1 |
04.351 SHAFT; TOP GEAR,TRANS
Z=29
|
8-97091-650-1 |
01 |
1 |
9312-9505 |
● |
|
|
|
|
|
|
|
| |
1 |
04.351 SHAFT; TOP GEAR,TRANS
4BD1 ENG(LJ6)
Z=29
|
8-97091-650-1 |
01 |
1 |
9506-9510 |
● |
|
|
|
|
|
|
|
| |
1 |
04.351 SHAFT; TOP GEAR,TRANS
4BD2 ENG(RLW)
Z=26
|
8-97093-120-0 |
01 |
1 |
9312-9510 |
|
● |
|
|
|
|
|
|
| |
1 |
04.351 SHAFT; TOP GEAR,TRANS
Z=26
|
8-97117-712-0 |
01 |
1 |
9511-9611 |
|
|
● |
|
|
|
|
|
| |
1 |
04.351 SHAFT; TOP GEAR,TRANS
Z=26
|
8-97168-983-0 |
01 |
1 |
9612-9711 |
|
|
● |
|
|
|
|
|
| |
1 |
04.351 SHAFT; TOP GEAR,TRANS
4HG1 ENG(RJH),4HF1 ENG(RLS),4BD2
ENG(RLW),4HE1 ENG(RLY)
Z=29
|
8-97183-680-0 |
01 |
1 |
9712-9804 |
|
|
|
● |
|
|
|
|
| |
1 |
04.351 SHAFT; TOP GEAR,TRANS
4HE1 ENG(RLY)
Z=29
|
8-97183-680-0 |
01 |
1 |
9805- |
|
|
|
● |
|
|
|
|
| |
1 |
04.351 SHAFT; TOP GEAR,TRANS
Z=29
|
8-97034-848-0 |
01 |
1 |
9312-9506 |
|
|
|
● |
● |
|
|
|
| |
1 |
04.351 SHAFT; TOP GEAR,TRANS
4HF1 ENG(RLS)
Z=29
|
8-97034-848-0 |
01 |
1 |
9507-9510 |
|
|
|
● |
● |
|
|
|
| |
1 |
04.351 SHAFT; TOP GEAR,TRANS
4HF1 ENG(RLS),4BD2 ENG(RLW)
Z=29
|
8-97034-848-0 |
01 |
1 |
9511-9612 |
|
|
|
● |
● |
● |
|
|
| |
1 |
04.351 SHAFT; TOP GEAR,TRANS
4HF1 ENG(RLS),4BD2 ENG(RLW)
Z=29
|
8-97168-980-0 |
01 |
1 |
9612-9711 |
|
|
|
● |
● |
● |
|
|
| |
1 |
04.351 SHAFT; TOP GEAR,TRANS
4HG1 ENG(RJH),4HF1 ENG(RLS),4BD2
ENG(RLW)
Z=29
|
8-97168-980-0 |
01 |
1 |
9712-9804 |
|
|
|
|
● |
|
|
|
| |
1 |
04.351 SHAFT; TOP GEAR,TRANS
4HG1 ENG(RJH),4HF1 ENG(RLS),4BD2
ENG(RLW)
Z=29
|
8-97168-980-0 |
01 |
1 |
9805- |
|
|
|
● |
● |
|
|
|
| |
1 |
04.351 SHAFT; TOP GEAR,TRANS
Z=30
|
8-97103-632-0 |
01 |
1 |
9312-9506 |
|
|
|
|
|
|
● |
|
| |
1 |
04.351 SHAFT; TOP GEAR,TRANS
4JG2 ENG(RJC)
Z=30
|
8-97103-632-0 |
01 |
1 |
9507- |
|
|
|
|
|
|
● |
|
| |
1 |
04.351 SHAFT; TOP GEAR,TRANS
Z=26
|
8-97035-552-1 |
01 |
1 |
9312-9406 |
|
|
|
|
|
|
|
● |
| |
1 |
04.351 SHAFT; TOP GEAR,TRANS
4BE1 ENG(RLH)
Z=26
|
8-97035-552-1 |
01 |
1 |
9407- |
|
|
|
|
|
|
|
● |
| |
3 |
04.403 BEARING; TOP GEAR SHAFT
04.355
|
8-94178-731-0 |
01 |
1 |
9312-9505 |
● |
● |
|
|
|
|
|
● |
| |
3 |
04.403 BEARING; TOP GEAR SHAFT
4BD1 ENG(LJ6),4BE1 ENG(RLH),4BD2
ENG(RLW)
04.355
|
8-94178-731-0 |
01 |
1 |
9506-9510 |
● |
● |
|
|
|
|
|
● |
| |
3 |
04.403 BEARING; TOP GEAR SHAFT
4BE1 ENG(RLH)
04.355
|
8-94178-731-0 |
01 |
1 |
9511- |
|
|
|
|
|
|
|
● |
| |
3 |
04.403 BEARING; TOP GEAR SHAFT
|
8-97035-047-0 |
01 |
1 |
9312-9506 |
|
|
|
● |
● |
|
|
|
| |
3 |
04.403 BEARING; TOP GEAR SHAFT
4HF1 ENG(RLS)
|
8-97035-047-0 |
01 |
1 |
9507-9510 |
|
|
|
● |
● |
|
|
|
| |
3 |
04.403 BEARING; TOP GEAR SHAFT
4HF1 ENG(RLS),4BD2 ENG(RLW)
|
8-97035-047-0 |
01 |
1 |
9511-9711 |
|
|
● |
● |
● |
● |
|
|
| |
3 |
04.403 BEARING; TOP GEAR SHAFT
4HG1 ENG(RJH),4HF1 ENG(RLS),4BD2
ENG(RLW),4HE1 ENG(RLY)
|
8-97035-047-0 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
|
|
| |
3 |
04.403 BEARING; TOP GEAR SHAFT
04.408
NSK
|
8-94178-732-1 |
01 |
1 |
9312-9506 |
|
|
|
|
|
|
● |
|
| |
3 |
04.403 BEARING; TOP GEAR SHAFT
4JG2 ENG(RJC)
04.408
NSK
|
8-94178-732-1 |
01 |
1 |
9507- |
|
|
|
|
|
|
● |
|
| |
3 |
04.403 BEARING; TOP GEAR SHAFT
04.352
KOYO
|
8-94462-615-0 |
01 |
1 |
9312-9506 |
|
|
|
|
|
|
● |
|
| |
3 |
04.403 BEARING; TOP GEAR SHAFT
4JG2 ENG(RJC)
04.352
KOYO
|
8-94462-615-0 |
01 |
1 |
9507- |
|
|
|
|
|
|
● |
|
| |
4 |
04.416 RING; SNAP,BRG TO TOP GEAR SHAFT
04.353
ID=41.5
|
5-09589-009-0 |
01 |
1 |
9312-9505 |
● |
● |
|
|
|
|
|
● |
| |
4 |
04.416 RING; SNAP,BRG TO TOP GEAR SHAFT
4BD1 ENG(LJ6),4BE1 ENG(RLH),4BD2
ENG(RLW)
04.353
ID=41.5
|
5-09589-009-0 |
01 |
1 |
9506-9510 |
● |
● |
|
|
|
|
|
● |
| |
4 |
04.416 RING; SNAP,BRG TO TOP GEAR SHAFT
4BE1 ENG(RLH)
04.353
ID=41.5
|
5-09589-009-0 |
01 |
1 |
9511- |
|
|
|
|
|
|
|
● |
| |
4 |
04.416 RING; SNAP,BRG TO TOP GEAR SHAFT
|
8-97035-040-0 |
01 |
1 |
9312-9506 |
|
|
|
● |
● |
|
|
|
| |
4 |
04.416 RING; SNAP,BRG TO TOP GEAR SHAFT
4HF1 ENG(RLS)
|
8-97035-040-0 |
01 |
1 |
9507-9510 |
|
|
|
● |
● |
|
|
|
| |
4 |
04.416 RING; SNAP,BRG TO TOP GEAR SHAFT
4HF1 ENG(RLS),4BD2 ENG(RLW)
|
8-97035-040-0 |
01 |
1 |
9511-9711 |
|
|
● |
● |
● |
● |
|
|
| |
4 |
04.416 RING; SNAP,BRG TO TOP GEAR SHAFT
4HG1 ENG(RJH),4HF1 ENG(RLS),4BD2
ENG(RLW),4HE1 ENG(RLY)
|
8-97035-040-0 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
|
|
| |
4 |
04.416 RING; SNAP,BRG TO TOP GEAR SHAFT
08.934
ID=37.0
|
9-09180-040-0 |
01 |
1 |
9312-9506 |
|
|
|
|
|
|
● |
|
| |
4 |
04.416 RING; SNAP,BRG TO TOP GEAR SHAFT
4JG2 ENG(RJC)
08.934
ID=37.0
|
9-09180-040-0 |
01 |
1 |
9507- |
|
|
|
|
|
|
● |
|
| |
13 |
04.415 GEAR; 5TH,MAINSHAFT
Z=23
|
8-94316-706-1 |
01 |
1 |
9312-9505 |
● |
|
|
|
|
|
|
|
| |
13 |
04.415 GEAR; 5TH,MAINSHAFT
4BD1 ENG(LJ6)
Z=23
|
8-94316-706-1 |
01 |
1 |
9506-9510 |
● |
|
|
|
|
|
|
|
| |
13 |
04.415 GEAR; 5TH,MAINSHAFT
Z=23
|
8-97034-856-0 |
01 |
1 |
9312-9506 |
|
|
|
● |
● |
|
|
|
| |
13 |
04.415 GEAR; 5TH,MAINSHAFT
4HF1 ENG(RLS)
Z=23
|
8-97034-856-0 |
01 |
1 |
9507-9510 |
|
|
|
● |
● |
|
|
|
| |
13 |
04.415 GEAR; 5TH,MAINSHAFT
4HF1 ENG(RLS),4BD2 ENG(RLW)
Z=23
|
8-97034-856-0 |
01 |
1 |
9511-9711 |
|
|
|
● |
● |
● |
|
|
| |
13 |
04.415 GEAR; 5TH,MAINSHAFT
4HG1 ENG(RJH),4HF1 ENG(RLS),4BD2
ENG(RLW),4HE1 ENG(RLY)
Z=23
|
8-97034-856-0 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
|
|
| |
13 |
04.415 GEAR; 5TH,MAINSHAFT
Z=25
|
8-97077-339-1 |
01 |
1 |
9312-9506 |
|
|
|
|
|
|
● |
|
| |
13 |
04.415 GEAR; 5TH,MAINSHAFT
4JG2 ENG(RJC)
Z=25
|
8-97077-339-1 |
01 |
1 |
9507-9604 |
|
|
|
|
|
|
● |
|
| |
13 |
04.415 GEAR; 5TH,MAINSHAFT
4JG2 ENG(RJC)
Z=25
|
8-97147-817-0 |
01 |
1 |
9604- |
|
|
|
|
|
|
● |
|
| |
13 |
04.415 GEAR; 5TH,MAINSHAFT
Z=21
|
8-94316-704-1 |
01 |
1 |
9312-9406 |
|
|
|
|
|
|
|
● |
| |
13 |
04.415 GEAR; 5TH,MAINSHAFT
4BE1 ENG(RLH)
Z=21
|
8-94316-704-1 |
01 |
1 |
9407- |
|
|
|
|
|
|
|
● |
| |
14 |
04.419 BEARING; NEEDLE,5TH
|
8-97035-069-0 |
01 |
1 |
9312-9506 |
|
|
|
● |
● |
|
|
|
| |
14 |
04.419 BEARING; NEEDLE,5TH
4HF1 ENG(RLS)
|
8-97035-069-0 |
01 |
1 |
9507-9510 |
|
|
|
● |
● |
|
|
|
| |
14 |
04.419 BEARING; NEEDLE,5TH
4HF1 ENG(RLS),4BD2 ENG(RLW)
|
8-97035-069-0 |
01 |
1 |
9511-9512 |
|
|
|
● |
● |
● |
|
|
| |
14 |
04.419 BEARING; NEEDLE,5TH
4HF1 ENG(RLS),4BD2 ENG(RLW)
|
8-97147-572-0 |
01 |
1 |
9601-9711 |
|
|
|
● |
● |
● |
|
|
| |
14 |
04.419 BEARING; NEEDLE,5TH
4HG1 ENG(RJH),4HF1 ENG(RLS),4BD2
ENG(RLW),4HE1 ENG(RLY)
|
8-97147-572-0 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
|
|
| |
32 |
04.415 COLLAR; 3RD GEAR
|
8-94178-500-2 |
01 |
1 |
9312-9506 |
|
● |
|
● |
● |
|
|
|
| |
32 |
04.415 COLLAR; 3RD GEAR
4HF1 ENG(RLS),4BD2 ENG(RLW)
|
8-94178-500-2 |
01 |
1 |
9507-9510 |
|
● |
|
● |
● |
|
|
|
| |
32 |
04.415 COLLAR; 3RD GEAR
4HF1 ENG(RLS),4BD2 ENG(RLW)
|
8-94178-500-2 |
01 |
1 |
9511-9711 |
|
|
● |
● |
● |
● |
|
|
| |
32 |
04.415 COLLAR; 3RD GEAR
4HG1 ENG(RJH),4HF1 ENG(RLS),4BD2
ENG(RLW),4HE1 ENG(RLY)
|
8-94178-500-2 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
|
|
| |
33 |
04.352 BEARING; NEEDLE,3RD GEAR
NTN
|
8-94340-671-0 |
01 |
1 |
9312-9505 |
● |
|
|
|
|
|
|
● |
| |
33 |
04.352 BEARING; NEEDLE,3RD GEAR
4BD1 ENG(LJ6),4BE1 ENG(RLH)
NTN
|
8-94340-671-0 |
01 |
1 |
9506-9506 |
● |
|
|
|
|
|
|
● |
| |
33 |
04.352 BEARING; NEEDLE,3RD GEAR
4BD1 ENG(LJ6),4BE1 ENG(RLH),4BD2
