-0 |
02 |
1 |
9804-0004 |
|
● |
|
|
|
|
| |
95 |
BUSHING; PIPE,FUEL TANK
SHORT CHASSIS(FV***C)
ID=28 OD=35 T=25
|
1-09332-011-1 |
02 |
1 |
9601-9701 |
● |
● |
● |
● |
● |
● |
| |
95 |
BUSHING; PIPE,FUEL TANK
ID=28 OD=35 T=25
|
1-09332-011-1 |
01 |
1 |
9702-9803 |
● |
● |
● |
● |
|
|
| |
95 |
BUSHING; PIPE,FUEL TANK
ID=28 OD=35 T=25
|
1-09332-011-1 |
01 |
1 |
9804-9903 |
● |
● |
● |
● |
● |
|
| |
95 |
BUSHING; PIPE,FUEL TANK
MIDDLE CHASSIS(FV***F)
ID=28 OD=35 T=25
|
1-09332-011-1 |
01 |
1 |
9904-0004 |
● |
● |
|
|
● |
|
| |
95 |
BUSHING; PIPE,FUEL TANK
ID=28 OD=35 T=25
|
1-09332-011-1 |
01 |
1 |
9904-0004 |
|
|
● |
● |
|
|
| |
95 |
BUSHING; PIPE,FUEL TANK
MIDDLE CHASSIS(FV***F)
ID=28 OD=35 T=25
|
1-09332-011-1 |
01 |
1 |
0005-0607 |
● |
● |
|
|
|
|
| |
95 |
BUSHING; PIPE,FUEL TANK
ID=28 OD=35 T=25
|
1-09332-011-1 |
01 |
1 |
0005-0607 |
|
|
● |
● |
|
|
| |
95 |
BUSHING; PIPE,FUEL TANK
MIDDLE CHASSIS(FV***F)
ID=28 OD=35 T=25
|
1-09332-011-1 |
01 |
1 |
0608- |
● |
● |
|
|
|
● |
| |
95 |
BUSHING; PIPE,FUEL TANK
ID=28 OD=35 T=25
|
1-09332-011-1 |
01 |
1 |
0608- |
|
|
● |
● |
|
|
| |
95 |
BUSHING; PIPE,FUEL TANK
MIDDLE CHASSIS(FV***F)
ID=28 OD=35 T=25
|
1-09332-011-1 |
01 |
1 |
9601-9701 |
● |
● |
● |
● |
|
|
| |
95 |
BUSHING; PIPE,FUEL TANK
SHORT CHASSIS(FV***C)
ID=28 OD=35 T=25
|
1-09332-011-1 |
02 |
1 |
9904-0004 |
● |
● |
|
|
● |
|
| |
95 |
BUSHING; PIPE,FUEL TANK
SHORT CHASSIS(FV***C)
ID=28 OD=35 T=25
|
1-09332-011-1 |
02 |
1 |
0005- |
● |
● |
|
|
|
|
| |
208 |
COVER; RUBBER
MIDDLE CHASSIS(FV***F)
WHEEL BASE 4600MM(46W)
FUEL TANK 200L+200L<NF7>
L=800
|
1-09360-379-1 |
01 |
1 |
9701-9803 |
|
● |
|
|
|
|
| |
208 |
COVER; RUBBER
FUEL TANK 200L+200L<NF7>
L=800
|
1-09360-379-1 |
01 |
1 |
9804-0004 |
|
● |
|
|
|
|
| |
228 |
BOLT; BRKT,SEDIMENTER
M10X40 FLANGE
|
0-28081-040-0 |
02 |
1 |
9601-9606 |
● |
● |
● |
● |
|
|
| |
228 |
BOLT; BRKT,SEDIMENTER
M10X45 FLANGE
|
0-28081-045-0 |
02 |
1 |
9607-9803 |
● |
● |
● |
● |
|
|
| |
228 |
BOLT; BRKT,SEDIMENTER
M10X45 FLANGE
|
0-28081-045-0 |
02 |
1 |
9804-0004 |
● |
● |
● |
● |
● |
|
| |
228 |
BOLT; BRKT,SEDIMENTER
M10X45 FLANGE
|
0-28081-045-0 |
02 |
1 |
0005-0209 |
● |
● |
● |
● |
|
|
| |
228 |
BOLT; BRKT,SEDIMENTER
M10X40 FLANGE
|
0-28681-040-0 |
02 |
1 |
0210-0512 |
● |
● |
● |
● |
|
|
| |
228 |
BOLT; BRKT,SEDIMENTER
M10X40 FLANGE
|
0-28651-040-0 |
02 |
1 |
0601-0607 |
● |
● |
● |
● |
|
|
| |
228 |
BOLT; BRKT,SEDIMENTER
M10X40 FLANGE
|
0-28651-040-0 |
02 |
1 |
0608- |
● |
● |
● |
● |
|
● |
| |
229 |
NUT; BRKT,FUEL FILTER
MIDDLE CHASSIS(FV***F)
M10
|
9-09110-510-0 |
02 |
1 |
9601-9606 |
● |
● |
● |
● |
|
|
| |
229 |
NUT; BRKT,FUEL FILTER
MIDDLE CHASSIS(FV***F)
M10 FLANGE
|
0-91150-210-0 |
02 |
1 |
9607-9610 |
● |
● |
● |
● |
|
|
| |
229 |
NUT; BRKT,FUEL FILTER
M10 FLANGE
|
0-91150-210-0 |
02 |
1 |
9611-9803 |
● |
● |
● |
● |
|
|
| |
229 |
NUT; BRKT,FUEL FILTER
M10 FLANGE
|
0-91150-210-0 |
02 |
1 |
9804-0004 |
● |
● |
● |
● |
● |
|
| |
229 |
NUT; BRKT,FUEL FILTER
M10 FLANGE
|
0-91150-210-0 |
02 |
1 |
0005-0602 |
● |
● |
