2 |
HOSE; ACL
|
1-14232-126-0 |
01 |
1 |
0406- |
● |
|
|
|
| |
2 |
HOSE; ACL
FSS STD CAB(FS**M*)
|
1-14231-919-1 |
01 |
1 |
9604-9803 |
|
● |
|
|
| |
2 |
HOSE; ACL
|
1-14231-919-1 |
01 |
1 |
9604-9803 |
|
|
● |
|
| |
2 |
HOSE; ACL
FSS STD CAB(FS**M*)
WEST MALAYSIA EQUIPMENT(SEQ)
|
1-14231-919-1 |
01 |
1 |
9804-0004 |
|
● |
|
|
| |
2 |
HOSE; ACL
WEST MALAYSIA EQUIPMENT(SEQ)
|
1-14231-919-1 |
01 |
1 |
9804-0004 |
|
|
● |
|
| |
2 |
HOSE; ACL
FSS STD CAB(FS**M*)
WEST MALAYSIA EQUIPMENT(SEQ)
|
1-14231-919-1 |
01 |
1 |
0005-0405 |
|
● |
|
● |
| |
2 |
HOSE; ACL
WEST MALAYSIA EQUIPMENT(SEQ)
|
1-14231-919-1 |
01 |
1 |
0005-0405 |
|
|
● |
|
| |
2 |
HOSE; ACL
FSS STD CAB(FS**M*)
WEST MALAYSIA EQUIPMENT(SEQ)
|
1-14231-919-1 |
01 |
1 |
0406- |
|
● |
|
|
| |
2 |
HOSE; ACL
WEST MALAYSIA EQUIPMENT(SEQ)
|
1-14231-919-1 |
01 |
1 |
0406- |
|
|
● |
|
| |
2 |
HOSE; ACL
FTS SHORT CHASSIS(FT***C)
|
1-14231-951-0 |
01 |
1 |
9604-9612 |
|
● |
|
|
| |
2 |
HOSE; ACL
FTS STD CAB MIDDLE CHASSIS(FT**MF)
EXC. AUSTRALIA EQUIPMENT(RR3)
|
1-14231-951-0 |
01 |
1 |
9604-9612 |
|
● |
|
|
| |
2 |
HOSE; ACL
FTS ALL(FT****)
EXC. AUSTRALIA EQUIPMENT(RR3),EMISSION SYSTEM
ECE REQUIREMENTS<SFV>
|
1-14231-951-0 |
01 |
1 |
9701-9904 |
|
● |
|
|
| |
2 |
HOSE; ACL
FTS ALL(FT****)
EXC. AUSTRALIA EQUIPMENT(RR3),EMISSION SYSTEM
ECE REQUIREMENTS<SFV>,EURO2 SPECIFICATION<THN>
|
1-14231-951-0 |
01 |
1 |
9905-0004 |
|
● |
|
|
| |
2 |
HOSE; ACL
FTS STD CAB(FT**M*)
EXC. EMISSION SYSTEM ECE REQUIREMENTS<SFV>,
EURO2SPECIFICATION<THN>
|
1-14231-951-0 |
01 |
1 |
0005- |
|
● |
|
|
| |
2 |
HOSE; ACL
FSS STD CAB(FS**M*)
EXC. WEST MALAYSIA EQUIPMENT(SEQ)
|
1-14231-857-0 |
01 |
1 |
9804- |
|
● |
|
|
| |
2 |
HOSE; ACL
EXC. WEST MALAYSIA EQUIPMENT(SEQ)
|
1-14231-857-0 |
01 |
1 |
9804- |
|
|
● |
|
| |
2 |
HOSE; ACL
FSS DOUBLE CAB(FS**W*)
|
1-14231-876-0 |
01 |
1 |
9604-0004 |
|
● |
|
|
| |
2 |
HOSE; ACL
FTS STD CAB MIDDLE CHASSIS(FT**MF)
AUSTRALIA EQUIPMENT(RR3)
|
1-14231-929-0 |
01 |
1 |
9604-9612 |
|
● |
|
|
| |
2 |
HOSE; ACL
FTS STD CAB MIDDLE CHASSIS(FT**MF)
AUSTRALIA EQUIPMENT(RR3)
|
1-14231-929-0 |
01 |
1 |
9701-0004 |
|
● |
|
|
| |
2 |
HOSE; ACL
FTS STD CAB MIDDLE CHASSIS(FT**MF)
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
|
1-14231-929-0 |