ENG(RLW)
NTN
|
8-94340-671-0 |
01 |
1 |
9507-9510 |
● |
|
|
|
|
|
|
● |
| |
33 |
04.352 BEARING; NEEDLE,3RD GEAR
4BE1 ENG(RLH)
NTN
|
8-94340-671-0 |
01 |
1 |
9511- |
|
|
|
|
|
|
|
● |
| |
33 |
04.352 BEARING; NEEDLE,3RD GEAR
KOYO
|
8-94388-911-0 |
01 |
1 |
9312-9505 |
● |
|
|
|
|
|
|
● |
| |
33 |
04.352 BEARING; NEEDLE,3RD GEAR
4BD1 ENG(LJ6),4BE1 ENG(RLH)
KOYO
|
8-94388-911-0 |
01 |
1 |
9506-9506 |
● |
|
|
|
|
|
|
● |
| |
33 |
04.352 BEARING; NEEDLE,3RD GEAR
4BD1 ENG(LJ6),4BE1 ENG(RLH),4BD2
ENG(RLW)
KOYO
|
8-94388-911-0 |
01 |
1 |
9507-9510 |
● |
|
|
|
|
|
|
● |
| |
33 |
04.352 BEARING; NEEDLE,3RD GEAR
4BE1 ENG(RLH)
KOYO
|
8-94388-911-0 |
01 |
1 |
9511- |
|
|
|
|
|
|
|
● |
| |
33 |
04.352 BEARING; NEEDLE,3RD GEAR
NSK
|
9-00096-638-0 |
01 |
1 |
9312-9506 |
|
● |
|
● |
● |
|
|
|
| |
33 |
04.352 BEARING; NEEDLE,3RD GEAR
4HF1 ENG(RLS),4BD2 ENG(RLW)
NSK
|
9-00096-638-0 |
01 |
1 |
9507-9510 |
|
● |
|
● |
● |
|
|
|
| |
33 |
04.352 BEARING; NEEDLE,3RD GEAR
4HF1 ENG(RLS),4BD2 ENG(RLW)
NSK
|
9-00096-638-0 |
01 |
1 |
9511-9711 |
|
|
● |
● |
● |
● |
|
|
| |
33 |
04.352 BEARING; NEEDLE,3RD GEAR
4HG1 ENG(RJH),4HF1 ENG(RLS),4BD2
ENG(RLW),4HE1 ENG(RLY)
NSK
|
9-00096-638-0 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
|
|
| |
33 |
04.352 BEARING; NEEDLE,3RD GEAR
4HG1 ENG(RJH),4HF1 ENG(RLS),4BD2
ENG(RLW),4HE1 ENG(RLY)
04.419
NTN
|
8-97201-005-0 |
01 |
1 |
9802- |
|
|
|
● |
● |
|
|
|
| |
33 |
04.352 BEARING; NEEDLE,3RD GEAR
|
8-94317-158-0 |
01 |
1 |
9312-9506 |
|
|
|
|
|
|
● |
|
| |
33 |
04.352 BEARING; NEEDLE,3RD GEAR
4JG2 ENG(RJC)
|
8-94317-158-0 |
01 |
1 |
9507- |
|
|
|
|
|
|
● |
|
| |
35 |
04.383 RING; BLOCK,4TH & 3RD
Z=36
|
8-94128-775-2 |
02 |
1 |
9312-9506 |
● |
● |
|
● |
● |
|
● |
● |
| |
35 |
04.383 RING; BLOCK,4TH & 3RD
4BD1 ENG(LJ6),4JG2 ENG(RJC),4BE1
ENG(RLH),4HF1 ENG(RLS),4BD2 ENG(RLW)
Z=36
|
8-94128-775-2 |
02 |
1 |
9507-9510 |
● |
● |
|
● |
● |
|
● |
● |
| |
35 |
04.383 RING; BLOCK,4TH & 3RD
4BE1 ENG(RLH),4HF1 ENG(RLS),4BD2
ENG(RLW)
Z=36
|
8-94128-775-2 |
02 |
1 |
9511-9606 |
|
|
● |
● |
● |
● |
● |
● |
| |
35 |
04.383 RING; BLOCK,4TH & 3RD
4JG2 ENG(RJC),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW)
Z=36
|
8-94128-775-2 |
02 |
1 |
9607-9711 |
|
|
● |
● |
● |
● |
● |
● |
| |
35 |
04.383 RING; BLOCK,4TH & 3RD
4JG2 ENG(RJC),4HG1 ENG(RJH),4BE1
ENG(RLH),4HF1 ENG(RLS),4BD2 ENG(RLW),
4HE1 ENG(RLY)
Z=36
|
8-94128-775-2 |
02 |
1 |
9712- |
|
|
|
● |
● |
|
● |
● |
| |
36 |
04.415 GEAR; 3RD,MAINSHAFT
Z=38
|
8-94316-686-3 |
01 |
1 |
9312-9505 |
● |
|
|
|
|
|
|
|
| |
36 |
04.415 GEAR; 3RD,MAINSHAFT
4BD1 ENG(LJ6)
Z=38
|
8-94316-686-3 |
01 |
1 |
9506-9510 |
● |
|
|
|
|
|
|
|
| |
36 |
04.415 GEAR; 3RD,MAINSHAFT
4BD2 ENG(RLW)
Z=35 W/SYNCHRO CONE
|
8-94178-501-2 |
01 |
1 |
9312-9510 |
|
● |
|
|
|
|
|
|
| |
36 |
04.415 GEAR; 3RD,MAINSHAFT
Z=35
|
8-97129-448-0 |
01 |
1 |
9511-9711 |
|
|
● |
|
|
|
|
|
| |
36 |
04.415 GEAR; 3RD,MAINSHAFT
4HG1 ENG(RJH),4HF1 ENG(RLS),4BD2
ENG(RLW),4HE1 ENG(RLY)
Z=38
|
8-97183-678-0 |
01 |
1 |
9712-9804 |
|
|
|
● |
|
|
|
|
| |
36 |
04.415 GEAR; 3RD,MAINSHAFT
4HE1 ENG(RLY)
Z=38
|
8-97183-678-0 |
01 |
1 |
9805- |
|
|
|
● |
|
|
|
|
| |
36 |
04.415 GEAR; 3RD,MAINSHAFT
4HF1 ENG(RLS)
Z=37
|
8-97091-430-1 |
01 |
1 |
9312-9510 |
|
|
|
|
● |
|
|
|
| |
36 |
04.415 GEAR; 3RD,MAINSHAFT
4HF1 ENG(RLS),4BD2 ENG(RLW)
Z=37
|
8-97091-430-1 |
01 |
1 |
9511-9711 |
|
|
|
|
● |
|
|
|
| |
36 |
04.415 GEAR; 3RD,MAINSHAFT
4HG1 ENG(RJH),4HF1 ENG(RLS),4BD2
ENG(RLW)
Z=37
|
8-97091-430-1 |
01 |
1 |
9712- |
|
|
|
|
● |
|
|
|
| |
36 |
04.415 GEAR; 3RD,MAINSHAFT
Z=38
|
8-97092-559-1 |
01 |
1 |
9312-9506 |
|
|
|
● |
|
|
|
|
| |
36 |
04.415 GEAR; 3RD,MAINSHAFT
4HF1 ENG(RLS)
Z=38
|
8-97092-559-1 |
01 |
1 |
9507-9510 |
|
|
|
● |
|
|
|
|
| |
36 |
04.415 GEAR; 3RD,MAINSHAFT
4HF1 ENG(RLS),4BD2 ENG(RLW)
Z=38
|
8-97092-559-1 |
01 |
1 |
9511-9711 |
|
|
|
● |
|
● |
|
|
| |
36 |
04.415 GEAR; 3RD,MAINSHAFT
4HG1 ENG(RJH),4HF1 ENG(RLS),4BD2
ENG(RLW)
Z=38
|
8-97208-021-0 |
01 |
1 |
9805- |
|
|
|
● |
|
|
|
|
| |
36 |
04.415 GEAR; 3RD,MAINSHAFT
Z=33
|
8-94316-761-2 |
01 |
1 |
9312-9506 |
|
|
|
|
|
|
● |
|
| |
36 |
04.415 GEAR; 3RD,MAINSHAFT
4JG2 ENG(RJC)
Z=33
|
8-94316-761-2 |
01 |
1 |
9507- |
|
|
|
|
|
|
● |
|
| |
36 |
04.415 GEAR; 3RD,MAINSHAFT
Z=33
|
8-94316-688-3 |
01 |
1 |
9312-9406 |
|
|
|
|
|
|
|
● |
| |
36 |
04.415 GEAR; 3RD,MAINSHAFT
4BE1 ENG(RLH)
Z=33
|
8-94316-688-3 |
01 |
1 |
9407- |
|
|
|
|
|
|
|
● |
| |
40 |
04.384 SPRING; INSERT,LOW & 2ND
|
8-97023-708-0 |
02 |
1 |
9312-9506 |
● |
● |
|
● |
● |
|
● |
● |
| |
40 |
04.384 SPRING; INSERT,LOW & 2ND
4BD1 ENG(LJ6),4JG2 ENG(RJC),4BE1
ENG(RLH),4HF1 ENG(RLS),4BD2 ENG(RLW)
|
8-97023-708-0 |
02 |
1 |
9507-9510 |
● |
● |
|
● |
● |
|
● |
● |
| |
40 |
04.384 SPRING; INSERT,LOW & 2ND
4BE1 ENG(RLH),4HF1 ENG(RLS),4BD2
ENG(RLW)
|
8-97023-708-0 |
02 |
1 |
9511-9606 |
|
|
● |
● |
● |
● |
● |
● |
| |
40 |
04.384 SPRING; INSERT,LOW & 2ND
4JG2 ENG(RJC),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW)
|
8-97023-708-0 |
02 |
1 |
9607-9711 |
|
|
● |
● |
● |
● |
● |
● |
| |
40 |
04.384 SPRING; INSERT,LOW & 2ND
4JG2 ENG(RJC),4HG1 ENG(RJH),4BE1
ENG(RLH),4HF1 ENG(RLS),4BD2 ENG(RLW),
4HE1 ENG(RLY)
|
8-97023-708-0 |
02 |
1 |
9712- |
|
|
|
● |
● |
|
● |
● |
| |
49 |
04.352 BEARING; NEEDLE,2ND GEAR
NSK
|
9-00096-638-0 |
01 |
1 |
9312-9410 |
● |
● |
|
● |
● |
|
|
● |
| |
49 |
04.352 BEARING; NEEDLE,2ND GEAR
4BD1 ENG(LJ6),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW)
NSK
|
9-00096-638-0 |
01 |
1 |
9411-9510 |
● |
● |
|
● |
● |
|
|
● |
| |
49 |
04.352 BEARING; NEEDLE,2ND GEAR
4BE1 ENG(RLH),4HF1 ENG(RLS),4BD2
ENG(RLW)
NSK
|
9-00096-638-0 |
01 |
1 |
9511-9711 |
|
|
● |
● |
● |
● |
|
● |
| |
49 |
04.352 BEARING; NEEDLE,2ND GEAR
4HG1 ENG(RJH),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW),4HE1 ENG(RLY)
NSK
|
9-00096-638-0 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
|
● |
| |
49 |
04.352 BEARING; NEEDLE,2ND GEAR
4HG1 ENG(RJH),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW),4HE1 ENG(RLY)
04.419
NTN
|
8-97201-005-0 |
01 |
1 |
9802- |
|
|
|
● |
● |
|
|
● |
| |
49 |
04.352 BEARING; NEEDLE,2ND GEAR
04.419
NSK
|
5-09811-014-0 |
01 |
1 |
9312-9506 |
|
|
|
|
|
|
● |
|
| |
49 |
04.352 BEARING; NEEDLE,2ND GEAR
4JG2 ENG(RJC)
04.419
NSK
|
5-09811-014-0 |
01 |
1 |
9507- |
|
|
|
|
|
|
● |
|
| |
50 |
04.395 GEAR; 2ND,MAINSHAFT
Z=37
|
8-94172-564-2 |
01 |
1 |
9312-9505 |
● |
|
|
|
|
|
|
|
| |
50 |
04.395 GEAR; 2ND,MAINSHAFT
4BD1 ENG(LJ6)
Z=37
|
8-94172-564-2 |
01 |
1 |
9506-9510 |
● |
|
|
|
|
|
|
|
| |
50 |
04.395 GEAR; 2ND,MAINSHAFT
Z=37
|
8-94178-506-4 |
01 |
1 |
9312-9506 |
|
● |
|
● |
● |
|
|
|
| |
50 |
04.395 GEAR; 2ND,MAINSHAFT
4HF1 ENG(RLS),4BD2 ENG(RLW)
Z=37
|
8-94178-506-4 |
01 |
1 |
9507-9510 |
|
● |
|
● |
● |
|
|
|
| |
50 |
04.395 GEAR; 2ND,MAINSHAFT
4HF1 ENG(RLS),4BD2 ENG(RLW)
Z=37
|
8-94178-506-4 |
01 |
1 |
9511-9711 |
|
|
● |
● |
● |
● |
|
|
| |
50 |
04.395 GEAR; 2ND,MAINSHAFT
4HG1 ENG(RJH),4HF1 ENG(RLS),4BD2
ENG(RLW),4HE1 ENG(RLY)
Z=37
|
8-94178-506-4 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
|
|
| |
50 |
04.395 GEAR; 2ND,MAINSHAFT
Z=36
|
8-94316-766-3 |
01 |
1 |
9312-9506 |
|
|
|
|
|
|
● |
|
| |
50 |
04.395 GEAR; 2ND,MAINSHAFT
4JG2 ENG(RJC)
Z=36
|
8-94316-766-3 |
01 |