● |
● |
|
|
| |
229 |
NUT; BRKT,FUEL FILTER
M10 FLANGE
|
0-91180-210-0 |
02 |
1 |
0603-0607 |
● |
● |
● |
● |
|
|
| |
229 |
NUT; BRKT,FUEL FILTER
M10 FLANGE
|
0-91180-210-0 |
02 |
1 |
0608- |
● |
● |
● |
● |
|
● |
| |
232 |
BOLT; CLIP,PIPE
MIDDLE CHASSIS(FV***F)
FUEL TANK 200L FRAME SIDE<N20>
TAIL PIPE SINGLE HORIZONTAL TURN LEFT<SBR>
M8X30 FLANGE
|
0-28680-830-0 |
06 |
1 |
0010-0109 |
● |
|
|
|
|
|
| |
232 |
BOLT; CLIP,PIPE
MIDDLE CHASSIS(FV***F)
M8X30 FLANGE
|
0-28080-830-0 |
03 |
1 |
9601-9606 |
● |
● |
|
|
|
|
| |
232 |
BOLT; CLIP,PIPE
MIDDLE CHASSIS(FV***F)
M8X35 FLANGE
|
0-28680-835-0 |
03 |
1 |
9607-9806 |
● |
● |
|
|
|
|
| |
232 |
BOLT; CLIP,PIPE
MIDDLE CHASSIS(FV***F)
M8X35 FLANGE
|
0-28680-835-0 |
03 |
1 |
9807-9807 |
● |
● |
|
|
● |
|
| |
232 |
BOLT; CLIP,PIPE
MIDDLE CHASSIS(FV***F)
M8X30 FLANGE
|
0-28680-830-0 |
03 |
1 |
9808-0004 |
● |
● |
|
|
● |
|
| |
232 |
BOLT; CLIP,PIPE
SHORT CHASSIS(FV***C)
M8X30 FLANGE
|
0-28080-830-0 |
05 |
1 |
9601-9606 |
|
● |
|
|
|
|
| |
232 |
BOLT; CLIP,PIPE
SHORT CHASSIS(FV***C)
M8X35 FLANGE
|
0-28680-835-0 |
05 |
1 |
9607-9705 |
|
● |
|
|
|
|
| |
232 |
BOLT; CLIP,PIPE
SHORT CHASSIS(FV***C)
M8X35 FLANGE
|
0-28680-835-0 |
05 |
1 |
9706-9806 |
● |
● |
|
|
|
|
| |
232 |
BOLT; CLIP,PIPE
SHORT CHASSIS(FV***C)
M8X35 FLANGE
|
0-28680-835-0 |
05 |
1 |
9807-9807 |
● |
● |
|
|
● |
|
| |
232 |
BOLT; CLIP,PIPE
SHORT CHASSIS(FV***C)
M8X30 FLANGE
|
0-28680-830-0 |
05 |
1 |
9808-0004 |
● |
● |
|
|
● |
|
| |
232 |
BOLT; CLIP,PIPE
FUEL TANK 400L<SDH>
COLOMBIA EQUIPMENT(WJ2)
M8X30 FLANGE
|
0-28680-830-0 |
03 |
1 |
0005-0109 |
● |
|
|
|
|
|
| |
232 |
BOLT; CLIP,PIPE
FUEL TANK 200L FRAME SIDE<N20>
TAIL PIPE SINGLE HORIZONTAL TURN LEFT<SBR>
M8X30 FLANGE
|
0-28680-830-0 |
01 |
1 |
0110-0512 |
● |
|
|
|
|
|
| |
232 |
BOLT; CLIP,PIPE
FUEL TANK 200L FRAME SIDE<N20>
TAIL PIPE SINGLE HORIZONTAL TURN LEFT<SBR>
M8X30 FLANGE
|
0-28650-830-0 |
01 |
1 |
0601-0607 |
● |
|
|
|
|
|
| |
232 |
BOLT; CLIP,PIPE
FUEL TANK 200L FRAME SIDE<N20>
TAIL PIPE SINGLE HORIZONTAL TURN LEFT<SBR>
M8X30 FLANGE
|
0-28650-830-0 |
01 |
1 |
0608-0612 |
● |
|
|
|
|
|
| |
232 |
BOLT; CLIP,PIPE
MIDDLE CHASSIS(FV***F)
FUEL TANK 200L FRAME SIDE<N20>
TAIL PIPE SINGLE HORIZONTAL TURN LEFT<SBR>
M8X30 FLANGE
|
0-28650-830-0 |
01 |
1 |
0608-0612 |
|
|
|
|
|
● |
| |
232 |
BOLT; CLIP,PIPE
MIDDLE CHASSIS(FV***F)
FUEL TANK 200L FRAME SIDE<N20>
TAIL PIPE SINGLE HORIZONTAL TURN LEFT<SBR>
M8X30 FLANGE
|
0-28650-830-0 |
01 |
1 |
0701- |
● |
|
|
|
|
● |
| |
232 |
BOLT; CLIP,PIPE
SHORT CHASSIS(FV***C)
TAIL PIPE SINGLE HORIZONTAL TURN LEFT<SBR>
M8X30 FLANGE
|
0-28650-830-0 |
01 |
1 |
0701- |
● |
|
|
|
|
|
| |
232 |
BOLT; CLIP,PIPE
SHORT CHASSIS(FV***C)
M8X30 FLANGE
|
0-28080-830-0 |
13 |
1 |
9601-9606 |
|
|
● |
● |
|
|
| |
232 |
BOLT; CLIP,PIPE
SHORT CHASSIS(FV***C)
M8X35 FLANGE
|
0-28680-835-0 |
13 |
1 |
9607-9807 |
|
|
● |
● |
|
|
| |
232 |
BOLT; CLIP,PIPE
SHORT CHASSIS(FV***C)
M8X30 FLANGE
|
0-28680-830-0 |
13 |
1 |
9808-0004 |
|
|
● |
● |
|
|
| |
232 |
BOLT; CLIP,PIPE
FUEL TANK 200L FRAME SIDE<N20>