01 |
1 |
9701-0004 |
|
● |
|
|
| |
2 |
HOSE; ACL
FTS STD CAB(FT**M*)
EMISSION SYSTEM ECE REQUIREMENTS<SFV>
|
1-14231-929-0 |
01 |
1 |
0005- |
|
● |
|
|
| |
2 |
HOSE; ACL
FTS STD CAB MIDDLE CHASSIS(FT**MF)
EURO2 SPECIFICATION<THN>
EXC. AUSTRALIA EQUIPMENT(RR3)
|
1-14232-069-0 |
01 |
1 |
9905-0004 |
● |
● |
|
● |
| |
2 |
HOSE; ACL
FTS STD CAB(FT**M*)
EURO2 SPECIFICATION<THN>
|
1-14232-069-0 |
01 |
1 |
0005-0010 |
|
● |
|
|
| |
2 |
HOSE; ACL
FTS STD CAB(FT**M*)
EURO2 SPECIFICATION<THN>
|
1-14232-069-0 |
01 |
1 |
0011-0405 |
|
● |
|
|
| |
2 |
HOSE; ACL
|
1-14232-069-0 |
01 |
1 |
0011-0405 |
|
|
|
● |
| |
2 |
HOSE; ACL
FTS STD CAB(FT**M*)
EURO2 SPECIFICATION<THN>
|
1-14232-069-0 |
01 |
1 |
0406- |
|
● |
|
|
| |
2 |
HOSE; ACL
FTS DOUBLE CAB MIDDLE CHASSIS(FT**W*)
|
1-14231-941-0 |
01 |
1 |
9604-0004 |
|
● |
|
|
| |
5 |
CLIP; AIR DUCT
EXC. KD PREPARATORY PACK<6HF>
(A)
ID=87-116
|
1-09707-138-0 |
01 |
1 |
1002- |
● |
● |
● |
● |
| |
5 |
CLIP; AIR DUCT
EXC. KD PREPARATORY PACK<6HF>
(B)
ID=104-142
|
1-09707-139-0 |
01 |
1 |
1002- |
● |
● |
● |
● |
| |
5 |
CLIP; AIR DUCT
EXC. KD PREPARATORY PACK<6HF>
(A)
ID=77-99
|
1-09707-141-0 |
01 |
1 |
1002- |
● |
|
|
|
| |
5 |
CLIP; AIR DUCT
EXC. KD PREPARATORY PACK<6HF>
(B)
ID=130-169
|
8-98155-950-0 |
01 |
1 |
1002- |
● |
|
|
|
| |
5 |
CLIP; AIR DUCT
(A)
ID=77-95
|
1-09707-198-0 |
01 |
1 |
0406-0810 |
● |
|
|
|
| |
5 |
CLIP; AIR DUCT
(A)
ID=75-95
|
8-98133-357-0 |
01 |
1 |
0811-1001 |
● |
|
|
|
| |
5 |
CLIP; AIR DUCT
KD PREPARATORY PACK<6HF>
(A)
ID=75-95
|
8-98133-357-0 |
01 |
1 |
1002- |
● |
|
|
|
| |
5 |
CLIP; AIR DUCT
(B)
ID=130-165
|
1-09707-201-0 |
01 |
1 |
0406-0810 |
● |
|
|
|
| |
5 |
CLIP; AIR DUCT
(B)
ID=130-150
|
8-98133-360-0 |
01 |
1 |
0811-1001 |
● |
|
|
|
| |
5 |
CLIP; AIR DUCT
KD PREPARATORY PACK<6HF>
(B)
ID=130-150
|
8-98133-360-0 |
01 |
1 |
1002- |
● |
|
|
|
| |
5 |
CLIP; AIR DUCT
(A)
ID=87-116
|
1-09707-144-0 |
01 |
1 |
9604-0004 |
|
● |
● |
|
| |
5 |
CLIP; AIR DUCT
(A)
ID=87-116
|
1-09707-144-0 |
01 |
1 |
0005-0212 |
|
● |
● |
● |
| |
5 |
CLIP; AIR DUCT
(A)
ID=87-113
|
1-09707-199-0 |
01 |
1 |
0301-0405 |
|
● |
● |
● |
| |
5 |
CLIP; AIR DUCT
(A)
ID=87-113
|
1-09707-199-0 |
01 |
1 |
0406-0811 |
|
● |
● |
|
| |
5 |
CLIP; AIR DUCT
(A)
ID=90-110
|
