1 |
SHOE; BRK,FRT
BRAKE SYSTEM HEAVY DUTY(J55)
LEADING
|
1-47110-975-0 |
01 |
1 |
9002- |
| |
1 |
SHOE; BRK,FRT
BRAKE SYSTEM HEAVY DUTY(J55)
TRAILING
|
1-47110-976-0 |
01 |
1 |
9002- |
| |
1 |
SHOE; BRK,FRT
BRAKE SYSTEM HEAVY DUTY(J55)
LEADING
|
1-47110-973-0 |
01 |
1 |
9002- |
| |
1 |
SHOE; BRK,FRT
BRAKE SYSTEM HEAVY DUTY(J55)
TRAILING
|
1-47110-974-0 |
01 |
1 |
9002- |
| |
1 |
SHOE; BRK,FRT
EXC. BRAKE SYSTEM HEAVY DUTY(J55)
LEADING
|
1-47110-965-0 |
01 |
1 |
9002- |
| |
1 |
SHOE; BRK,FRT
EXC. BRAKE SYSTEM HEAVY DUTY(J55)
TRAILING
|
1-47110-966-0 |
01 |
1 |
9002- |
| |
1 |
SHOE; BRK,FRT
EXC. BRAKE SYSTEM HEAVY DUTY(J55)
LEADING
|
1-47110-963-0 |
01 |
1 |
9002- |
| |
1 |
SHOE; BRK,FRT
EXC. BRAKE SYSTEM HEAVY DUTY(J55)
TRAILING
|
1-47110-964-0 |
01 |
1 |
9002- |
| |
2 |
LINING; FRT BRK SHOE,STANDARD
BRAKE SYSTEM HEAVY DUTY(J55)
LEADING
|
1-47115-678-0 |
04 |
1 |
9002- |
| |
2 |
LINING; FRT BRK SHOE,STANDARD
BRAKE SYSTEM HEAVY DUTY(J55)
TRAILING
|
1-47115-744-0 |
04 |
1 |
9002- |
| |
2 |
LINING; FRT BRK SHOE,STANDARD
EXC. BRAKE SYSTEM HEAVY DUTY(J55)
LEADING
|
1-47115-771-0 |
04 |
1 |
9002- |
| |
2 |
LINING; FRT BRK SHOE,STANDARD
EXC. BRAKE SYSTEM HEAVY DUTY(J55)
TRAILING
|
1-47115-814-0 |
04 |
1 |
9002- |
| |
3 |
LINING; FRT BRK SHOE,OVER SIZE
BRAKE SYSTEM HEAVY DUTY(J55)
LEADING
|
1-47115-679-0 |
04 |
1 |
9002- |
| |
3 |
LINING; FRT BRK SHOE,OVER SIZE
BRAKE SYSTEM HEAVY DUTY(J55)
TRAILING
|
1-47115-745-0 |
04 |
1 |
9002- |
| |
3 |
LINING; FRT BRK SHOE,OVER SIZE
EXC. BRAKE SYSTEM HEAVY DUTY(J55)
LEADING
|
1-47115-772-0 |
04 |
1 |
9002- |
| |
3 |
LINING; FRT BRK SHOE,OVER SIZE
EXC. BRAKE SYSTEM HEAVY DUTY(J55)
TRAILING
|
1-47115-815-0 |
04 |
1 |
9002- |
| |
4 |
LINING SET; FRT BRK,STANDARD
BRAKE SYSTEM HEAVY DUTY(J55)
LEADING
|
1-88302-855-0 |
01 |
1 |
9002- |
| |
4 |
LINING SET; FRT BRK,STANDARD
BRAKE SYSTEM HEAVY DUTY(J55)
TRAILING
|
1-88302-982-0 |
01 |
1 |
9002- |
| |
4 |
LINING SET; FRT BRK,STANDARD
EXC. BRAKE SYSTEM HEAVY DUTY(J55)
LEADING
|
1-88302-923-0 |
01 |
1 |
9002- |
| |
4 |
LINING SET; FRT BRK,STANDARD
EXC. BRAKE SYSTEM HEAVY DUTY(J55)
TRAILING
|
1-88302-931-0 |
01 |
1 |
9002- |
| |
5 |
LINING SET; FRT BRK,OVER SIZE
BRAKE SYSTEM HEAVY DUTY(J55)
LEADING
|
1-88302-856-0 |
01 |
1 |
9002- |
| |
5 |
LINING SET; FRT BRK,OVER SIZE
BRAKE SYSTEM HEAVY DUTY(J55)
TRAILING
|
1-88302-983-0 |
01 |
1 |
9002- |
| |
5 |
LINING SET; FRT BRK,OVER SIZE
EXC. BRAKE SYSTEM HEAVY DUTY(J55)
LEADING
|
1-88302-924-0 |
01 |
1 |
9002- |
| |
5 |
LINING SET; FRT BRK,OVER SIZE
EXC. BRAKE SYSTEM HEAVY DUTY(J55)
TRAILING
|
1-88302-932-0 |
01 |
1 |
9002- |
| |
7 |
RIVET; LINING,FRT BRK