M8X30 FLANGE
|
0-28680-830-0 |
11 |
1 |
0005-0512 |
|
|
● |
● |
|
|
| |
232 |
BOLT; CLIP,PIPE
FUEL TANK 200L FRAME SIDE<N20>
M8X30 FLANGE
|
0-28650-830-0 |
11 |
1 |
0601- |
|
|
● |
● |
|
|
| |
232 |
BOLT; CLIP,PIPE
MIDDLE CHASSIS(FV***F)
WHEEL BASE 4200MM(42W),WHEEL BASE 4600MM(46W),
WHEEL BASE 5500MM(55W)
M8X30 FLANGE
|
0-28080-830-0 |
09 |
1 |
9601-9606 |
|
|
● |
● |
|
|
| |
232 |
BOLT; CLIP,PIPE
MIDDLE CHASSIS(FV***F)
WHEEL BASE 4200MM(42W),WHEEL BASE 4600MM(46W),
WHEEL BASE 5500MM(55W)
M8X35 FLANGE
|
0-28680-835-0 |
09 |
1 |
9607-9709 |
|
|
● |
● |
|
|
| |
232 |
BOLT; CLIP,PIPE
MIDDLE CHASSIS(FV***F)
WHEEL BASE 4200MM(42W),WHEEL BASE 4600MM(46W),
WHEEL BASE 5500MM(55W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
EXC. EURO2 SPECIFICATION<THN>
M8X35 FLANGE
|
0-28680-835-0 |
09 |
1 |
9710-9803 |
|
|
● |
● |
|
|
| |
232 |
BOLT; CLIP,PIPE
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5000MM(50W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
CHILE EQUIPMENT(TDK),COLOMBIA EQUIPMENT(WJ2)
M8X35 FLANGE
|
0-28680-835-0 |
16 |
1 |
9804-9807 |
|
|
● |
|
|
|
| |
232 |
BOLT; CLIP,PIPE
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5000MM(50W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
CHILE EQUIPMENT(TDK),COLOMBIA EQUIPMENT(WJ2)
M8X30 FLANGE
|
0-28680-830-0 |
16 |
1 |
9808-0004 |
|
|
● |
|
|
|
| |
232 |
BOLT; CLIP,PIPE
FUEL TANK 200L FRAME SIDE<N20>
M8X30 FLANGE
|
0-28680-830-0 |
05 |
1 |
0005-0009 |
● |
● |
|
|
|
|
| |
232 |
BOLT; CLIP,PIPE
FUEL TANK 200L FRAME SIDE<N20>
EXC. TAIL PIPE SINGLE HORIZONTAL TURN
LEFT<SBR>
M8X30 FLANGE
|
0-28680-830-0 |
05 |
1 |
0010-0109 |
● |
● |
|
|
|
|
| |
232 |
BOLT; CLIP,PIPE
FUEL TANK 200L FRAME SIDE<N20>
M8X30 FLANGE
|
0-28680-830-0 |
03 |
1 |
0110-0512 |
● |
● |
|
|
|
|
| |
232 |
BOLT; CLIP,PIPE
FUEL TANK 400L<SDH>
COLOMBIA EQUIPMENT(WJ2)
M8X30 FLANGE
|
0-28680-830-0 |
03 |
1 |
0110-0512 |
● |
|
|
|
|
|
| |
232 |
BOLT; CLIP,PIPE
FUEL TANK 200L FRAME SIDE<N20>
M8X30 FLANGE
|
0-28650-830-0 |
03 |
1 |
0601-0607 |
● |
● |
|
|
|
|
| |
232 |
BOLT; CLIP,PIPE
FUEL TANK 400L<SDH>
COLOMBIA EQUIPMENT(WJ2)
M8X30 FLANGE
|
0-28650-830-0 |
03 |
1 |
0601-0607 |
● |
|
|
|
|
|
| |
232 |
BOLT; CLIP,PIPE
FUEL TANK 200L FRAME SIDE<N20>
M8X30 FLANGE
|
0-28650-830-0 |
03 |
1 |
0608-0612 |
● |
● |
|
|
|
|
| |
232 |
BOLT; CLIP,PIPE
FUEL TANK 400L<SDH>
COLOMBIA EQUIPMENT(WJ2)
M8X30 FLANGE
|
0-28650-830-0 |
03 |
1 |
0608-0612 |
● |
|
|
|
|
|
| |
232 |
BOLT; CLIP,PIPE
MIDDLE CHASSIS(FV***F)
FUEL TANK 200L FRAME SIDE<N20>
M8X30 FLANGE
|
0-28650-830-0 |
03 |
1 |
0608-0612 |
|
|
|
|
|
● |
| |
232 |
BOLT; CLIP,PIPE
MIDDLE CHASSIS(FV***F)
FUEL TANK 200L FRAME SIDE<N20>
M8X30 FLANGE
|
0-28650-830-0 |
03 |
1 |
0701- |
● |
● |
|
|
|
● |
| |
232 |
BOLT; CLIP,PIPE
SHORT CHASSIS(FV***C)
M8X30 FLANGE
|
0-28650-830-0 |
03 |
1 |
0701- |
● |
● |
|
|
|
|
| |
232 |
BOLT; CLIP,PIPE
MIDDLE CHASSIS(FV***F)
FUEL TANK 400L<SDH>
COLOMBIA EQUIPMENT(WJ2)
M8X30 FLANGE
|
0-28650-830-0 |
03 |
1 |
0701- |
● |
|
|
|
|
|
| |
232 |