8-98133-365-0 |
01 |
1 |
0812-1001 |
|
● |
● |
|
| |
5 |
CLIP; AIR DUCT
KD PREPARATORY PACK<6HF>
(A)
ID=90-110
|
8-98133-365-0 |
01 |
1 |
1002- |
● |
● |
● |
● |
| |
5 |
CLIP; AIR DUCT
(B)
ID=104-142
|
1-09707-155-0 |
01 |
1 |
9604-0004 |
|
● |
● |
|
| |
5 |
CLIP; AIR DUCT
(B)
ID=104-142
|
1-09707-155-0 |
01 |
1 |
0005-0212 |
|
● |
● |
● |
| |
5 |
CLIP; AIR DUCT
(B)
ID=104-139
|
1-09707-200-0 |
01 |
1 |
0301-0405 |
|
● |
● |
● |
| |
5 |
CLIP; AIR DUCT
(B)
ID=104-139
|
1-09707-200-0 |
01 |
1 |
0406-0812 |
|
● |
● |
|
| |
5 |
CLIP; AIR DUCT
(B)
ID=110-130
|
8-98133-359-0 |
01 |
1 |
0901-1001 |
|
● |
● |
|
| |
5 |
CLIP; AIR DUCT
KD PREPARATORY PACK<6HF>
(B)
ID=110-130
|
8-98133-359-0 |
01 |
1 |
1002- |
● |
● |
● |
● |
| |
26 |
DUCT; AIR INT
|
1-14230-173-2 |
01 |
1 |
0406- |
● |
|
|
|
| |
26 |
DUCT; AIR INT
FSS STD CAB(FS**M*)
FTS STD CAB(FT**M*)
|
1-14230-126-4 |
01 |
1 |
9604-9610 |
|
● |
|
|
| |
26 |
DUCT; AIR INT
|
1-14230-126-4 |
01 |
1 |
9604-9610 |
|
|
● |
|
| |
26 |
DUCT; AIR INT
FSS STD CAB(FS**M*)
FTS STD CAB(FT**M*)
|
1-14230-153-0 |
01 |
1 |
9611-9712 |
|
● |
|
|
| |
26 |
DUCT; AIR INT
|
1-14230-153-0 |
01 |
1 |
9611-9712 |
|
|
● |
|
| |
26 |
DUCT; AIR INT
FSS STD CAB(FS**M*)
FTS STD CAB(FT**M*)
|
1-14230-176-0 |
01 |
1 |
9801-0004 |
|
● |
|
|
| |
26 |
DUCT; AIR INT
|
1-14230-176-0 |
01 |
1 |
9801-0004 |
|
|
● |
|
| |
26 |
DUCT; AIR INT
FSS STD CAB(FS**M*)
FTS STD CAB(FT**M*)
|
1-14230-176-2 |
01 |
1 |
0005-0403 |
|
● |
|
● |
| |
26 |
DUCT; AIR INT
|
1-14230-176-2 |
01 |
1 |
0005-0403 |
|
|
● |
|
| |
26 |
DUCT; AIR INT
|
1-14230-176-2 |
01 |
1 |
0404-0405 |
|
● |
● |
● |
| |
26 |
DUCT; AIR INT
|
1-14230-176-2 |
01 |
1 |
0406- |
|
● |
● |
|
| |
26 |
DUCT; AIR INT
FSS DOUBLE CAB(FS**W*)
FTS DOUBLE CAB MIDDLE CHASSIS(FT**W*)
|
1-14230-142-0 |
01 |
1 |
9604-0004 |
|
● |
|
|
| |
35 |
SEAL; DUCT,INT
FSS DOUBLE CAB(FS**W*)
FTS DOUBLE CAB MIDDLE CHASSIS(FT**W*)
OD=30 BLACK
|
1-76798-035-0 |
04 |
1 |
9604-0004 |
|
● |
|
|
| |
48 |
BOLT; AIR DUCT
(A)
M10X60
|
1-09030-044-1 |
02 |
1 |
9604-0004 |
|
● |
● |
|
| |
48 |
BOLT; AIR DUCT
(A)
M10X60
|
1-09030-044-1 |
02 |
1 |
0005-0405 |
|
● |
● |
● |
| |
48 |
BOLT; AIR DUCT
(A)
M10X60
|
1-09030-044-1 |
02 |
1 |
0406- |
● |
● |
● |
|
| |
48 |
