Isuzu WW
▶
TRUCKS
▶
NPR
▶
51397 - NPR/NQR(AUST)
▶
7 - Interior Trim, Emblems / Labels, Seats, Mirrors
▶
7-41 - UNDER COVER; INSTRUMENT
▶
7-41 — UNDER COVER; INSTRUMENT
(#34862) — 15 parça
Tümü
A - NPC5SC
B - NPC5SF
C - NPC5SK
D - NPC5SN
E - NPC5WF
53
88
58
42
53
67
48
53
53
53
53
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
C
D
E
42
16.110 BRACKET; UNDER COVER
8-97217-299-1
01
1
0211-
●
●
●
●
●
48
16.081 NUT; UNDER COVER
04.594 M6 FLANGE
0-91150-106-0
02
1
0211-0602
●
●
●
●
●
48
16.081 NUT; UNDER COVER
01.062 M6 FLANGE
0-91180-106-0
02
1
0603-
●
●
●
●
●
53
16.085 CLIP; UNDER COVER
16.100 (A)
8-97853-169-0
04
1
0211-
●
●
●
●
●
53
16.085 CLIP; UNDER COVER
(B)
8-97853-249-5
03
1
0211-
●
●
●
●
●
53
16.085 CLIP; UNDER COVER
06.521 (C) DARK GRAY
8-97857-542-0
01
1
0211-0501
●
●
●
●
●
53
16.085 CLIP; UNDER COVER
06.521 (C) DARK GRAY
8-97582-246-0
01
1
0502-
●
●
●
●
●
58
09.264 SCREW; UNDER COVER
16.067 M5X14
8-94279-325-0
02
1
0211-0612
●
●
●
●
●
58
09.264 SCREW; UNDER COVER
09.655 M5X14 TAPPING W/TORQUES
8-98061-856-0
02
1
0701-
●
●
●
●
●
67
16.081 COVER; UNDER,INST PNL
8-97856-661-6
01
1
0211-
●
●
●
●
●
88
16.081 COVER; UNDER,INST PNL SIDE
H.S.A SYSTEM<6EP> EXC. TRANSMISSION CONTROL-SMOOTHER(8GF) DARK GRAY
8-97582-204-2
01
1
0502-
●
●
●
●
88
16.081 COVER; UNDER,INST PNL SIDE
TRANSMISSION CONTROL-SMOOTHER(8GF) EXC. H.S.A SYSTEM<6EP> DARK GRAY
8-97582-204-2
01
1
0502-
●
●
●
●
88
16.081 COVER; UNDER,INST PNL SIDE
DARK GRAY
8-97582-204-2
01
1
0502-
●
88
16.081 COVER; UNDER,INST PNL SIDE
DARK GRAY
8-97859-801-2
01
1
0211-0501
●
●
●
●
●
88
16.081 COVER; UNDER,INST PNL SIDE
EXC. H.S.A SYSTEM<6EP>,TRANSMISSION CONTROL-SMOOTHER(8GF) DARK GRAY
8-97582-201-2
01
1
0502-
●
●
●
●