BOLT; CLIP,PIPE
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5000MM(50W)
M8X30 FLANGE
|
0-28080-830-0 |
11 |
1 |
9601-9606 |
|
|
● |
● |
|
|
| |
232 |
BOLT; CLIP,PIPE
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5000MM(50W)
M8X35 FLANGE
|
0-28680-835-0 |
11 |
1 |
9607-9803 |
|
|
● |
● |
|
|
| |
232 |
BOLT; CLIP,PIPE
MIDDLE CHASSIS(FV***F)
WHEEL BASE 4200MM(42W),WHEEL BASE 4600MM(46W),
WHEEL BASE 5500MM(55W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
EXC. CHILE EQUIPMENT(TDK),COLOMBIA
EQUIPMENT(WJ2)
M8X35 FLANGE
|
0-28680-835-0 |
09 |
1 |
9804-9807 |
|
|
● |
● |
|
|
| |
232 |
BOLT; CLIP,PIPE
MIDDLE CHASSIS(FV***F)
WHEEL BASE 4200MM(42W),WHEEL BASE 4600MM(46W),
WHEEL BASE 5500MM(55W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
EXC. CHILE EQUIPMENT(TDK),COLOMBIA
EQUIPMENT(WJ2)
M8X30 FLANGE
|
0-28680-830-0 |
09 |
1 |
9808-0004 |
|
|
● |
● |
|
|
| |
232 |
BOLT; CLIP,PIPE
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5500MM(55W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
CHILE EQUIPMENT(TDK),COLOMBIA EQUIPMENT(WJ2)
M8X35 FLANGE
|
0-28680-835-0 |
14 |
1 |
9804-9807 |
|
|
● |
● |
|
|
| |
232 |
BOLT; CLIP,PIPE
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5500MM(55W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
CHILE EQUIPMENT(TDK),COLOMBIA EQUIPMENT(WJ2)
M8X30 FLANGE
|
0-28680-830-0 |
14 |
1 |
9808-0004 |
|
|
● |
● |
|
|
| |
232 |
BOLT; CLIP,PIPE
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5500MM(55W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
EURO2 SPECIFICATION<THN>
M8X35 FLANGE
|
0-28680-835-0 |
14 |
1 |
9710-9803 |
|
|
● |
● |
|
|
| |
232 |
BOLT; CLIP,PIPE
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5000MM(50W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
EXC. CHILE EQUIPMENT(TDK),COLOMBIA
EQUIPMENT(WJ2)
M8X35 FLANGE
|
0-28680-835-0 |
11 |
1 |
9804-9807 |
|
|
● |
● |
|
|
| |
232 |
BOLT; CLIP,PIPE
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5000MM(50W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
EXC. CHILE EQUIPMENT(TDK),COLOMBIA
EQUIPMENT(WJ2)
M8X30 FLANGE
|
0-28680-830-0 |
11 |
1 |
9808-0004 |
|
|
● |
● |
|
|
| |
232 |
BOLT; CLIP,PIPE
MIDDLE CHASSIS(FV***F)
FUEL TANK 400L<SDH>
M8X30 FLANGE
|
0-28680-830-0 |
08 |
1 |
0102-0512 |
|
|
● |
|
|
|
| |
232 |
BOLT; CLIP,PIPE
MIDDLE CHASSIS(FV***F)
FUEL TANK 400L<SDH>
M8X30 FLANGE
|
0-28650-830-0 |
08 |
1 |
0601- |
|
|
● |
|
|
|
| |
239 |
CLIP; FUEL PIPE
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
02 |
1 |
9601-9806 |
● |
|
|
|
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
02 |
1 |
9601-9806 |
|
● |
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
02 |
1 |
9807-9901 |
● |
● |
|
|
● |
|
| |
239 |
CLIP; FUEL PIPE
SHORT CHASSIS(FV***C)
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
02 |
1 |
9807-9901 |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
02 |
1 |
9807-9901 |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
SHORT CHASSIS(FV***C)
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