BOLT; AIR DUCT
FSS DOUBLE CAB(FS**W*)
FTS DOUBLE CAB MIDDLE CHASSIS(FT**W*)
(B)
M8X20 FLANGE
|
0-28080-820-0 |
02 |
1 |
9604-9606 |
|
● |
|
|
| |
48 |
BOLT; AIR DUCT
FSS DOUBLE CAB(FS**W*)
FTS DOUBLE CAB MIDDLE CHASSIS(FT**W*)
(B)
M8X20 FLANGE
|
0-28680-820-0 |
02 |
1 |
9607-0004 |
|
● |
|
|
| |
56 |
WASHER; LK,AIR INT DUCT
M10
|
1-09500-046-0 |
01 |
1 |
9604-0004 |
|
● |
● |
|
| |
56 |
WASHER; LK,AIR INT DUCT
M10
|
1-09500-046-0 |
01 |
1 |
0005-0405 |
|
● |
● |
● |
| |
56 |
WASHER; LK,AIR INT DUCT
M10
|
1-09500-046-0 |
01 |
1 |
0406- |
● |
● |
● |
|
| |
57 |
WASHER; PL,AIR INT DUCT
ID=10.5 OD=26 T=2.6
|
1-09985-184-0 |
01 |
1 |
9604-0004 |
|
● |
● |
|
| |
57 |
WASHER; PL,AIR INT DUCT
ID=10.5 OD=26 T=2.6
|
1-09985-184-0 |
01 |
1 |
0005-0405 |
|
● |
● |
● |
| |
57 |
WASHER; PL,AIR INT DUCT
ID=10.5 OD=26 T=2.6
|
1-09985-184-0 |
01 |
1 |
0406- |
● |
● |
● |
|
| |
58 |
SUPPORT; AIR INL DUCT
FSS STD CAB(FS**M*)
FTS STD CAB(FT**M*)
OD=40 T=18.5
|
1-14119-267-0 |
04 |
1 |
9604-0004 |
|
● |
|
|
| |
58 |
SUPPORT; AIR INL DUCT
OD=40 T=18.5
|
1-14119-267-0 |
04 |
1 |
9604-0004 |
|
|
● |
|
| |
58 |
SUPPORT; AIR INL DUCT
FSS STD CAB(FS**M*)
FTS STD CAB(FT**M*)
OD=40 T=18.5
|
1-14119-267-0 |
04 |
1 |
0005-0405 |
|
● |
|
● |
| |
58 |
SUPPORT; AIR INL DUCT
OD=40 T=18.5
|
1-14119-267-0 |
04 |
1 |
0005-0405 |
|
|
● |
|
| |
58 |
SUPPORT; AIR INL DUCT
OD=40 T=18.5
|
1-14119-267-0 |
04 |
1 |
0406- |
● |
● |
● |
|
| |
58 |
SUPPORT; AIR INL DUCT
FSS DOUBLE CAB(FS**W*)
FTS DOUBLE CAB MIDDLE CHASSIS(FT**W*)
OD=40 T=18.5
|
1-14119-267-0 |
06 |
1 |
9604-0004 |
|
● |
|
|
| |
60 |
BRACKET; AIR DUCT,UPR
FSS STD CAB(FS**M*)
FTS STD CAB(FT**M*)
|
1-79998-748-2 |
01 |
1 |
9604-0004 |
|
● |
|
|
| |
60 |
BRACKET; AIR DUCT,UPR
|
1-79998-748-2 |
01 |
1 |
9604-0004 |
|
|
● |
|
| |
60 |
BRACKET; AIR DUCT,UPR
FSS STD CAB(FS**M*)
FTS STD CAB(FT**M*)
|
1-79998-748-2 |
01 |
1 |
0005-0405 |
|
● |
|
● |
| |
60 |
BRACKET; AIR DUCT,UPR
|
1-79998-748-2 |
01 |
1 |
0005-0405 |
|
|
● |
|
| |
60 |
BRACKET; AIR DUCT,UPR
|
1-79998-748-2 |
01 |
1 |
0406- |
● |
● |
● |
|
| |
60 |
BRACKET; AIR DUCT,UPR
FSS DOUBLE CAB(FS**W*)
FTS DOUBLE CAB MIDDLE CHASSIS(FT**W*)
|
1-79998-571-2 |
01 |
1 |
9604-0004 |
|
● |
|
|
| |
61 |
BOLT; BRKT,AIR DUCT
FSS STD CAB(FS**M*)