1 |
9507- |
|
|
|
|
|
|
● |
|
| |
50 |
04.395 GEAR; 2ND,MAINSHAFT
Z=35
|
8-94172-563-2 |
01 |
1 |
9312-9406 |
|
|
|
|
|
|
|
● |
| |
50 |
04.395 GEAR; 2ND,MAINSHAFT
4BE1 ENG(RLH)
Z=35
|
8-94172-563-2 |
01 |
1 |
9407- |
|
|
|
|
|
|
|
● |
| |
51 |
04.383 RING; BLOCK,LOW & 2ND
Z=30
|
8-97074-619-1 |
02 |
1 |
9312-9506 |
● |
● |
|
● |
● |
|
● |
● |
| |
51 |
04.383 RING; BLOCK,LOW & 2ND
4BD1 ENG(LJ6),4JG2 ENG(RJC),4BE1
ENG(RLH),4HF1 ENG(RLS),4BD2 ENG(RLW)
Z=30
|
8-97074-619-1 |
02 |
1 |
9507-9510 |
● |
● |
|
● |
● |
|
● |
● |
| |
51 |
04.383 RING; BLOCK,LOW & 2ND
4BE1 ENG(RLH),4HF1 ENG(RLS),4BD2
ENG(RLW)
Z=30
|
8-97074-619-1 |
02 |
1 |
9511-9606 |
|
|
● |
● |
● |
● |
● |
● |
| |
51 |
04.383 RING; BLOCK,LOW & 2ND
4JG2 ENG(RJC),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW)
Z=30
|
8-97074-619-1 |
02 |
1 |
9607-9711 |
|
|
● |
● |
● |
● |
● |
● |
| |
51 |
04.383 RING; BLOCK,LOW & 2ND
4JG2 ENG(RJC),4HG1 ENG(RJH),4BE1
ENG(RLH),4HF1 ENG(RLS),4BD2 ENG(RLW),
4HE1 ENG(RLY)
Z=30
|
8-97074-619-1 |
02 |
1 |
9712- |
|
|
|
● |
● |
|
● |
● |
| |
59 |
04.417 GEAR; REV MAINSHAFT
Z=40
|
8-94317-146-2 |
01 |
1 |
9312-9506 |
● |
|
|
● |
● |
|
|
● |
| |
59 |
04.417 GEAR; REV MAINSHAFT
4BD1 ENG(LJ6),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW)
Z=40
|
8-94317-146-2 |
01 |
1 |
9507-9510 |
● |
|
|
● |
● |
|
|
● |
| |
59 |
04.417 GEAR; REV MAINSHAFT
4BE1 ENG(RLH),4HF1 ENG(RLS),4BD2
ENG(RLW)
Z=40
|
8-94317-146-2 |
01 |
1 |
9511-9711 |
|
|
● |
● |
● |
● |
|
● |
| |
59 |
04.417 GEAR; REV MAINSHAFT
4HG1 ENG(RJH),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW),4HE1 ENG(RLY)
Z=40
|
8-94317-146-2 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
|
● |
| |
59 |
04.417 GEAR; REV MAINSHAFT
4BD2 ENG(RLW)
Z=40
|
8-94341-270-2 |
01 |
1 |
9312-9510 |
|
● |
|
|
|
|
|
|
| |
59 |
04.417 GEAR; REV MAINSHAFT
Z=41
|
8-94317-252-1 |
01 |
1 |
9312-9408 |
|
|
|
|
|
|
● |
|
| |
59 |
04.417 GEAR; REV MAINSHAFT
Z=41
|
8-97115-777-0 |
01 |
1 |
9409-9506 |
|
|
|
|
|
|
● |
|
| |
59 |
04.417 GEAR; REV MAINSHAFT
4JG2 ENG(RJC)
Z=41
|
8-97115-777-0 |
01 |
1 |
9507- |
|
|
|
|
|
|
● |
|
| |
62 |
04.384 SPRING; INSERT,REV & 5TH
|
8-97023-709-0 |
02 |
1 |
9312-9410 |
● |
● |
|
● |
● |
|
|
● |
| |
62 |
04.384 SPRING; INSERT,REV & 5TH
4BD1 ENG(LJ6),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW)
|
8-97023-709-0 |
02 |
1 |
9411-9510 |
● |
● |
|
● |
● |
|
|
● |
| |
62 |
04.384 SPRING; INSERT,REV & 5TH
4BE1 ENG(RLH),4HF1 ENG(RLS),4BD2
ENG(RLW)
|
8-97023-709-0 |
02 |
1 |
9511-9711 |
|
|
● |
● |
● |
● |
|
● |
| |
62 |
04.384 SPRING; INSERT,REV & 5TH
4HG1 ENG(RJH),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW),4HE1 ENG(RLY)
|
8-97023-709-0 |
02 |
1 |
9712- |
|
|
|
● |
● |
|
|
● |
| |
62 |
04.384 SPRING; INSERT,REV & 5TH
|
8-97023-710-0 |
02 |
1 |
9312-9506 |
|
|
|
|
|
|
● |
|
| |
62 |
04.384 SPRING; INSERT,REV & 5TH
4JG2 ENG(RJC)
|
8-97023-710-0 |
02 |
1 |
9507- |
|
|
|
|
|
|
● |
|
| |
63 |
04.384 INSERT; SYN,REV & 5TH
|
9-33263-613-0 |
03 |
1 |
9312-9506 |
● |
● |
|
● |
● |
|
● |
● |
| |
63 |
04.384 INSERT; SYN,REV & 5TH
4BD1 ENG(LJ6),4JG2 ENG(RJC),4BE1
ENG(RLH),4HF1 ENG(RLS),4BD2 ENG(RLW)
|
9-33263-613-0 |
03 |
1 |
9507-9510 |
● |
● |
|
● |
● |
|
● |
● |
| |
63 |
04.384 INSERT; SYN,REV & 5TH
4BE1 ENG(RLH),4HF1 ENG(RLS),4BD2
ENG(RLW)
|
9-33263-613-0 |
03 |
1 |
9511-9606 |
|
|
● |
● |
● |
● |
● |
● |
| |
63 |
04.384 INSERT; SYN,REV & 5TH
4JG2 ENG(RJC),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW)
|
9-33263-613-0 |
03 |
1 |
9607-9711 |
|
|
● |
● |
● |
● |
● |
● |
| |
63 |
04.384 INSERT; SYN,REV & 5TH
4JG2 ENG(RJC),4HG1 ENG(RJH),4BE1
ENG(RLH),4HF1 ENG(RLS),4BD2 ENG(RLW),
4HE1 ENG(RLY)
|
9-33263-613-0 |
03 |
1 |
9712- |
|
|
|
● |
● |
|
● |
● |
| |
66 |
04.383 RING; BLOCK,SYN
Z=45
|
8-97061-752-0 |
01 |
1 |
9312-9410 |
● |
● |
|
● |
● |
|
|
● |
| |
66 |
04.383 RING; BLOCK,SYN
4BD1 ENG(LJ6),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW)
Z=45
|
8-97061-752-0 |
01 |
1 |
9411-9510 |
● |
● |
|
● |
● |
|
|
● |
| |
66 |
04.383 RING; BLOCK,SYN
4BE1 ENG(RLH),4HF1 ENG(RLS),4BD2
ENG(RLW)
Z=45
|
8-97061-752-0 |
01 |
1 |
9511-9711 |
|
|
● |
● |
● |
● |
|
● |
| |
66 |
04.383 RING; BLOCK,SYN
4HG1 ENG(RJH),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW),4HE1 ENG(RLY)
Z=45
|
8-97061-752-0 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
|
● |
| |
66 |
04.383 RING; BLOCK,SYN
Z=36
|
8-94128-775-2 |
01 |
1 |
9312-9506 |
|
|
|
|
|
|
● |
|
| |
66 |
04.383 RING; BLOCK,SYN
4JG2 ENG(RJC)
Z=36
|
8-94128-775-2 |
01 |
1 |
9507- |
|
|
|
|
|
|
● |
|
| |
70 |
04.417 GEAR; 1ST,MAINSHAFT
Z=45
|
8-97084-377-1 |
01 |
1 |
9312-9506 |
● |
|
|
● |
● |
|
|
|
| |
70 |
04.417 GEAR; 1ST,MAINSHAFT
4BD1 ENG(LJ6),4HF1 ENG(RLS),4BD2
ENG(RLW)
Z=45
|
8-97084-377-1 |
01 |
1 |
9507-9510 |
● |
|
|
● |
● |
|
|
|
| |
70 |
04.417 GEAR; 1ST,MAINSHAFT
4HF1 ENG(RLS),4BD2 ENG(RLW)
Z=45
|
8-97084-377-1 |
01 |
1 |
9511-9711 |
|
|
|
● |
● |
● |
|
|
| |
70 |
04.417 GEAR; 1ST,MAINSHAFT
4HG1 ENG(RJH),4HF1 ENG(RLS),4BD2
ENG(RLW),4HE1 ENG(RLY)
Z=45
|
8-97084-377-1 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
|
|
| |
70 |
04.417 GEAR; 1ST,MAINSHAFT
4BD2 ENG(RLW)
Z=43
|
8-97084-379-1 |
01 |
1 |
9312-9510 |
|
● |
|
|
|
|
|
|
| |
70 |
04.417 GEAR; 1ST,MAINSHAFT
Z=43
|
8-97084-379-1 |
01 |
1 |
9511-9711 |
|
|
● |
|
|
|
|
|
| |
70 |
04.417 GEAR; 1ST,MAINSHAFT
Z=43
|
8-97014-033-3 |
01 |
1 |
9312-9506 |
|
|
|
|
|
|
● |
|
| |
70 |
04.417 GEAR; 1ST,MAINSHAFT
4JG2 ENG(RJC)
Z=43
|
8-97014-033-3 |
01 |
1 |
9507- |
|
|
|
|
|
|
● |
|
| |
70 |
04.417 GEAR; 1ST,MAINSHAFT
Z=43
|
8-97084-378-1 |
01 |
1 |
9312-9406 |
|
|
|
|
|
|
|
● |
| |
70 |
04.417 GEAR; 1ST,MAINSHAFT
4BE1 ENG(RLH)
Z=43
|
8-97084-378-1 |
01 |
1 |
9407- |
|
|
|
|
|
|
|
● |
| |
74 |
04.419 WASHER; THRUST,REV GEAR
04.416
|
9-33271-606-1 |
01 |
1 |
9312-9505 |
● |
● |
|
|
|
|
|
● |
| |
74 |
04.419 WASHER; THRUST,REV GEAR
4BD1 ENG(LJ6),4BE1 ENG(RLH),4BD2
ENG(RLW)
04.416
|
9-33271-606-1 |
01 |
1 |
9506-9510 |
● |
● |
|
|
|
|
|
● |
| |
74 |
04.419 WASHER; THRUST,REV GEAR
4BE1 ENG(RLH)
04.416
|
9-33271-606-1 |
01 |
1 |
9511- |
|
|
|
|
|
|
|
● |
| |
74 |
04.419 WASHER; THRUST,REV GEAR
|
9-33271-607-1 |
01 |
1 |
9312-9506 |
|
|
|
|
|
|
● |
|
| |
74 |
04.419 WASHER; THRUST,REV GEAR
4JG2 ENG(RJC)
|
9-33271-607-1 |
01 |
1 |
9507- |
|
|
|
|
|
|
● |
|
| |
80 |
04.343 GEAR; SPD DRIVE
Z=4
|
8-97011-348-0 |
01 |
1 |
9312-9410 |
● |
● |
|
● |
● |
|
|
● |
| |
80 |
04.343 GEAR; SPD DRIVE
4BD1 ENG(LJ6),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW)
Z=4
|
8-97011-348-0 |
01 |
1 |
9411-9510 |
● |
● |
|
● |
● |
|
|
● |
| |
80 |
04.343 GEAR; SPD DRIVE
4BE1 ENG(RLH),4HF1 ENG(RLS),4BD2
ENG(RLW)
Z=4
|
8-97011-348-0 |
01 |
1 |
9511-9711 |
|
|
● |
● |
● |
|
|
● |
| |
80 |
04.343 GEAR; SPD DRIVE
4HG1 ENG(RJH),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW),4HE1 ENG(RLY)
Z=4
|
8-97011-348-0 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
|
● |
| |
80 |
04.343 GEAR; SPD DRIVE
Z=4
|
8-97011-350-0 |
01 |
1 |
9312-9506 |
|
|
|
|
|
|
● |
|
| |
80 |
04.343 GEAR; SPD DRIVE
4JG2 ENG(RJC)
Z=4
|
8-97011-350-0 |
01 |
1 |
9507- |
|
|
|
|
|
|
● |
|
| |
80 |
04.343 GEAR; SPD DRIVE
4HF1 ENG(RLS),4BD2 ENG(RLW)
Z=4
|
8-97034-874-0 |
01 |
1 |
9511-9711 |
|
|
|
|
|
● |