01 |
1 |
9902-0004 |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
01 |
1 |
9902-0004 |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
FUEL TANK 400L<SDH>
COLOMBIA EQUIPMENT(WJ2)
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
02 |
1 |
0005-0101 |
● |
|
|
|
|
|
| |
239 |
CLIP; FUEL PIPE
FUEL TANK 400L<SDH>
COLOMBIA EQUIPMENT(WJ2)
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
02 |
1 |
0102-0109 |
● |
|
|
|
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
FUEL TANK 400L<SDH>
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
02 |
1 |
0102-0109 |
|
|
● |
|
|
|
| |
239 |
CLIP; FUEL PIPE
FUEL TANK 200L FRAME SIDE<N20>
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
02 |
1 |
0110-0607 |
● |
● |
|
|
|
|
| |
239 |
CLIP; FUEL PIPE
FUEL TANK 400L<SDH>
COLOMBIA EQUIPMENT(WJ2)
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
02 |
1 |
0110-0607 |
● |
|
|
|
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
FUEL TANK 400L<SDH>
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
02 |
1 |
0110-0607 |
|
|
● |
|
|
|
| |
239 |
CLIP; FUEL PIPE
FUEL TANK 200L FRAME SIDE<N20>
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
02 |
1 |
0608-0612 |
● |
● |
|
|
|
|
| |
239 |
CLIP; FUEL PIPE
FUEL TANK 400L<SDH>
COLOMBIA EQUIPMENT(WJ2)
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
02 |
1 |
0608-0612 |
● |
|
|
|
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
FUEL TANK 400L<SDH>
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
02 |
1 |
0608-0612 |
|
|
● |
|
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
FUEL TANK 200L FRAME SIDE<N20>
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
02 |
1 |
0608-0612 |
|
|
|
|
|
● |
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
FUEL TANK 200L FRAME SIDE<N20>
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
02 |
1 |
0701- |
● |
● |
|
|
|
● |
| |
239 |
CLIP; FUEL PIPE
SHORT CHASSIS(FV***C)
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
02 |
1 |
0701- |
● |
● |
|
|
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
FUEL TANK 400L<SDH>
COLOMBIA EQUIPMENT(WJ2)
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
02 |
1 |
0701- |
● |
|
|
|
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
FUEL TANK 400L<SDH>
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
02 |
1 |
0701- |
|
|
● |
|
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
FUEL TANK 200L FRAME SIDE<N20>
TAIL PIPE SINGLE HORIZONTAL TURN LEFT<SBR>
(D)
ID=14X29 H=15 L=20
|
1-09700-744-0 |
01 |
1 |
0010-0109 |
● |
|
|
|
|
|
| |
239 |
CLIP; FUEL PIPE
FUEL TANK 200L FRAME SIDE<N20>
TAIL PIPE SINGLE HORIZONTAL TURN LEFT<SBR>
(D)
ID=14X29 H=15 L=20
|
1-09700-744-0 |
01 |
1 |
0110-0607 |
● |
|
|
|
|
|
| |
239 |
CLIP; FUEL PIPE
FUEL TANK 200L FRAME SIDE<N20>
TAIL PIPE SINGLE HORIZONTAL TURN LEFT<SBR>
(D)
ID=14X29 H=15 L=20
|
1-09700-744-0 |
01 |
1 |
0608-0612 |
● |
|
|
|
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
FUEL TANK 200L FRAME SIDE<N20>
