7 |
04.550 CABLE; CONT,TRANSFER
4HG1-T ENG(RDP),4HG1 ENG(RJH)
|
8-97363-358-1 |
01 |
1 |
0612- |
| |
7 |
04.550 CABLE; CONT,TRANSFER
4HK1-TCN ENG(RDQ)
|
8-97361-762-3 |
01 |
1 |
0612- |
| |
29 |
04.027 BRACKET; TRANSFER CONT
04.439
|
8-97117-352-0 |
01 |
1 |
0612- |
| |
39 |
04.027 WASHER; LK
00.832
ID=15 OD=25
|
8-11053-111-0 |
01 |
1 |
0612- |
| |
48 |
04.012 BUSHING; CONT LEVER
04.792
|
8-94238-596-0 |
02 |
1 |
0612- |
| |
50 |
04.027 BRACKET; CONT LEVER
04.439
|
8-97088-406-3 |
01 |
1 |
0612- |
| |
60 |
04.027 BOLT; BRKT
00.662
(C)
M8X14 FLANGE
|
0-28080-814-0 |
01 |
1 |
0612- |
| |
60 |
04.027 BOLT; BRKT
02.559
(A)
M4X10 W/LK&PL WASHER
|
0-36230-410-0 |
01 |
1 |
0612- |
| |
60 |
04.027 BOLT; BRKT
01.531
(B)
M8X16 W/LK WASHER
|
0-50540-816-0 |
02 |
1 |
0612- |
| |
66 |
04.006 LEVER; CHANGE
|
8-97311-454-1 |
01 |
1 |
0612- |
| |
93 |
04.030 LEVER; TRANSFER SELECT CONT
|
8-97177-802-1 |
01 |
1 |
0612- |
| |
105 |
04.027 PIN; SNAP,CONT CABLE,TRANSFER
00.833
L=27.7
|
8-94111-137-0 |
02 |
1 |
0612- |
| |
107 |
04.027 CLIP; CONT CABLE,TRANSFER
(B)
|
8-94152-900-0 |
01 |
1 |
0612- |
| |
107 |
04.027 CLIP; CONT CABLE,TRANSFER
4HG1-T ENG(RDP),4HG1 ENG(RJH)
02.559
(E)
L=250
|
5-09707-030-1 |
01 |
1 |
0612- |
| |
107 |
04.027 CLIP; CONT CABLE,TRANSFER
4HG1-T ENG(RDP),4HG1 ENG(RJH)
03.162
(A)
L=140
|
5-09707-031-1 |
02 |
1 |
0612- |
| |
107 |
04.027 CLIP; CONT CABLE,TRANSFER
4HG1-T ENG(RDP),4HG1 ENG(RJH)
02.559
(C)
ID=13 L=90
|
8-97015-782-1 |
01 |
1 |
0612- |
| |
107 |
04.027 CLIP; CONT CABLE,TRANSFER
4HK1-TCN ENG(RDQ)
03.162
(D)
ID=21 H=25.5 L=26
|
8-94176-806-0 |
01 |
1 |
0612- |
| |
110 |
04.027 CLIP; CONT CABLE,TRANSFER
4HG1-T ENG(RDP),4HG1 ENG(RJH)
ID=21 & 9.8
|
8-97309-945-0 |
01 |
1 |
0612- |
| |
152 |
04.027 WASHER; PL,CONT CABLE
03.417
ID=8.4 OD=16
|
0-91610-508-0 |
02 |
1 |
0612- |
| |
154 |
04.570 ACTUATOR; SELECT,TRANSFER
|
8-98031-513-0 |
01 |
1 |
0612- |
| |
155 |
04.570 BOLT; SELECT ACTUATOR
01.531
M8X20 FLANGE
|
0-28650-820-0 |
02 |
1 |
0612- |
| |
156 |
04.570 PIN; JOINT,SELECT ACTUATOR
OD=4 L=16
|
0-82353-416-0 |
01 |
1 |
0612- |
| |
157 |
04.570 PIN; SNAP,SELECT ACTUATOR
|
1-09747-001-0 |
01 |
1 |
0612- |
| |
176 |
04.027 WASHER; CONT LEVER
04.595
ID=8.4 OD=22
|
0-91610-708-0 |
01 |
1 |
0612- |
| |
182 |
04.027 NUT
00.777
M8 W/LK WASHER
|
8-94279-050-0 |
01 |
1 |
0612- |
| |
187 |
04.012 BOLT; CONT LEVER
00.662
M8X14 FLANGE
|
0-28080-814-0 |
03 |
1 |
0612- |
| |
193 |
04.027 STOPPER
04.439
|
8-97117-351-0 |
01 |
1 |
0612- |
| |
196 |
04.027 BRACKET; CONT CABLE,TRANSFER
|
8-97088-407-1 |
01 |
1 |
0612- |