|
|
| |
82 |
04.403 SHAFT; MAIN,TRANS
Z=27-40-28
|
8-97045-931-1 |
01 |
1 |
9312-9505 |
● |
|
|
|
|
|
|
● |
| |
82 |
04.403 SHAFT; MAIN,TRANS
4BD1 ENG(LJ6),4BE1 ENG(RLH)
Z=27-40-28
|
8-97045-931-1 |
01 |
1 |
9506-9506 |
● |
|
|
|
|
|
|
● |
| |
82 |
04.403 SHAFT; MAIN,TRANS
4BD1 ENG(LJ6),4BE1 ENG(RLH),4BD2
ENG(RLW)
Z=27-40-28
|
8-97045-931-1 |
01 |
1 |
9507-9510 |
● |
|
|
|
|
|
|
● |
| |
82 |
04.403 SHAFT; MAIN,TRANS
4BE1 ENG(RLH)
Z=27-40-28
|
8-97045-931-1 |
01 |
1 |
9511- |
|
|
|
|
|
|
|
● |
| |
82 |
04.403 SHAFT; MAIN,TRANS
4BD2 ENG(RLW)
Z=27-40-28
|
8-97093-117-0 |
01 |
1 |
9312-9510 |
|
● |
|
|
|
|
|
|
| |
82 |
04.403 SHAFT; MAIN,TRANS
4HF1 ENG(RLS),4BD2 ENG(RLW)
Z=27-40-28
|
8-97034-846-1 |
01 |
1 |
9511-9512 |
|
|
|
|
|
● |
|
|
| |
82 |
04.403 SHAFT; MAIN,TRANS
4HF1 ENG(RLS),4BD2 ENG(RLW)
Z=27-40-28-28-28
|
8-97131-507-0 |
01 |
1 |
9601-9610 |
|
|
|
|
|
● |
|
|
| |
82 |
04.403 SHAFT; MAIN,TRANS
4HF1 ENG(RLS),4BD2 ENG(RLW)
Z=27-40-28-28-23
|
8-97163-908-0 |
01 |
1 |
9611-9711 |
|
|
|
|
|
● |
|
|
| |
82 |
04.403 SHAFT; MAIN,TRANS
Z=27-40-40-28
|
8-97034-847-1 |
01 |
1 |
9312-9506 |
|
|
|
● |
● |
|
|
|
| |
82 |
04.403 SHAFT; MAIN,TRANS
4HF1 ENG(RLS)
Z=27-40-40-28
|
8-97034-847-1 |
01 |
1 |
9507-9510 |
|
|
|
● |
● |
|
|
|
| |
82 |
04.403 SHAFT; MAIN,TRANS
4HF1 ENG(RLS),4BD2 ENG(RLW)
Z=27-40-40-28
|
8-97034-847-1 |
01 |
1 |
9511-9711 |
|
|
● |
● |
● |
|
|
|
| |
82 |
04.403 SHAFT; MAIN,TRANS
4HG1 ENG(RJH),4HF1 ENG(RLS),4BD2
ENG(RLW),4HE1 ENG(RLY)
Z=27-40-40-28
|
8-97034-847-1 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
|
|
| |
82 |
04.403 SHAFT; MAIN,TRANS
Z=27-40-31-24
|
8-97045-932-1 |
01 |
1 |
9312-9506 |
|
|
|
|
|
|
● |
|
| |
82 |
04.403 SHAFT; MAIN,TRANS
4JG2 ENG(RJC)
Z=27-40-31-24
|
8-97045-932-1 |
01 |
1 |
9507- |
|
|
|
|
|
|
● |
|
| |
84 |
04.422 BEARING; COUNTER SHAFT,FRT
|
8-94455-830-0 |
01 |
1 |
9312-9505 |
● |
● |
|
|
|
|
|
● |
| |
84 |
04.422 BEARING; COUNTER SHAFT,FRT
4BD1 ENG(LJ6),4BE1 ENG(RLH),4BD2
ENG(RLW)
|
8-94455-830-0 |
01 |
1 |
9506-9510 |
● |
● |
|
|
|
|
|
● |
| |
84 |
04.422 BEARING; COUNTER SHAFT,FRT
4BE1 ENG(RLH)
|
8-94455-830-0 |
01 |
1 |
9511- |
|
|
|
|
|
|
|
● |
| |
84 |
04.422 BEARING; COUNTER SHAFT,FRT
NSK
|
8-97035-048-0 |
01 |
1 |
9312-9506 |
|
|
|
● |
● |
|
|
|
| |
84 |
04.422 BEARING; COUNTER SHAFT,FRT
4HF1 ENG(RLS)
NSK
|
8-97035-048-0 |
01 |
1 |
9507-9510 |
|
|
|
● |
● |
|
|
|
| |
84 |
04.422 BEARING; COUNTER SHAFT,FRT
4HF1 ENG(RLS),4BD2 ENG(RLW)
NSK
|
8-97035-048-0 |
01 |
1 |
9511-9711 |
|
|
● |
● |
● |
● |
|
|
| |
84 |
04.422 BEARING; COUNTER SHAFT,FRT
4HG1 ENG(RJH),4HF1 ENG(RLS),4BD2
ENG(RLW),4HE1 ENG(RLY)
NSK
|
8-97035-048-0 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
|
|
| |
84 |
04.422 BEARING; COUNTER SHAFT,FRT
NSK
|
5-09800-062-1 |
01 |
1 |
9312-9506 |
|
|
|
|
|
|
● |
|
| |
84 |
04.422 BEARING; COUNTER SHAFT,FRT
4JG2 ENG(RJC)
NSK
|
5-09800-062-1 |
01 |
1 |
9507- |
|
|
|
|
|
|
● |
|
| |
87 |
04.416 BALL; THRUST WASHER
|
8-94340-506-0 |
01 |
1 |
9312-9505 |
● |
|
|
|
|
|
|
● |
| |
87 |
04.416 BALL; THRUST WASHER
4BD1 ENG(LJ6),4BE1 ENG(RLH)
|
8-94340-506-0 |
01 |
1 |
9506-9506 |
● |
|
|
|
|
|
|
● |
| |
87 |
04.416 BALL; THRUST WASHER
4BD1 ENG(LJ6),4BE1 ENG(RLH),4BD2
ENG(RLW)
|
8-94340-506-0 |
01 |
1 |
9507-9510 |
● |
|
|
|
|
|
|
● |
| |
87 |
04.416 BALL; THRUST WASHER
4BE1 ENG(RLH)
|
8-94340-506-0 |
01 |
1 |
9511- |
|
|
|
|
|
|
|
● |
| |
109 |
04.422 BEARING; COUNTER SHAFT,RR
|
8-94178-734-0 |
01 |
1 |
9312-9505 |
● |
● |
|
|
|
|
|
● |
| |
109 |
04.422 BEARING; COUNTER SHAFT,RR
4BD1 ENG(LJ6),4BE1 ENG(RLH),4BD2
ENG(RLW)
|
8-94178-734-0 |
01 |
1 |
9506-9510 |
● |
● |
|
|
|
|
|
● |
| |
109 |
04.422 BEARING; COUNTER SHAFT,RR
4BE1 ENG(RLH)
|
8-94178-734-0 |
01 |
1 |
9511- |
|
|
|
|
|
|
|
● |
| |
109 |
04.422 BEARING; COUNTER SHAFT,RR
|
8-97035-049-0 |
01 |
1 |
9312-9506 |
|
|
|
● |
● |
|
|
|
| |
109 |
04.422 BEARING; COUNTER SHAFT,RR
4HF1 ENG(RLS)
|
8-97035-049-0 |
01 |
1 |
9507-9510 |
|
|
|
● |
● |
|
|
|
| |
109 |
04.422 BEARING; COUNTER SHAFT,RR
4HF1 ENG(RLS),4BD2 ENG(RLW)
|
8-97035-049-0 |
01 |
1 |
9511-9711 |
|
|
● |
● |
● |
● |
|
|
| |
109 |
04.422 BEARING; COUNTER SHAFT,RR
4HG1 ENG(RJH),4HF1 ENG(RLS),4BD2
ENG(RLW),4HE1 ENG(RLY)
|
8-97035-049-0 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
|
|
| |
109 |
04.422 BEARING; COUNTER SHAFT,RR
|
8-97095-913-0 |
01 |
1 |
9312-9506 |
|
|
|
|
|
|
● |
|
| |
109 |
04.422 BEARING; COUNTER SHAFT,RR
4JG2 ENG(RJC)
|
8-97095-913-0 |
01 |
1 |
9507- |
|
|
|
|
|
|
● |
|
| |
132 |
04.433 SHAFT; REV
|
8-94415-162-1 |
01 |
1 |
9312-9410 |
● |
● |
|
● |
● |
|
|
● |
| |
132 |
04.433 SHAFT; REV
4BD1 ENG(LJ6),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW)
|
8-94415-162-1 |
01 |
1 |
9411-9510 |
● |
● |
|
● |
● |
|
|
● |
| |
132 |
04.433 SHAFT; REV
4BE1 ENG(RLH),4HF1 ENG(RLS),4BD2
ENG(RLW)
|
8-94415-162-1 |
01 |
1 |
9511-9711 |
|
|
● |
● |
● |
● |
|
● |
| |
132 |
04.433 SHAFT; REV
4HG1 ENG(RJH),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW),4HE1 ENG(RLY)
|
8-94415-162-1 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
|
● |
| |
132 |
04.433 SHAFT; REV
|
9-33351-604-1 |
01 |
1 |
9312-9506 |
|
|
|
|
|
|
● |
|
| |
132 |
04.433 SHAFT; REV
4JG2 ENG(RJC)
|
9-33351-604-1 |
01 |
1 |
9507- |
|
|
|
|
|
|
● |
|
| |
135 |
04.430 GEAR; REV IDLER
Z=27
|
5-33361-042-2 |
01 |
1 |
9312-9506 |
● |
|
|
● |
● |
|
|
● |
| |
135 |
04.430 GEAR; REV IDLER
4BD1 ENG(LJ6),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW)
Z=27
|
5-33361-042-2 |
01 |
1 |
9507-9510 |
● |
|
|
● |
● |
|
|
● |
| |
135 |
04.430 GEAR; REV IDLER
4BE1 ENG(RLH),4HF1 ENG(RLS),4BD2
ENG(RLW)
Z=27
|
5-33361-042-2 |
01 |
1 |
9511-9711 |
|
|
● |
● |
● |
● |
|
● |
| |
135 |
04.430 GEAR; REV IDLER
4HG1 ENG(RJH),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW),4HE1 ENG(RLY)
Z=27
|
5-33361-042-2 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
|
● |
| |
135 |
04.430 GEAR; REV IDLER
4BD2 ENG(RLW)
Z=26 W/BUSH
|
8-94178-518-1 |
01 |
1 |
9312-9510 |
|
● |
|
|
|
|
|
|
| |
135 |
04.430 GEAR; REV IDLER
Z=29
|
8-97081-539-3 |
01 |
1 |
9312-9506 |
|
|
|
|
|
|
● |
|
| |
135 |
04.430 GEAR; REV IDLER
4JG2 ENG(RJC)
Z=29
|
8-97081-539-3 |
01 |
1 |
9507- |
|
|
|
|
|
|
● |
|
| |
172 |
04.412 RING; SNAP,CLU HUB
04.384
T=1.75
|
8-94402-405-0 |
01 |
1 |
9312-9506 |
● |
● |
|
● |
● |
|
● |
● |
| |
172 |
04.412 RING; SNAP,CLU HUB
4BD1 ENG(LJ6),4JG2 ENG(RJC),4BE1
ENG(RLH),4HF1 ENG(RLS),4BD2 ENG(RLW)
04.384
T=1.75
|
8-94402-405-0 |
01 |
1 |
9507-9510 |
● |
● |
|
● |
● |
|
● |
● |
| |
172 |
04.412 RING; SNAP,CLU HUB
4BE1 ENG(RLH),4HF1 ENG(RLS),4BD2
ENG(RLW)
04.384
T=1.75
|
8-94402-405-0 |
01 |
1 |
9511-9606 |
|
|
● |
● |
● |
● |
● |
● |
| |
172 |
04.412 RING; SNAP,CLU HUB
4JG2 ENG(RJC),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW)
04.384
T=1.75
|
8-94402-405-0 |
01 |
1 |
9607-9711 |
|
|
● |
● |
● |
● |
● |
● |
| |
172 |
04.412 RING; SNAP,CLU HUB
4JG2 ENG(RJC),4HG1 ENG(RJH),4BE1
ENG(RLH),4HF1 ENG(RLS),4BD2 ENG(RLW),
4HE1 ENG(RLY)
04.384
T=1.75
|
8-94402-405-0 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
● |
● |
| |
172 |
04.412 RING; SNAP,CLU HUB
04.384
T=1.80
|
8-94402-406-0 |
01 |
1 |
9312-9506 |
● |
● |
|
● |
● |
|
● |
● |
| |
172 |
04.412 RING; SNAP,CLU HUB