TAIL PIPE SINGLE HORIZONTAL TURN LEFT<SBR>
(D)
ID=14X29 H=15 L=20
|
1-09700-744-0 |
01 |
1 |
0608-0612 |
|
|
|
|
|
● |
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
FUEL TANK 200L FRAME SIDE<N20>
TAIL PIPE SINGLE HORIZONTAL TURN LEFT<SBR>
(D)
ID=14X29 H=15 L=20
|
1-09700-744-0 |
01 |
1 |
0701- |
● |
|
|
|
|
● |
| |
239 |
CLIP; FUEL PIPE
SHORT CHASSIS(FV***C)
TAIL PIPE SINGLE HORIZONTAL TURN LEFT<SBR>
(D)
ID=14X29 H=15 L=20
|
1-09700-744-0 |
01 |
1 |
0701- |
● |
|
|
|
|
|
| |
239 |
CLIP; FUEL PIPE
(A)
ID=13X2 H=25 L=50
|
1-09700-777-0 |
01 |
1 |
9601-9806 |
● |
● |
|
|
|
|
| |
239 |
CLIP; FUEL PIPE
(A)
ID=13X2 H=25 L=50
|
1-09700-777-0 |
01 |
1 |
9807-9907 |
● |
● |
|
|
● |
|
| |
239 |
CLIP; FUEL PIPE
(A)
M13X2 H=20 L=60
|
1-09701-280-0 |
01 |
1 |
9908-0004 |
● |
● |
|
|
● |
|
| |
239 |
CLIP; FUEL PIPE
(A)
M13X2 H=20 L=60
|
1-09701-280-0 |
01 |
1 |
0005-0607 |
● |
● |
|
|
|
|
| |
239 |
CLIP; FUEL PIPE
(A)
M13X2 H=20 L=60
|
1-09701-280-0 |
01 |
1 |
0608- |
● |
● |
|
|
|
● |
| |
239 |
CLIP; FUEL PIPE
SHORT CHASSIS(FV***C)
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
04 |
1 |
9601-9807 |
● |
● |
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
SHORT CHASSIS(FV***C)
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
04 |
1 |
9808-0004 |
● |
● |
|
|
● |
|
| |
239 |
CLIP; FUEL PIPE
FUEL TANK 200L FRAME SIDE<N20>
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
04 |
1 |
0005-0006 |
● |
● |
|
|
|
|
| |
239 |
CLIP; FUEL PIPE
(C)
ID=16X2 L=20
|
9-09535-536-0 |
02 |
1 |
0007-0606 |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
(C)
ID=16X2 L=20
|
0-95325-536-0 |
02 |
1 |
0607- |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
02 |
1 |
9902-0004 |
● |
● |
|
|
● |
|
| |
239 |
CLIP; FUEL PIPE
SHORT CHASSIS(FV***C)
(D)
ID=14X29 H=15 L=20
|
1-09700-744-0 |
02 |
1 |
9601-9803 |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5000MM(50W)
(D)
ID=14X29 H=15 L=20
|
1-09700-744-0 |
02 |
1 |
9601-9803 |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
SHORT CHASSIS(FV***C)
(D)
ID=14X29 H=15 L=20
|
1-09700-744-0 |
02 |
1 |
9804-9807 |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5000MM(50W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
(D)
ID=14X29 H=15 L=20
|
1-09700-744-0 |
02 |
1 |
9804-9807 |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5500MM(55W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
CHILE EQUIPMENT(TDK),COLOMBIA EQUIPMENT(WJ2)
(D)
ID=14X29 H=15 L=20
|
1-09700-744-0 |
02 |
1 |
9804-9807 |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
SHORT CHASSIS(FV***C)
(D)
ID=14X29 H=15 L=20
|
1-09700-744-0 |
02 |
1 |
9808-0004 |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5000MM(50W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
(D)
ID=14X29 H=15 L=20
|
1-09700-744-0 |
02 |
1 |
9808-0004 |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
CHILE EQUIPMENT(TDK),COLOMBIA EQUIPMENT(WJ2)
(D)
ID=14X29 H=15 L=20
|
1-09700-744-0 |
02 |
1 |
9808-0004 |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
