Isuzu WW
▶
TRUCKS
▶
NQR
▶
51132 - NQR BUS CHAS(THAI)
▶
3 - Brakes, Brake System
▶
3-01 - FRONT WHEEL BRAKE
▶
3-01 — FRONT WHEEL BRAKE
(#35669) — 34 parça
Tümü
A - NPC5SF
B - NPC5SN
15
17
16
18
19
84
99
70
35
70
73
24
25
72
66
76
29
99
71
71
1
67
29
9
130
10
1
11
10
6
26
1
7
1
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
1
SHOE; BRK,FRT
8-97188-455-0
04
1
0701-
●
●
6
LINING KIT; FRT BRK
5-87831-692-0
01
1
0701-
●
●
7
RIVET; LINING,FRT BRK
1-09732-029-0
64
1
0701-
●
●
9
PIN; SHOE HOLDER
8-97122-870-0
04
1
0701-
●
●
10
CUP; SHOE HOLDING
9-47165-096-0
08
1
0701-
●
●
11
SPRING; SHOE HOLDING
5-09580-101-1
04
1
0701-
●
●
15
CYLINDER; WHEEL,FRT BRK
FRONT
8-97353-574-0
01
1
0701-
●
●
15
CYLINDER; WHEEL,FRT BRK
REAR
8-97353-576-0
01
1
0701-
●
●
15
CYLINDER; WHEEL,FRT BRK
FRONT
8-97353-573-0
01
1
0701-
●
●
15
CYLINDER; WHEEL,FRT BRK
REAR
8-97353-575-0
01
1
0701-
●
●
16
SCREW; BLEEDER,FRT BRK
9-47615-027-0
02
1
0701-0710
●
●
16
SCREW; BLEEDER,FRT BRK
8-98050-477-0
02
1
0711-
●
●
17
CAP; BLEEDER,FRT WHEEL CYL
1-47619-009-0
02
1
0701-0710
●
●
17
CAP; BLEEDER,FRT WHEEL CYL
8-98050-479-0
02
1
0711-
●
●
18
STOPPER; ADJ SCREW
8-94128-486-0
04
1
0701-
●
●
19
SCREW; STOPPER SETTING
8-94128-727-0
04
1
0701-
●
●
24
PISTON; FRT WHEEL CYL
8-97353-579-0
04
1
0701-
●
●
25
SCREW; ADJ,FRT WHEEL CYL
8-94414-702-0
04
1
0701-
●
●
26
CUP SET; FRT WHEEL CYL
5-87832-080-0
01
1
0701-
●
●
29
SPRING; RETURN,FRT BRK SHOE
8-97122-869-0
04
1
0701-
●
●
35
BOLT; FRT WHEEL CYL
8-97081-305-0
16
1
0701-
●
●
66
BOLT; OIL SHIELD COVER
M14X40
8-98007-879-0
08
1
0701-
●
●
67
PLATE; BACK,FRT BRK
8-97160-411-0
01
1
0701-
●
●
67
PLATE; BACK,FRT BRK
8-97160-410-0
01
1
0701-
●
●
70
CLIP; PIPE HOLD
8-97022-086-0
04
1
0701-
●
●
71
GROMMET; CHECK HOLE
(A)
8-97017-507-0
02
1
0701-
●
●
71
GROMMET; CHECK HOLE
(B) THA
8-97044-742-1
02
1
0701-
●
●
72
NUT; OIL SHIELD COVER
M14
0-91110-514-0
08
1
0701-
●
●
73
WASHER; LK,OIL SHIELD COVER
ID=14.2
0-91510-814-0
08
1
0701-
●
●
76
PIPE; OIL,BACKWARD,FRT BRK
THA
8-97079-847-0
02
1
0701-
●
●
84
PIPE; BRK,WHEEL CYL TO HOSE
THA
8-97039-677-0
01
1
0701-
●
●
84
PIPE; BRK,WHEEL CYL TO HOSE
THA
8-97039-676-0
01
1
0701-
●
●
99
NUT; ANCHOR PIN
0-92107-605-0
08
1
0701-
●
●
130
SHOE KIT; BRK,FRT
5-87831-693-0
01
1
0701-
●
●
