Isuzu WW
▶
PICKUP
▶
TFR
▶
50727 - TFR/TFS(EUROPE)-LHD
▶
9 - Tools
▶
9-32 - REAR BODY; GUARD FRAME
▶
9-32 — REAR BODY; GUARD FRAME
(#36375) — 14 parça
Tümü
A - TFB6CF
B - TFB6SF
C - TFB6WF
D - TFS6CF
E - TFS6SF
F - TFS6WF
7
3
5
37
10
35
61
1
55
61
34
29
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
C
D
E
F
1
17.455 FRAME; GUARD,RR BODY
8-97118-527-3
01
1
9611-
●
●
●
●
●
●
3
17.447 STOPPER; GUARD FRAME,RR BODY
8-94217-998-0
02
1
9611-
●
●
●
●
●
●
5
17.447 WASHER; PL,GUARD FRAME STOPPER
8-94481-019-0
02
1
9611-
●
●
●
●
●
●
7
17.447 BOLT; GUARD FRAME STOPPER,RR BOD
M6X45
8-94481-022-0
02
1
9611-
●
●
●
●
●
●
10
17.447 NUT; GUARD FRAME STOPPER
M6 FLANGE
8-94481-428-0
02
1
9611-
●
●
●
●
●
●
29
17.455 COVER; GUARD FRAME
17.447
8-94430-184-1
02
1
9611-
●
●
●
●
●
●
34
17.455 PANEL; FRT,RR BODY
8-97114-839-1
01
1
9611-
●
●
●
●
34
17.455 PANEL; FRT,RR BODY
8-97114-841-2
01
1
9611-
●
●
35
17.455 BOLT; FRT PANEL,RR BODY
02.559 M8X25 FLANGE
0-28680-825-0
10
1
9611-
●
●
●
●
35
17.455 BOLT; FRT PANEL,RR BODY
02.559 M8X25 FLANGE
0-28680-825-0
06
1
9611-
●
●
37
17.455 BOLT; GUARD FRAME
00.738 M6X16 FLANGE
0-28080-616-0
06
1
9611-
●
●
●
●
●
●
55
17.070 NUT; MEMBER
16.545 M6
9-09114-086-0
06
1
9611-
●
●
●
●
●
●
61
17.447 BAR ASM
(B)
8-97115-003-0
01
1
9611-
●
●
●
●
●
●
61
17.447 BAR ASM
(A)
8-97117-550-1
01
1
9611-
●
●
●
●
●
●
