1 |
DRUM; BRK,RR
BRAKE SYSTEM HEAVY DUTY(J55)
|
1-42315-314-2 |
02 |
1 |
9002- |
| |
1 |
DRUM; BRK,RR
EXC. BRAKE SYSTEM HEAVY DUTY(J55)
|
1-42315-220-4 |
02 |
1 |
9002- |
| |
8 |
HUB; RR AXLE
BRAKE SYSTEM HEAVY DUTY(J55)
H=237.5
|
1-42311-032-4 |
02 |
1 |
9002-9508 |
| |
8 |
HUB; RR AXLE
BRAKE SYSTEM HEAVY DUTY(J55)
|
1-42311-100-0 |
02 |
1 |
9509- |
| |
8 |
HUB; RR AXLE
EXC. BRAKE SYSTEM HEAVY DUTY(J55)
|
1-42311-033-4 |
02 |
1 |
9002- |
| |
9 |
PIN; WHEEL,RR AXLE
BRAKE SYSTEM HEAVY DUTY(J55)
M20X34.5 LH THREAD,M22X51.5 RH THREAD
|
1-42332-110-0 |
08 |
1 |
9002- |
| |
9 |
PIN; WHEEL,RR AXLE
BRAKE SYSTEM HEAVY DUTY(J55)
M20X34.5,M22X51.5 RH THREAD
|
1-42331-110-0 |
08 |
1 |
9002- |
| |
9 |
PIN; WHEEL,RR AXLE
EXC. BRAKE SYSTEM HEAVY DUTY(J55)
M22X51.5,M22X49.5 RH THREAD
|
1-42331-041-0 |
20 |
1 |
9002-9111 |
| |
9 |
PIN; WHEEL,RR AXLE
EXC. BRAKE SYSTEM HEAVY DUTY(J55)
M22X51.5,M22X53.5 RH THREAD
|
1-42331-136-0 |
20 |
1 |
9112- |
| |
10 |
NUT; WHEEL PIN,RR AXLE
BRAKE SYSTEM HEAVY DUTY(J55)
M22
|
9-09110-522-0 |
16 |
1 |
9002- |
| |
10 |
NUT; WHEEL PIN,RR AXLE
EXC. BRAKE SYSTEM HEAVY DUTY(J55)
M22
|
1-09400-037-0 |
20 |
1 |
9002-9111 |
| |
10 |
NUT; WHEEL PIN,RR AXLE
EXC. BRAKE SYSTEM HEAVY DUTY(J55)
M22
|
1-09400-071-0 |
20 |
1 |
9112- |
| |
15 |
BEARING; HUB OUTER,RR AXLE
NSK
|
1-09812-079-0 |
02 |
1 |
9002- |
| |
15 |
BEARING; HUB OUTER,RR AXLE
NACHI
|
1-09812-166-0 |
02 |
1 |
9002- |
| |
16 |
SEAL; OIL,RR HUB,OUTER
NOK
|
1-09625-226-1 |
02 |
1 |
9002- |
| |
16 |
SEAL; OIL,RR HUB,OUTER
TKK
|
1-09625-444-0 |
02 |
1 |
9002- |
| |
20 |
NUT; BRG,RR HUB
M88
|
9-09843-062-2 |
02 |
1 |
9002- |
| |
21 |
WASHER; LK,BRG NUT
ID=88
|
9-09854-112-0 |
02 |
1 |
9002- |
| |
24 |
BOLT; LK WASHER
M6X16 W/LK WASHER
|
9-01910-616-0 |
06 |
1 |
9002-9005 |
| |
24 |
BOLT; LK WASHER
M6X16 W/LK WASHER
|
0-50040-616-0 |
06 |
1 |
9006- |
| |
25 |
SHAFT; AXLE,RR
L=1050
|
1-42171-291-1 |
02 |
1 |
9002-9405 |
| |
25 |
SHAFT; AXLE,RR
L=1054
|
1-42171-355-0 |
02 |
1 |
9406- |
| |
30 |
BOLT; HUB TO AXLE SHAFT
M14X58
|
1-09020-095-1 |
20 |
1 |
9002-9306 |
| |
30 |
BOLT; HUB TO AXLE SHAFT
BRAKE POWER CHAMBER FORWARD<BCQ>
M14X58
|
1-09020-095-1 |
20 |
1 |
9307-9509 |
| |
30 |
BOLT; HUB TO AXLE SHAFT
BRAKE POWER CHAMBER FORWARD<BCQ>
EXC. BRAKE SYSTEM HEAVY DUTY(J55)
M14X58
|