4BD1 ENG(LJ6),4JG2 ENG(RJC),4BE1
ENG(RLH),4HF1 ENG(RLS),4BD2 ENG(RLW)
04.384
T=1.80
|
8-94402-406-0 |
01 |
1 |
9507-9510 |
● |
● |
|
● |
● |
|
● |
● |
| |
172 |
04.412 RING; SNAP,CLU HUB
4BE1 ENG(RLH),4HF1 ENG(RLS),4BD2
ENG(RLW)
04.384
T=1.80
|
8-94402-406-0 |
01 |
1 |
9511-9606 |
|
|
● |
● |
● |
● |
● |
● |
| |
172 |
04.412 RING; SNAP,CLU HUB
4JG2 ENG(RJC),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW)
04.384
T=1.80
|
8-94402-406-0 |
01 |
1 |
9607-9711 |
|
|
● |
● |
● |
● |
● |
● |
| |
172 |
04.412 RING; SNAP,CLU HUB
4JG2 ENG(RJC),4HG1 ENG(RJH),4BE1
ENG(RLH),4HF1 ENG(RLS),4BD2 ENG(RLW),
4HE1 ENG(RLY)
04.384
T=1.80
|
8-94402-406-0 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
● |
● |
| |
172 |
04.412 RING; SNAP,CLU HUB
04.384
T=1.85
|
8-94402-407-0 |
01 |
1 |
9312-9506 |
● |
● |
|
● |
● |
|
● |
● |
| |
172 |
04.412 RING; SNAP,CLU HUB
4BD1 ENG(LJ6),4JG2 ENG(RJC),4BE1
ENG(RLH),4HF1 ENG(RLS),4BD2 ENG(RLW)
04.384
T=1.85
|
8-94402-407-0 |
01 |
1 |
9507-9510 |
● |
● |
|
● |
● |
|
● |
● |
| |
172 |
04.412 RING; SNAP,CLU HUB
4BE1 ENG(RLH),4HF1 ENG(RLS),4BD2
ENG(RLW)
04.384
T=1.85
|
8-94402-407-0 |
01 |
1 |
9511-9606 |
|
|
● |
● |
● |
● |
● |
● |
| |
172 |
04.412 RING; SNAP,CLU HUB
4JG2 ENG(RJC),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW)
04.384
T=1.85
|
8-94402-407-0 |
01 |
1 |
9607-9711 |
|
|
● |
● |
● |
● |
● |
● |
| |
172 |
04.412 RING; SNAP,CLU HUB
4JG2 ENG(RJC),4HG1 ENG(RJH),4BE1
ENG(RLH),4HF1 ENG(RLS),4BD2 ENG(RLW),
4HE1 ENG(RLY)
04.384
T=1.85
|
8-94402-407-0 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
● |
● |
| |
173 |
04.416 RING; SNAP,OVERDRIVE GEAR
T=1.85
|
8-94151-522-0 |
01 |
1 |
9312-9506 |
● |
● |
|
● |
● |
|
● |
● |
| |
173 |
04.416 RING; SNAP,OVERDRIVE GEAR
4BD1 ENG(LJ6),4JG2 ENG(RJC),4BE1
ENG(RLH),4HF1 ENG(RLS),4BD2 ENG(RLW)
T=1.85
|
8-94151-522-0 |
01 |
1 |
9507-9510 |
● |
● |
|
● |
● |
|
● |
● |
| |
173 |
04.416 RING; SNAP,OVERDRIVE GEAR
4BE1 ENG(RLH),4HF1 ENG(RLS),4BD2
ENG(RLW)
T=1.85
|
8-94151-522-0 |
01 |
1 |
9511-9606 |
|
|
● |
● |
● |
● |
● |
● |
| |
173 |
04.416 RING; SNAP,OVERDRIVE GEAR
4JG2 ENG(RJC),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW)
T=1.85
|
8-94151-522-0 |
01 |
1 |
9607-9711 |
|
|
● |
● |
● |
● |
● |
● |
| |
173 |
04.416 RING; SNAP,OVERDRIVE GEAR
4JG2 ENG(RJC),4HG1 ENG(RJH),4BE1
ENG(RLH),4HF1 ENG(RLS),4BD2 ENG(RLW),
4HE1 ENG(RLY)
T=1.85
|
8-94151-522-0 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
● |
● |
| |
173 |
04.416 RING; SNAP,OVERDRIVE GEAR
T=1.90
|
8-94151-523-0 |
01 |
1 |
9312-9506 |
● |
● |
|
● |
● |
|
● |
● |
| |
173 |
04.416 RING; SNAP,OVERDRIVE GEAR
4BD1 ENG(LJ6),4JG2 ENG(RJC),4BE1
ENG(RLH),4HF1 ENG(RLS),4BD2 ENG(RLW)
T=1.90
|
8-94151-523-0 |
01 |
1 |
9507-9510 |
● |
● |
|
● |
● |
|
● |
● |
| |
173 |
04.416 RING; SNAP,OVERDRIVE GEAR
4BE1 ENG(RLH),4HF1 ENG(RLS),4BD2
ENG(RLW)
T=1.90
|
8-94151-523-0 |
01 |
1 |
9511-9606 |
|
|
● |
● |
● |
● |
● |
● |
| |
173 |
04.416 RING; SNAP,OVERDRIVE GEAR
4JG2 ENG(RJC),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW)
T=1.90
|
8-94151-523-0 |
01 |
1 |
9607-9711 |
|
|
● |
● |
● |
● |
● |
● |
| |
173 |
04.416 RING; SNAP,OVERDRIVE GEAR
4JG2 ENG(RJC),4HG1 ENG(RJH),4BE1
ENG(RLH),4HF1 ENG(RLS),4BD2 ENG(RLW),
4HE1 ENG(RLY)
T=1.90
|
8-94151-523-0 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
● |
● |
| |
173 |
04.416 RING; SNAP,OVERDRIVE GEAR
T=1.95
|
8-94151-524-0 |
01 |
1 |
9312-9506 |
● |
● |
|
● |
● |
|
● |
● |
| |
173 |
04.416 RING; SNAP,OVERDRIVE GEAR
4BD1 ENG(LJ6),4JG2 ENG(RJC),4BE1
ENG(RLH),4HF1 ENG(RLS),4BD2 ENG(RLW)
T=1.95
|
8-94151-524-0 |
01 |
1 |
9507-9510 |
● |
● |
|
● |
● |
|
● |
● |
| |
173 |
04.416 RING; SNAP,OVERDRIVE GEAR
4BE1 ENG(RLH),4HF1 ENG(RLS),4BD2
ENG(RLW)
T=1.95
|
8-94151-524-0 |
01 |
1 |
9511-9606 |
|
|
● |
● |
● |
● |
● |
● |
| |
173 |
04.416 RING; SNAP,OVERDRIVE GEAR
4JG2 ENG(RJC),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW)
T=1.95
|
8-94151-524-0 |
01 |
1 |
9607-9711 |
|
|
● |
● |
● |
● |
● |
● |
| |
173 |
04.416 RING; SNAP,OVERDRIVE GEAR
4JG2 ENG(RJC),4HG1 ENG(RJH),4BE1
ENG(RLH),4HF1 ENG(RLS),4BD2 ENG(RLW),
4HE1 ENG(RLY)
T=1.95
|
8-94151-524-0 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
● |
● |
| |
173 |
04.416 RING; SNAP,OVERDRIVE GEAR
T=2.00
|
8-94157-747-0 |
01 |
1 |
9312-9506 |
● |
● |
|
● |
● |
|
● |
● |
| |
173 |
04.416 RING; SNAP,OVERDRIVE GEAR
4BD1 ENG(LJ6),4JG2 ENG(RJC),4BE1
ENG(RLH),4HF1 ENG(RLS),4BD2 ENG(RLW)
T=2.00
|
8-94157-747-0 |
01 |
1 |
9507-9510 |
● |
● |
|
● |
● |
|
● |
● |
| |
173 |
04.416 RING; SNAP,OVERDRIVE GEAR
4BE1 ENG(RLH),4HF1 ENG(RLS),4BD2
ENG(RLW)
T=2.00
|
8-94157-747-0 |
01 |
1 |
9511-9606 |
|
|
● |
● |
● |
● |
● |
● |
| |
173 |
04.416 RING; SNAP,OVERDRIVE GEAR
4JG2 ENG(RJC),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW)
T=2.00
|
8-94157-747-0 |
01 |
1 |
9607-9711 |
|
|
● |
● |
● |
● |
● |
● |
| |
173 |
04.416 RING; SNAP,OVERDRIVE GEAR
4JG2 ENG(RJC),4HG1 ENG(RJH),4BE1
ENG(RLH),4HF1 ENG(RLS),4BD2 ENG(RLW),
4HE1 ENG(RLY)
T=2.00
|
8-94157-747-0 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
● |
● |
| |
174 |
04.380 SYNCHRONIZER ASM; 2ND-3RD
|
8-97091-432-0 |
01 |
1 |
9312-9407 |
● |
|
|
● |
● |
|
|
● |
| |
174 |
04.380 SYNCHRONIZER ASM; 2ND-3RD
|
8-97091-432-0 |
01 |
1 |
9408-9410 |
● |
● |
|
● |
● |
|
|
● |
| |
174 |
04.380 SYNCHRONIZER ASM; 2ND-3RD
4BD1 ENG(LJ6),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW)
|
8-97091-432-0 |
01 |
1 |
9411-9510 |
● |
● |
|
● |
● |
|
|
● |
| |
174 |
04.380 SYNCHRONIZER ASM; 2ND-3RD
4BE1 ENG(RLH),4HF1 ENG(RLS),4BD2
ENG(RLW)
|
8-97091-432-0 |
01 |
1 |
9511-9711 |
|
|
● |
● |
● |
● |
|
● |
| |
174 |
04.380 SYNCHRONIZER ASM; 2ND-3RD
4BE1 ENG(RLH),4HF1 ENG(RLS),4BD2
ENG(RLW)
|
8-97190-992-0 |
01 |
1 |
9712-9712 |
|
|
● |
● |
● |
● |
|
● |
| |
174 |
04.380 SYNCHRONIZER ASM; 2ND-3RD
4HG1 ENG(RJH),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW),4HE1 ENG(RLY)
|
8-97190-992-0 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
|
● |
| |
174 |
04.380 SYNCHRONIZER ASM; 2ND-3RD
4BD2 ENG(RLW)
|
8-97093-118-0 |
01 |
1 |
9312-9407 |
|
● |
|
|
|
|
|
|
| |
175 |
04.380 SYNCHRONIZER; LOW-REV
|
8-97091-434-0 |
01 |
1 |
9312-9410 |
● |
● |
|
● |
● |
|
|
● |
| |
175 |
04.380 SYNCHRONIZER; LOW-REV
4BD1 ENG(LJ6),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW)
|
8-97091-434-0 |
01 |
1 |
9411-9510 |
● |
● |
|
● |
● |
|
|
● |
| |
175 |
04.380 SYNCHRONIZER; LOW-REV
4BE1 ENG(RLH),4HF1 ENG(RLS),4BD2
ENG(RLW)
|
8-97091-434-0 |
01 |
1 |
9511-9711 |
|
|
● |
● |
● |
● |
|
● |
| |
175 |
04.380 SYNCHRONIZER; LOW-REV
4HG1 ENG(RJH),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW),4HE1 ENG(RLY)
|
8-97091-434-0 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
|
● |
| |
180 |
04.422 RING; SNAP,CLUSTER GEAR
(A)
ID=29.6
|
9-09180-032-0 |
01 |
1 |
9312-9505 |
● |
● |
|
|
|
|
|
● |
| |
180 |
04.422 RING; SNAP,CLUSTER GEAR
4BD1 ENG(LJ6),4BE1 ENG(RLH),4BD2
ENG(RLW)
(A)
ID=29.6
|
9-09180-032-0 |
01 |
1 |
9506-9510 |
● |
● |
|
|
|
|
|
● |
| |
180 |
04.422 RING; SNAP,CLUSTER GEAR
4BE1 ENG(RLH)
(A)
ID=29.6
|
9-09180-032-0 |
01 |
1 |
9511- |
|
|
|
|
|
|
|
● |
| |
180 |
04.422 RING; SNAP,CLUSTER GEAR
08.934
(A)
ID=32.2
|
9-09180-035-0 |
01 |
1 |
9312-9506 |
|
|
|
● |
● |
|
● |
|
| |
180 |
