Isuzu WW
▶
BUSES
▶
LT
▶
11031 - LT134-RHD EURO4
▶
0 - Engine, Emission, Engine Electrical
▶
0-28 - VENTILATION SYSTEM
▶
0-28 — VENTILATION SYSTEM
(#35994) — 27 parça
21
59
188
272
59
63
307
59
316
21
59
59
63
59
151
316
59
63
59
59
63
59
90
279
90
151
262
263
261
263
315
318
3
275
3
3
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
3
GASKET; BODY TO CAP
8-97385-921-0
01
1
0610-
21
BOLT; CLIP
(A) M6X12 FLANGE
0-28050-612-0
01
1
0610-
21
BOLT; CLIP
(B) M8X12 FLANGE
0-28050-812-0
02
1
0610-
59
CLIP; HOSE
(D) ID=31 H=30 L=35
1-09700-994-0
02
1
0610-
59
CLIP; HOSE
(A) ID=30X2 L=28
1-09701-266-0
01
1
0610-
59
CLIP; HOSE
(B) ID=28.5
1-09707-150-0
03
1
0610-
59
CLIP; HOSE
(C) ID=33.6
8-94362-518-0
05
1
0610-
63
HOSE; RUBBER,AIR BREATHER
(A) L=70
0-02828-070-0
01
1
0610-1005
63
HOSE; RUBBER,AIR BREATHER
(A) L=70
0-02728-070-0
01
1
1006-
63
HOSE; RUBBER,AIR BREATHER
(B)
1-09360-925-0
03
1
0610-
90
CLIP; RUBBER HOSE
ID=14
1-09704-102-0
02
1
0610-
151
SEPARATOR; OIL,PCV
8-97602-262-2
01
1
0610-
188
BOLT; BRKT
M6X12 FLANGE
0-28050-612-0
01
1
0610-
261
BOLT; SEPARETOR
M8X16 FLANGE
0-28050-816-0
04
1
0610-
262
BRACKET; OIL SEPARETOR
8-97604-921-0
01
1
0610-
263
BOLT; BRKT,OIL SEPARETOR
M10X25 FLANGE
0-28751-025-0
02
1
0610-
272
BRACKET; PIPE
8-97607-397-0
01
1
0610-
275
CAP; PCV
8-97606-319-0
01
1
0610-
279
HOSE; RUBBER,OIL DRAIN
0-02709-140-0
01
1
0610-0712
279
HOSE; RUBBER,OIL DRAIN
L=160
0-02709-160-0
01
1
0801-
307
HOSE; RUBBER,HEAD COVER TO OIL SEPARAT
8-98055-316-2
01
1
0610-1208
307
HOSE; RUBBER,HEAD COVER TO OIL SEPARAT
8-98218-154-0
01
1
1209-
315
HOSE; RUBBER
8-97615-918-1
01
1
0610-1006
315
HOSE; RUBBER
8-98154-176-1
01
1
1007-
316
HOSE; BREATHER
(B) L=1320
8-97600-189-0
01
1
0610-
316
HOSE; BREATHER
(A) L=800
8-97602-932-0
01
1
0610-
318
ELEMENT KIT; PCV
8-97606-318-0
01
1
0610-