L=18.5
|
1-09732-034-0 |
80 |
1 |
9002- |
| |
8 |
BUSHING; BRK SHOE
|
1-47112-011-0 |
04 |
1 |
9002- |
| |
9 |
PIN; SHOE HOLDER
|
1-09744-060-0 |
04 |
1 |
9002- |
| |
12 |
ROLLER; CAM,BRK SHOE
|
1-47113-007-0 |
04 |
1 |
9002- |
| |
13 |
CLIP; ROLLER PIN,BRK SHOE
|
9-47119-022-0 |
04 |
1 |
9002- |
| |
14 |
PIN; SHOE RETURN SPR
L=73.5
|
1-47119-017-1 |
04 |
1 |
9002- |
| |
29 |
SPRING; RETURN,FRT BRK SHOE
|
1-09583-185-2 |
02 |
1 |
9002- |
| |
30 |
BRACKET; ANCHOR,FRT
|
1-47137-119-3 |
01 |
1 |
9002- |
| |
30 |
BRACKET; ANCHOR,FRT
|
1-47137-118-3 |
01 |
1 |
9002- |
| |
31 |
SEAL; OIL,CM/SHF
|
1-09625-228-0 |
02 |
1 |
9002- |
| |
43 |
PIN; ANCHOR
L=106.5
|
1-47131-038-0 |
04 |
1 |
9002- |
| |
44 |
BOLT; LOCK,ANCHOR PIN
M10X16
|
9-02041-016-0 |
02 |
1 |
9002-9204 |
| |
44 |
BOLT; LOCK,ANCHOR PIN
M10X16
|
0-20801-016-0 |
02 |
1 |
9205- |
| |
45 |
WASHER; LK
|
1-47133-007-0 |
02 |
1 |
9002-9109 |
| |
45 |
WASHER; LK
|
1-47133-011-0 |
02 |
1 |
9110- |
| |
46 |
PLATE; LOCK
|
1-47133-005-0 |
02 |
1 |
9002- |
| |
47 |
CAMSHAFT; FRT BRK
|
1-47141-052-0 |
01 |
1 |
9002- |
| |
47 |
CAMSHAFT; FRT BRK
|
1-47141-051-0 |
01 |
1 |
9002- |
| |
48 |
RING; SPACER,CM/SHF
|
1-47143-005-0 |
02 |
1 |
9002- |
| |
49 |
NIPPLE; GREASE,SLACK ADJ
|
9-09031-010-0 |
01 |
1 |
9002- |
| |
49 |
NIPPLE; GREASE,SLACK ADJ
PT1/8 ELBOW 67.5?
|
9-09031-110-0 |
01 |
1 |
9002- |
| |
50 |
RING; FELT,CM/SHF
|
1-09620-009-0 |
02 |
1 |
9002- |
| |
51 |
COLLAR; RING,CM/SHF
|
1-47143-003-0 |
02 |
1 |
9002- |
| |
52 |
BUSHING; SLACK ADJ
|
1-09330-041-0 |
02 |
1 |
9002- |
| |
53 |
ADJUSTER ASM; SLACK
|
1-48270-044-0 |
01 |
1 |
9002- |
| |
53 |
ADJUSTER ASM; SLACK
|
1-48270-043-0 |
01 |
1 |
9002- |
| |
54 |
SPACER; CM/SHF
|
1-47143-004-0 |
02 |
1 |
9002- |
| |
55 |
PLATE; STOPPER,CM/SHF
|
1-47149-021-0 |
02 |
1 |
9002- |
| |
56 |
CLIP; ANCHOR PIN
|
9-09180-038-0 |
02 |
1 |
9002- |
| |
57 |
NIPPLE; GREASE,ANCHOR BRKT
PT1/8 STRAIGHT
|
9-09031-010-0 |
02 |
1 |
9002- |
| |
58 |
PIN; SPLIT,JAW JOINT
OD=3.7 L=28
|
9-08114-028-0 |
02 |
1 |
9002- |
| |
59 |
WASHER; PL,JAW JOINT
ID=17
|
9-09160-516-0 |
02 |
1 |
9002-9401 |
| |
59 |
WASHER; PL,JAW JOINT
ID=17 OD=32
|
9-09160-616-0 |
02 |
1 |
9402- |
| |
60 |
JOINT; JAW,POWER CHAMBER
|
1-09768-060-1 |
02 |
1 |
9002- |
| |
61 |
PIN; JAW JOINT,POWER CHAMBER
|
1-09744-088-0 |
02 |
1 |
9002- |
| |
62 |
NUT; LK,JAW JOINT
M16
|
9-99111-416-0 |
02 |
1 |
9002- |
| |
63 |
NUT; POWER CHAMBER
M16
|
9-99110-416-0 |
04 |
1 |
9002- |
| |
64 |
WASHER; LK,POWER CHAMBER
ID=16.2
|
9-09150-516-0 |
04 |
1 |
9002- |
| |
109 |
BUSHING; CM/SHF,FRT BRK
|
1-47146-003-1 |
04 |
1 |
9002- |