04.422 RING; SNAP,CLUSTER GEAR
4JG2 ENG(RJC),4HF1 ENG(RLS),4BD2
ENG(RLW)
08.934
(A)
ID=32.2
|
9-09180-035-0 |
01 |
1 |
9507-9510 |
|
|
|
● |
● |
|
● |
|
| |
180 |
04.422 RING; SNAP,CLUSTER GEAR
4JG2 ENG(RJC),4HF1 ENG(RLS),4BD2
ENG(RLW)
08.934
(A)
ID=32.2
|
9-09180-035-0 |
01 |
1 |
9511-9606 |
|
|
|
● |
● |
● |
● |
|
| |
180 |
04.422 RING; SNAP,CLUSTER GEAR
4JG2 ENG(RJC),4HF1 ENG(RLS),4BD2
ENG(RLW)
08.934
(A)
ID=32.2
|
9-09180-035-0 |
01 |
1 |
9607-9711 |
|
|
● |
● |
● |
● |
● |
|
| |
180 |
04.422 RING; SNAP,CLUSTER GEAR
4JG2 ENG(RJC),4HG1 ENG(RJH),4HF1
ENG(RLS),4BD2 ENG(RLW),4HE1 ENG(RLY)
08.934
(A)
ID=32.2
|
9-09180-035-0 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
● |
|
| |
180 |
04.422 RING; SNAP,CLUSTER GEAR
(B)
ID=38.5
|
8-94146-483-0 |
01 |
1 |
9312-9506 |
|
|
|
|
|
|
● |
|
| |
180 |
04.422 RING; SNAP,CLUSTER GEAR
4JG2 ENG(RJC)
(B)
ID=38.5
|
8-94146-483-0 |
01 |
1 |
9507- |
|
|
|
|
|
|
● |
|
| |
182 |
04.422 PLATE; CLUSTER GEAR
|
8-94131-924-1 |
01 |
1 |
9312-9504 |
● |
|
|
● |
● |
|
|
|
| |
182 |
04.422 PLATE; CLUSTER GEAR
4BD2 ENG(RLW)
|
8-94178-516-1 |
01 |
1 |
9312-9510 |
|
● |
|
|
|
|
|
|
| |
182 |
04.422 PLATE; CLUSTER GEAR
|
8-94178-516-1 |
01 |
1 |
9511-9711 |
|
|
● |
|
|
|
|
|
| |
182 |
04.422 PLATE; CLUSTER GEAR
4HF1 ENG(RLS),4BD2 ENG(RLW)
|
8-94131-924-1 |
01 |
1 |
9606-9711 |
|
|
|
● |
● |
● |
|
|
| |
182 |
04.422 PLATE; CLUSTER GEAR
4HG1 ENG(RJH),4HF1 ENG(RLS),4BD2
ENG(RLW),4HE1 ENG(RLY)
|
8-94131-924-1 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
|
|
| |
182 |
04.422 PLATE; CLUSTER GEAR
|
8-97095-984-0 |
01 |
1 |
9312-9506 |
|
|
|
|
|
|
● |
|
| |
182 |
04.422 PLATE; CLUSTER GEAR
4JG2 ENG(RJC)
|
8-97095-984-0 |
01 |
1 |
9507- |
|
|
|
|
|
|
● |
|
| |
182 |
04.422 PLATE; CLUSTER GEAR
|
8-94131-923-1 |
01 |
1 |
9312-9406 |
|
|
|
|
|
|
|
● |
| |
182 |
04.422 PLATE; CLUSTER GEAR
4BE1 ENG(RLH)
|
8-94131-923-1 |
01 |
1 |
9407-9504 |
|
|
|
|
|
|
|
● |
| |
182 |
04.422 PLATE; CLUSTER GEAR
4BE1 ENG(RLH)
|
8-94131-923-1 |
01 |
1 |
9606- |
|
|
|
|
|
|
|
● |
| |
183 |
04.422 SPRING; PLATE,CLUSTER GEAR
|
8-94148-196-0 |
03 |
1 |
9312-9410 |
● |
● |
|
● |
● |
|
|
● |
| |
183 |
04.422 SPRING; PLATE,CLUSTER GEAR
4BD1 ENG(LJ6),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW)
|
8-94148-196-0 |
03 |
1 |
9411-9504 |
● |
● |
|
● |
● |
|
|
● |
| |
183 |
04.422 SPRING; PLATE,CLUSTER GEAR
4BD2 ENG(RLW)
|
8-94148-196-0 |
03 |
1 |
9505-9510 |
|
● |
|
|
|
|
|
|
| |
183 |
04.422 SPRING; PLATE,CLUSTER GEAR
|
8-94148-196-0 |
03 |
1 |
9511-9605 |
|
|
● |
|
|
|
|
|
| |
183 |
04.422 SPRING; PLATE,CLUSTER GEAR
4BE1 ENG(RLH),4HF1 ENG(RLS),4BD2
ENG(RLW)
|
8-94148-196-0 |
03 |
1 |
9606-9711 |
|
|
● |
● |
● |
● |
|
● |
| |
183 |
04.422 SPRING; PLATE,CLUSTER GEAR
4HG1 ENG(RJH),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW),4HE1 ENG(RLY)
|
8-94148-196-0 |
03 |
1 |
9712- |
|
|
|
● |
● |
|
|
● |
| |
183 |
04.422 SPRING; PLATE,CLUSTER GEAR
|
8-94132-168-0 |
03 |
1 |
9312-9506 |
|
|
|
|
|
|
● |
|
| |
183 |
04.422 SPRING; PLATE,CLUSTER GEAR
4JG2 ENG(RJC)
|
8-94132-168-0 |
03 |
1 |
9507- |
|
|
|
|
|
|
● |
|
| |
184 |
04.422 SPRING; CLUSTER GEAR
|
8-94101-320-0 |
01 |
1 |
9312-9410 |
● |
● |
|
● |
● |
|
|
● |
| |
184 |
04.422 SPRING; CLUSTER GEAR
4BD1 ENG(LJ6),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW)
|
8-94101-320-0 |
01 |
1 |
9411-9504 |
● |
● |
|
● |
● |
|
|
● |
| |
184 |
04.422 SPRING; CLUSTER GEAR
4BD2 ENG(RLW)
|
8-94101-320-0 |
01 |
1 |
9505-9510 |
|
● |
|
|
|
|
|
|
| |
184 |
04.422 SPRING; CLUSTER GEAR
|
8-94101-320-0 |
01 |
1 |
9511-9605 |
|
|
● |
|
|
|
|
|
| |
184 |
04.422 SPRING; CLUSTER GEAR
4BE1 ENG(RLH),4HF1 ENG(RLS),4BD2
ENG(RLW)
|
8-94101-320-0 |
01 |
1 |
9606-9711 |
|
|
● |
● |
● |
● |
|
● |
| |
184 |
04.422 SPRING; CLUSTER GEAR
4HG1 ENG(RJH),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW),4HE1 ENG(RLY)
|
8-94101-320-0 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
|
● |
| |
184 |
04.422 SPRING; CLUSTER GEAR
|
8-94128-790-1 |
01 |
1 |
9312-9506 |
|
|
|
|
|
|
● |
|
| |
184 |
04.422 SPRING; CLUSTER GEAR
4JG2 ENG(RJC)
|
8-94128-790-1 |
01 |
1 |
9507- |
|
|
|
|
|
|
● |
|
| |
186 |
04.422 RING; SNAP,CLUSTER GEAR
08.934
ID=32.2
|
9-09180-035-0 |
01 |
1 |
9312-9410 |
● |
● |
|
● |
● |
|
|
● |
| |
186 |
04.422 RING; SNAP,CLUSTER GEAR
4BD1 ENG(LJ6),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW)
08.934
ID=32.2
|
9-09180-035-0 |
01 |
1 |
9411-9510 |
● |
● |
|
● |
● |
|
|
● |
| |
186 |
04.422 RING; SNAP,CLUSTER GEAR
4BE1 ENG(RLH),4HF1 ENG(RLS),4BD2
ENG(RLW)
08.934
ID=32.2
|
9-09180-035-0 |
01 |
1 |
9511-9711 |
|
|
● |
● |
● |
|
|
● |
| |
186 |
04.422 RING; SNAP,CLUSTER GEAR
4HG1 ENG(RJH),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW),4HE1 ENG(RLY)
08.934
ID=32.2
|
9-09180-035-0 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
|
● |
| |
186 |
04.422 RING; SNAP,CLUSTER GEAR
ID=29.6
|
9-09180-032-0 |
01 |
1 |
9312-9506 |
|
|
|
|
|
|
● |
|
| |
186 |
04.422 RING; SNAP,CLUSTER GEAR
4JG2 ENG(RJC)
ID=29.6
|
9-09180-032-0 |
01 |
1 |
9507- |
|
|
|
|
|
|
● |
|
| |
190 |
04.435 BALL; LK,REV SHAFT
04.311
|
9-00097-509-0 |
01 |
1 |
9312-9410 |
● |
● |
|
● |
● |
|
|
● |
| |
190 |
04.435 BALL; LK,REV SHAFT
4BD1 ENG(LJ6),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW)
04.311
|
9-00097-509-0 |
01 |
1 |
9411-9510 |
● |
● |
|
● |
● |
|
|
● |
| |
190 |
04.435 BALL; LK,REV SHAFT
4BE1 ENG(RLH),4HF1 ENG(RLS),4BD2
ENG(RLW)
04.311
|
9-00097-509-0 |
01 |
1 |
9511-9711 |
|
|
● |
● |
● |
● |
|
● |
| |
190 |
04.435 BALL; LK,REV SHAFT
4HG1 ENG(RJH),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW),4HE1 ENG(RLY)
04.311
|
9-00097-509-0 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
|
● |
| |
234 |
04.380 SYNCHRONIZER ASM; 4TH TO 5TH
|
8-97048-745-2 |
01 |
1 |
9312-9505 |
● |
● |
|
|
|
|
|
● |
| |
234 |
04.380 SYNCHRONIZER ASM; 4TH TO 5TH
4BD1 ENG(LJ6),4BE1 ENG(RLH),4BD2
ENG(RLW)
|
8-97048-745-2 |
01 |
1 |
9506-9510 |
● |
● |
|
|
|
|
|
● |
| |
234 |
04.380 SYNCHRONIZER ASM; 4TH TO 5TH
4BE1 ENG(RLH)
|
8-97048-745-2 |
01 |
1 |
9511- |
|
|
|
|
|
|
|
● |
| |
234 |
04.380 SYNCHRONIZER ASM; 4TH TO 5TH
|
8-97034-841-1 |
01 |
1 |
9312-9506 |
|
|
|
● |
● |
|
|
|
| |
234 |
04.380 SYNCHRONIZER ASM; 4TH TO 5TH
4HF1 ENG(RLS)
|
8-97034-841-1 |
01 |
1 |
9507-9510 |
|
|
|
● |
● |
|
|
|
| |
234 |
04.380 SYNCHRONIZER ASM; 4TH TO 5TH
4HF1 ENG(RLS),4BD2 ENG(RLW)
|
8-97034-841-1 |
01 |
1 |
9511-9711 |
|
|
● |
● |
● |
● |
|
|
| |
234 |
04.380 SYNCHRONIZER ASM; 4TH TO 5TH
4HG1 ENG(RJH),4HF1 ENG(RLS),4BD2
ENG(RLW),4HE1 ENG(RLY)
|
8-97034-841-1 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
|
|
| |
276 |
04.419 SPACER; BRG TO DRIVE GEAR
04.545
|
9-33235-602-2 |
01 |
1 |
9312-9505 |
● |
● |
|
|
|
|
|
● |
| |
276 |
04.419 SPACER; BRG TO DRIVE GEAR
4BD1 ENG(LJ6),4BE1 ENG(RLH),4BD2
ENG(RLW)
04.545
|
9-33235-602-2 |
01 |
1 |
9506-9510 |
● |
● |
|
|
|
|
|
● |
| |
276 |
04.419 SPACER; BRG TO DRIVE GEAR
4BE1 ENG(RLH)
04.545
|
9-33235-602-2 |
01 |
1 |
9511- |
|
|
|
|
|
|
|
● |
| |
276 |
04.419 SPACER; BRG TO DRIVE GEAR
|
8-97034-876-0 |
01 |
1 |
9312-9506 |
|
|
|
● |
● |
|
|
|
| |
276 |
04.419 SPACER; BRG TO DRIVE GEAR
4HF1 ENG(RLS)
|
8-97034-876-0 |
01 |
1 |
9507-9510 |
|
|
|
● |
● |
|
|
|
| |
276 |