1-09020-095-1 |
20 |
1 |
9510- |
| |
30 |
BOLT; HUB TO AXLE SHAFT
EXC. BRAKE POWER CHAMBER FORWARD<BCQ>
M14X58
|
1-09020-095-1 |
32 |
1 |
9307- |
| |
33 |
WASHER; AXLE SHAFT
ID=14.2
|
9-09150-614-0 |
20 |
1 |
9002-9306 |
| |
33 |
WASHER; AXLE SHAFT
BRAKE POWER CHAMBER FORWARD<BCQ>
ID=14.2
|
9-09150-614-0 |
20 |
1 |
9307-9408 |
| |
33 |
WASHER; AXLE SHAFT
BRAKE POWER CHAMBER FORWARD<BCQ>
ID=14.2
|
9-09150-814-0 |
20 |
1 |
9409-9509 |
| |
33 |
WASHER; AXLE SHAFT
BRAKE POWER CHAMBER FORWARD<BCQ>
EXC. BRAKE SYSTEM HEAVY DUTY(J55)
ID=14.2
|
9-09150-814-0 |
20 |
1 |
9510- |
| |
33 |
WASHER; AXLE SHAFT
EXC. BRAKE POWER CHAMBER FORWARD<BCQ>
ID=14.2
|
9-09150-614-0 |
32 |
1 |
9307-9408 |
| |
33 |
WASHER; AXLE SHAFT
EXC. BRAKE POWER CHAMBER FORWARD<BCQ>
ID=14.2
|
9-09150-814-0 |
32 |
1 |
9409- |
| |
37 |
BEARING; HUB INNER,RR AXLE
NSK
|
1-09812-077-0 |
02 |
1 |
9002- |
| |
37 |
BEARING; HUB INNER,RR AXLE
NACHI
|
1-09812-165-0 |
02 |
1 |
9002- |
| |
38 |
SEAL; OIL,RR HUB,INNER
NOK
|
1-09625-265-0 |
02 |
1 |
9002- |
| |
38 |
SEAL; OIL,RR HUB,INNER
TKK
|
1-09625-350-0 |
02 |
1 |
9002- |
| |
43 |
RING; SNAP,HUB SEAL,RR AXLE
OD=179
|
1-09587-057-0 |
02 |
1 |
9002- |
| |
49 |
CASE; RR AXLE
L TYPE ENG<90L>
BRAKE SYSTEM HEAVY DUTY(J55)
EXC. REAR SHOCK ABSORBER(GL6)
|
1-42150-550-1 |
01 |
1 |
9012-9306 |
| |
49 |
CASE; RR AXLE
L TYPE ENG<90L>
BRAKE SYSTEM HEAVY DUTY(J55)
|
1-42150-550-1 |
01 |
1 |
9307- |
| |
49 |
CASE; RR AXLE
L TYPE ENG<90L>
REAR SHOCK ABSORBER(GL6)
BRAKE SYSTEM HEAVY DUTY(J55)
|
1-42150-552-1 |
01 |
1 |
9012-9306 |
| |
49 |
CASE; RR AXLE
L TYPE ENG<90L>
REAR SHOCK ABSORBER(GL6)
EXC. BRAKE SYSTEM HEAVY DUTY(J55)
W/NUT
|
1-42130-923-4 |
01 |
1 |
9002-9306 |
| |
49 |
CASE; RR AXLE
L TYPE ENG<90L>
REAR SHOCK ABSORBER(GL6)
W/NUT
|
1-42130-923-4 |
01 |
1 |
9307-9509 |
| |
49 |
CASE; RR AXLE
L TYPE ENG<90L>
REAR SHOCK ABSORBER(GL6)
EXC. BRAKE SYSTEM HEAVY DUTY(J55)
W/NUT
|
1-42130-923-4 |
01 |
1 |
9510- |
| |
49 |
CASE; RR AXLE
L TYPE ENG<90L>
EXC. REAR SHOCK ABSORBER(GL6),BRAKE SYSTEM HEAVY
DUTY(J55)
WO/NUT
|
1-42130-886-4 |
01 |
1 |
9002- |
| |
49 |
CASE; RR AXLE
V TYPE ENG<91L>
BRAKE SYSTEM HEAVY DUTY(J55)
EXC. REAR SHOCK ABSORBER(GL6)
|
1-42150-403-3 |
01 |
1 |
9002-9306 |
| |
49 |
CASE; RR AXLE
V TYPE ENG<91L>
BRAKE SYSTEM HEAVY DUTY(J55)
|
1-42150-403-3 |