FUEL TANK 200L FRAME SIDE<N20>
(C)
ID=32 L=50
|
1-09701-055-1 |
02 |
1 |
0005-0101 |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
FUEL TANK 200L FRAME SIDE<N20>
(C)
ID=32 L=50
|
1-09701-055-1 |
02 |
1 |
0102-0612 |
|
|
|
● |
|
|
| |
239 |
CLIP; FUEL PIPE
FUEL TANK 200L FRAME SIDE<N20>,FUEL TANK
400L<SDH>
(C)
ID=32 L=50
|
1-09701-055-1 |
02 |
1 |
0102-0612 |
|
|
● |
|
|
|
| |
239 |
CLIP; FUEL PIPE
SHORT CHASSIS(FV***C)
(C)
ID=32 L=50
|
1-09701-055-1 |
02 |
1 |
0701- |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
FUEL TANK 200L FRAME SIDE<N20>
(C)
ID=32 L=50
|
1-09701-055-1 |
02 |
1 |
0701- |
|
|
|
● |
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
FUEL TANK 200L FRAME SIDE<N20>,FUEL TANK
400L<SDH>
(C)
ID=32 L=50
|
1-09701-055-1 |
02 |
1 |
0701- |
|
|
● |
|
|
|
| |
239 |
CLIP; FUEL PIPE
SHORT CHASSIS(FV***C)
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
09 |
1 |
9601-0004 |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
FUEL TANK 200L FRAME SIDE<N20>
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
06 |
1 |
0005-0006 |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
FUEL TANK 200L FRAME SIDE<N20>
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
04 |
1 |
0007-0109 |
● |
● |
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
FUEL TANK 200L FRAME SIDE<N20>
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
04 |
1 |
0110-0612 |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
SHORT CHASSIS(FV***C)
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
04 |
1 |
0701- |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
FUEL TANK 200L FRAME SIDE<N20>
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
04 |
1 |
0701- |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
SHORT CHASSIS(FV***C)
(B)
ID=16X2 H=76 L=50
|
1-09700-902-0 |
01 |
1 |
9902-0004 |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
(B)
ID=16X2 H=76 L=50
|
1-09700-902-0 |
01 |
1 |
9902-0004 |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
FUEL TANK 200L FRAME SIDE<N20>
(B)
ID=16X2 H=76 L=50
|
1-09700-902-0 |
03 |
1 |
0005- |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
WHEEL BASE 4200MM(42W),WHEEL BASE 4600MM(46W),
WHEEL BASE 5500MM(55W)
(D)
ID=14X29 H=15 L=20
|
1-09700-744-0 |
01 |
1 |
9601-9709 |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
WHEEL BASE 4200MM(42W),WHEEL BASE 4600MM(46W),
WHEEL BASE 5500MM(55W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
EXC. EURO2 SPECIFICATION<THN>
(D)
ID=14X29 H=15 L=20
|
1-09700-744-0 |
01 |
1 |
9710-9803 |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
WHEEL BASE 4200MM(42W),WHEEL BASE 4600MM(46W),
WHEEL BASE 5500MM(55W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
EXC. CHILE EQUIPMENT(TDK),COLOMBIA
EQUIPMENT(WJ2)
(D)
ID=14X29 H=15 L=20
|
1-09700-744-0 |
01 |
1 |
9804-0004 |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
WHEEL BASE 4200MM(42W),WHEEL BASE 4600MM(46W),
WHEEL BASE 5500MM(55W)
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