04.419 SPACER; BRG TO DRIVE GEAR
4HF1 ENG(RLS),4BD2 ENG(RLW)
|
8-97034-876-0 |
01 |
1 |
9511-9711 |
|
|
● |
● |
● |
|
|
|
| |
276 |
04.419 SPACER; BRG TO DRIVE GEAR
4HG1 ENG(RJH),4HF1 ENG(RLS),4BD2
ENG(RLW),4HE1 ENG(RLY)
|
8-97034-876-0 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
|
|
| |
276 |
04.419 SPACER; BRG TO DRIVE GEAR
|
9-33235-606-1 |
01 |
1 |
9312-9506 |
|
|
|
|
|
|
● |
|
| |
276 |
04.419 SPACER; BRG TO DRIVE GEAR
4JG2 ENG(RJC)
|
9-33235-606-1 |
01 |
1 |
9507- |
|
|
|
|
|
|
● |
|
| |
281 |
04.419 WASHER; THRUST,MAINSHAFT
|
8-94340-194-1 |
01 |
1 |
9312-9505 |
● |
|
|
|
|
|
|
● |
| |
281 |
04.419 WASHER; THRUST,MAINSHAFT
4BD1 ENG(LJ6),4BE1 ENG(RLH)
|
8-94340-194-1 |
01 |
1 |
9506-9506 |
● |
|
|
|
|
|
|
● |
| |
281 |
04.419 WASHER; THRUST,MAINSHAFT
4BD1 ENG(LJ6),4BE1 ENG(RLH),4BD2
ENG(RLW)
|
8-94340-194-1 |
01 |
1 |
9507-9510 |
● |
|
|
|
|
|
|
● |
| |
281 |
04.419 WASHER; THRUST,MAINSHAFT
4BE1 ENG(RLH)
|
8-94340-194-1 |
01 |
1 |
9511- |
|
|
|
|
|
|
|
● |
| |
281 |
04.419 WASHER; THRUST,MAINSHAFT
4BD2 ENG(RLW)
04.416
|
5-33271-022-1 |
01 |
1 |
9312-9510 |
|
● |
|
|
|
|
|
|
| |
281 |
04.419 WASHER; THRUST,MAINSHAFT
|
5-33271-007-0 |
01 |
1 |
9312-9506 |
|
|
|
|
|
|
● |
|
| |
281 |
04.419 WASHER; THRUST,MAINSHAFT
4JG2 ENG(RJC)
|
5-33271-007-0 |
01 |
1 |
9507- |
|
|
|
|
|
|
● |
|
| |
287 |
04.422 PIN; COUNTER GEAR
|
8-94402-462-0 |
03 |
1 |
9312-9410 |
● |
● |
|
● |
● |
|
|
● |
| |
287 |
04.422 PIN; COUNTER GEAR
4BD1 ENG(LJ6),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW)
|
8-94402-462-0 |
03 |
1 |
9411-9510 |
● |
● |
|
● |
● |
|
|
● |
| |
287 |
04.422 PIN; COUNTER GEAR
4BE1 ENG(RLH),4HF1 ENG(RLS),4BD2
ENG(RLW)
|
8-94402-462-0 |
03 |
1 |
9511-9711 |
|
|
● |
● |
● |
● |
|
● |
| |
287 |
04.422 PIN; COUNTER GEAR
4HG1 ENG(RJH),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW),4HE1 ENG(RLY)
|
8-94402-462-0 |
03 |
1 |
9712- |
|
|
|
● |
● |
|
|
● |
| |
287 |
04.422 PIN; COUNTER GEAR
|
8-94402-462-0 |
01 |
1 |
9312-9506 |
|
|
|
|
|
|
● |
|
| |
287 |
04.422 PIN; COUNTER GEAR
4JG2 ENG(RJC)
|
8-94402-462-0 |
01 |
1 |
9507- |
|
|
|
|
|
|
● |
|
| |
313 |
04.419 BEARING; NEEDLE,LOW GEAR
04.352
NSK
|
9-00096-638-0 |
01 |
1 |
9312-9410 |
● |
● |
|
● |
● |
|
|
● |
| |
313 |
04.419 BEARING; NEEDLE,LOW GEAR
4BD1 ENG(LJ6),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW)
04.352
NSK
|
9-00096-638-0 |
01 |
1 |
9411-9510 |
● |
● |
|
● |
● |
|
|
● |
| |
313 |
04.419 BEARING; NEEDLE,LOW GEAR
4BE1 ENG(RLH),4HF1 ENG(RLS),4BD2
ENG(RLW)
04.352
NSK
|
9-00096-638-0 |
01 |
1 |
9511-9711 |
|
|
● |
● |
● |
● |
|
● |
| |
313 |
04.419 BEARING; NEEDLE,LOW GEAR
4HG1 ENG(RJH),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW),4HE1 ENG(RLY)
04.352
NSK
|
9-00096-638-0 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
|
● |
| |
313 |
04.419 BEARING; NEEDLE,LOW GEAR
4HG1 ENG(RJH),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW),4HE1 ENG(RLY)
NTN
|
8-97201-005-0 |
01 |
1 |
9802- |
|
|
|
● |
● |
|
|
● |
| |
313 |
04.419 BEARING; NEEDLE,LOW GEAR
NSK
|
8-94317-161-0 |
01 |
1 |
9312-9506 |
|
|
|
|
|
|
● |
|
| |
313 |
04.419 BEARING; NEEDLE,LOW GEAR
4JG2 ENG(RJC)
NSK
|
8-94317-161-0 |
01 |
1 |
9507- |
|
|
|
|
|
|
● |
|
| |
313 |
04.419 BEARING; NEEDLE,LOW GEAR
KOYO
|
8-97010-547-0 |
01 |
1 |
9312-9506 |
|
|
|
|
|
|
● |
|
| |
313 |
04.419 BEARING; NEEDLE,LOW GEAR
4JG2 ENG(RJC)
KOYO
|
8-97010-547-0 |
01 |
1 |
9507- |
|
|
|
|
|
|
● |
|
| |
314 |
04.419 BEARING; NEEDLE,REV GEAR
04.352
NSK
|
9-00096-638-0 |
01 |
1 |
9312-9410 |
● |
● |
|
● |
● |
|
|
● |
| |
314 |
04.419 BEARING; NEEDLE,REV GEAR
4BD1 ENG(LJ6),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW)
04.352
NSK
|
9-00096-638-0 |
01 |
1 |
9411-9510 |
● |
● |
|
● |
● |
|
|
● |
| |
314 |
04.419 BEARING; NEEDLE,REV GEAR
4BE1 ENG(RLH),4HF1 ENG(RLS),4BD2
ENG(RLW)
04.352
NSK
|
9-00096-638-0 |
01 |
1 |
9511-9711 |
|
|
● |
● |
● |
● |
|
● |
| |
314 |
04.419 BEARING; NEEDLE,REV GEAR
4HG1 ENG(RJH),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW),4HE1 ENG(RLY)
04.352
NSK
|
9-00096-638-0 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
|
● |
| |
314 |
04.419 BEARING; NEEDLE,REV GEAR
4HG1 ENG(RJH),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW),4HE1 ENG(RLY)
NTN
|
8-97201-005-0 |
01 |
1 |
9802- |
|
|
|
● |
● |
|
|
● |
| |
314 |
04.419 BEARING; NEEDLE,REV GEAR
NSK
|
5-09811-014-0 |
01 |
1 |
9312-9506 |
|
|
|
|
|
|
● |
|
| |
314 |
04.419 BEARING; NEEDLE,REV GEAR
4JG2 ENG(RJC)
NSK
|
5-09811-014-0 |
01 |
1 |
9507- |
|
|
|
|
|
|
● |
|
| |
318 |
04.419 COLLAR; DIST,REV GEAR
04.416
|
9-33234-618-1 |
01 |
1 |
9312-9505 |
● |
● |
|
|
|
|
|
● |
| |
318 |
04.419 COLLAR; DIST,REV GEAR
4BD1 ENG(LJ6),4BE1 ENG(RLH),4BD2
ENG(RLW)
04.416
|
9-33234-618-1 |
01 |
1 |
9506-9510 |
● |
● |
|
|
|
|
|
● |
| |
318 |
04.419 COLLAR; DIST,REV GEAR
4BE1 ENG(RLH)
04.416
|
9-33234-618-1 |
01 |
1 |
9511- |
|
|
|
|
|
|
|
● |
| |
318 |
04.419 COLLAR; DIST,REV GEAR
|
8-97076-908-0 |
01 |
1 |
9312-9506 |
|
|
|
● |
● |
|
|
|
| |
318 |
04.419 COLLAR; DIST,REV GEAR
4HF1 ENG(RLS)
|
8-97076-908-0 |
01 |
1 |
9507-9510 |
|
|
|
● |
● |
|
|
|
| |
318 |
04.419 COLLAR; DIST,REV GEAR
4HF1 ENG(RLS),4BD2 ENG(RLW)
|
8-97076-908-0 |
01 |
1 |
9511-9711 |
|
|
● |
● |
● |
● |
|
|
| |
318 |
04.419 COLLAR; DIST,REV GEAR
4HG1 ENG(RJH),4HF1 ENG(RLS),4BD2
ENG(RLW),4HE1 ENG(RLY)
|
8-97076-908-0 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
|
|
| |
387 |
04.384 INSERT; SYN,4TH & 3RD
|
5-33263-001-0 |
03 |
1 |
9312-9506 |
● |
● |
|
● |
● |
|
● |
● |
| |
387 |
04.384 INSERT; SYN,4TH & 3RD
4BD1 ENG(LJ6),4JG2 ENG(RJC),4BE1
ENG(RLH),4HF1 ENG(RLS),4BD2 ENG(RLW)
|
5-33263-001-0 |
03 |
1 |
9507-9510 |
● |
● |
|
● |
● |
|
● |
● |
| |
387 |
04.384 INSERT; SYN,4TH & 3RD
4BE1 ENG(RLH),4HF1 ENG(RLS),4BD2
ENG(RLW)
|
5-33263-001-0 |
03 |
1 |
9511-9606 |
|
|
● |
● |
● |
● |
● |
● |
| |
387 |
04.384 INSERT; SYN,4TH & 3RD
4JG2 ENG(RJC),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW)
|
5-33263-001-0 |
03 |
1 |
9607-9711 |
|
|
● |
● |
● |
● |
● |
● |
| |
387 |
04.384 INSERT; SYN,4TH & 3RD
4JG2 ENG(RJC),4HG1 ENG(RJH),4BE1
ENG(RLH),4HF1 ENG(RLS),4BD2 ENG(RLW),
4HE1 ENG(RLY)
|
5-33263-001-0 |
03 |
1 |
9712- |
|
|
|
● |
● |
|
● |
● |
| |
390 |
04.383 RING; SNAP,CLU HUB
04.384
T=1.75
|
8-94151-520-0 |
01 |
1 |
9312-9505 |
● |
|
|
|
|
|
● |
● |
| |
390 |
04.383 RING; SNAP,CLU HUB
4BD1 ENG(LJ6),4JG2 ENG(RJC),4BE1
ENG(RLH),4BD2 ENG(RLW)
04.384
T=1.75
|
8-94151-520-0 |
01 |
1 |
9506-9506 |
● |
|
|
|
|
|
● |
● |
| |
390 |
04.383 RING; SNAP,CLU HUB
4BD1 ENG(LJ6),4JG2 ENG(RJC),4BE1
ENG(RLH)
04.384
T=1.75
|
8-94151-520-0 |
01 |
1 |
9507-9510 |
● |
|
|
|
|
|
● |
● |
| |
390 |
04.383 RING; SNAP,CLU HUB
4JG2 ENG(RJC),4BE1 ENG(RLH)
04.384
T=1.75
|
8-94151-520-0 |
01 |
1 |
9511- |
|
|
|
|
|
|
● |
● |
| |
390 |
04.383 RING; SNAP,CLU HUB
04.384
T=1.80
|
8-94151-521-0 |
01 |
1 |
9312-9505 |
● |
|
|
|
|
|
● |
● |
| |
390 |
04.383 RING; SNAP,CLU HUB
4BD1 ENG(LJ6),4JG2 ENG(RJC),4BE1
ENG(RLH),4BD2 ENG(RLW)
04.384
T=1.80
|
8-94151-521-0 |
01 |
1 |
9506-9506 |
● |
|
|
|
|
|
● |
● |
| |
390 |
04.383 RING; SNAP,CLU HUB
4BD1 ENG(LJ6),4JG2 ENG(RJC),4BE1
ENG(RLH)
04.384
T=1.80
|
8-94151-521-0 |
01 |
1 |
9507-9510 |
● |
|
|
|
|
|
● |
● |
| |
390 |
04.383 RING; SNAP,CLU HUB