FTS STD CAB(FT**M*)
M8X25 W/LK&PL WASHER
|
1-09980-526-0 |
02 |
1 |
9604-0004 |
|
● |
|
|
| |
61 |
BOLT; BRKT,AIR DUCT
M8X25 W/LK&PL WASHER
|
1-09980-526-0 |
02 |
1 |
9604-0004 |
|
|
● |
|
| |
61 |
BOLT; BRKT,AIR DUCT
FSS STD CAB(FS**M*)
FTS STD CAB(FT**M*)
M8X25 W/LK&PL WASHER
|
1-09980-526-0 |
02 |
1 |
0005-0405 |
|
● |
|
● |
| |
61 |
BOLT; BRKT,AIR DUCT
M8X25 W/LK&PL WASHER
|
1-09980-526-0 |
02 |
1 |
0005-0405 |
|
|
● |
|
| |
61 |
BOLT; BRKT,AIR DUCT
M8X25 W/LK&PL WASHER
|
1-09980-526-0 |
02 |
1 |
0406- |
● |
● |
● |
|
| |
61 |
BOLT; BRKT,AIR DUCT
FSS DOUBLE CAB(FS**W*)
FTS DOUBLE CAB MIDDLE CHASSIS(FT**W*)
M6X19.5 W/LK&PL WASHER
|
8-94279-201-0 |
02 |
1 |
9604-0004 |
|
● |
|
|
| |
63 |
BRACKET; AIR DUCT,LWR
FSS STD CAB(FS**M*)
FTS STD CAB(FT**M*)
|
1-79998-749-3 |
01 |
1 |
9604-0004 |
|
● |
|
|
| |
63 |
BRACKET; AIR DUCT,LWR
|
1-79998-749-3 |
01 |
1 |
9604-0004 |
|
|
● |
|
| |
63 |
BRACKET; AIR DUCT,LWR
FSS STD CAB(FS**M*)
FTS STD CAB(FT**M*)
|
1-79998-749-3 |
01 |
1 |
0005-0405 |
|
● |
|
● |
| |
63 |
BRACKET; AIR DUCT,LWR
|
1-79998-749-3 |
01 |
1 |
0005-0405 |
|
|
● |
|
| |
63 |
BRACKET; AIR DUCT,LWR
|
1-79998-749-3 |
01 |
1 |
0406- |
● |
● |
● |
|
| |
63 |
BRACKET; AIR DUCT,LWR
FSS DOUBLE CAB(FS**W*)
FTS DOUBLE CAB MIDDLE CHASSIS(FT**W*)
|
1-79998-572-2 |
01 |
1 |
9604-0004 |
|
● |
|
|
| |
64 |
BOLT; BRKT,AIR DUCT
M8X25 W/LK&PL WASHER
|
1-09980-526-0 |
02 |
1 |
9604-0004 |
|
● |
● |
|
| |
64 |
BOLT; BRKT,AIR DUCT
M8X25 W/LK&PL WASHER
|
1-09980-526-0 |
02 |
1 |
0005-0405 |
|
● |
● |
● |
| |
64 |
BOLT; BRKT,AIR DUCT
M8X25 W/LK&PL WASHER
|
1-09980-526-0 |
02 |
1 |
0406- |
● |
● |
● |
|
| |
71 |
CLIP; AIR DUCT
FSS DOUBLE CAB(FS**W*)
FTS DOUBLE CAB MIDDLE CHASSIS(FT**W*)
ID=104-142
|
1-09707-155-0 |
01 |
1 |
9604-0004 |
|
● |
|
|
| |
153 |
BRACKET; ACL,FRT
FSS DOUBLE CAB(FS**W*)
|
1-14239-222-0 |
01 |
1 |
9604-0004 |
|
● |
|
|
| |
153 |
BRACKET; ACL,FRT
FTS DOUBLE CAB MIDDLE CHASSIS(FT**W*)
|
1-14239-248-0 |
01 |
1 |
9604-0004 |
|
● |
|
|
| |
154 |
BRACKET; ACL,RR
FSS DOUBLE CAB(FS**W*)
FTS DOUBLE CAB MIDDLE CHASSIS(FT**W*)
|
1-14239-232-0 |
01 |
1 |
9604-0004 |
|
● |
|
|
| |
155 |
BOLT; BRKT
FSS DOUBLE CAB(FS**W*)
FTS DOUBLE CAB MIDDLE CHASSIS(FT**W*)
M8X25 FLANGE
|
0-28080-825-0 |
04 |