06 |
1 |
9601-9709 |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
WHEEL BASE 4200MM(42W),WHEEL BASE 4600MM(46W),
WHEEL BASE 5500MM(55W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
EXC. EURO2 SPECIFICATION<THN>
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
06 |
1 |
9710-9803 |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5000MM(50W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
CHILE EQUIPMENT(TDK),COLOMBIA EQUIPMENT(WJ2)
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
12 |
1 |
9804-0004 |
|
|
● |
|
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5000MM(50W)
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
07 |
1 |
9601-9803 |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
WHEEL BASE 4200MM(42W),WHEEL BASE 4600MM(46W),
WHEEL BASE 5500MM(55W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
EXC. CHILE EQUIPMENT(TDK),COLOMBIA
EQUIPMENT(WJ2)
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
06 |
1 |
9804-0004 |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5500MM(55W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
CHILE EQUIPMENT(TDK),COLOMBIA EQUIPMENT(WJ2)
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
10 |
1 |
9804-0004 |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5500MM(55W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
EURO2 SPECIFICATION<THN>
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
10 |
1 |
9710-9803 |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
WHEEL BASE 5000MM(50W)
BRAKE SYSTEM FULL AIR DUAL CIRCUIT(Z06)
EXC. CHILE EQUIPMENT(TDK),COLOMBIA
EQUIPMENT(WJ2)
(B)
ID=14X29 H=30 L=25
|
1-09701-101-0 |
07 |
1 |
9804-0004 |
|
|
● |
● |
|
|
| |
239 |
CLIP; FUEL PIPE
MIDDLE CHASSIS(FV***F)
FUEL TANK 400L<SDH>
(B)
ID=16X2 H=76 L=50
|
1-09700-902-0 |
02 |
1 |
0102- |
|
|
● |
|
|
|
| |
288 |
HOSE; RUBBER,FUEL TANK TO TANK
MIDDLE CHASSIS(FV***F)
WHEEL BASE 4600MM(46W)
FUEL TANK 200L+200L<NF7>
L=900
SERVICED BY L=3000
|
0-01262-300-0 |
01 |
1 |
9701-9803 |
|
● |
|
|
|
|
| |
288 |
HOSE; RUBBER,FUEL TANK TO TANK
FUEL TANK 200L+200L<NF7>
L=900
SERVICED BY L=3000
|
0-01262-300-0 |
01 |
1 |
9804-0004 |
|
● |
|
|
|
|
| |
634 |
HOSE; RUBBER RETURN
FUEL TANK 200L FRAME SIDE<N20>
L=3550
SERVICED BY L=8000
|
0-01260-800-0 |
01 |
1 |
0005-0604 |
|
|
● |
● |
|
|
| |
634 |
HOSE; RUBBER RETURN
FUEL TANK 200L FRAME SIDE<N20>
L=3650
SERVICED BY L=8000
|
0-01260-800-0 |
01 |
1 |
0605- |
|
|
● |
● |
|
|
| |
634 |
HOSE; RUBBER RETURN
FUEL TANK 400L<SDH>
COLOMBIA EQUIPMENT(WJ2)
L=1350
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0005- |
● |
|
|
|
|
|
| |
634 |
HOSE; RUBBER RETURN
FUEL TANK 200L FRAME SIDE<N20>
L=1300
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0005-0607 |
● |
● |
|
|
|
|
| |
634 |
HOSE; RUBBER RETURN
FUEL TANK 200L FRAME SIDE<N20>
L=1300
SERVICED BY L=3000
|
0-01260-300-0 |
01 |
1 |
0608- |
● |
● |
|
|
|
● |
| |
634 |
HOSE; RUBBER RETURN
FUEL TANK 400L<SDH>
L=3450
SERVICED BY L=8000
|
0-01260-800-0 |
01 |
1 |
0102- |
|
|
● |
|
|
|