4JG2 ENG(RJC),4BE1 ENG(RLH)
04.384
T=1.80
|
8-94151-521-0 |
01 |
1 |
9511- |
|
|
|
|
|
|
● |
● |
| |
390 |
04.383 RING; SNAP,CLU HUB
04.416
T=1.85
|
8-94151-522-0 |
01 |
1 |
9312-9505 |
● |
|
|
|
|
|
● |
● |
| |
390 |
04.383 RING; SNAP,CLU HUB
4BD1 ENG(LJ6),4JG2 ENG(RJC),4BE1
ENG(RLH),4BD2 ENG(RLW)
04.416
T=1.85
|
8-94151-522-0 |
01 |
1 |
9506-9506 |
● |
|
|
|
|
|
● |
● |
| |
390 |
04.383 RING; SNAP,CLU HUB
4BD1 ENG(LJ6),4JG2 ENG(RJC),4BE1
ENG(RLH)
04.416
T=1.85
|
8-94151-522-0 |
01 |
1 |
9507-9510 |
● |
|
|
|
|
|
● |
● |
| |
390 |
04.383 RING; SNAP,CLU HUB
4JG2 ENG(RJC),4BE1 ENG(RLH)
04.416
T=1.85
|
8-94151-522-0 |
01 |
1 |
9511- |
|
|
|
|
|
|
● |
● |
| |
393 |
04.352 BEARING; MAINSHAFT END
04.408
(A)
NSK
|
8-94178-732-1 |
01 |
1 |
9312-9505 |
● |
● |
|
|
|
|
|
● |
| |
393 |
04.352 BEARING; MAINSHAFT END
4BD1 ENG(LJ6),4BE1 ENG(RLH),4BD2
ENG(RLW)
04.408
(A)
NSK
|
8-94178-732-1 |
01 |
1 |
9506-9510 |
● |
● |
|
|
|
|
|
● |
| |
393 |
04.352 BEARING; MAINSHAFT END
4BE1 ENG(RLH)
04.408
(A)
NSK
|
8-94178-732-1 |
01 |
1 |
9511- |
|
|
|
|
|
|
|
● |
| |
393 |
04.352 BEARING; MAINSHAFT END
(A)
KOYO
|
8-94462-615-0 |
01 |
1 |
9312-9505 |
● |
● |
|
|
|
|
|
● |
| |
393 |
04.352 BEARING; MAINSHAFT END
4BD1 ENG(LJ6),4BE1 ENG(RLH),4BD2
ENG(RLW)
(A)
KOYO
|
8-94462-615-0 |
01 |
1 |
9506-9510 |
● |
● |
|
|
|
|
|
● |
| |
393 |
04.352 BEARING; MAINSHAFT END
4BE1 ENG(RLH)
(A)
KOYO
|
8-94462-615-0 |
01 |
1 |
9511- |
|
|
|
|
|
|
|
● |
| |
393 |
04.352 BEARING; MAINSHAFT END
04.355
(A)
|
8-94178-731-0 |
01 |
1 |
9312-9506 |
|
|
|
● |
● |
|
|
|
| |
393 |
04.352 BEARING; MAINSHAFT END
4HF1 ENG(RLS)
04.355
(A)
|
8-94178-731-0 |
01 |
1 |
9507-9510 |
|
|
|
● |
● |
|
|
|
| |
393 |
04.352 BEARING; MAINSHAFT END
4HF1 ENG(RLS),4BD2 ENG(RLW)
04.355
(A)
|
8-94178-731-0 |
01 |
1 |
9511-9711 |
|
|
● |
● |
● |
● |
|
|
| |
393 |
04.352 BEARING; MAINSHAFT END
4HG1 ENG(RJH),4HF1 ENG(RLS),4BD2
ENG(RLW),4HE1 ENG(RLY)
04.355
(A)
|
8-94178-731-0 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
|
|
| |
393 |
04.352 BEARING; MAINSHAFT END
04.422
|
8-97095-913-0 |
01 |
1 |
9312-9506 |
|
|
|
|
|
|
● |
|
| |
393 |
04.352 BEARING; MAINSHAFT END
4JG2 ENG(RJC)
04.422
|
8-97095-913-0 |
01 |
1 |
9507- |
|
|
|
|
|
|
● |
|
| |
393 |
04.352 BEARING; MAINSHAFT END
4HF1 ENG(RLS),4BD2 ENG(RLW)
(B)
|
8-97035-045-0 |
01 |
1 |
9511-9711 |
|
|
|
|
|
● |
|
|
| |
396 |
04.352 BEARING; NEEDLE,MAINSHAFT
04.399
|
8-94178-729-1 |
01 |
1 |
9312-9505 |
● |
● |
|
|
|
|
|
● |
| |
396 |
04.352 BEARING; NEEDLE,MAINSHAFT
4BD1 ENG(LJ6),4BE1 ENG(RLH),4BD2
ENG(RLW)
04.399
|
8-94178-729-1 |
01 |
1 |
9506-9510 |
● |
● |
|
|
|
|
|
● |
| |
396 |
04.352 BEARING; NEEDLE,MAINSHAFT
4BE1 ENG(RLH)
04.399
|
8-94178-729-1 |
01 |
1 |
9511- |
|
|
|
|
|
|
|
● |
| |
396 |
04.352 BEARING; NEEDLE,MAINSHAFT
|
8-97035-050-0 |
01 |
1 |
9312-9506 |
|
|
|
● |
● |
|
|
|
| |
396 |
04.352 BEARING; NEEDLE,MAINSHAFT
4HF1 ENG(RLS)
|
8-97035-050-0 |
01 |
1 |
9507-9510 |
|
|
|
● |
● |
|
|
|
| |
396 |
04.352 BEARING; NEEDLE,MAINSHAFT
4HF1 ENG(RLS),4BD2 ENG(RLW)
|
8-97035-050-0 |
01 |
1 |
9511-9711 |
|
|
● |
● |
● |
● |
|
|
| |
396 |
04.352 BEARING; NEEDLE,MAINSHAFT
4HG1 ENG(RJH),4HF1 ENG(RLS),4BD2
ENG(RLW),4HE1 ENG(RLY)
|
8-97035-050-0 |
01 |
1 |
9712- |
|
|
|
● |
● |
|
|
|
| |
396 |
04.352 BEARING; NEEDLE,MAINSHAFT
04.520
|
9-00096-606-0 |
01 |
1 |
9312-9506 |
|
|
|
|
|
|
● |
|
| |
396 |
04.352 BEARING; NEEDLE,MAINSHAFT
4JG2 ENG(RJC)
04.520
|
9-00096-606-0 |
01 |
1 |
9507- |
|
|
|
|
|
|
● |
|
| |
397 |
04.384 SPRING; INSERT,4TH & 3RD
|
8-97023-710-0 |
02 |
1 |
9312-9506 |
● |
● |
|
● |
● |
|
● |
● |
| |
397 |
04.384 SPRING; INSERT,4TH & 3RD
4BD1 ENG(LJ6),4JG2 ENG(RJC),4BE1
ENG(RLH),4HF1 ENG(RLS),4BD2 ENG(RLW)
|
8-97023-710-0 |
02 |
1 |
9507-9510 |
● |
● |
|
● |
● |
|
● |
● |
| |
397 |
04.384 SPRING; INSERT,4TH & 3RD
4BE1 ENG(RLH),4HF1 ENG(RLS),4BD2
ENG(RLW)
|
8-97023-710-0 |
02 |
1 |
9511-9606 |
|
|
● |
● |
● |
● |
● |
● |
| |
397 |
04.384 SPRING; INSERT,4TH & 3RD
4JG2 ENG(RJC),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW)
|
8-97023-710-0 |
02 |
1 |
9607-9711 |
|
|
● |
● |
● |
● |
● |
● |
| |
397 |
04.384 SPRING; INSERT,4TH & 3RD
4JG2 ENG(RJC),4HG1 ENG(RJH),4BE1
ENG(RLH),4HF1 ENG(RLS),4BD2 ENG(RLW),
4HE1 ENG(RLY)
|
8-97023-710-0 |
02 |
1 |
9712- |
|
|
|
● |
● |
|
● |
● |
| |
398 |
04.421 GEAR; COUNTER
Z=49
|
8-97017-877-0 |
01 |
1 |
9312-9505 |
● |
|
|
|
|
|
|
|
| |
398 |
04.421 GEAR; COUNTER
4BD1 ENG(LJ6)
Z=49
|
8-97017-877-0 |
01 |
1 |
9506-9510 |
● |
|
|
|
|
|
|
|
| |
398 |
04.421 GEAR; COUNTER
4HF1 ENG(RLS),4BD2 ENG(RLW)
Z=35-20-14-13
|
8-97092-564-0 |
01 |
1 |
9511-9711 |
|
|
|
|
|
● |
|
|
| |
398 |
04.421 GEAR; COUNTER
4BD2 ENG(RLW)
Z=34-20-14-13
|
8-94316-721-0 |
01 |
1 |
9312-9510 |
|
● |
|
|
|
|
|
|
| |
398 |
04.421 GEAR; COUNTER
Z=48-43-34-20-14-13
|
8-97129-447-0 |
01 |
1 |
9511-9711 |
|
|
● |
|
|
|
|
|
| |
398 |
04.421 GEAR; COUNTER
4HF1 ENG(RLS)
Z=45-49-36-20-14-13
|
8-97075-976-0 |
01 |
1 |
9312-9510 |
|
|
|
|
● |
|
|
|
| |
398 |
04.421 GEAR; COUNTER
4HF1 ENG(RLS),4BD2 ENG(RLW)
Z=45-49-36-20-14-13
|
8-97075-976-0 |
01 |
1 |
9511-9711 |
|
|
|
|
● |
|
|
|
| |
398 |
04.421 GEAR; COUNTER
4HG1 ENG(RJH),4HF1 ENG(RLS),4BD2
ENG(RLW)
Z=45-49-36-20-14-13
|
8-97075-976-0 |
01 |
1 |
9712- |
|
|
|
|
● |
|
|
|
| |
398 |
04.421 GEAR; COUNTER
Z=35-20-14-13
|
8-97092-565-0 |
01 |
1 |
9312-9506 |
|
|
|
● |
|
|
|
|
| |
398 |
04.421 GEAR; COUNTER
4HF1 ENG(RLS)
Z=35-20-14-13
|
8-97092-565-0 |
01 |
1 |
9507-9606 |
|
|
|
● |
|
|
|
|
| |
398 |
04.421 GEAR; COUNTER
4HF1 ENG(RLS),4BD2 ENG(RLW)
Z=35-20-14-13
|
8-97092-565-0 |
01 |
1 |
9607-9711 |
|
|
|
● |
|
|
|
|
| |
398 |
04.421 GEAR; COUNTER
4HG1 ENG(RJH),4HF1 ENG(RLS),4BD2
ENG(RLW),4HE1 ENG(RLY)
Z=45-49-35-20-14-13
|
8-97183-677-0 |
01 |
1 |
9712-9804 |
|
|
|
● |
|
|
|
|
| |
398 |
04.421 GEAR; COUNTER
4HE1 ENG(RLY)
Z=45-49-35-20-14-13
|
8-97183-677-0 |
01 |
1 |
9805- |
|
|
|
● |
|
|
|
|
| |
398 |
04.421 GEAR; COUNTER
4HG1 ENG(RJH),4HF1 ENG(RLS),4BD2
ENG(RLW)
Z=45-49-35-20-14-13
|
8-97208-023-0 |
01 |
1 |
9805- |
|
|
|
● |
|
|
|
|
| |
398 |
04.421 GEAR; COUNTER
Z=49-34-22-14
|
8-97077-337-0 |
01 |
1 |
9312-9506 |
|
|
|
|
|
|
● |
|
| |
398 |
04.421 GEAR; COUNTER
4JG2 ENG(RJC)
Z=49-34-22-14
|
8-97077-337-0 |
01 |
1 |
9507- |
|
|
|
|
|
|
● |
|
| |
398 |
04.421 GEAR; COUNTER
Z=49
|
8-97017-874-0 |
01 |
1 |
9312-9406 |
|
|
|
|
|
|
|
● |
| |
398 |
04.421 GEAR; COUNTER
4BE1 ENG(RLH)
Z=49
|
8-97017-874-0 |
01 |
1 |
9407- |
|
|
|
|
|
|
|
● |
| |
405 |
04.384 INSERT; SYN,LOW & 2ND
|
5-33263-001-0 |
03 |
1 |
9312-9506 |
● |
● |
|
● |
● |
|
● |
● |
| |
405 |
04.384 INSERT; SYN,LOW & 2ND
4BD1 ENG(LJ6),4JG2 ENG(RJC),4BE1
ENG(RLH),4HF1 ENG(RLS),4BD2 ENG(RLW)
|
5-33263-001-0 |
03 |
1 |
9507-9510 |
● |
● |
|
● |
● |
|
● |
● |
| |
405 |
04.384 INSERT; SYN,LOW & 2ND
4BE1 ENG(RLH),4HF1 ENG(RLS),4BD2
ENG(RLW)
|
5-33263-001-0 |
03 |
1 |
9511-9606 |
|
|
● |
● |
● |
● |
● |
● |
| |
405 |
04.384 INSERT; SYN,LOW & 2ND
4JG2 ENG(RJC),4BE1 ENG(RLH),4HF1
ENG(RLS),4BD2 ENG(RLW)
|
5-33263-001-0 |
03 |
1 |
9607-9711 |
|
|
● |
● |
● |
● |
● |
● |
| |
405 |
04.384 INSERT; SYN,LOW & 2ND
4JG2 ENG(RJC),4HG1 ENG(RJH),4BE1
ENG(RLH),4HF1 ENG(RLS),4BD2 ENG(RLW),
4HE1 ENG(RLY)
|
5-33263-001-0 |
03 |
1 |
9712- |
|
|
|
● |
● |
|
● |
● |