1 |
9604-9606 |
|
● |
|
|
| |
155 |
BOLT; BRKT
FSS DOUBLE CAB(FS**W*)
FTS DOUBLE CAB MIDDLE CHASSIS(FT**W*)
M8X25 FLANGE
|
0-28680-825-0 |
04 |
1 |
9607-0004 |
|
● |
|
|
| |
156 |
NUT; BRKT
FSS DOUBLE CAB(FS**W*)
FTS DOUBLE CAB MIDDLE CHASSIS(FT**W*)
M8
|
9-09110-408-0 |
02 |
1 |
9604-9606 |
|
● |
|
|
| |
156 |
NUT; BRKT
FSS DOUBLE CAB(FS**W*)
FTS DOUBLE CAB MIDDLE CHASSIS(FT**W*)
M8 FLANGE
|
0-91150-108-0 |
02 |
1 |
9607-0004 |
|
● |
|
|
| |
179 |
HOSE; AIR INT
FSS DOUBLE CAB(FS**W*)
FTS DOUBLE CAB MIDDLE CHASSIS(FT**W*)
|
1-14231-810-1 |
01 |
1 |
9604-0004 |
|
● |
|
|
| |
180 |
CLIP; AIR INT HOSE
FSS DOUBLE CAB(FS**W*)
FTS DOUBLE CAB MIDDLE CHASSIS(FT**W*)
ID=104-142
|
1-09707-155-0 |
02 |
1 |
9604-0004 |
|
● |
|
|
| |
209 |
BRACKET; ACL
(B)
|
1-53497-701-0 |
02 |
1 |
0406- |
● |
|
|
|
| |
209 |
BRACKET; ACL
(C)
|
1-53497-703-0 |
01 |
1 |
0406- |
● |
|
|
|
| |
209 |
BRACKET; ACL
FSS STD CAB(FS**M*)
(A)
|
1-53497-508-2 |
01 |
1 |
9604-0405 |
● |
● |
|
● |
| |
209 |
BRACKET; ACL
(A)
|
1-53497-508-2 |
01 |
1 |
9604-0405 |
|
|
● |
|
| |
209 |
BRACKET; ACL
FSS ALL(FS****)
(A)
|
1-53497-508-2 |
01 |
1 |
0406- |
|
● |
|
|
| |
209 |
BRACKET; ACL
(A)
|
1-53497-508-2 |
01 |
1 |
0406- |
|
|
● |
|
| |
209 |
BRACKET; ACL
FSS DOUBLE CAB(FS**W*)
FTS DOUBLE CAB MIDDLE CHASSIS(FT**W*)
(A)
|
1-53497-554-0 |
01 |
1 |
9604-0004 |
|
● |
|
|
| |
209 |
BRACKET; ACL
FTS STD CAB(FT**M*)
(A)
|
1-53497-480-2 |
01 |
1 |
9604-9803 |
● |
● |
|
● |
| |
209 |
BRACKET; ACL
FTS STD CAB(FT**M*)
(A)
|
1-53497-480-2 |
01 |
1 |
9804-0004 |
|
● |
|
|
| |
209 |
BRACKET; ACL
FTS STD CAB(FT**M*)
(A)
|
1-53497-480-2 |
01 |
1 |
0005-0403 |
● |
● |
|
● |
| |
209 |
BRACKET; ACL
(A)
|
1-53497-480-2 |
01 |
1 |
0404-0405 |
|
● |
● |
● |
| |
209 |
BRACKET; ACL
FTS ALL(FT****)
(A)
|
1-53497-480-2 |
01 |
1 |
0406- |
|
● |
|
|
| |
210 |
BOLT; ACL BRKT
FSS STD CAB(FS**M*)
M12X35 FLANGE
|
0-28081-235-0 |
04 |
1 |
9604-9606 |
|
● |
|
|
| |
210 |
BOLT; ACL BRKT
M12X35 FLANGE
|
0-28081-235-0 |
04 |
1 |
9604-9606 |
|
|
● |
|
| |
210 |
BOLT; ACL BRKT
FSS STD CAB(FS**M*)
M12X35 FLANGE
|
0-28681-235-0 |
04 |
1 |
9607-0405 |
● |
● |
|
● |
| |
210 |
BOLT; ACL BRKT
M12X35 FLANGE
|
0-28681-235-0 |
04 |
1 |
9607-0405 |
|
|
● |
|
| |
210 |
BOLT; ACL BRKT
