8-21 — METER ASM (#36040) — 58 parça

2 1 110 480 81 461 8

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
1	METER COMPL; CLUSTER AUSTRALIA EQUIPMENT(B13) EXC. MULTI INFORMATION DISPLAY<7NY>	8-98070-126-6	01	1	0809-	●
1	METER COMPL; CLUSTER EXC. AUSTRALIA EQUIPMENT(B13),MULTI INFORMATION DISPLAY<7NY>	8-98064-911-5	01	1	0809-1010	●
1	METER COMPL; CLUSTER EXC. AUSTRALIA EQUIPMENT(B13),AUTO CRUISE<K30>, MULTI INFORMATION DISPLAY<7NY>	8-98064-911-6	01	1	1011-	●
1	METER COMPL; CLUSTER	8-98064-930-3	01	1	0710-0808	●	●
1	METER COMPL; CLUSTER 6HK1-TCS ENG(80L)	8-98064-930-5	01	1	0809-		●
1	METER COMPL; CLUSTER AUSTRALIA EQUIPMENT(B13) MULTI INFORMATION DISPLAY<7NY>	8-98064-930-5	01	1	0809-	●
2	PANEL; CLUSTER	8-98054-432-0	01	1	0710-	●	●
8	TACHOGRAPH; CLUSTER METER TACHOGRAPH 140KM/H<WC7>	8-97387-082-2	01	1	0710-	●	●
81	METER SUB ASM AUSTRALIA EQUIPMENT(B13) EXC. MULTI INFORMATION DISPLAY<7NY>	8-98079-681-0	01	1	0809-	●
81	METER SUB ASM EXC. AUSTRALIA EQUIPMENT(B13),MULTI INFORMATION DISPLAY<7NY>	8-98079-680-0	01	1	0809-1010	●
81	METER SUB ASM EXC. AUSTRALIA EQUIPMENT(B13),AUTO CRUISE<K30>, MULTI INFORMATION DISPLAY<7NY>	8-98079-680-0	01	1	1011-	●
81	METER SUB ASM	8-98079-689-0	01	1	0710-0808	●	●
81	METER SUB ASM 6HK1-TCS ENG(80L)	8-98079-689-0	01	1	0809-		●
81	METER SUB ASM AUSTRALIA EQUIPMENT(B13) MULTI INFORMATION DISPLAY<7NY>	8-98079-689-0	01	1	0809-	●
110	GLASS; CLUSTER METER EXC. MULTI INFORMATION DISPLAY<7NY>	8-98054-431-0	01	1	0809-1010	●
110	GLASS; CLUSTER METER AUSTRALIA EQUIPMENT(B13) EXC. MULTI INFORMATION DISPLAY<7NY>	8-98054-431-0	01	1	1011-	●
110	GLASS; CLUSTER METER EXC. AUSTRALIA EQUIPMENT(B13),AUTO CRUISE<K30>, MULTI INFORMATION DISPLAY<7NY>	8-98054-431-0	01	1	1011-	●
110	GLASS; CLUSTER METER	8-98054-642-0	01	1	0710-0808	●	●
110	GLASS; CLUSTER METER 6HK1-TCS ENG(80L)	8-98054-642-0	01	1	0809-		●
110	GLASS; CLUSTER METER AUSTRALIA EQUIPMENT(B13) MULTI INFORMATION DISPLAY<7NY>	8-98054-642-0	01	1	0809-	●
461	CARTRIDGE ASM; TACHOGRAPH TACHOGRAPH 140KM/H<WC7>	1-83129-433-0	01	1	0710-	●	●
480	COVER; METER (B) BLACK	8-98054-433-0	01	1	0710-	●	●
480	COVER; METER (A) BLACK DOT MATRIX FOR FPC PROTECTION	8-98054-881-0	01	1	0710-0808	●	●
480	COVER; METER 6HK1-TCS ENG(80L) (A) BLACK DOT MATRIX FOR FPC PROTECTION	8-98054-881-0	01	1	0809-		●
480	COVER; METER AUSTRALIA EQUIPMENT(B13) MULTI INFORMATION DISPLAY<7NY> (A) BLACK DOT MATRIX FOR FPC PROTECTION	8-98054-881-0	01	1	0809-	●