01 |
1 |
9307- |
| |
49 |
CASE; RR AXLE
V TYPE ENG<91L>
REAR SHOCK ABSORBER(GL6)
BRAKE SYSTEM HEAVY DUTY(J55)
|
1-42150-216-3 |
01 |
1 |
9002-9306 |
| |
49 |
CASE; RR AXLE
V TYPE ENG<91L>
REAR SHOCK ABSORBER(GL6)
EXC. BRAKE SYSTEM HEAVY DUTY(J55)
W/NUT
|
1-42130-921-4 |
01 |
1 |
9002-9306 |
| |
49 |
CASE; RR AXLE
V TYPE ENG<91L>
REAR SHOCK ABSORBER(GL6)
W/NUT
|
1-42130-921-4 |
01 |
1 |
9307-9509 |
| |
49 |
CASE; RR AXLE
V TYPE ENG<91L>
REAR SHOCK ABSORBER(GL6)
EXC. BRAKE SYSTEM HEAVY DUTY(J55)
W/NUT
|
1-42130-921-4 |
01 |
1 |
9510- |
| |
49 |
CASE; RR AXLE
V TYPE ENG<91L>
EXC. REAR SHOCK ABSORBER(GL6),BRAKE SYSTEM HEAVY
DUTY(J55)
WO/NUT
|
1-42130-918-4 |
01 |
1 |
9002- |
| |
58 |
PLUG; DRAIN,AXLE CASE
M24X17 FLANGE
|
1-09604-023-0 |
01 |
1 |
9002- |
| |
59 |
GASKET; DRAIN PLUG
ID=26.8
|
9-09920-605-0 |
01 |
1 |
9002- |
| |
60 |
BREATHER; RR AXLE CASE
DESERT ZONE PACKAGE(W01)
|
9-36122-015-1 |
01 |
1 |
9002- |
| |
60 |
BREATHER; RR AXLE CASE
EXC. DESERT ZONE PACKAGE(W01)
|
1-09893-011-1 |
01 |
1 |
9002- |
| |
63 |
PLUG; OIL FILLER,AXLE CASE
|
1-09604-021-0 |
01 |
1 |
9002-9307 |
| |
63 |
PLUG; OIL FILLER,AXLE CASE
|
1-09604-022-0 |
01 |
1 |
9308- |
| |
64 |
GASKET; OIL FILLER,AXLE CASE
ID=24.5 OD=32.5
|
9-09920-392-0 |
01 |
1 |
9002-9307 |
| |
64 |
GASKET; OIL FILLER,AXLE CASE
ID=26.8
|
9-09920-605-0 |
01 |
1 |
9308- |
| |
67 |
BOLT; FINAL DRIVE SETTING
M16X70
|
9-91056-670-0 |
04 |
1 |
9002-9004 |
| |
67 |
BOLT; FINAL DRIVE SETTING
M16X70
|
9-91066-670-0 |
04 |
1 |
9005- |
| |
67 |
BOLT; FINAL DRIVE SETTING
M16X45
|
9-92061-645-0 |
08 |
1 |
9002-9004 |
| |
67 |
BOLT; FINAL DRIVE SETTING
M16X40
|
9-92061-640-0 |
08 |
1 |
9005- |
| |
71 |
WASHER; LK,FINAL DRIVE SETTING
ID=16.2
|
9-09150-516-0 |
12 |
1 |
9002-9004 |
| |
71 |
WASHER; LK,FINAL DRIVE SETTING
ID=16.2
|
9-09150-816-0 |
12 |
1 |
9005- |
| |
74 |
BOLT; RR BRK ASM SETTING
M14X50
|
1-09040-066-0 |
14 |
1 |
9002- |
| |
75 |
WASHER; LK,RR BRK ASM SETTING
ID=14.2
|
9-09150-614-0 |
16 |
1 |
9002-9401 |
| |
75 |
WASHER; LK,RR BRK ASM SETTING
ID=14.2
|
9-09150-814-0 |
16 |
1 |
9402- |
| |
76 |
NUT; RR BRK ASM SETTING
M14
|
9-99110-514-0 |
16 |
1 |
9002- |
| |
161 |
RING; SPRING,REAR WHEEL
EXC. WHEEL 8 STUD 22.5X8.25 165-13<QM6>,WHEEL
8STUD7.50VX20 165-13<Q62>
|
1-42339-025-1 |
20 |
1 |
9002- |