FSS STD CAB(FS**M*)
M12X35 FLANGE
|
0-28681-235-0 |
04 |
1 |
0406-0512 |
|
● |
|
|
| |
210 |
BOLT; ACL BRKT
M12X35 FLANGE
|
0-28681-235-0 |
04 |
1 |
0406-0512 |
● |
|
● |
|
| |
210 |
BOLT; ACL BRKT
FSS STD CAB(FS**M*)
M12X35 FLANGE
|
0-28651-235-0 |
04 |
1 |
0601- |
|
● |
|
|
| |
210 |
BOLT; ACL BRKT
M12X35 FLANGE
|
0-28651-235-0 |
04 |
1 |
0601- |
● |
|
● |
|
| |
210 |
BOLT; ACL BRKT
FSS DOUBLE CAB(FS**W*)
FTS DOUBLE CAB MIDDLE CHASSIS(FT**W*)
M12X50 FLANGE
|
0-28081-250-0 |
04 |
1 |
9604-0004 |
|
● |
|
|
| |
210 |
BOLT; ACL BRKT
FTS STD CAB(FT**M*)
M12X35 FLANGE
|
0-28081-235-0 |
02 |
1 |
9604-9606 |
|
● |
|
|
| |
210 |
BOLT; ACL BRKT
FTS STD CAB(FT**M*)
M12X35 FLANGE
|
0-28681-235-0 |
02 |
1 |
9607-0004 |
|
● |
|
|
| |
210 |
BOLT; ACL BRKT
FTS STD CAB(FT**M*)
M12X35 FLANGE
|
0-28681-235-0 |
02 |
1 |
0005-0403 |
● |
● |
|
● |
| |
210 |
BOLT; ACL BRKT
M12X35 FLANGE
|
0-28681-235-0 |
02 |
1 |
0404-0405 |
|
● |
● |
● |
| |
210 |
BOLT; ACL BRKT
FTS ALL(FT****)
M12X35 FLANGE
|
0-28681-235-0 |
02 |
1 |
0406-0512 |
|
● |
|
|
| |
210 |
BOLT; ACL BRKT
FTS ALL(FT****)
M12X35 FLANGE
|
0-28651-235-0 |
02 |
1 |
0601- |
|
● |
|
|
| |
211 |
NUT; BRKT
FSS ALL(FS****)
FTS DOUBLE CAB MIDDLE CHASSIS(FT**W*)
M12 FLANGE
|
0-91150-112-0 |
02 |
1 |
9604-9608 |
● |
● |
|
● |
| |
211 |
NUT; BRKT
M12 FLANGE
|
0-91150-112-0 |
02 |
1 |
9604-9608 |
|
|
● |
|
| |
211 |
NUT; BRKT
FSS ALL(FS****)
FTS DOUBLE CAB MIDDLE CHASSIS(FT**W*)
M12 FLANGE
|
0-91150-212-0 |
02 |
1 |
9609-9609 |
|
● |
|
|
| |
211 |
NUT; BRKT
M12 FLANGE
|
0-91150-212-0 |
02 |
1 |
9609-9609 |
|
|
● |
|
| |
211 |
NUT; BRKT
M12 FLANGE
|
0-91150-212-0 |
02 |
1 |
9610-0602 |
● |
● |
● |
● |
| |
211 |
NUT; BRKT
M12 FLANGE
|
0-91180-212-0 |
02 |
1 |
0603- |
● |
● |
● |
● |
| |
211 |
NUT; BRKT
FTS STD CAB(FT**M*)
M12 FLANGE
|
0-91150-112-0 |
03 |
1 |
9604-9608 |
|
● |
|
|
| |
211 |
NUT; BRKT
FTS STD CAB(FT**M*)
M12 FLANGE
|
0-91150-212-0 |
03 |
1 |
9609-9609 |
|
● |
|
|
| |
245 |
PIECE; DIST,AIR DUCT
FSS STD CAB(FS**M*)
FTS STD CAB(FT**M*)
|
1-79998-228-0 |
02 |
1 |
9604-0004 |
|
● |
|
|
| |
245 |
PIECE; DIST,AIR DUCT
|
1-79998-228-0 |
02 |
1 |
9604-0004 |
|
|
● |
|
| |
245 |
PIECE; DIST,AIR DUCT
FSS STD CAB(FS**M*)
FTS STD CAB(FT**M*)
|
1-79998-228-0 |
02 |