8 461 8 21 259 31 11 1 1 81 2 480 110 480

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
1	METER COMPL; CLUSTER AUSTRALIA EQUIPMENT(B13) EXC. MULTI INFORMATION DISPLAY<7NY>	8-98070-126-6	01	1	0809-	●
1	METER COMPL; CLUSTER EXC. AUSTRALIA EQUIPMENT(B13),MULTI INFORMATION DISPLAY<7NY>	8-98064-911-5	01	1	0809-1010	●
1	METER COMPL; CLUSTER EXC. AUSTRALIA EQUIPMENT(B13),AUTO CRUISE<K30>, MULTI INFORMATION DISPLAY<7NY>	8-98064-911-6	01	1	1011-	●
1	METER COMPL; CLUSTER	8-98064-930-3	01	1	0710-0808	●	●
1	METER COMPL; CLUSTER 6HK1-TCS ENG(80L)	8-98064-930-5	01	1	0809-		●
1	METER COMPL; CLUSTER AUSTRALIA EQUIPMENT(B13) MULTI INFORMATION DISPLAY<7NY>	8-98064-930-5	01	1	0809-	●
2	PANEL; CLUSTER	8-98054-432-0	01	1	0710-	●	●
8	TACHOGRAPH; CLUSTER METER TACHOGRAPH 140KM/H<WC7>	8-97387-082-2	01	1	0710-	●	●
11	CLUSTER ASM; METER TACHOGRAPH DIGITAL<EBB> DARK GRAY	8-97414-681-0	01	1	0801-0805	●	●
11	CLUSTER ASM; METER DARK GRAY	8-97405-350-3	01	1	0710-0712	●	●
11	CLUSTER ASM; METER EXC. TACHOGRAPH DIGITAL<EBB> DARK GRAY	8-97405-350-6	01	1	0801-0805	●	●
11	CLUSTER ASM; METER DARK GRAY	8-97405-350-6	01	1	0806-	●	●
21	HARNESS; TACHOGRAPH TACHOGRAPH DIGITAL<EBB>	8-98078-839-0	01	1	0710-0802	●	●
21	HARNESS; TACHOGRAPH TACHOGRAPH 140KM/H<WC7>	8-98074-077-0	01	1	0710-	●	●
31	SCREW; METER,INST PANEL M5X16 TAPPING HEXALOBULAR	0-72180-516-0	04	1	0710-	●	●
81	METER SUB ASM AUSTRALIA EQUIPMENT(B13) EXC. MULTI INFORMATION DISPLAY<7NY>	8-98079-681-0	01	1	0809-	●
81	METER SUB ASM EXC. AUSTRALIA EQUIPMENT(B13),MULTI INFORMATION DISPLAY<7NY>	8-98079-680-0	01	1	0809-1010	●
81	METER SUB ASM EXC. AUSTRALIA EQUIPMENT(B13),AUTO CRUISE<K30>, MULTI INFORMATION DISPLAY<7NY>	8-98079-680-0	01	1	1011-	●
81	METER SUB ASM	8-98079-689-0	01	1	0710-0808	●	●
81	METER SUB ASM 6HK1-TCS ENG(80L)	8-98079-689-0	01	1	0809-		●
81	METER SUB ASM AUSTRALIA EQUIPMENT(B13) MULTI INFORMATION DISPLAY<7NY>	8-98079-689-0	01	1	0809-	●
110	GLASS; CLUSTER METER EXC. MULTI INFORMATION DISPLAY<7NY>	8-98054-431-0	01	1	0809-1010	●
110	GLASS; CLUSTER METER AUSTRALIA EQUIPMENT(B13) EXC. MULTI INFORMATION DISPLAY<7NY>	8-98054-431-0	01	1	1011-	●
110	GLASS; CLUSTER METER EXC. AUSTRALIA EQUIPMENT(B13),AUTO CRUISE<K30>, MULTI INFORMATION DISPLAY<7NY>	8-98054-431-0	01	1	1011-	●
110	GLASS; CLUSTER METER	8-98054-642-0	01	1	0710-0808	●	●
110	GLASS; CLUSTER METER 6HK1-TCS ENG(80L)	8-98054-642-0	01	1	0809-		●
110	GLASS; CLUSTER METER AUSTRALIA EQUIPMENT(B13) MULTI INFORMATION DISPLAY<7NY>	8-98054-642-0	01	1	0809-	●
259	SCREW; TACHOGRAPH TACHOGRAPH 140KM/H<WC7> M5X7 HEXALOBULAR SOCKET	8-98063-767-0	04	1	0710-	●	●
461	CARTRIDGE ASM; TACHOGRAPH TACHOGRAPH 140KM/H<WC7>	1-83129-433-0	01	1	0710-	●	●
480	COVER; METER (B) BLACK	8-98054-433-0	01	1	0710-	●	●
480	COVER; METER (A) BLACK DOT MATRIX FOR FPC PROTECTION	8-98054-881-0	01	1	0710-0808	●	●
480	COVER; METER 6HK1-TCS ENG(80L) (A) BLACK DOT MATRIX FOR FPC PROTECTION	8-98054-881-0	01	1	0809-		●
480	COVER; METER AUSTRALIA EQUIPMENT(B13) MULTI INFORMATION DISPLAY<7NY> (A) BLACK DOT MATRIX FOR FPC PROTECTION	8-98054-881-0	01	1	0809-	●

İpucu: çizimdeki balona veya tablodaki Balon sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
