Isuzu WW
▶
TRUCKS
▶
EXR
▶
10672 - EXR LHD
▶
0 - Engine, Emission, Engine Electrical
▶
0-22A - ENGINE MOUNTING
▶
0-22A — ENGINE MOUNTING
(#3487) — 40 parça
Tümü
A - 6RB1 STD ENG
B - 6RB1TC-N ENG
83
89
105
106
90
89
91
90
91
92
99
104
99
97
100
68
101
93
94
95
96
102
101
103
27
28
29
1
2
11
20
42
43
73
33
32
31
30
52
97
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
1
RUBBER; ENG FOOT,FRT
1-53215-132-2
02
1
9002-
●
●
2
FOOT; ENG
1-11771-142-0
02
1
9002-
●
●
11
BRACKET; CUSHION RUBBER,FRT
1-53211-120-1
01
1
9002-
●
●
11
BRACKET; CUSHION RUBBER,FRT
1-53211-119-1
01
1
9002-
●
●
20
BOLT; ENG FOOT
M14X32
9-92361-432-0
07
1
9002-
●
●
27
NUT; CUSHION RUBBER TO ENG FOOT
M18
9-99110-418-0
02
1
9002-
●
●
28
WASHER; LK,SUPPORT BRKT
ID=18.2
9-09150-518-0
02
1
9002-
●
●
29
PLATE; LK,CUSHION RUBBER,FRT
1-53229-040-0
02
1
9002-
●
●
30
BOLT; BRKT TO FRAME
M14X35
9-92061-435-0
08
1
9002-
●
●
31
WASHER; LK,BRKT TO FRAME
ID=14.2
9-09150-814-0
08
1
9002-
●
●
32
WASHER; PL,BRKT TO FRAME
ID=15 OD=26
9-09164-514-0
08
1
9002-
●
●
33
NUT; CUSHION RUBBER TO BRKT
M14
9-99110-414-0
04
1
9002-
●
●
42
BOLT; FOOT COOLER BRKT
M14X45
9-92361-445-0
01
1
9002-
●
●
43
WASHER; ENG FOOT
ID=14.2
1-09503-050-0
08
1
9002-
●
●
52
RUBBER; CUSHION,ENG MTG,RR
1-53220-088-1
02
1
9002-
●
●
68
WASHER; LK,CUSHION RUBBER
ID=16.2
9-09150-516-0
02
1
9002-
●
●
73
WASHER; LK,CUSHION RUBBER TO FRAME
(A) ID=14.2
9-09150-514-0
04
1
9002-
●
●
83
NUT; UPR BRKT RR
M12
9-99110-512-0
08
1
9002-
●
●
89
BOLT; BRKT
M16X55
9-92361-655-0
02
1
9002-
●
●
89
BOLT; BRKT
M16X70
9-92361-670-0
02
1
9002-
●
●
90
WASHER; LK
ID=16.2
9-09150-616-0
04
1
9002-
●
●
91
WASHER; PL
ID=16.2
1-09503-223-0
04
1
9002-
●
●
92
BRACKET; ENG TO CUSHION RUBBER
1-53221-130-3
01
1
9002-
●
●
92
BRACKET; ENG TO CUSHION RUBBER
1-53221-129-3
01
1
9002-
●
●
93
BRACKET; MEMBER,ENG MTG RR
1-53221-128-1
02
1
9002-
●
●
94
WASHER; PL,BRKT
ID=15
9-09651-069-0
08
1
9002-
●
●
95
WASHER; LK,BRKT
ID=14.2
9-09150-614-0
08
1
9002-
●
●
96
BOLT; BRKT
M14X45
9-92061-445-0
08
1
9002-
●
●
97
RUBBER; STOPPER
9-53225-239-0
04
1
9002-
●
●
99
BOLT; LWR BRKT RR
M14X32
9-92351-432-0
08
1
9002-9005
●
99
BOLT; LWR BRKT RR
M14X32
0-23801-432-0
08
1
9006-
●
●
99
BOLT; LWR BRKT RR
M12X60
1-09000-431-0
08
1
9002-
●
●
100
NUT; CUSHION RUBBER
M16
9-99110-416-0
02
1
9002-
●
●
101
COLLAR; CUSHION RUBBER
9-53229-075-0
04
1
9002-
●
●
102
BRACKET; LWR CUSHION RUBBER
1-53221-101-3
01
1
9002-
●
●
102
BRACKET; LWR CUSHION RUBBER
1-53221-136-3
01
1
9002-
●
●
103
BOLT; CUSHION RUBBER RR,LWR
M16X200
9-09801-097-0
02
1
9002-
●
●
104
WASHER; PL,CUSHION RUBBER
ID=15
9-09651-069-0
08
1
9002-
●
●
105
WASHER
ID=12.2
1-09503-224-0
16
1
9002-
●
●
106
MEMBER; MTG,RR
1-53221-134-4
01
1
9002-
●
●