1 |
0005-0405 |
|
● |
|
● |
| |
245 |
PIECE; DIST,AIR DUCT
|
1-79998-228-0 |
02 |
1 |
0005-0405 |
|
|
● |
|
| |
245 |
PIECE; DIST,AIR DUCT
|
1-79998-228-0 |
02 |
1 |
0406- |
● |
● |
● |
|
| |
245 |
PIECE; DIST,AIR DUCT
FSS DOUBLE CAB(FS**W*)
FTS DOUBLE CAB MIDDLE CHASSIS(FT**W*)
|
1-79998-228-0 |
03 |
1 |
9604-0004 |
|
● |
|
|
| |
252 |
DUCT; AIR INT
FSS DOUBLE CAB(FS**W*)
FTS DOUBLE CAB MIDDLE CHASSIS(FT**W*)
(B)
|
1-14219-222-0 |
01 |
1 |
9604-0004 |
|
● |
|
|
| |
252 |
DUCT; AIR INT
FSS DOUBLE CAB(FS**W*)
FTS DOUBLE CAB MIDDLE CHASSIS(FT**W*)
(A)
|
1-14231-819-1 |
01 |
1 |
9604-0004 |
|
● |
|
|
| |
258 |
NUT; AIR DUCT
FSS DOUBLE CAB(FS**W*)
FTS DOUBLE CAB MIDDLE CHASSIS(FT**W*)
M8
|
9-09110-408-0 |
02 |
1 |
9604-9606 |
|
● |
|
|
| |
258 |
NUT; AIR DUCT
FSS DOUBLE CAB(FS**W*)
FTS DOUBLE CAB MIDDLE CHASSIS(FT**W*)
M8 FLANGE
|
0-91150-108-0 |
02 |
1 |
9607-0004 |
|
● |
|
|
| |
259 |
BOLT; AIR DUCT TO BRKT
FSS DOUBLE CAB(FS**W*)
FTS DOUBLE CAB MIDDLE CHASSIS(FT**W*)
M8X20 FLANGE
|
0-28080-820-0 |
02 |
1 |
9604-9606 |
|
● |
|
|
| |
259 |
BOLT; AIR DUCT TO BRKT
FSS DOUBLE CAB(FS**W*)
FTS DOUBLE CAB MIDDLE CHASSIS(FT**W*)
M8X20 FLANGE
|
0-28680-820-0 |
02 |
1 |
9607-0004 |
|
● |
|
|
| |
291 |
BOLT; ACL
M8X20 FLANGE
|
0-28080-820-0 |
04 |
1 |
9604-9606 |
|
● |
● |
|
| |
291 |
BOLT; ACL
M8X20 FLANGE
|
0-28680-820-0 |
04 |
1 |
9607-9609 |
|
● |
● |
|
| |
291 |
BOLT; ACL
FSS DOUBLE CAB(FS**W*)
FTS DOUBLE CAB MIDDLE CHASSIS(FT**W*)
M8X20 FLANGE
|
0-28680-820-0 |
04 |
1 |
9610-0004 |
|
● |
|
|
| |
296 |
NUT; ACL
M8 FLANGE
|
0-91150-108-0 |
04 |
1 |
9604-0004 |
|
● |
● |
|
| |
296 |
NUT; ACL
M8 FLANGE
|
0-91150-108-0 |
04 |
1 |
0005-0405 |
|
● |
● |
● |
| |
296 |
NUT; ACL
M8 FLANGE
|
0-91150-108-0 |
04 |
1 |
0406-0602 |
● |
● |
● |
|
| |
296 |
NUT; ACL
M8 FLANGE
|
0-91180-108-0 |
04 |
1 |
0603- |
● |
● |
● |
|
| |
400 |
NUT; CAP,AIR DUCT
M10
|
1-09984-145-0 |
01 |
1 |
9604-0004 |
|
● |
● |
|
| |
400 |
NUT; CAP,AIR DUCT
M10
|
1-09984-145-0 |
01 |
1 |
0005-0405 |
|
● |
● |
● |
| |
400 |
NUT; CAP,AIR DUCT
M10
|
1-09984-145-0 |
01 |
1 |
0406- |
● |
● |
● |
|
| |
409 |
WASHER; PL,BRKT
FSS DOUBLE CAB(FS**W*)
FTS DOUBLE CAB MIDDLE CHASSIS(FT**W*)
ID=8.4 OD=18
|
9-09160-608-0 |
02 |
1 |
9604-9606 |
|
● |
|
|
